Coway Air Purifier AP-1008DH User manual

Coway Air Purier
· This product is for domestic use only.It cannot be used in an
overseas country where the power voltage is different.
· Warranty card is included in this user’s manual.
·Read and save these instructions
AP-1008DH

1
1. MCC
TM
medium lter
2. Pollution level indicator/ mood lamp
It has the function showing in the pollution level indicator by
sensing the pollution of the indoor air automatically and added
up to the interior-wise function.
4. Slim design
The slim design makes the product t well in any place in
harmony with the surroundings.
3. Power saving mode
AS the fan is automatically turned on/off according to the
pollution level of the surrounding area, it helps the electricity
saving for continuous operation of the product.
∗Available only in auto mode operation
A2
This is a versatile lter which removes the yellow dust that
occurs during the spring season as well as toxic gases,
viruses and bacteria such as inuenza, legionella, etc.
MCCmedium filterMCC medium filter
TMTM
FEATURES

2
Maintenance
For Information
Thank you for using the coway air purier.
Please read the user’s manual to use and maintain the product correctly.
If you encounter a problem while using the product, you may easily solve the problem by
referring to the user’s manual. As this manual contains the product warranty card,
please keep it in a safe place.
DEAR CUSTOMERS
Others
CONTENTS
- Please keep the User’s Manual where it can be readily reached or found. -
SAFETY INFORMATION ………………… 03
- Electricity Safety ………………………… 03
- Installation Safety ………………………… 04
- Operation Safety ………………………… 05
PARTS NAME ……………………………… 07
AIR PURIFIED PROCESS ………………… 08
PREPARATIONS …………………………… 09
- How to Install Filter ……………………… 09
OPERATION/INDICATION PART ………… 10
HOW TO USE ……………………………… 13
ADJUST PARTICLE SENSOR …………… 15
CLEANING METHOD ……………………… 16
- Product …………………………………… 16
- Filter ……………………………………… 17
FILTER REPLACEMENT ………………… 18
TROUBLESHOOTING……………………… 19
SPECIFICATION …………………………… 20
WARRANTY CARD ………………………… 21
C
O
W
A
Y
FEATURES CONTENTS
/
How to Use

3
SAFETY INFORMATION
The following information is for user safety that should be observed.
It is to ensure user safety and prevent property damage.
Please read the precautions carefully and use the product correctly.
If not observed, serious physical
injury or property damage may
occur as a result.
Danger
If not observed, serious physical
injury or property damage may
occur as a result.
Warning
If not observed, minor physical
injury or property damage may
occur as a result.
Caution
Do not forcibly bend the
power cord or run it under
a heavy object to prevent
it from being damaged or
deformed.
Otherwise electric shock or re may
occur as a result.
Do not use a damaged power
plug or loose electric outlet.
Otherwise electric shock or re
may occur as a result.
Make sure to connect the
power plug to a dedicated
electric outlet for
120 V~ 60 Hz.
Otherwise electric shock or re may
occur as a result.
Do not move the product by
pulling the power cord.
Otherwise electric shock or re
may occur as a result
Do not handle the power plug
with a wet hand.
Otherwise electric shock or re may
occur as a result.
Do not plug in and plug out
the power plug repeatedly.
Otherwise electric shock or re may
occur as a result.
If the electric outlet is wet,
carefully unplug the product
and let the electric outlet
completely dry before
subsequent use.
Otherwise electric shock or re may
occur as a result.
8IFODPNQMFUFMZESZ
Unplug the product before
repair, inspection, or parts
replacement.
Otherwise electric shock or re may
occur as a result.
6OQMVHCFGPSF
SFQBJS
Electricity Safety

