Thermo King V-520 RT Series User manual

Revision A
July 2018 TTKK 5566661122--1188--IIMM--EENN
Vehicle Powered Truck Edition
V-520 RT Series
Single and Multi-Temperature Systems
Installation Manual

©2018 Trane Tec nologies TK 56612-18-IM-EN
Introduction
T is manual was written to assist wit t e general installation of T ermo King®components onto trucks designed and
built for refrigerated applications. T e TT eerrmmoo KKiinngg IInnssttaallllaattiioonn SSttaannddaarrddss aanndd PPrroocceedduurreess GGuuiiddee (TK 56430)
provides more detailed information t at must be followed to safely and properly complete t e entire installation.
Due to its complexity, you s ould not attempt t is installation unless you:
• Are an experienced mec anic.
• Can safely lift 34 kg (75 lbs.).
• In t e U.S., EPA 608 certified and trained in t e repair and maintenance of transport refrigeration systems.
• Have a basic understanding of electricity and electrical wiring.
• Have t e necessary tools and equipment to complete t e installation.
• Have a truck body designed and built to meet t e requirements of t is installation.
T is manual is publis ed for informational purposes only. T ermo King makes no representations warranties express
or implied, wit respect to t e information recommendations and descriptions contained erein. Information provided
s ould not be regarded as all-inclusive or covering all contingencies. If furt er information is required, T ermo King
Corporation Service Department s ould be consulted.
TT eerrmmoo KKiinngg’’ss wwaarrrraannttyy ss aallll nnoott aappppllyy ttoo aannyy eeqquuiippmmeenntt ww iicc aass bbeeeenn ““ssoo iinnssttaalllleedd,, mmaaiinnttaaiinneedd,, rreeppaaiirreedd
oorr aalltteerreedd aass,, iinn tt ee mmaannuuffaaccttuurreerr’’ss jjuuddggmmeenntt,, ttoo aaffffeecctt iittss iinntteeggrriittyy..””
MMaannuuffaaccttuurreerr sshhaallll hhaavvee nnoo lliiaabbiilliittyy ttoo aannyy ppeerrssoonn oorr eennttiittyy ffoorr aannyy ppeerrssoonnaall iinnjjuurryy,, pprrooppeerrttyy ddaammaaggee oorr aannyy
ootthheerr ddiirreecctt,, iinnddiirreecctt,, ssppeecciiaall,, oorr ccoonnsseeqquueennttiiaall ddaammaaggeess wwhhaattssooeevveerr,, aarriissiinngg oouutt ooff tthhee uussee ooff tthhiiss mmaannuuaall oorr
aannyy iinnffoorrmmaattiioonn,, rreeccoommmmeennddaattiioonnss oorr ddeessccrriippttiioonnss ccoonnttaaiinneedd hheerreeiinn.. TThhee pprroocceedduurreess ddeessccrriibbeedd hheerreeiinn sshhoouulldd
oonnllyy bbee uunnddeerrttaakkeenn bbyy ssuuiittaabbllyy qquuaalliiffiieedd ppeerrssoonnnneell.. FFaaiilluurree ttoo iimmpplleemmeenntt tthheessee pprroocceedduurreess ccoorrrreeccttllyy mmaayy ccaauussee
ddaammaaggee ttoo tthhee TThheerrmmoo KKiinngg uunniitt oorr ootthheerr pprrooppeerrttyy oorr ppeerrssoonnaall iinnjjuurryy..
Revision History
Revision A (07/18) New manual.
ustomer Satisfaction Survey
Let your voice be eard!
Your feedback will elp improve our manuals. T e survey is accessible t roug any internet-connected device wit a
web browser.
Scan t e Quick Response (QR) code or click Tec nical Publications TK Americas Feedback to complete t e survey.

