Crestron CLT-2DIM8 User manual

CLT- & CLX-2DIM8
Functional Summary
The Crestron®2-Feed, 8-Dimmer Terminal Block and
Module (CLT-2DIM8 and CLX-2DIM8, respectively),
are considered a single entity and must be used together.
They ship separately to permit termination of the field
wiring to the CLT-2DIM8 prior to installation of the
CLX-2DIM8, as described in this guide. They can be
mounted in any Crestron Automation Enclosure (CAEN-
Series Enclosures). The terminal block is designed to
terminate two circuit feeds (HOT and NEUTRAL) and
distribute the controlled circuits (LOAD) to the fixtures.
The module connects to the terminal block and performs
dimming control of eight incandescent, magnetic low
voltage, neon, cold cathode, or dimmable 2-wire
fluorescent lighting loads. The maximum load is 16 amps
for any controlled circuit, limited to 16 amps total for
circuits 1 through 4 and 16 amps total for circuits 5
through 8. The unit requires 120VAC 50/60 Hz, 1 phase
input voltage. An oversize heat sink dissipates heat
efficiently. There are LEDs on the module to indicate
communication to a Cresnet®network, input power to the
module, and output power to the load.
NOTE: The two input lines must be the same phase or
split phase.
NOTE: When connecting to an Arc Fault Breaker, the
load should not exceed 1000 watts per breaker.
Industry Compliance
This product is Listed to applicable UL Standards and
requirements by Underwriters Laboratories Inc.
(E103692)
Installation
The terminal block and module must be mounted into a
Crestron Automation Enclosure by a licensed electrician,
in accordance with all national and local codes.
CAUTION: This equipment is for indoor use only
and needs to be air-cooled. Mount in a well-
ventilated area. The ambient temperature must be
32°F to 104°F (0°C to 40°C). The relative humidity
must be 0% to 90% (non-condensing).
Terminal blocks are installed along the left side of single-
wide enclosures and along the outside edges (left and
right sides) of double-wide enclosures. Modules are
installed along the right side of single-wide enclosures
and side-by-side in the center of double-wide enclosures.
When installing modules and terminal blocks in a double-
wide enclosure, be sure to invert units on the right side so
that they can be properly wired. Refer to the illustrations
shown in the next column when considering the location
of terminal blocks and modules within an enclosure.
NOTE: Modules and terminal blocks must be
installed into the lowest available spaces and
continue toward the top of the enclosure.
Terminal Block & Module Locations (Single-wide Enclosure)
TERMINAL
BLOCK
GROUNDING
TERMINAL
BLOCK
MODULE
Terminal Block & Module Locations (Double-wide Enclosure)
Crestron Electronics, Inc. Installation Guide – DOC. 6280A
15 Volvo Drive Rockleigh, NJ 07647 (2010978)
Tel: 888.CRESTRON 01.06
Fax: [phone] Specifications subject to
www.crestron.com change without notice.
TERMINAL BLOCK
(RIGHT)
GROUNDING TERMINAL BLOCKS
TERMINAL BLOCK
(LEFT)
MODULE

Terminal Block & Module Crestron CLT- & CLX-2DIM8
4. Test the circuit for electrical faults by turning on
the circuit breaker and checking that the breaker
does not trip and that power is delivered to the
loads.
NOTE: Unless otherwise indicated, the lighting
system specified in this guide is modular, requiring
assembly in the field by a licensed electrician, in
accordance with all national and local codes.
Wiring Diagram of the Terminal Block to the Feed and
Load(s)(Single-wide and Left Side Double-wide Enclosures)
If you require a UL Listed panel, Crestron offers this
service through its UL Listed panel shop. This
includes complete in factory system configuration
and assembly by Crestron for an additional fee.
FROM 15 OR 20 AMP
CIRCUIT BREAKER
HOT 1
NEUTRAL
GROUNDING
TERMINAL
BLOCK
GND
TERMINAL
BL
OC
K
LEFT SIDE
WIRIN
G
LABEL
TO
LOAD(S)
AREA FOR
MODULE
LOCATION
LABEL
NEUTRAL
HOT 2
FROM 15 OR 20 AMP
CIRCUIT BREAKER
BYPASS
JUMPERS
Terminal Block Installation and Field
Wiring
1. Use the two supplied self-tapping pan Phillips
screws (8B x ¼” length) to secure the terminal
block and the appropriate (left or right) wiring
label to the Crestron Automation Enclosure. The
wiring label lies beneath the terminal block as
shown in the two wiring diagrams on this page.
NOTE: Both left and right wiring labels are
provided. The left-side labels are common for both
single and double-wide enclosures. The right-side
labels are only used in double-wide enclosures since
the modules and terminal blocks along the right side
must be inverted when mounting.
