Cres Cor CCB-150 Series Manual

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Banquet
Cabinets FL-2252
Rev. 5 (8/10) Page 1 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for CCB-150 Series Banquet Warming Cabinet
ELECTRICAL SPECIFICATIONS: AC SERVICE
Volts Watts Amps Hertz Phase NEMA *NEMA
120 1650 13.8 60 1 5-15P 5-20P
240 1650 6.9 60 1 6-15P 6-15P
* For Canadian use
HOW TO INSTALL UNIT:
1. Remove all packing materials from inside the cabi-
net and clean the cabinet thoroughly.
2. Install all angles and shelves before the unit is
turned on.
3. Plug the power cord into the proper wall outlet.
HOW TO TURN OFF UNIT:
Push power switch to “OFF”. The yellow light will
turn off.
HOW TO START UNIT:
1. Push the power switch to “ON”. Yellow light will
turn on.
2. Turn the thermostat to #10 (220°F/105°C).
3. Preheat (assuming a “cold” cabinet of 75°F/25°C)
a) To 150°F/65°C takes about 30 minutes
b) To 175°F/79°C takes about 45 minutes
c) To 190°F/88°C takes about 1 hour.
4. Put food into the cabinet.
5. Turn the thermostat to the required temperature.
NOTE: No. 8 is about 175°F/79°C
No. 7 is about 160°F/71°C.
No. 6 is about 145°F/63°C
Proper food holding temperature is
140°F/60°C or higher.
REMOVABLE HOT UNIT
PARTS IDENTIFICATION
1. Thermostat
2. Power Switch
3. Yellow Indicator Light
4. Temperature Display
ON
OFF
12 3 4
HOW TO INSERT CANNED FUEL:
1. Install all channels and shelves before unit is put
into operation.
2. Lift and pull drawer open and inset canned fuel.
3. Remove lids from canned fuel; light with external
flame.
4. Close drawers completely.
It is recommended to electrically pre-heat the cabinet
to at least 160°F/71°C before inserting and/or lighting
the canned fuel. This will take about 45 minutes.
Approximate cabinet temperature, using a total of
two(2) cans of canned fuel, will be 180°F/82°C
FOR CANNED FUEL USE:
The canned heat drawers on this unit have cutouts that
will permit the 7-oz. can (size 3-3/8” dia. x 2-7/16” hi.)
of STERNO to be used. The burn time of this size can
is a nominal two (2) hours.
STERNO brand of canned heat is from the Candle
Corp. of America.
WARNING Risk of Fire!
Do NOT store combustible materials or
flammable liquids near this appliance.

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Banquet
Cabinets FL-2252
Rev. 5 (8/10) Page 2 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for CCB-150 Series Banquet Warming Cabinet
BEFORE CLEANING THE CABINET:
1. Allow cabinet to cool.
2. Remove Hot Unit BEFORE cleaning. (Unit
is designed to lift off from front and rear.)
3. Do NOT use abrasives or harsh chemicals.
MAINTENANCE:
1. Unplug power cord from wall outlet.
2. Lift unit off from front and rear of cabinet.
Soil Cleaner Method
CABINETS
(Stainless Steel)
Routine Cleaning Soap, ammonia, or
detergent* and water 1. Sponge on with cloth. 2. Rinse.
Stubborn spots
and stains Mild abrasive made for stainless steel 1. Apply with damp cloth. 2. Rub lightly.
Burnt-on foods or
grease. Chemical oven cleaner 1. Apply generous coating. 2. Allow to stand for 10-15
minutes.
3. Rinse.
4. Repeat application if
necessary.
Hard water spots
and scale. Vinegar 1. Swab or wipe with cloth. 2. Rinse dry.
*Mild detergents include soaps and non-abrasive cleaners.
Cleaning Notes:
1. Wipe up spills as soon as possible.
2. Clean cabinet regularly to avoid heavy dirt build-up.
3. Make a test spot with cleaner.
4. Follow manufacturer’s directions on cleaner.
5. Do not mix cleaners.
6. Avoid drips and splashes.
REMOVABLE PARTS IDENTIFICATION:
Description Qty.
1. Hot Unit ....................................... 1
2. Air Tunnels...................................2
3. Wire Grids.................................... 6
4. Channel Post ................................ 1
5. Shelf Channels.............................3
6. Canned Fuel Drawers...................2
7. Canned Fuel Covers.....................2
WARNING
HOW TO CLEAN THE UNIT:
1
2
3
4 5
6 7