4
Danger Warning Caution
Installation Safety
Unplug the product if it is not
to be used for a long time.
Otherwise electric shock or re
may occur as a result.
Do not attempt to repair
or modify the power cord.
Otherwise electric shock or re may
occur as a result.
Do not plug into an electric
outlet or power strip that is
being used by several other
appliances. Use an electric
outlet dedicated to the
product.
Otherwise re may occur as a
result.
If the power cord is damaged,
do not replace the cord
yourself. Call coway service
center to have it replaced.
Otherwise electric shock or re may
occur as a result.
Do not install the air purier
near a heating device.
Otherwise re may occur as a
result.
Do not place the product on
top of an electrical appliance
such as a heater or tv.
Otherwise re, electrical shock, or
malfunction may occur as a result.
Do not install the product on a
sloped oor.
Otherwise injury to the user or
damage to the product may occur
as a result.
Do not install the product in
areas where moisture, dust or
water (rainwater) is present.
Otherwise electric shock or re may
occur as a result.
Do not use the product in
areas where ammable gases
or combustible materials are
used or stored.
Otherwise electric shock or re may
occur as a result.
Do not exert excessive force
or shock on the product.
Otherwise the product may break
as a result.
Remove any dust or water
from the power plug.
Otherwise electric shock or re
may occur as a result.
SAFETY INFORMATION I Electricity Safety I Installation Safety
For Information

5
SAFETY INFORMATION
Operation Safety
Do not use the product
in areas where it will be
subjected to heavy smoke,
odors, or oil.
Otherwise product performance
may deteriorate as a result.
Do not use the air purier in
a location exposed to direct
sunlight.
Otherwise deformation or
discoloration may occur as a result.
When the product is in use,
maintain a distance of at least
20 cm from walls or adjacent
objects and 30 cm - 60 cm
above the product.
Otherwise walls, ceilings, or
surrounding objects may be
contaminated .
Use the air purier away
from lighting devices or
direct sunlight.
Otherwise operation of the
remote control may be interrupted.
Install the product where no
obstacles around the product
block the circulation of air.
Install the air purier at least
2 m away from electronic
products such as tv.
Otherwise radio interference may
occur as a result.
.BJOUBJO
BEJTUBODF
"JSDJSDVMBUJPO
If the air purier produces
a strange noise, burning
smell, or smoke, immediately
remove the power plug from
the electric outlet and call our
service center.
Otherwise electric shock or re may
occur as a result.
Do not spray any ammable
materials such as insecticides
or fragrances to the air inlet.
Otherwise re may occur or product
performance may deteriorate as a
result.
Do not stick sharp objects
such as a screw driver into
the pollution sensor unit.
Otherwise electric shock may occur
as a result.
Never put the product in
water.
Otherwise electric shock may
occur as a result.
Do not disassemble, repair,
or modify the product.
Otherwise electric shock or product
damage may occur as a result.
Do not place on top of the
product any containers with
water, medicine, food, any
metallic objects, or any
ammable material.
If they get inside the product, electric
shock, re, or product damage may
occur as a result.

6
Do not stick ngers or foreign
objects into the air inlet or
outlet.
Otherwise physical injury or product
malfunction may occur as a result.
When removing the front
cover, exercise caution not to
have part of you body or other
objects stuck in the upper part
of the product.
Otherwise physical injury or product
malfunction may occur as a result.
Do not let children hang on to
the product or climb on it.
Otherwise physical injury or product
malfunction may occur as a result.
Replace lters with new ones
according to lter replacement
cycles.
Otherwise product performance
may deteriorate as a result.
Unplug the product before
you clean it.
Otherwise electric shock or re may
occur as a result.
Do not clean the product by
applying water directly to the
product or using benzene or
thinner.
Otherwise electric shock or re may
occur as a result.
Do not push or lean against
this product, as it may
topple over the product.
Otherwise physical injury or product
malfunction may occur as a result.
3FQMBDFXJUIPSJHJOBM
$PXBZGJMUFST
Clean the pre-lter with water
regularly and dry completely
before use.
%SZBGU FSDMFB OJOH
XJ UIXB UFS
Danger Warning Caution
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of
electric shock, this plug is intended to t in a polarized outlet only one way. If the plug does not
t fully in the outlet, reverse the plug. If it still does not t, contact a qualied electrician. Do not
attempt to defeat this safety feature.
Do not operate any fan with a damaged cord or plug. Discard fan or return to an authorized
service facility for examination and/or repair.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Arrange cord away from trafc area and where it will not be tripped over.
Never let children insert their
hands into the hole.
If they fall down with the product,
an injury may occur.
SAFETY INFORMATION I Installation Safety I Operation Safety
For Information

