Creative MUVO TX FM User manual

P/N : 03PD051100007 Rev B
Quick Start

English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Français. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Brasileiro. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Türkçe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Language TOC.fm Page 1 Thursday, May 20, 2004 4:34 PM

Language TOC.fm Page 2 Thursday, May 20, 2004 4:34 PM

1
English
Your Player At A Glance
Liquid Crystal
Display (LCD)
Play/Pause
Microphone
Scroller
Volume
Increase
Volume
Decrease
Front View Side View
Earphone
connector
Volume
Increase
MuVo TX FM QSB English 20th May.fm Page 1 Wednesday, May 19, 2004 4:44 PM

2
English
Getting Started
1
1Install the Software
Your Creative MuVo TX FM comes with software that helps you create audio tracks, manage
your music library and use your player.
1. Make sure that your player is not connected to your computer.
2. Insert the Installation CD into your CD-ROM drive.
3. The disc supports Windows AutoPlay mode and starts running automatically. If not, click
Start →Run. In the Open box, type d:\ctrun\ctrun.exe (replace d:\ with the drive
letter of your CD/DVD-ROM drive), and then click the OK button.
4. Click the Install software for Creative MuVo TX FM to select it.
5. Click the OK button.
6. Follow the instructions on the screen.
7. When prompted, restart your system.
For Windows 2000/XP users:
To install the software, you must log in as the computer administrator. For more
information, refer to your operating system's online Help.
MuVo TX FM QSB English 20th May.fm Page 2 Wednesday, May 19, 2004 4:44 PM

3
2
2Connect the USB Flash Drive to your
computer
Do not press the buttons on your USB Flash Drive while connecting it to your computer.
USB port
Battery
module
USB port
USB Flash
Drive
a
b
MuVo TX FM QSB English 20th May.fm Page 3 Wednesday, May 19, 2004 4:44 PM

4
3
3Transferring tracks or files
1. After connecting the USB Flash Drive to your computer, you will see
Figure 1 on the player's LCD screen.
2. On your Desktop, right-click the My Computer icon, and then click
Explore. The USB Flash Drive appears as a removable disk icon
(Figure 2).
3. Drag and drop files into your player. During the transfer, Figure 3
appears on the LCD screen.
You can also use applications such as Creative MediaSource (included with the Installation CD)
to manage the music tracks in your player.
For Windows 98 SE users only:
Do not remove the USB Flash Drive until Figure 1 appears on the screen again for at least
five seconds.
For other Windows operating system users only:
Make sure you stop your player properly, using the Eject or Safely remove USB Mass
Storage Device option, before disconnecting it from your computer. Failure to
disconnect the player properly can result in corrupted files or music tracks. See the
“Troubleshooting” section in this booklet for details.
Music tracks are played in alphanumeric order starting with the tracks in the root level
followed by those in folders. The MuVo TX FM will only play supported music tracks that
are stored in either the root level or the first level of a folder. Tracks stored in sub-folders
of a folder will not be recognized.
Figure 1
Figure 2
Figure 3
MuVo TX FM QSB English 20th May.fm Page 4 Wednesday, May 19, 2004 4:44 PM

5
Formatting Your Player
If you need to format your player, back up the files in your player first. When you format your
player, all songs and files will be deleted. By default, your player is already formatted.
1. Connect your player to your computer's USB port.
2. Launch Windows Explorer on your computer. Your player is recognized as a Removable
Disk in Windows Explorer.
3. Right-click the Removable Disk icon and
click the Format option. The Format F:\
dialog box appears (replace F:\ with the
drive letter of your player).
4. Follow the instructions on the screen to
format your player.
5. After the formatting is complete, make sure you stop your player before disconnecting it
from your computer.
For more information about using Windows Explorer, refer to its online Help.
Your MuVo TX FM must be formatted in the FAT or FAT16 file system only. Do not select
FAT32 or NTFS. Those formats are not recognized by your MuVo TX FM.
Windows 98SE users must have MuVo TX FM drivers installed before formatting the
player.
MuVo TX FM QSB English 20th May.fm Page 5 Wednesday, May 19, 2004 4:44 PM