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Banquet
Cabinets FL-2252
Rev. 5 (8/10) Page 3 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for CCB-150 Series Banquet Warming Cabinet
TROUBLE-SHOOTING CHART:
FAILURE POSSIBLE CAUSE
1. Yellow light at switch does NOT light. 1a. Circuit breaker/fuse to wall outlet blown. 2a. Cord is unplugged from wall outlet.
3a. Switch is “OFF.”
2. Unit does not get hot. 2a. Thermostat set too low or are off.
2b. Switch is “OFF.”
3. Unit gets too hot or won’t shut off 3a. Defective electrical parts.
3b. UNPLUG UNIT FROM WALL OUTLET
4. Blower does not work or makes noise. 4a. Defective Blower
5. Excess moisture in cabinet. 5a. Open vent. 5b. Foods taken from oven or fryer should be “slacked
out” for 5 minutes before placing in hot cabinet.
NOTE: Optional digital thermometer will flash if cabinet temperature is below 140°F or above 250°F.
Call the Factory if you need different settings.
If cause is none of the above, refer to our list of Authorized Service Centers, FL-1400.
REPLACEMENT PARTS: CABINET PARTS:
DESCRIPTION 120 VOLT 240 VOLT DESCRIPTION PART NO.
Hot Unit HU18671-164* HU18671-165 Door Latch Kit 1006-143-K
Blower Kit 0769-180-K 0769-182-K Door Strike 1006-144-K
Heater Kit 0811-214-01 0811-215-01 Door Hinge 0519-084
Thermostat Kit 0848-062-K 0848-062-K Door Gasket 0861-225
Thermometer Kit 5238-030-K 5238-030-K Door Assembly Complete 1221-462-K
Power Cord 0810-029-02*0810-039-03 Wire Grid 1170-204
Switch Kit 0808-116-K 0808-116-K Push Handle 1072-089
Pilot Light 0766-094 0766-095 Canned Heat Drawer 5069-009-K
Canned Heat Cover Ass’y 0977-080-K
For Canadian Use:* Center Channel Assembly 1043-049-K
Hot Unit (120 Volt) HU18671-164C
Power Cord Plug 0713-017

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Banquet
Cabinets FL-2252
Rev. 5 (8/10) Page 4 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for CCB-150 Series Banquet Warming Cabinet
ELECTRICAL SPECS
HOT UNIT #0671-164
1650W, 120V, 60Hz, 1 Ph
AC SERVICE
HOT UNIT #0671-165
1650W, 240V, 60Hz, 1 Ph
AC SERVICE
GREEN
G
THERMOSTAT
THERMOSTAT
GREEN
8
2
8
7
SWITCH
POWER
3
1
LIGHT
PILOT
4
3
13
7 4
12
11
240V, 15A
TERMINAL
BLOCK
W
G
6-15P
BROWN
12
7
8
SWITCH
POWER
1
BLUE
3
3
13
LIGHT
PILOT
12
10
9
13
12
BLOWER
SLEEVING
HEATER
9 11 10
13
12
HEATER
BLOCK
TERMINAL
GW
BROWN
12
120V, 15A
G
5-15P
7 2
BLUE
11
HEATER
10118 9 9
BLOWER
10
HEATER
SLEEVING
DIAGRAM FOR 240V UNITS
DIAGRAM FOR 120V UNITS
BLOWER
BLOWER
