Crestron CLT-1MC4 User manual

CLT- & CLX-1MC4
Functional Summary NOTE: Modules and terminal blocks must be
installed into the lowest available spaces and
continue toward the top of the enclosure.
The Crestron®1-Feed, 4-Motor Terminal Block and
Module (CLT-1MC4 and CLX-1MC4, respectively), are
considered a single entity and must be used together.
They ship separately to permit termination of the field
wiring to the CLT-1MC4 prior to installation of the CLX-
1MC4, as described in this guide. They can be mounted in
any Crestron Automation Enclosure (CAEN-Series
Enclosures). The terminal block is designed to terminate
the circuit feed (HOT and NEUTRAL) and distribute the
controlled circuits (LOAD) to the motors. The module
connects to the terminal block and performs control of
four bi-directional motors. The maximum load is 10 amps
(1/2 HP) for any controlled circuit, limited to 16 amps
total per module. The unit requires 120VAC 50/60 Hz, 1
phase input voltage. An oversize heat sink dissipates heat
efficiently. There are LEDs on the module to indicate
communication to a Cresnet®network, input power to the
module, and output power to the load.
Terminal Block & Module Locations (Single-wide Enclosure)
MODULETERMINAL
BLOCK
GROUNDING
TERMINAL
BLOCK
Industry Compliance
This product is Listed to applicable UL Standards and
requirements by Underwriters Laboratories Inc.
(E103692)
Terminal Block & Module Locations (Double-wide Enclosure)
Installation
GROUNDING TERMINAL BLOCKS
MODULETERMINAL BLOCK
(LEFT)
TERMINAL BLOCK
(RIGHT)
Terminal block and module must be mounted into a
Crestron Automation Enclosure by a licensed electrician,
in accordance with all national and local codes.
CAUTION: This equipment is for indoor use only and
needs to be air-cooled. Mount in a well-ventilated area.
The ambient temperature must be 32°F to 104°F (0°C to
40°C). The relative humidity must be 0% to 90% (non-
condensing).
Terminal blocks are installed along the left side of single-
wide enclosures and along the outside edges (left and
right sides) of double-wide enclosures. Modules are
installed along the right side of single-wide enclosures
and side-by-side in the center of double-wide enclosures.
When installing modules and terminal blocks in a double-
wide enclosure, be sure to invert units on the right side so
that they can be properly wired. Refer to the illustrations
shown in the next column when considering the location
of terminal blocks and modules within an enclosure.
Crestron Electronics, Inc. Installation Guide – DOC. 5991B
15 Volvo Drive Rockleigh, NJ 07647 (2002073)
Tel: 888.CRESTRON 01.06
Fax: [phone] Specifications subject to
www.crestron.com change without notice.

Terminal Block & Module Crestron CLT- & CLX-1MC4
Wiring Diagram of the Terminal Block to the Feed and
Load(s)(Single-wide and Left Side Double-wide Enclosures)
NOTE: Unless otherwise indicated, the lighting
system specified in this guide is modular, requiring
assembly in the field by a licensed electrician, in
accordance with all national and local codes.
GROUNDING
TERMINAL
BLOCK
GND
NEUTRAL
AREA FOR
MODULE
LOCATION
LABEL
JUMPER
HOT
(FROM 15
OR 20 AMP
CIRCUIT
BREAKER)
TERMINAL
BLOCK
LEFT SIDE
WIRING LABEL
TO
MOTOR 1
TO
MOTOR 2
TO
MOTOR 3
TO
MOTOR 4
If you require a UL Listed panel, Crestron offers this
service through its UL Listed panel shop. This
includes complete in factory system configuration
and assembly by Crestron for an additional fee.
Terminal Block Installation and Field
Wiring
1. Use the two supplied self-tapping pan Phillips
screws (8B x ¼" length) to secure the terminal
block and the appropriate (left or right) wiring
label to the Crestron Automation Enclosure. The
wiring label lies beneath the terminal block as
shown in the two wiring diagrams on this page.
