Cres Cor H137UA C Series Manual

OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137UA...C & H13818...C Series Hot Cabinets (Aluminum)
H137SUA...C & H138S18...C Series Hot Cabinets (Stainless)
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Hot Cabinet FL-2251
Rev. 11 (5/14) Page 1 of 5
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
ELECTRICAL SPECIFICATIONS:
Model No. Volts Watts Amps Hertz Phase NEMA
H137SUA12C2K
H137UA12C2K
H138S1834C2K
H1381834C2K
120 2000 16.7 60 1 5-20P
H137SUA12C208
H137UA12C208
H138S1834C208
H1381834C208
208 2000 9.6 60 1 6-15P
H137SUA12C240
H137UA12C240
H138S1834C240
H1381834C240
240 2000 8.3 60 1 6-15P
H137SUA12CCAN
H137UA12CCAN
H137SUA9CCAN
H137UA9CCAN
H138S1834CCAN
H1381834CCAN
120 1500 12.5 60 1 5-20P
H137SUA12CC15A
H137UA12CC15A
H137SUA9CC15A
H137UA9CC15A
H138S1834CC15A
H1381834CC15A
120 1400 11.7 60 1 5-15P
H137SUA12C
H137UA12C
H137SUA9C
H137UA9C
H138S1834C
H1381834C
120 1500 12.5 60 1 5-15P
H137SUA9C208
H137UA9C208 208 1500 7.2 60 1 6-15P
H137SUA9C240
H137UA9C240 240 1500 6.2 60 1 6-15P
H137SUA6C
H137SUA5C
H138S1816C
H138S185C
120 1000 8.3 60 1 5-15P
H137SUA6C208
H138S1816C208
H137SUA5C208
H138S185C208
208 1000 4.8 60 1 6-15P
H137SUA6C240
H138S1816C240
H137SUA5C240
H138S185C240
240 1000 4.2 60 1 6-15P
NOTE: The above model numbers are basic models. They may be followed by letters: M
L, D or ending with S and/or Z.
U.S.
and
Canada
}
U.S.
and
Canada
}
U.S.
Only
}

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137UA...C & H13818...C Series Hot Cabinets (Aluminum)
H137SUA...C & H138S18...C Series Hot Cabinets (Stainless)
Insulated
Hot Cabinet FL-2251
Rev. 11 (5/14) Page 2 of 5
HOW TO INSTALL UNIT:
1. Place cabinet on level oor.
2. Place cabinet in a well ventilated area.
3. Plug cord end into proper wall outlet.
1. Turn the POWER switch on. The yellow light will
turn on.
2. Turn thermostat to #10.
3. Let unit operate for one hour.
4. Turn unit off and let cool.
5. Wipe inside clean with detergent and hot water.
INITIAL OPERATION:
(For rst-time operation only):
NOTE: A new oven needs to “burn off” manufacturing
oils and excess adhesive before its rst use.
Do NOT load food into oven until this has
been done!
HOW TO START UNIT:
1. Turn the POWER switch on. The yellow light will
turn on.
2. Turn the thermostat to #6½.
3. Preheat cabinet for one (1) hour.
4. Put food into cabinet.
5. Turn thermostat to desired setting and close door.
No. 8 setting = approx. 85°C / 185°F
No.6 setting = approx. 71°C / 160°F
No.4 setting = approx. 54°C / 130°F
Proper food holding temperature is 60°C / 140°F or higher.
TO TURN OFF UNIT:
Turn the POWER switch off. The yellow light will go out.
NOTE: The optional digital thermometer display
ashes when temperature in center of cabi-
net is below 140°F (60°C) or above 250°F
(121°C). Call the factory if you need different
settings.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE
PERSONNEL ONLY
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
WARNING

OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137UA...C & H13818...C Series Hot Cabinets (Aluminum)
H137SUA...C & H138S18...C Series Hot Cabinets (Stainless)
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Hot Cabinet FL-2251
Rev. 11 (5/14) Page 3 of 5
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Cleaning hints:
1. Wipe up spills as soon as possible.
2. Clean cabinet regularly to avoid heavy dirt build-up.
3. Make a test spot with cleaner.
4. Follow manufacturer’s directions on cleaner.
5. Do not mix cleaners.
6. Avoid drips and splashes.
BEFORE CLEANING CABINET:
1. Allow the cabinet to cool.
2. Do NOT use abrasives or harsh chemicals.
Is your cabinet aluminum or stainless steel
construction? Be sure your cleaner is suitable
for that material.
Note: Stainless Steel cabinets have an “S” in their
model numbers.
HOW TO CLEAN THE UNIT:
Soil Cleaner Method
Dirt
Mild Detergent* and hot water, or
mild abrasive cleaner.
1. Wipe with soft, damp cloth.
2. Rinse with hot water.
3. Wipe Dry.
Steam (no strong alkaline additive) 1. Rinse after steam cleaning.
2. Wipe Dry
Fingerprints, grease, oil
Mild abrasive cleaner.
Oily or waxy cleaner. Apply with soft, clean cloth.
Chemical oven cleaner. Follow oven cleaner manufacturer’s
instructions
Water Spots Mild abrasive cleaner. 1. Apply with soft, clean cloth.
2. Wipe with damp cloth.
*Mild detergent includes soaps and non-abrasive cleaners.
Note: Gaskets are removable for cleaning.
TROUBLE-SHOOTING CHART:
FAILURE: POSSIBLE CAUSE:
1. Yellow light at switch does NOT light. 1a. Circuit breaker/fuse to wall outlet is blown
1b. Cord is unplugged from wall outlet.
1c. Switch is “OFF.”
2. Unit does not heat. 2a. Thermostat set too low or is “OFF.”
2b. Switch is “OFF.”
3. Unit gets too hot or won’t shut off. 3a. Defective electrical parts.
UNPLUG UNIT FROM WALL OUTLET
4. Blower does not work or makes noise. 4a. Defective blower
WARNING

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137UA...C & H13818...C Series Hot Cabinets (Aluminum)
H137SUA...C & H138S18...C Series Hot Cabinets (Stainless)
Insulated
Hot Cabinet FL-2251
Rev. 11 (5/14) Page 4 of 5
REPLACEMENT PARTS: H137UA…C/H1381834C and H137SUA…C/H138S1834C
120 V 208 V 240 V
Power Unit 2000W 0675-002 0675-005 0675-005
2000W + dig thrm 0675-002-D 0675-005-D 0675-005-D
Blower kit 0769-180-K 0769-182-K 0769-182-K
Heater kit 2000W 0811-268 0811-269 0811-270
1500W 0811-265 0811-266 0811-267
1400W 0811-275 None None
1000W 0811-074 None 0811-074-01
High Limit 0848-060 0848-060 0848-060
Terminal Block 0852-091 0852-091 0852-091
Thermometer Analog 5238-030-K 5238-030-K 5238-030-K
Digital 5238-034-K 5238-034-K 5238-034-K
Transformer (used w/digital thermometer) 0769-159 0769-159 0769-159
Thermostat Analog 0848-062-K 0848-062-K 0848-062-K
Power Cord 2000W 0810-065-12 0810-039-07 0810-039-07
1500W (USA) 0810-029-05 0810-039-07 0810-039-07
1500W (Canada) 0810-065-12 0810-039-07 0810-039-07
1000W 0810-029-06 0810-039-07 0810-039-07
Power Switch 0808-116 0808-116 0808-116
Power Light 0766-094 0766-095 0766-095
Vent Fan 0769-165 0769-174 0769-174
Door, complete Aluminum UA12/UA6/1834 1221-524-K
Aluminum UA9 1221-527-K
Stainless Steel UA12/UA6/1834 1221-525-K
Stainless Steel UA9 1221-526-K
Stainless Steel UA5/185 1221-545-K
Door, gasket Aluminum UA12/UA6/1834 0861-235-K
Aluminum UA9 0861-236-K
Stainless Steel UA12/UA6/1834 0861-185-K
Stainless Steel UA9 0861-182-K
Stainless Steel UA5/185 0861-250-K
Door, handle Aluminum 0911-111
Door, hinge Aluminum 0519-087-K
Stainless Steel 0519-074-K
Door, latch Stainless Steel 1006-122-01-K
3” Casters 0569-313-K
w/ Brake 0569-313-BK
5” Casters 0569-306-K
w/ Brake 0569-306-BK
H138 Rack Insert (1) 1103-103-K
Wire Angle Kit (set of 2) 0621-281-K

OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137UA...C & H13818...C Series Hot Cabinets (Aluminum)
H137SUA...C & H138S18...C Series Hot Cabinets (Stainless)
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Hot Cabinet FL-2251
Rev. 11 (5/14) Page 5 of 5
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
WIRING DIAGRAM