7
PARTS NAME
Front Rear
Others
User’s manual
Display part/
operation part
Pollution level
indicator/mood lamp
Pollution sensor
unit
Filter replacement
reset button
Speed indicator
< AP-1008DH >
Air outlet
Handle
Power cord

8
2. MCC
TM
medium lter
■ MCC
TM
medium lter
This is a versatile lter which removes the yellow dust that occurs during the spring
season as well as toxic gases, viruses and bacteria such as inuenza, legionella, etc.
AIR PURIFIED PROCESS
■ Pre-lter
Treated with antibacterial materials, the pre-lter removes relatively large dust, mold,
human hair, pet hair, and others.
■ Deodorization lter
By applying the activated lter that remove odor and the harmful
gas effectively, it eliminates food odors and unpleasant household smells.
■ HEPA lter
The high-performance composite HEPA lter effectively removes ne dust and cigarette
smoke while the antibacterial and anti-mold functions of organic antibacterial materials
eliminate germs and mold.
PARTS NAME AIR PURIFIED PROCESS
For Information
/
▶ ▶
3. Deodorization lter 4. HEPA lter
▶
1. Pre-lter

9
- Make sure to remove each lter’s plastic packing before installing lters.
- The product is for household use. Use the product indoors only.
- When the product is not in use, remove the power plug from the electric outlet.
- When installing lters, check that the front side of lters is in the correct direction.
▶ Order of lters : Pre-lter → MCC
TM
Medium Filter →Deodorization lter
→ HEPA lter
Tips
PREPARATIONS
The product is for 120 V~ 60 Hz only.
Make sure to connect the power plug to a grounded
electric outlet (120 V~ 60 Hz) dedicated to the product.
How to install lter
Please Check Before Use!
1. Open the front cover.
Open the front cover by pulling the
upper part of it.
2. Take out lters and remove
the plastic packing.
Remove the plastic packing of the
lters except the pre-lter and then
install lters according to the order of
lters.
▶
▶
▶

10
ඖ ඖ ඖ
ඖ ඖ
ඖ
1
1
2
OPERATION / INDICATION PART
Indication Part
Light sensor
It is a sensor that detects light.
2Speed indicator
By using the speed button, it is possible to select the airow speed in 4 steps
(Step 1 →Step 2 →Step 3 →Turbo)
∗ When the product is in sleep mode and power saving mode, the airow speed
indicators are not turned on.
PREPARATIONS OPERATION/INDICATION PART
How to Use
/

11
Operation Part
ඖ ඖ ඖ
ඖ ඖ
ඖ
1
2
3
4
5
OPERATION / INDICATION PART
1Power button and its
indicator
Use it to turn the product
on/off. When the power
is on, the indicator is turned on.
∗
To turn off the power, press and hold the
power button for approximately 1 second.
2Auto mode button and its
indicator
Use it to select the automatic
operation mode. When the auto
mode is selected, the indicator is
turned on.
3Mood button and its
indicator
Use it to turn mood lamp
on/off .
When mood lamp is turned
on, the indicator is turned on.
4Silent mode button and its
indicator
Use it to select the silent
operation mode.
When the silent mode is
selected, the indicator is turned on.
5Speed button and its indicator
Use it to select the desired airow speed.
∗
Pressing the speed button in Auto, or silent mode
makes the product immediately switch to manual mode.

