Creality CR-10 Smart User manual

CR-10 Smart
Create reality，achieve dreams
CR-10 Smart
V1.0
1
25
7
13
19
Mode d’Emploi de l'Imprimante 3D de Série CR-10 Smart
Benutzerhandbuch 3D-Drucker CR-10 Smart Serie
Stampante 3D Serie CR-10 Smart Manuale d’Uso
Impresora 3D de Serie CR-10 Smart Manual de Usuario
CR-10 Smart Series 3D Printer User Manual
FR SETI NEED
3D Printer User Manual

Contents
Introduction 28-28
Parameters 29-29
Parts List 30-30
31-35
Assemble the 3D Printer
36-41
Use the 3D Printer
43-43
44-45
Off-line print
46-46
Start print
47-47
Network reset
48-48
49-49
Wiring Connection
50-50
Troubleshooting
Creality Cloud print
42-42
Pairing via Bluetooth
Printer maintenance
27

1. Introduction
1X Limit Switch
2Spotlight
3Nozzle Kit
4Feeding holder components
5Z-axis photoelectric switch
6Printing Platform
7Y-axis belt adjusting knob
8Tool Box
9Storage Card Slot
10 Touch screen
11 USB interface
12 Network Interface
13 Power-on button
14 X-axis belt adjusting knob
15 Pull rod
16 Screw rod
17 Coupling
18 Z-axis motor
19 Power switch
20 AC power supply
21 Y-axis Motor
22 X-axis Motor
23 Filament Detector
24 Extruder Motor
12
1
2
3
4
5
8
6
9
14
13
11
10
17
18
15
16
19
20 21
18
22
23
24
28

Basic Parameters
Model CR-10 Smart
300*300*400mm
FDM
1
0.1mm-0.4mm
Standard 0.4mm
±0.1mm
1.75mm PLA/ABS/TPU/PETG/Wood
STL/OBJ/AMF
Creality Slicer/Cura/Repetier-Host/Simplify3D
Input: AC100-240V 50/60Hz Output: DC 24V
350W
≤100℃
≤260℃
Yes
Yes
Yes
Yes
English
80-100mm/s
Printing Size
Molding Tech
Nozzle Number
Slice Thickness
Nozzle Diameter
Precision
Filament
File Format
File Transfer
Slice Software
Power Supply
Total Power
Bed Temp
Nozzle Temp
Resume Printing
Filament Detector
Dual Z-axis
Auto Leveling
Language
Printing Speed
Wifi/Storage card
2. Equipment parameters
29

3. Package Content
x 1
7Filament 9M5x45 Sems Screw ×4 10 M5×12 Hexagon flat round
head screw x2
11 M5x20 Hexagon flat round
head screws x2
Storage Card &
Card Reader
x 1
19
Spade
x 1
13 Nozzle Cleaner x 1 16
Diagonal Pliers
x 1
17
Wrench x 1
14
Allen wrench
x 1
18
20
Quick Connect Buckles x 2
21
Quick Release Claw x 2
x 1
Gantry Frame
2
x 1
Base Frame
1x 1
Touch screen
3x 1
5Rack
22
Nozzles x 2
15 x 1
Socker Spanner
x 1
4Power Cord
Tips: the above accessories are for reference only, please refer to the physical accessories!
Pull rods
8x 2
x 1
6Spool
12 M5 Large Flat gasket×2
x 1
23
Threading fixture
30

4. Install the Gantry Frame
Twist the coupling to raise the X axis
to the position shown in Figure 16.
Two Z-axis profiles, installed on the
inner step of the Y-axis bottom profile.
9M5x45 Sems Screw ×4
x 1
Gantry Frame
2
x 1
Base Frame
1
Fix the lines on the nozzle kit with a black rolling belt as shown
in the figure and re-fix it if any re-assembly before operation.
99
16
2
1
X axis
31

5. Pull Rod Installation
10 M5×12 Hexagon flat round
head screw x2
11 M5x20 Hexagon flat round
head screws x2
Adjust the proper length of assembled pull rod and install in the position shown in the figure
10
11
11
10
M5 Large Flat gasket×2
12
12
32

6. Install the Rack
x 1
6Spool
x 1
5Rack
5
6
Follow the installation diagram to assemble the rack on the left of the machine.
33

7.Install the touch screen
1
2
Caution
●Do not connect or disconnect the cables when the machine is powered on.
3
x 1
Touch screen
3
1. Connect the FFC on the base with the touch screen.
2. Fix the three screen locks on the touch screen to the studs of the base and press them into place.
34

x 1
8. Cable Connection
Caution
●Do not connect or disconnect the cables when the machine is powered on.
4Power Cord
4
C
D
E
A 、Connect the 15pin port to the nozzle adapter board as shown in the figure
B、Connect Z-axis motor cable
C、Connect the photoelectric switch wire
D、Connect it to the power cord and turn on the power
E、Long press the power button and wait the display screen to start
B
A
Z1
Z2
B
35