NOTE: Both left and right wiring labels are
provided. The left-side labels are common for both
single and double-wide enclosures. The right-side
labels are only used in double-wide enclosures since
the modules and terminal blocks along the right side
must be inverted when mounting.
CAUTION: The jumper on the white section of the
terminal block ties all neutrals together. Do not
remove the jumper. Wiring Diagram of the Terminal Block to the Feed and
Load(s) (Right Side Double-wide Enclosures)
NOTE: Use copper conductors only – rated 75°C
NEUTRAL
AREA FOR
MODULE
LOCATION
LABEL
JUMPER
TERMINAL
BLOCK
RIGHT SIDE
WIRING LABEL
TO
MOTOR 4
TO
MOTOR 3
TO
MOTOR 2
TO
MOTOR 1
HOT
(FROM 15
OR 20 AMP
CIRCUIT
BREAKER)
GROUNDING
TERMINAL
BLOCK
GND
2. With the circuit breaker turned off, connect the
circuit feed (HOT and NEUTRAL) and
controlled circuit (LOAD) wires to the terminal
block per the markings provided on the wiring
label (as shown in the diagrams on this page).
Terminal blocks accept one 14 - 10 AWG wire.
Wires should be stripped to ½ inch. Tighten
terminal blocks to 9 in-lbs.
3. Grounding terminal blocks are available in the
cabinet for termination of ground wires. Tighten
to 35 in-lbs. (14 – 10 AWG), 40 in-lbs.
(8 AWG), or 45 in-lbs. (6 – 4 AWG).
4. Test the circuit for electrical faults by connecting
LINE to OPEN 1. Switch on the circuit breaker
and check that it does not trip and that the load
connected to OPEN 1 is receiving power.
Switch off the circuit breaker, remove the
connection between LINE and OPEN 1, and
repeat this step for CLOSE 1 and then
sequentially for each OPEN and CLOSE motor
connection.
2 •Terminal Block & Module: CLT- & CLX-1MC4 Installation Guide – DOC. 5991B

Crestron CLT- & CLX-1MC4 Terminal Block & Module
Module Installation Wiring Diagram of the Terminal Block to the Module
(Single-wide and Left Side Double-wide Enclosures)
JUMPER
RED
BLACK
BLUE
RED
BLUE
RED
BLUE
RED
BLUE
WHITE
ATTACH MODULE INTERCONNECT
CABLE (DESCRIBED IN STEP 3)
ENLARGEMENT DETAIL:
JUMPER ON WHITE
SECTION REMAINS
INSTALLED.
CAUTION: Module contains electrostatic sensitive
devices (ESDs); unit must be handled from metal
chassis – do not touch PC board or components.
NOTE: Modules are to be installed after enclosure
has been completely wired. Refer to the terminal
block installation procedure on page 2 for details.
1. Use the four supplied self-tapping pan Phillips
screws (8B x ¼” length) to secure the module to
the enclosure.
2. As shown in the wiring diagrams (next column),
connect the wires from the module to the
terminal block. Each wire exits the module
directly in line with, and is the same color as, the
terminal to which it should be connected. Wires
are pre-stripped to ½ inch. Tighten to 9 in-lbs.
3. If the module is being installed above another
module within the enclosure, attach the supplied
module interconnect cable between the two
modules. The illustration below depicts the area
within a double-wide enclosure where the
corners of four modules meet.
NOTE: One wire on the module interconnect cable
may be a different color from the rest. The color has
no bearing on its orientation during installation. Wiring Diagram of the Terminal Block to the Module
(Right Side Double-wide Enclosures)
Use Module Interconnect Cable to Wire Module to Module
JUMPER
RED
BLACK
WHITE
BLUE
RED
BLUE
RED
BLUE
RED
BLUE
ATTACH MODULE INTERCONNECT
CABLE (DESCRIBED IN STEP 3)
ENLARGEMENT DETAIL:
JUMPER ON WHITE
SECTION REMAINS
INSTALLED.
