CrimeStopper SecurView SV-6910 User manual

SV-6910 ColorCamera
InstallationManual
FEATURES:
lHighResolution Color Camera
lCompactZincAlloy DieCastBody
lWaterproofHousing
lAdjustableMountingAngle
lWideAngleLens
lInfraredLEDfor NightVision
lReverseImage Selectable

1
Figure 1
CameraInstallation1(Viewingangleisadjustable)

2
Figure 2
Installation1:
1. Locateasuitablemounting locationatrearofvehicle.
2. Usethesuppliedbrackettomarkthemountingholelocations.
3. Drill two3/16”holesformountinghardwareyouareusing.Drill a11/16”holein
thecablelocation.Routethecableintothevehicleand theninserttheGrommetto
preventwaterfrompouringin.
4. Attachthecamera-mountingbrackettothevehiclewiththelensshroud ontopside.
If lensshroud isonthebottom,thenthecameramustberemovedfromthebracket
andturned180degreesandthenreattachedtothebracket.
5. Routethecameracabletowardsdisplaymonitor.
6. Connectthecameracabletomonitor.
7. Selectcameraimagenormalormirrorimagebyreverseimagejumper. (Figure1)
CameraInstallation2(Viewingangledoesnotadjust)

3
Figure 3
Installation2:
1. Locateasuitablemounting locationatrearofvehicle.
2. Usethecamerabackplatetomarkthemountingholelocations.
3. Drill two3/16”holesformounting hardwareyou areusing.
4. Usescrewstoattachthecamerabackboardtothevehiclewiththelensshroudon
topside.
5. Routethecameracabletowardsdisplaymonitor.
6. Connectthecameracabletomonitor.
7. Selectcameraimagenormalormirrorimagebyreverseimagejumper. (Figure1)
Specification
1. Signal System:NTSC
* 2. Image Display: Mirror Imageor Normal ImageOptional
3. Voltage:DC 12V
4. Current: 100mA
5. ImageSensor: CMOS
6. HorizontalDefinition: 420Lines
7. Viewing Angle: 130 degrees
8. MinimumIllumination:0.3LUX
9. Outer Dimensions:2.52” (W) x 2.15”(H) x 1.73” (D)
10.Weight: 7OZ
*Note:The cameracanreversetheimagebyremoving the reverse
image jumper at theendofcameracable.
WARNING
TheSV-6910Back upcamerasystemisstrictlyadriverassistantdevice.It
shouldnotbeconsideredasafetydeviceforanypurposes.The
Manufacturerand distributorsoftheproductdo notguarantee orassume
liabilityforcollisionordamagesthattakeplacewhenbacking upyour
vehicle.