12
∗The cleanliness (pollution) level of the room is
determined by the color at the end of the
penetrating hole.
Clean:Blue Lightly polluted:
Light purple
Polluted:
Dark purple
Highly
polluted : Red
It displays the current cleanliness (pollution) level of the room.
OPERATION/INDICATION PART
How to Use

13
HOW TO USE
Press the power button and then select
the auto mode button.
- Before operating the product, connect the power plug to a dedicated
electric outlet.
- Once the power is turned on, you will see the previously used operation mode,
already set for you to use.
Tips
■ To operate the manual mode
■ To select the auto mode
Press the power button and then select
the speed of the wind by pressing the
speed button.
Auto operating mode sets the wind speeds (step 1, 2, or 3) depending on the air pollution states
that are detected by the pollution sensor.
When the pollution levels stay in step 1 for approximately 10 minutes, the product switches to
power saving mode.
In the power saving mode, the fan is turned off to minimize the power consumption and
all displays except the power and auto indicators are turned off.
When the pollution level increases to level 2 or higher, the power saving mode is turned off.
When the power saving mode continues for 30 minutes, the product temporarily switches from
the power saving mode to step 1 to blend the surrounding air.
▶ Auto mode
Pollution level 1 Pollution level 2 Pollution level 3 or higher Power saving mode
SPEED Step 1 Step 2 Step 3 Fan off
▶
▶

14
■ To operate the sleep mode(available only in auto
mode operation)
If the surroundings are dark for 3 minutes or longer in auto
mode operation, the product automatically switches to sleep
mode, lowering the airow speed, noise, and electricity
consumption.If the surroundings become bright again for
5 minutes or longer, the unit resumes normal operation.
In sleep mode, all displays except the power indicator are
turned off.
■ To operate the silent mode
Press the power button and then the
silent button.
In silent mode, the airow speed is
lowered below step 1 (lower rpm),
making the environment quiet and
pleasant.
▶
HOW TO USE
How to Use

15
ADJUST PARTICLE SENSOR
1. With the mood mode button pressed down,
insert the power plug in the electric outlet.
2. With a tone ringing twice, the current sensitivity
indicator of the sensor blinks.
3. Adjust the sensitivity by pressing the speed button.
The sensitivity of the sensor is displayed by
ablinking airow speed indicator.
4. After adjustment, the sensitivity of the pollution
sensor is set when the power button is pressed to
turn the product off or automatically set when 20
seconds have passed in the setting mode.
How to Adjust the Sensitivity of the Pollution Sensor
When the product is shipped out, the pollution sensor is set to standard sensitivity. If the pollution level
stays at the highest level after 2 hours of operation or stays at the lowest level for more than 1 hour when
the air does not seem clean, users can adjust the sensitivity of the pollution sensor as follows.
Sensitive Standard Insensitive
Speed step 1 Speed step 2 Speed step 3

16
CLEANING METHOD
- Always unplug the air purier before cleaning the product.
- Do not use detergents that contain organic solvents (solvent, thinner, etc),
bleach, chlorine, or abrasives.
- Do not put the air purier in water or spray water directly on it.
Tips
■ Cleaning the pollution sensor (every 2 months)
A
ir outlet
Air inlet
■ Cleaning the air inlet and outlet (every 2 months)
Clean the air inlet and outlet with a soft brush.
∗
Exercise caution not to have dust fall inside the air purier.
1. Open the pollution sensor cover on the
right-hand side of the product. Clean
the air inlet and outlet vent and then
the pollution sensor with a soft brush or
vacuum cleaner.
Dust outlet
Dust inlet
2. Wet a cotton swab lightly and clean the lens, dust inlet,
and dust outlet. Clean them with a dry cotton swab
to remove remaining moisture.
∗ Without regular cleaning, the performance of the pollution sensor deteriorates.
∗ The cleaning cycle differs depending on the operation environment.
When using the product in a dusty environment, clean the sensor more often.
■ Cleaning the product body (every 2 ~ 4 weeks)
Use dry, soft cloth to clean the product.
∗
Use lightly wet cloth if the contamination is serious but do not use abrasives.
■ Cleaning the front cover
Separate the front cover from the product and remove the dust
attached to the surface with a soft dry brush or cloth.
∗
Use lightly wet cloth if the contamination is serious but do not use abrasives.
ADJUST PARTICLE SENSOR
▶
ADJUST PARTICLE SENSOR CLEANING METHOD
How to Use
/