6
How To Use Your Player
Remember to unplug the USB Flash Drive from your computer and insert it into the battery
module before turning on the player. For more usage information, refer to the PDF User's
Guide. Go to d:\manual\<language>\manual.pdf (replace d:\ with the drive letter of your
CD\DVD-ROM drive and <language> with the language the document is in).
Inserting the battery
The life of a battery depends on the type of battery used. It is recommended that you use
an alkaline battery. With an alkaline battery, you can play up to fourteen hours worth of
.MP3 files or eleven hours of .WMA files.
abc
MuVo TX FM QSB English 20th May.fm Page 6 Wednesday, May 19, 2004 4:44 PM

7
Using Your Scroller
"Scroll Select", indicates that you should use the Scroller to scroll through options, and then
select the option by pressing the Scroller.
Using Your Player
Turning on the player
Press and hold the Play/Pause button for a few seconds. The Creative logo appears
on the screen, followed by the Creative MuVo TX FM logo, and there is music playback.
If your player contains no audio tracks, the message "No Music" or "No Recording" will appear
onscreen, depending on whether you are in Music or Recordings mode.
Turning off the player
Press and hold the Play/Pause button for a few seconds until after the Power off
message disappears
1. Use the Scroller to scroll through
options.
3. Press the Scroller to select the option.
2. Scroll to an option. 4. The selection appears.
MuVo TX FM QSB English 20th May.fm Page 7 Wednesday, May 19, 2004 4:44 PM

8
Stopping/Pausing a music track
Press the Play/Pause button .
Skipping folders (Albums)
1. Press the Scroller.
2. Scroll Select Skip Folder (Figure 4).
3. The Skip Folder menu appears.
4. Scroll to the folder that you want to skip to.
5. To resume normal playback, press the Scroller again.
Making a voice recording
1. Press the Scroller. Scroll Select Microphone (Figure 5).
2. The recording bar appears onscreen.
3. Press the Play/Pause button to start the recording.
4. Press the Play/Pause button again to end the recording.
5. A name is automatically assigned to your recording and is saved in your player. The naming
convention typically used is: VOC [Current File Number].
For easy navigation, store your albums as folders in the root directory.
When recording, the available recording time is determined by:
- available memory space in your player.
- battery power remaining in your player.
Figure 4
Figure 5
MuVo TX FM QSB English 20th May.fm Page 8 Wednesday, May 19, 2004 4:44 PM

9
Listening to FM radio
To change the FM region
Perform these steps first when scanning for stations for the first time.
1. Press the Scroller.
The Main Menu appears.
2. Scroll Select the Settings icon (Figure 6). A list appears.
3. Scroll Select the FM Region icon (Figure 7). A list appears.
Scroll Select the region that you are in.
To perform an autoscan and autosave
1. Press the Scroller.
The Main Menu appears.
2. Scroll Select the FM Radio icon (Figure 8).
A radio frequency appears on the LCD screen.
3. Press the Scroller.
4. Scroll Select the Autoscan icon (Figure 9).
The player scans and stores channels it detects. At the end of
the autoscan, it plays the first channel.
To select a channel
1. Press the Scroller.
The Main Menu appears.
2. Scroll Select the FM Radio icon (Figure 8).
A radio frequency appears on the LCD screen.
3. Turn the Scroller to select the preset channel you want.
Figure 6
Figure 7
Figure 8
Figure 9
MuVo TX FM QSB English 20th May.fm Page 9 Wednesday, May 19, 2004 4:44 PM

10
Software Included
Creative MediaSource
Creative MediaSource allows you to rip CDs and create high quality digital audio files, play and
organize media files on your computer as well as transfer music tracks or files seamlessly to
and from your player. Special features such as SMARTFIT, using intelligent track management
and WMA compression, enable you to transfer a higher number of music tracks to your player.
For more information, refer to the Creative MediaSource online Help.
Go to Start →Programs/All Programs →Creative →Creative MediaSource →
Creative MediaSource Organizer.
MuVo TX FM QSB English 20th May.fm Page 10 Wednesday, May 19, 2004 4:44 PM