TK 56612-18-IM-EN 3
SSaaffeettyy PPrreeccaauuttiioonnss ............................................................................................................................................................ 55
EEnnggiinnee DDrriivveenn CCoommpprreessssoorr IInnssttaallllaattiioonn ................................................................................................................ 66
EEvvaappoorraattoorr IInnssttaallllaattiioonn .................................................................................................................................................. 77
Preparing Evaporator for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cover Removal (All Models). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing t e Accumulator Assembly (Heat Option Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Evaporator to Bulk ead Clearance Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ES500 Single Temperature Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Preferred Installation Met od — Pre-Installed Support Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Alternate Installation Met od — Backer Plates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Alternate Installation Met od — Lag Bolts and Ad esive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
ES300 Multi-Temperature Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Preferred Installation Met od — Pre-Installed Support Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Alternate Installation Met od — Backer Plates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Alternate Installation Met od — Lag Bolts and Ad esive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
RReeffrriiggeerraattiioonn MMoodduullee IInnssttaallllaattiioonn .. .. ...... .. .................... .. ...... .. .. ................................ .. ............................ .. .............. 1166
Preferred Installation Met od — Pre-Installed Support Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Alternate Installation Met od — Lag Bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
PPoowweerr PPaacckk MMoodduullee IInnssttaallllaattiioonn ...... .. ...... .. .................... .. ...... .. ................ .. ............................ ................ .. ................ 1188
Preferred Installation Met od — Pre-Installed Support Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Alternate Installation Met od — Lag Bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
CCoonnddeennsseerr MMoodduullee IInnssttaallllaattiioonn.. .. ................ ................ .. ...... .. .................... .. ...... .. .................... .. ............................ .. 2211
Preferred Installation Met od - Pre-Installed Support Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Alternate Installation Met od – Lag Bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
CCoommpprreessssoorr OOiill RReeqquuiirreemmeennttss ........ .. ...... .. .................... .. ........................ ................ .. ...... .. .. ............................ .. ...... 2233
RReeffrriiggeerraattiioonn HHoossee IInnssttaallllaattiioonn .. .. .. ...... .. .. ............................ .. ................................ .. ................................ .. .............. 2244
Model 10 and MAX 10 — Single Temperature Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Model 30 and MAX 30 — Single Temperature Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Model 20, MAX 20 and MAX 50 — Single Temperature Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
MAX 50 — Single Temperature Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
SPECTRUM Multi-Temperature Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
LLeeaakk CC eecckk aanndd EEvvaaccuuaattiioonn PPrroocceedduurreess.............................................................................................................. 2299
Solenoid Valve Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Leak C eck and Evacuation Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
EElleeccttrriiccaall CCoonnnneeccttiioonnss ........ ................ .. ...... .. .................... .. ...... .. .................... .. ...... .. .. ................................ .. ................ 3311
Single Temperature Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Table of ontents

4TK 56612-18-IM-EN
SPECTRUM Multi-Temperature Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
EEvvaappoorraattoorr DDrraaiinn HHoossee IInnssttaallllaattiioonn...................... .. ................................ .. ............................ .. ............................ .. .. 3344
SSyysstteemm CC aarrggiinngg PPrroocceedduurreess.. ........................ .. ...... .. .................... .. ...... .. .................... .. ...... .. .. ............................ .. .... 3355
SSPPRR aanndd CCPPRR AAddjjuussttmmeenntt PPrroocceedduurreess .... ...... .. ...... .. ...... ...... .. ...... .. .......... ...... .. ...... .. .......... ...... .. ...... .................... .. 3377
SPR Valve Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
CPR Valve Settings — Single Temperature Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
CPR Valve Settings — SPECTRUM Multi-Temperature Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
IInnssttaallllaattiioonn CC eecckk LLiisstt.. .. ............................ .. ................................ .. ................................ .. ............................ .. ................ 4400
CCoommmmiissssiioonniinngg aanndd PPDDII FFoorrmmss...................... .. ...... .. .. ................................ .. ............................ .. ............................ .. 4411
CCoommppoonneenntt DDiimmeennssiioonnss aanndd WWeeiigg ttss.. .. .................... .. ........................ ................ .. ...... .. .. ............................ .. ...... 4422
TTaabbllee ooff CCoonntteennttss