CAUTION: Bypass jumpers are installed on the
terminal blocks to allow testing of circuits and to
protect the module during installation. When properly
secured by five screws, the bypass jumpers on the
black and red sections of the terminal block short the
hot to dim so that all circuits receive power. Do not
remove these bypass jumpers until all feed and load
wiring has been completed, the circuit has been tested
for electrical faults, and the module has been
installed. Refer to “Module Installation” on next
page. Jumpers are also installed on the white sections
of the terminal block and tie all neutrals together.
These jumpers should never be removed.
Wiring Diagram of the Terminal Block to the Feed and
Load(s) (Right Side Double-wide Enclosures)
BYPASS
JUMPERS HOT 1
FROM 15 OR 20 AMP
CIRCUIT BREAKER
NEUTRAL
TO
LOAD(S)
TERMINAL
BLOCK
RIGHT SIDE
WIRING LABEL
AREA FOR
MODULE
LOCATION
LABEL
FROM 15 OR 20 AMP
CIRCUIT BREAKER
HOT 2
NEUTRAL
GND
GROUNDING
TERMINAL
BLOCK
NOTE: Use copper conductors only – rated 75°C
2. With the circuit breaker turned off, connect the
circuit feeds (HOT and NEUTRAL) and
controlled circuit (LOAD) wires to the terminal
block per the markings provided on the wiring
label (as shown in the diagrams on this page).
Terminal blocks accept one 14 - 10 AWG wire.
Wires should be stripped to ½ inch. Tighten
terminal blocks to 9 in-lbs.
3. Grounding terminal blocks are available in the
cabinet for termination of ground wires. Tighten
to 35 in-lbs. (14 – 10 AWG), 40 in-lbs.
(8 AWG), or 45 in-lbs. (6 – 4 AWG).
2 •Terminal Block & Module: CLT- & CLX-2DIM8 Installation Guide – DOC. 6280A

Crestron CLT- & CLX-2DIM8 Terminal Block & Module
Module Installation
CAUTION: Module contains electrostatic sensitive
devices (ESDs); unit must be handled from metal
chassis – do not touch PC board or components.
NOTE: Modules are to be installed after enclosure
has been completely wired. Refer to the terminal
block installation procedure on page 2 for details.
1. Use the four supplied self-tapping pan Phillips
screws (8B x ¼ length) to secure the module to
the enclosure.
2. As shown in the wiring diagrams (next column),
connect the wires from the module to the
terminal block. Each wire exits the module
directly in line with, and is the same color as, the
terminal to which it should be connected. Wires
are pre-stripped to ½ inch. Tighten to 9 in-lbs.
3. If the module is being installed above another
module within the enclosure, attach the supplied
module interconnect cable between the two
modules. The illustration below depicts the area
within a double-wide enclosure where the
corners of four modules meet.
NOTE: One wire on the module interconnect cable
may be a different color from the rest. The color has
no bearing on its orientation during installation.
Use Module Interconnect Cable to Wire Module to Module
MODULE
INTERCONNECT
CABLE ATTACHE
D
CONNECTION
NOT
MADE
4. Turn on the circuit breaker and verify that the
green PWR LED on the module lights, the
breaker does not trip, and power is delivered to
the loads.
5. Turn off the circuit breaker and remove the
bypass jumpers on the black and red sections of
the terminal block. The jumpers on the white
sections of the terminal block must remain
installed. Refer to the figures in the next column
for a close-up of the jumpers.
NOTE: Before the bypass jumpers, shown in the
illustration, are removed, the Crestron Professional
Automation Computer (PAC2), which provides
control to the system, should be properly connected
and contain a valid program to provide control of the
module.
Wiring Diagram of the Terminal Block to the Module
(Single-wide and Left Side Double-wide Enclosures)
ENLARGEMENT DETAIL:
LOCATION OF BYPASS JUMPERS
ON TERMINAL BLOCK AS
DESCRIBED IN STEP 5.
JUMPERS ON RED AND BLACK
AFTER LOOSENING ALL SCREWS.
JUMPERS ON WHITE SECTIONS
REMAIN IN
S
TALLED.
INTERCONNECT CABLE
AS DESCRIBED IN STEP 3
ATTACH MODULE
JUMPER
INSTALLED
JUMPER
REMOVED
WHITE
TO LOADS
BLACK FROM BREAKER
RED
TO LOADS
RED
TO LOADS
BLACK FROM BREAKER
WHITE FROM BREAKER PANEL
WHITE
TO LOADS
WHITE FROM BREAKER PANEL
Wiring Diagram of the Terminal Block to the Module
(Right Side Double-wide Enclosures)
WHITE
TO LOADS
RED
TO LOADS
BLACK FROM BREAKER
RED
TO LOADS
WHITE FRO M BREAKER PANEL
WHITE
TO LOADS
BLACK FROM BREAKER
WHITE FRO M BREAKER PANEL
AS DESCRIBED IN STEP 3
INTERCONNECT CABLE
ATTACH MODULE
JUMPER
REMOVED
JUMPER
INSTALLED
ENLARGEMENT DETAIL:
LOCATION OF BYPASS JUMPERS
ON TERMINAL BLOCK AS
DESCRIBED IN STEP 5.
