Crestron 3 Series Dimensional drawing

DO GUIDE
DO Install the Device
The MC3 is designed to be placed onto a at surface.
DO Make Connections
Make the necessary connections as called out in the diagrams
below. Connect power last.
When making connections to the MC3, note the following:
• Use Crestron®power supplies for Crestron equipment.
• The included cable(s) cannot be extended.
NOTE: Ensure the unit is properly grounded by connecting the
chassis ground lug to an earth ground (building steel).
NOTE: The MC3 can be powered via the Cresnet®connection
or with the (included) 24-Vdc power pack.
DO Congure the Control System
The MC3 can be congured using Crestron Toolbox™ software
and the built-in, web-based setup tool.
1. Use Crestron Toolbox to set the time zone. For details,
refer to the Crestron Toolbox help le.
2. Use the Internet Explorer®web browser to navigate to
http://xxx.xx.xx.xxx/setup, where xxx.xx.xx.xxx is the
IP address of the control system. The control system’s
welcome screen is displayed.
NOTE: The web-based setup tool is accessible only from
Internet Explorer.
NOTE: If a security warning is displayed, click Install to
continue.
DO Check the Box
QTY PRODUCT COLOR PART NUM.
1Connector, 3-Pin Green 2003575
2Connector, 4-Pin Green 2003576
1 Antenna, 2.4 GHz, 1/4 Wave, Reverse Polarity, Female Black 2001016
1 Power Pack, 24 Vdc, 2.5 A, 100-240 Vac Black 2045873
1 Power Cord, 5' 10" (1.78 m) Black 2042043
1 Cable, USB 2.0, A-B, 6’ (1.83 m) Black 2014966
MC3
3-Series®Control System with Wireless Gateway
COM 1 - 2 Connections
PIN DESCRIPTION
2RXD - Receive Data
3TXD - Transmit Data
5 SG - Signal Ground
7 RTS - Request To Send
8 CTS - Clear To Send
• Use with a standard DB9 straight
through cable.
• Pins 1, 4, 6, and 9 are not used but may
be connected.
AUDIO IN (L R):
From Audio Source
AUDIO OUT (L R):
To OSD Device or
Associated Amplifier
VIDEO OUT
(COMPOSITE):
To OSD Device
IR 1–5:
To IR Controlled
Devices
IR IN:
From IR
Device
VIDEO OUT (Y Pb Pr):
To OSD Device
COM 1–2:
To RS-232 Device
LAN:
10/100 Base-T
Ethernet to LAN
NET (24 Y Z G):
To Cresnet Network
RELAY 1–2:
To Controllable
Devices Ground
24 Vdc:
From Power
Supply
USB 1–2:
To USB HID Device
or USB Mass
Storage Device
INPUT:
From Control
Devices

DO GUIDE DOC. 7774C (2043707) 04.16
Specications subject to change without notice.
3. Click Setup to display the MC3 Setup menu. The MC3 Setup menu displays the IP
address, hostname, and MAC address of the device. It also allows access to various setup
and programming screens.
4. From the MC3 Setup menu, click the following options to congure the control system:
• Ethernet Setup congures the MC3’s Ethernet settings and displays DHCP,
hostname, IP address, subnet mask, default router, domain, and MAC address
settings. In the Ethernet Setup menu, there are additional options:
• Click Advanced Settings to specify DNS servers, web server settings, and SSL
settings.
• Click MyCrestron Dynamic DNS to congure the myCrestron.com Dynamic
DNS service.
• Click Ethernet Diagnostics to test Ethernet communications.
• Click Reboot to reboot the MC3.
• Application Setup selects programs to be loaded on start-up and controls which
programs are running.
• Audo Setup congures the volume for the on-screen display.
• Input/Output Control congures the COM ports, operates the relays, and monitors
the Versiports.
• Video Setup congures the video resolution for the on-screen display.
• Diagnostics displays information about the connected devices, hardware
conguration, and error logs.
• About displays rmware information.
Click to return to the previous screen.
DO Learn More
Visit the website for additional information and the latest rmware updates. To learn
more about this product, use a QR reader application on your mobile device to scan
the QR image.