TK 56612-18-IM-EN 5
Safety Precautions
IImmppoorrttaanntt Additional Safety Precautions must be followed when installing this unit. See “Section 2 - Safety
Precautions” in the Thermo King Vehicle Powered Truck Installation Standards and Procedures Guide (TK
56430).
CCAAUUTTIIOONN
RRiisskk ooff IInnjjuurryy!!
TT eerrmmoo KKiinngg ccoonnddeennsseerr uunniittss aanndd rreemmoottee eevvaappoorraattoorrss aarree ss iippppeedd wwiitt aa 3355 kkPPaa ((55 ppssii)) oollddiinngg cc aarrggee ooff
HHeelliiuumm.. BBee ccaarreeffuull ww eenn rreemmoovviinngg ccaapp.. TT iiss oollddiinngg cc aarrggee mmaayy bbee ssaaffeellyy vveenntteedd iinnttoo tt ee aattmmoosspp eerree..

6TK 56612-18-IM-EN
Engine Driven ompressor Installation
IImmppoorrttaanntt See Section 5 - Compressor Selection and Installation Standards in the Thermo King Vehicle Powered Truck
Installation Standards and Procedures Guide (TK 56430). THESE PROCEDURES MUST BE FOLLOWED!
IImmppoorrttaanntt Failure to add the correct amount and type of oil will damage the compressor! Refer to “Compressor Oil
Requirements,” p. 23.
IImmppoorrttaanntt It is critical that a P–trap is installed in the suction line bbeeffoorree the roadside compressor. See Section 6 –
Refrigerant Hose and Fittings Standards in the Thermo King Vehicle Powered Truck Installation Standards
and Procedures Guide (TK 56430). THESE PROCEDURES MUST BE FOLLOWED!

TK 56612-18-IM-EN 7
Evaporator Installation
Preparing Evaporator for Installation
over Removal (All Models)
1. Remove plastic cover assembly to access t e unit mounting oles.

8TK 56612-18-IM-EN
Installing the Accumulator Assembly (Heat Option Only)
NNoottee ES500 shown, ES300 similar.
Wit evaporator cover removed, position accumulator assembly at rear of evaporator:
1. Remove cap and connect 7/8” tube from accumulator to mating tube inside evaporator.
IImmppoorrttaanntt Ensure O–ring is oiled and properly inserted.
a. Tig ten fitting to 28–33 lb-ft.
2. Secure accumulator to rear of evporator wit supplied ardware.
a. Tig ten ardware to 5.8–7.8 lb-ft.
EEvvaappoorraattoorr IInnssttaallllaattiioonn

TK 56612-18-IM-EN 9
Evaporator to Bulkhead learance Requirements
IImmppoorrttaanntt See Section 4 – Unit Installation Standards and Procedures in the Thermo King Vehicle Powered Truck
Installation Standards and Procedures Guide (TK 56430). THESE PROCEDURES MUST BE FOLLOWED!
EEvvaappoorraattoorr IInnssttaallllaattiioonn

10 TK 56612-18-IM-EN
ES500 Single Temperature Systems
IImmppoorrttaanntt See Section 4 – Unit Installation Standards and Procedures in the Thermo King Vehicle Powered Truck
Installation Standards and Procedures Guide (TK 56430). THESE PROCEDURES MUST BE FOLLOWED!
NNoottee Component dimensions are provided at the back of this manual.
Preferred Installation Method — Pre-Installed Support Plate
T ermo King recommends installing a support plate wit mounting studs or t readed inserts (installer supplied) to t e
truck’s interior roof structure to safely support t e weig t of t e evaporator(s). T e plate s ould be installed prior to
insulating and finis ing t e cargo area. T e plate s ould also position t e evaporator t e required distance from t e
front bulk ead wall to allow for refrigerant and drain ose connections.
1. Secure evaporator onto ceiling mounted support plate, install mounting ardware and tig ten securely.
EEvvaappoorraattoorr IInnssttaallllaattiioonn