11
Troubleshooting
When you turn on the player, an error message “File system error” appears
before the player turns off.
Try formatting your player. See section "Formatting Your Player".
After playing the first few music tracks, the player skips a music track.
The player will only play .MP3, .WMA or .WAV recordings. Other files will be skipped.
Files or music tracks are corrupted when transferred to the player.
After the transfer is complete, make sure you stop your player before disconnecting it from
your computer.
The player turns off immediately after it is turned on.
Check that the battery is not depleted.
I have to change the battery quite often. Is there anything I can do to make it last
longer?
Some operations consume more battery power:
• a long backlight timeout setting. A shorter timeout conserves battery power.
• frequent use of fast forward/reverse.
• turning the player on/off too many times.
• frequent use of passive speakers or high-powered headphones.
• playback of .WMA files.
Can I play DRM-protected WMA files on my Creative MuVo TX FM?
Yes.
WMA files with Digital Rights Management (DRM) code cannot be transferred into your
player using a drag-and-drop operation. Transfer these files using applications like
Windows Media Player or Creative MediaSource. Refer to your player’s User’s Guide for
more information on transferring audio.
MuVo TX FM QSB English 20th May.fm Page 11 Wednesday, May 19, 2004 4:44 PM

12
More Information
Register your product!
Enjoy a host of benefits by registering your product during installation, or at
www.creative.com/register. Benefits include:
• Service and product support from Creative
• Exclusive updates on promotions and events.
Technical Support and Warranty information
You can find Technical Support, Warranty and other information in the Installation CD.
(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, <region> with the
region that you are in, and <language> with the language that your document is in)
Technical Support d:\support\<language>\support.pdf
You can also click Start →Programs →Creative →Technical Support
Warranty d:\warranty\<region>\<language>\warranty.pdf
Please keep your Proof of Purchase for the duration of the warranty period.
Regulatory d:\fcc\<language>\doc.pdf
User’s Guide d:\manual\<language>\manual.pdf
WARNING: Handling the cord(s) on this product may expose you to lead, a chemical
known to the State of California to cause cancer and birth defects or other reproductive
harm. Wash hands after handling.
Creative Knowledge Base
Resolve and troubleshoot technical queries at Creative's 24-hour self-help Knowledge Base
.
Go to www.creative.com and select your region.
Copyright © 2004 Creative Technology Ltd. All rights reserved. The Creative logo, MuVo and Creative MediaSource are
trademarks or registered trademarks of Creative Technology Ltd. in the United States and/or other countries. NOMAD i
s
a registered trademark of Aonix and is used by Creative Technology Ltd. and/or its affiliates under license. Microsoft, Window
s
and the Windows logo are registered trademarks of Microsoft Corporation. All other products are trademarks or registered
trademarks of their respective owners and are hereby recognized as such. All specifications are subject to change withou
t
prior notice. Actual contents may differ slightly from those pictured.
MuVo TX FM QSB English 20th May.fm Page 12 Wednesday, May 19, 2004 4:44 PM

13
Français
Votre lecteur en un coup d'œil
Ecran à cristaux
liquides (LCD)
Lecture/Pause
Microphone
Molette
Augmentation
du volume
Diminution
du volume
Vue avant Vue latérale
Connecteur
des écouteurs
CLI_MuVo TX FM QSB.book Page 13 Thursday, May 13, 2004 12:33 PM

14
Français
Démarrage
1
1Installation du logiciel
Votre Creative MuVo TX FM est livré avec un logiciel qui permet de créer des pistes audio, de
gérer une bibliothèque de musique et d'utiliser le lecteur.
1. Assurez-vous que le lecteur n’est pas connecté à l’ordinateur.
2. Insérez le CD d'installation dans le lecteur de CD-ROM.
3. Le disque prend en charge le mode exécution automatique de Windows et démarre
automatiquement. Dans le cas contraire, cliquez sur Démarrer → Exécuter. Dans le
champ Ouvrir, tapez d:\ctrun\ctrun.exe (remplacez d:\ par la lettre de votre lecteur de
CD/DVD-ROM), puis cliquez sur le bouton OK.
4. Cliquez sur l’option Installer le logiciel pour Creative MuVo TX FM pour la
sélectionner.
5. Cliquez sur le bouton OK.
6. Suivez les instructions apparaissant à l'écran.
7. A l'invite, redémarrez votre système.
Pour les utilisateurs Windows 2000/XP :
Pour installer le logiciel, vous devez vous connecter en tant qu'administrateur système.
Pour plus d'informations, consultez l'aide en ligne de votre système d'exploitation.
CLI_MuVo TX FM QSB.book Page 14 Thursday, May 13, 2004 12:33 PM