17
CLEANING METHOD
- Always unplug the product before cleaning the lter.
- The pre-lter is reusable by removing dust or cleaning it with water.
- If the pre-lter is not cleaned for a long time, the product performance may deteriorate.
- The HEPA lter are not reusable with cleaning. Never clean them with water.
Tips
■ Cleaning the pre-lter (every 2 ~ 4 weeks)
1. Open the front cover by pulling
out the end part above the air
inlet.
2. Take out the pre-lter by pulling out on the handles.
∗
To prevent dust from falling off, remove the lter carefully without exerting a shock.
3. Clean the pre-ler with a vacuum cleaner or with water depending
on the level of contamination.
∗
When retting the pre-lter to the product, t it in the hook correctly.
4. Install the pre-lter after removing the moisture completely.
Fit the front cover back to the product.

18
1. Button indicator is turned on one by one clockwise when the lter needs
to be replaced.
2. Airow LED indicates a lter that needs to be replaced.
Step 1 LED : HEPA, Step 2 LED : deodorization,
Step 3 LED : MCC
TM
medium
3. When the lter replacement indicator is displayed, the pollution level
indicator is turned off.
4. The lter replacement indicator is displayed for 5 minutes in every half an hour.
5. When you have replaced a lter before the lter replacement cycle is reached, press and hold the
RESET button for 1 second(forcible reset). The forcible reset initializes all the lter replacement
cycle counters.
Filter cycles method
Pre-lter Every 2~4 weeks Cleaning and washing
MCC
TM
medium lter Every 4 months Replacement
Deodorization lter Every 12 months Replacement
HEPA lter Every 12 months Replacement
CLEANING METHOD FILTER REPLACEMENT
Maintenance
FILTER REPLACEMENT
■ How to replace lters
∗
Each service life is based on 24-hour use in auto mode.
∗
The recommended lter replacement cycles may differ depending on the operating environment.
■ Filter cleaning and replacement cycles
- Check that the ‘front’ sides of lters are in the correct direction.
- To maintain optimal performance of the product, use original coway lters.
- Always unplug the air purier before replacing lters.
■ Replacing lters
■ Filter replacement indicator
1. When replacing lter, check that the front side is In the correct
direction.
2. With the power is on, press the reset button with a sharp tool.
/

19
TROUBLESHOOTING
The air purier may operate abnormally not because of the product malfunction but because
of minor causes or the fact that the user is not familiar with the product use. In such a case,
problems can be solved easily even without the help from the service center just by checking
the following. If the problem still persists after you check the following, contact the service
center.
Symptom Check Measures to take
No air is blowing.
• Is the power cord connected? Connect the power cord to an electric
outlet for 120 V~ 60 Hz.
• Is the display part all turned off? Press the power button and then select
the desired function.
• Isn’t the power gone out? Use the air purier after the power
comes back on.
• Is the auto mode indicator turned on?
When the pollution level 1 lasts
continuously for 10 minutes, the product
switches to power saving mode, turning
off the fan automatically.
The airow speed
does not change.
• Isn’t it in manual or silent mode? Set the desired operating mode.
• Isn’t the room dark? When in sleep mode, the airow speed
is xed to the minimum level.
The airow speed is
signicantly weaker than
before.
• Isn’t the lter cleaning or
replacement time passed?
Check the lter cleaning and replacement
cycles and then clean/replace the lter(s)
if necessary.
A bad smell comes out
of the air outlet.
• Isn’t the lter cleaning or
replacement time passed?
Check the lter cleaning and replacement
cycles and then clean/replace the lter(s)
if necessary.
The color of the pollution
level indicator always
stays the same.
•Isn’t there dust on the pollution
sensor’s lens? Clean the lens of the pollution sensor.
• Does the pollution level keep
indicating a high level?
Adjust the sensitivity of the pollution
sensor to Insensitive or standard.
• Does the pollution level keep
indicating a low level?
Adjust the sensitivity of the pollution
sensor to sensitive or standard.
The pollution level
indicator blinks. • Request service or ask our service center.
When other functional
problems are detected
• Check the symptoms, unplug the product, and then request service or ask
service center.