TK 56612-18-IM-EN 11
Alternate Installation Method — Backer Plates
An alternate met od for securing t e evaporator(s) to t e cargo ceiling is by using backer plates (installer supplied).
1. Locate and mark center line ((CC//LL)) of interior compartment ceiling.
2. Center evaporator onto ceiling ((oorr uussee tteemmppllaattee)) and mark t e location of t e four mounting oles.
3. Inside t e cargo box:
a. Drill four guide oles into t e compartment ceiling and up t roug t e roof.
b. Enlarge guide oles to proper size.
4. Outside on t e rooftop:
a. Apply silicone sealer around all mounting oles, place backing plates over oles and insert mounting bolts
down into cargo box.
5. Inside t e cargo box:
a. Position evaporator onto mounting bolts, install was ers and locking nuts and and tig ten ardware securely.
b. Trim excess bolt lengt s as needed.
IImmppoorrttaanntt Apply silicone sealer to exterior bolt heads to prevent water from migrating into the cargo box.
EEvvaappoorraattoorr IInnssttaallllaattiioonn

12 TK 56612-18-IM-EN
Alternate Installation Method — Lag Bolts and Adhesive
An alternate installation met od for securing t e evaporator(s) to t e cargo ceiling is by using lag bolts and was ers
(supplied) and applying neutral/alco ol cure silicone sealer (installer supplied).
1. Locate and mark center line ((CC//LL)) of interior compartment ceiling.
2. Center evaporator onto ceiling ((oorr uussee tteemmppllaattee)) and mark t e location of t e four mounting oles.
3. Drill four 5mm (3/16 in.) mounting oles into t e ceiling.
4. Install t e supplied 1/4” lag bolts and was ers only a few turns into t e ceiling.
5. Apply neutral/alco ol cure silicone sealer (installer supplied) per t e manufacturer’s instructions to t e top surface
of t e evaporator.
6. Position evaporator onto t e lag bolts and and tig ten securely.
EEvvaappoorraattoorr IInnssttaallllaattiioonn

TK 56612-18-IM-EN 13
ES300 Multi-Temperature Units
IImmppoorrttaanntt See Section 4 – Unit Installation Standards and Procedures in the Thermo King Vehicle Powered Truck
Installation Standards and Procedures Guide (TK 56430). THESE PROCEDURES MUST BE FOLLOWED!
NNoottee Component dimensions are provided at the back of this manual.
Preferred Installation Method — Pre-Installed Support Plate
T ermo King recommends installing a support plate wit mounting studs or t readed inserts (installer supplied) to t e
truck’s interior roof structure to safely support t e weig t of t e evaporator(s). T e plate s ould be installed prior to
insulating and finis ing t e cargo area. T e plate s ould also position t e evaporator t e required distance from t e
front bulk ead wall to allow for refrigerant and drain ose connections.
IImmppoorrttaanntt Be sure to install the correct evaporator into each compartment.
•HHOOSSTT Evaporator as drain pan eater wires and installs in FFRROOZZEENN compartment.
•RREEMMOOTTEE Evaporator does not ave drain pan eater wires and installs in FFRREESSHH compartment.
1. Secure eac evaporator onto ceiling mounted support plates, install mounting ardware and tig ten securely.
Alternate Installation Method — Backer Plates
An alternate met od for securing t e evaporator(s) to t e cargo ceiling is by using backer plates (installer supplied).
1. Locate and mark center line ((CC//LL)) of interior compartment ceiling.
2. Center eac evaporator onto ceiling ((oorr uussee tteemmppllaattee)) and mark t e location of t e four mounting oles.
EEvvaappoorraattoorr IInnssttaallllaattiioonn