MODULE
INTERCONNECT
CABLE ATTACHED
CONNECTION
NOT
MADE
4. Turn on the circuit breaker and verify that the
green PWR LED on the module lights and the
breaker does not trip.
Installation Guide – DOC. 5991B Terminal Block & Module: CLT- & CLX-1MC4 •3

Terminal Block & Module Crestron CLT- & CLX-1MC4
4 •Terminal Block & Module: CLT- & CLX-1MC4 Installation Guide – DOC. 5991B
Further Inquiries
If you cannot locate specific information or have
questions after reviewing this guide, please take
advantage of Crestron's award winning customer service
team by calling the Crestron corporate headquarters at
1-888-CRESTRON [1-888-273-7876]. For assistance in
your local time zone, refer to the Crestron website
(www.crestron.com) for a listing of Crestron worldwide
offices.
You can also log onto the online help section of the
Crestron website to ask questions about Crestron
products. First-time users will need to establish a user
account to fully benefit from all available features.
Return and Warranty Policies
Merchandise Returns / Repair Service
1. No merchandise may be returned for credit, exchange, or
service without prior authorization from CRESTRON. To
obtain warranty service for CRESTRON products, contact
the factory and request an RMA (Return Merchandise
Authorization) number. Enclose a note specifying the nature
of the problem, name and phone number of contact person,
RMA number, and return address.
2. Products may be returned for credit, exchange, or service
with a CRESTRON Return Merchandise Authorization
(RMA) number. Authorized returns must be shipped freight
prepaid to CRESTRON, 6 Volvo Drive, Rockleigh, N.J., or
its authorized subsidiaries, with RMA number clearly marked
on the outside of all cartons. Shipments arriving freight
collect or without an RMA number shall be subject to refusal.
CRESTRON reserves the right in its sole and absolute
discretion to charge a 15% restocking fee, plus shipping
costs, on any products returned with an RMA.
3. Return freight charges following repair of items under
warranty shall be paid by CRESTRON, shipping by standard
ground carrier. In the event repairs are found to be non-
warranty, return freight costs shall be paid by the purchaser.
CRESTRON Limited Warranty
CRESTRON ELECTRONICS, Inc. warrants its products to be free from
manufacturing defects in materials and workmanship under normal use
for a period of three (3) years from the date of purchase from
CRESTRON, with the following exceptions: disk drives and any other
moving or rotating mechanical parts, pan/tilt heads and power supplies
are covered for a period of one (1) year; touchscreen display and overlay
components are covered for 90 days; batteries and incandescent lamps
are not covered.
This warranty extends to products purchased directly from CRESTRON
or an authorized CRESTRON dealer. Purchasers should inquire of the
dealer regarding the nature and extent of the dealer's warranty, if any.
CRESTRON shall not be liable to honor the terms of this warranty if the
product has been used in any application other than that for which it was
intended, or if it has been subjected to misuse, accidental damage,
modification, or improper installation procedures. Furthermore, this
warranty does not cover any product that has had the serial number
altered, defaced, or removed.
This warranty shall be the sole and exclusive remedy to the original
purchaser. In no event shall CRESTRON be liable for incidental or
consequential damages of any kind (property or economic damages
inclusive) arising from the sale or use of this equipment. CRESTRON is
not liable for any claim made by a third party or made by the purchaser
for a third party.
CRESTRON shall, at its option, repair or replace any product found
defective, without charge for parts or labor. Repaired or replaced
equipment and parts supplied under this warranty shall be covered only
by the unexpired portion of the warranty.
Except as expressly set forth in this warranty, CRESTRON makes no
other warranties, expressed or implied, nor authorizes any other party to
offer any warranty, including any implied warranties of merchantability
or fitness for a particular purpose. Any implied warranties that may be
imposed by law are limited to the terms of this limited warranty. This
warranty statement supercedes all previous warranties.
Trademark Information
All brand names, product names, and trademarks are the sole property of their respective
owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP
and WindowsNT/2000 are trademarks of Microsoft Corporation.