JUMPERS ON RED AND BLACK
SECTIONS HAVE BEEN REMOVED
AFTER LOOSENING ALL SCREWS.
JUMPERS ON WHITE SECTIONS
REMAIN INSTALLED.
6. Turn on the circuit breakers.
Installation Guide – DOC. 6280A Terminal Block & Module: CLT- & CLX-2DIM8 •3

Terminal Block & Module Crestron CLT- & CLX-2DIM8
4 •Terminal Block & Module: CLT- & CLX-2DIM8 Installation Guide – DOC. 6280A
NOTE: Power must be supplied to LINE 1 for
the module to communicate with the control
system or for any of the circuits to operate.
7. If the program is not running yet, loads can be
tested by using Local Mode.
Use Local Mode to verify that each load is connected to
the proper output on the modules.
1. Press the SETUP button momentarily (less than
three seconds) to enter Local Mode.
The SETUP LED and output LED 1illuminate
and power is applied to the devices connected to
output 1.
2. Press the SETUP button again to turn off output
1and turn on output 2.
3. Press the SETUP button again for each output.
4. After turning on the last output, press the
SETUP button again to turn on all outputs.
5. Press the SETUP button once more to turn off
all outputs and LEDs and exit Local Mode.
Further Inquiries
If you cannot locate specific information or have
questions after reviewing this guide, please take
advantage of Crestron's award winning customer service
team by calling the Crestron corporate headquarters at
1-888-CRESTRON [1-888-273-7876]. For assistance in
your local time zone, refer to the Crestron website
(www.crestron.com) for a listing of Crestron worldwide
offices.
You can also log onto the online help section of the
Crestron website to ask questions about Crestron
products. First-time users will need to establish a user
account to fully benefit from all available features.
Return and Warranty Policies
Merchandise Returns / Repair Service
1. No merchandise may be returned for credit, exchange, or
service without prior authorization from CRESTRON. To
obtain warranty service for CRESTRON products, contact
the factory and request an RMA (Return Merchandise
Authorization) number. Enclose a note specifying the nature
of the problem, name and phone number of contact person,
RMA number, and return address.
2. Products may be returned for credit, exchange, or service
with a CRESTRON Return Merchandise Authorization
(RMA) number. Authorized returns must be shipped freight
prepaid to CRESTRON, 6 Volvo Drive, Rockleigh, N.J., or
its authorized subsidiaries, with RMA number clearly marked
on the outside of all cartons. Shipments arriving freight
collect or without an RMA number shall be subject to refusal.
CRESTRON reserves the right in its sole and absolute
discretion to charge a 15% restocking fee, plus shipping
costs, on any products returned with an RMA.
3. Return freight charges following repair of items under
warranty shall be paid by CRESTRON, shipping by standard
ground carrier. In the event repairs are found to be non-
warranty, return freight costs shall be paid by the purchaser.
CRESTRON Limited Warranty
CRESTRON ELECTRONICS, Inc. warrants its products to be free from
manufacturing defects in materials and workmanship under normal use
for a period of three (3) years from the date of purchase from
CRESTRON, with the following exceptions: disk drives and any other
moving or rotating mechanical parts, pan/tilt heads and power supplies
are covered for a period of one (1) year; touchscreen display and overlay
components are covered for 90 days; batteries and incandescent lamps
are not covered.
This warranty extends to products purchased directly from CRESTRON
or an authorized CRESTRON dealer. Purchasers should inquire of the
dealer regarding the nature and extent of the dealer's warranty, if any.
CRESTRON shall not be liable to honor the terms of this warranty if the
product has been used in any application other than that for which it was
intended, or if it has been subjected to misuse, accidental damage,
modification, or improper installation procedures. Furthermore, this
warranty does not cover any product that has had the serial number
altered, defaced, or removed.
This warranty shall be the sole and exclusive remedy to the original
purchaser. In no event shall CRESTRON be liable for incidental or
consequential damages of any kind (property or economic damages
inclusive) arising from the sale or use of this equipment. CRESTRON is
not liable for any claim made by a third party or made by the purchaser
for a third party.
CRESTRON shall, at its option, repair or replace any product found
defective, without charge for parts or labor. Repaired or replaced
equipment and parts supplied under this warranty shall be covered only
by the unexpired portion of the warranty.
Except as expressly set forth in this warranty, CRESTRON makes no
other warranties, expressed or implied, nor authorizes any other party to
offer any warranty, including any implied warranties of merchantability
or fitness for a particular purpose. Any implied warranties that may be
imposed by law are limited to the terms of this limited warranty. This
warranty statement supercedes all previous warranties.
Trademark Information
All brand names, product names, and trademarks are the sole property of their respective
owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP
and WindowsNT/2000 are trademarks of Microsoft Corporation.