14 TK 56612-18-IM-EN
3. Inside t e cargo box:
a. Drill four guide oles into t e compartment ceiling and up t roug t e roof for eac evaporator.
b. Enlarge guide oles to proper size.
4. Outside on t e rooftop:
a. Apply silicone sealer around all mounting oles, place backing plates over oles and insert mounting bolts
down into cargo box.
5. Inside t e cargo box:
a. Position eac evaporator onto mounting bolts, install was ers and locking nuts and and tig ten ardware
securely.
b. Trim excess bolt lengt s as needed.
IImmppoorrttaanntt Apply silicone sealer to exterior bolt heads to prevent water from migrating into the cargo box.
EEvvaappoorraattoorr IInnssttaallllaattiioonn

TK 56612-18-IM-EN 15
Alternate Installation Method — Lag Bolts and Adhesive
An alternate installation met od for securing t e evaporator(s) to t e cargo ceiling is by using lag bolts and was ers
(supplied) and applying neutral/alco ol cure silicone sealer (installer supplied).
1. Locate and mark center line ((CC//LL)) of interior compartment ceiling.
2. Center evaporator onto ceiling ((oorr uussee tteemmppllaattee)) and mark t e location of t e four mounting oles.
3. Drill four 5mm (3/16 in.) mounting oles into t e ceiling.
4. Install t e supplied 1/4” lag bolts and was ers only a few turns into t e ceiling.
5. Apply neutral/alco ol cure silicone sealer (installer supplied) per t e manufacturer’s instructions to t e top surface
of t e evaporator.
6. Position evaporator onto t e lag bolts and and tig ten securely.
EEvvaappoorraattoorr IInnssttaallllaattiioonn

16 TK 56612-18-IM-EN
Refrigeration Module Installation
NNoottee Component dimensions are provided at the back of this manual.
Preferred Installation Method — Pre-Installed Support Plate
T ermo King recommends installing a support plate wit mounting studs or t readed inserts (installer supplied) to t e
truck’s interior roof structure to safely support t e weig t of t e refrigeration module. T e plate s ould be installed
prior to insulating and finis ing t e cargo area.
1. Remove plastic cover from module and trim t e foam gasket away from t e two drain oles located in t e corners
of t e module.
NNoottee The access hole must be located behind bulkhead and inside the cargo compartment. This is necessary so the
refrigeration hoses and electrical harness will be located on the inside of the cargo compartment, not in the
passengers compartment.
2. Mark and drill access ole completely t roug roof and into interior compartment.
3. Apply silicone sealant around access ole and install supplied gasket.
4. Apply silicone sealant around all mounting oles or inserts on t e roof of t e ve icle.
5. Use a 2-point lifting device wit locking ooks attac ed to module’s two lifting brackets and raise into position on
ve icle’s roof.
6. Secure module to support plate and tig ten ardware securely.
IImmppoorrttaanntt Apply silicone sealer to exterior mounting hardware to prevent water from migrating into the cargo box.

TK 56612-18-IM-EN 17
Alternate Installation Method — Lag Bolts
An alternate installation met od for securing t e Refrigeration Module to t e ve icle’s roof is by using t e supplied lag
bolts and was ers. Multiple mounting oles are provided along t e sides of t e module for mounting options. C oose
four mounting oles, ideally one in eac corner to secure t e module to t e ve icle’s roof.
1. Remove plastic cover from module and trim t e foam gasket away from t e two drain oles located in t e corners
of t e module.
NNoottee The access hole must be located behind bulkhead and inside the cargo compartment. This is necessary so the
refrigeration hoses and electrical harness will be located on the inside of the cargo compartment, not in the
passengers compartment.
2. Mark and drill access ole completely t roug roof and into interior compartment.
3. Apply silicone sealant around access ole and install supplied gasket.
4. Use a 2-point lifting device wit locking ooks attac ed to module’s two lifting brackets and raise into position on
ve icle’s roof.
5. Mark and drill four 5mm (3/16 in.) mounting oles only into internal ceiling roof supports.
6. Apply silicone sealant around eac mounting ole.
7. Secure module to roof wit supplied 1/4” lag bolts and was ers and and tig ten ardware securely.
IImmppoorrttaanntt Apply silicone sealer to exterior mounting hardware to prevent water from migrating into the cargo box
RReeffrriiggeerraattiioonn MMoodduullee IInnssttaallllaattiioonn

