Croydex Norton WC010322 Manual

1
Norton Column Storage Unit
storage
This installation guide applies to the following vanity unit:
WC010322 - Norton Column Storage Unit
Tools required - not supplied
Pencil;Tape Measure; Philips Screwdriver; Mallet; Drill; 8mm Drill Bit (Ceramic drill bit optional).
KEEP DIY TOOLS OUT OF THE REACH OF CHILDREN
Home Safety Advice
.
- Always take care when using power tools, particularly in the bathroom.
- Always check for hidden cables and pipework before drilling and take extreme care if there is any
water in the working area.
- It is advisable to use a residual current circuit breaker (RCCB).
- Always wear suitable eye protection when drilling.
- Always ensure that the drill hole passes through the central tiled area rather than through the grouted
area. To prevent damage to the tile, mask the area around the hole with tape before drilling.
- Do not strike the product with hard or sharp objects.
Product Care
Do not use abrasive or chemical cleaners as these will damage the product.
Product Location
The addition of backboards on the outside of the wall or appropriate strengthening of internal structures may be
required to provide adequate wall strength.
NOTE: If the wall is made of lightweight thermal blocks, aerated hollow brickwork or prefabricated partitions
the storage unit.
CAB 094 R01
Vanity Unit Components
B. Centre Panels (P002) x 4A. Side Panels (P001) x 2
C. Wall Plugs (H007) x 2
E. Vanity Unit Feet
(H006) x 4
D. Wall Screws (H008) x 2
F. Vanity Unit Feet Screws
x 16
A. Mounting Plate Screws
(H004) x 8
B. Mounting Plates
(H005) x 2
Vanity Unit Fixing Components

Installation
Step 1
Installation
Step 2
CAB 094 R01
2
Click!
B. Centre Panels (P002) x 4
A. Side Panels (P001) x 1
B. Centre Panels (P002) x 4
A. Side Panels (P001) x 1

Installation
Step 3
Installation
Step 4
CAB 094 R01
3
Click!
A. Side Panels (P001) x 1
A. Side Panels (P001) x 1

Installation
Step 5
CAB 094 R01
4
Vertical Wall Mounted Installation
Horizontal Wall Mounted Installation
A. Mounting Plate Screws
(H004) x 8
B. Mounting Plates
(H005) x 2
A. Mounting Plate Screws
(H004) x 8
B. Mounting Plates
(H005) x 2

Installation
Step 6
CAB 094 R01
5
Vertical Wall Mounted Installation
b
c+d
d
b
c+d
d
b
c
b
c
Horizontal Wall Mounted Installation

Installation
Step 7
CAB 094 R01
6
For details of the other items in the Croydex range please visit our website: www.croydex.com
Croydex Ltd, Central Way, Andover, Hants, SP10 5AW, UK
Tel: [phone]
Fax: [phone]
Email: [email protected]
Ø8
C. Wall Plugs (H007) x 2
D. Wall Screws (H008) x 2
Installation
Step 8
F. Vanity Unit Feet Screws
x 16
E. Vanity Unit Feet
(H006) x 4
Floor Standing Option
30 mm
8 mm