15
2
2Connexion du Flash Drive USB à votre
ordinateur
N’appuyez pas sur les boutons de votre Flash Drive USB lorsque vous le connectez à votre
ordinateur.
Port USB
Module
de pile
Port USB
Flash Drive
USB
a
b
CLI_MuVo TX FM QSB.book Page 15 Thursday, May 13, 2004 12:33 PM

16
3
3Transfert de pistes ou de fichiers
1. Après connexion du Flash Drive USB à votre ordinateur, Figure 1
apparaît sur l’écran LCD du lecteur.
2. Sur votre Poste de travail, cliquez avec le bouton droit sur l'icône
Poste de travail, puis sur Explorer. L’icône du Flash Drive USB
représente un disque amovible (Figure 2).
3. Glissez-déplacez les fichiers vers votre lecteur. Lors du transfert,
Figure 3 apparaît sur l’écran LCD.
Vous pouvez également utiliser des applications telles que Creative MediaSource (inclus sur le
CD d’installation) pour gérer les pistes musicales sur votre lecteur.
Pour les utilisateurs Windows 98 Deuxième Edition uniquement :
Ne retirez pas le Flash Drive USB jusqu’à ce que la figure 1 apparaisse de nouveau à l’écran
pendant au moins cinq secondes.
Pour les utilisateurs d’autres systèmes d’exploitation Windows uniquement :
Assurez-vous de correctement arrêter votre lecteur, en utilisant l’option Ejecter ou
Supprimer le périphérique de stockage USB en toute sécurité, avant de le
déconnecter de votre ordinateur. Les fichiers ou les pistes musicales risquent d’être
corrompus si le lecteur n’est pas correctement déconnecter. Reportez-vous à la section «
Dépannage » de cette brochure pour plus de détails.
Les pistes musicales sont lues dans un ordre alphanumérique, en commençant par les
pistes situées à la racine suivies de celles situées dans les dossiers. Le lecteur MuVo TX FM
ne lit que les pistes musicales prises en charge qui sont stockées soit à la racine, soit dans
le premier niveau de dossier. Les pistes stockées dans les sous-dossiers ne sont pas
reconnues.
Figure 1
Figure 2
Figure 3
CLI_MuVo TX FM QSB.book Page 16 Thursday, May 13, 2004 12:33 PM

17
Formatage de votre lecteur
Si vous devez formater votre lecteur, sauvegardez tout d’abord les fichiers qui se trouvent dans
votre lecteur. Lorsque vous formatez votre lecteur, toutes les chansons et tous les fichiers
seront supprimés. Par défaut, votre lecteur est déjà formaté.
1. Connectez votre lecteur au port USB de votre ordinateur.
2. Lancez l’Explorateur Windows sur votre ordinateur. Votre lecteur est reconnu en tant
que disque amovible dans l’Explorateur Windows.
3. Cliquez avec le bouton droit de la souris sur
l’icône Disque amovible et cliquez sur
l’option Formater. La boîte de dialogue
Formater F:\ s’affiche (remplacez F:\ par la
lettre de votre lecteur).
4. Suivez les instructions qui s'affichent à
l’écran pour formater votre lecteur.
5. Une fois le formatage terminé, assurez-vous de mettre votre lecteur hors tension avant de
le déconnecter de votre ordinateur.
Pour obtenir plus d’informations sur l’utilisation de l’Explorateur Windows, consultez l’aide en
ligne.
Votre lecteur MuVo TX FM doit être formaté au format de système de fichiers FAT ou
FAT16 uniquement. Ne sélectionnez pas le format FAT32 ou NTFS. Si ces options sont
disponibles sur votre système d’exploitation, ces formats ne sont pas reconnus par votre
lecteur MuVo TX FM.
Pour les utilisateurs Windows 98 Deuxième Edition, les pilotes MuVo TX FM doivent être
installés avant de formater le lecteur.
CLI_MuVo TX FM QSB.book Page 17 Thursday, May 13, 2004 12:33 PM