18 TK 56612-18-IM-EN
Power Pack Module Installation
MMooddeellss 2200 aanndd MMAAXX 2200,, 5500,, MMAAXX 5500 aanndd SSPPEECCTTRRUUMM OONNLLYY..
NNoottee It is recommended the suction and discharge copper tubing (supplied) be installed onto the standby compressor
prior to raising the Power Pack Module onto the roof of the vehicle. It is much easier to install the tubes on a
workbench rather then on the roof of the vehicle.
IImmppoorrttaanntt The standby compressor in the power pack module contains oil. Tip the module up slightly on a workbench
and place rags under the compressor’s ORS fittings before removing the protective caps.
1. Remove plastic cover assembly from t e Power Pack Module.
2. Tip module up slig tly and place rags under t e ORS fittings.
3. Remove protective caps from t e ORS fittings.
4. Lubricate t e O-rings and install t em onto t e copper tube fittings.
5. Position t e tubes onto t e compressor fittings and secure wit supplied manifold old down bracket and retaining
screw. Tig ten screw securely.
6. T e Power Pack Module can now be installed onto t e ve icle.

TK 56612-18-IM-EN 19
Preferred Installation Method — Pre-Installed Support Plate
NNoottee Component dimensions are provided at the back of this manual.
T ermo King recommends installing a support plate wit mounting studs or t readed inserts (installer supplied) to t e
truck’s interior roof structure to safely support t e weig t of t e Power Pack Module. T e plate s ould be installed prior
to insulating and finis ing t e cargo area.
1. Apply silicone sealant around all mounting bolts or inserts on t e roof of t e ve icle.
2. Wit t e cover removed, use a 4-point lifting device wit locking ooks attac ed to t e module’s four lifting oles
and raise into position onto ve icle’s roof.
3. Align t e Power Pack’s t ree front mounting studs wit t e t ree matc ing mounting oles on t e Refrigeration
Module’s frame.
a. Install flat was ers and locking nuts and tig ten ardware securely.
4. Secure module to support plate and tig ten ardware securely.
IImmppoorrttaanntt Apply silicone sealer to exterior mounting hardware to prevent water from migrating into the cargo box
PPoowweerr PPaacckk MMoodduullee IInnssttaallllaattiioonn

20 TK 56612-18-IM-EN
Alternate Installation Method — Lag Bolts
An alternate installation met od for securing t e Power Pack Module to t e ve icle’s roof is by using lag bolts and
was ers (supplied). Multiple mounting oles are provided every two inc es along t e sides of t e module for mounting
options. C oose four mounting oles, ideally one in eac corner to secure module to t e ve icle’s structural roof
supports.
1. Wit t e cover removed, use a 4-point lifting device wit locking ooks attac ed to t e module’s four lifting oles
and raise into position onto ve icle’s roof.
2. Align t e Power Pack Module’s t ree front mounting studs wit t e t ree matc ing mounting oles on t e
Refrigeration Module’s frame.
a. Attac flat was ers, locking nuts and tig ten ardware securely.
3. Use t e modules’s mounting oles as a template and drill four 5mm (3/16 in.) oles into t e internal structural roof
supports.
4. Apply silicone sealant around eac mounting ole.
5. Secure module to roof wit supplied 1/4” lag bolts and was ers and and tig ten ardware securely.
IImmppoorrttaanntt Apply silicone sealer to exterior mounting hardware to prevent water from migrating into the cargo box
PPoowweerr PPaacckk MMoodduullee IInnssttaallllaattiioonn
