Chinnock Vanity Units
your
This installation guide applies to the following vanity unit:
WS010522 - Chinnock Vanity Unit (46cm)
WS010722 - Chinnock Vanity Unit (36cm)
WS010731 - Chinnock Vanity Unit (36cm)
Tools required - not supplied
Pencil;Tape Measure; Philips Screwdriver; Flat Head Screwdriver; Mallet; Drill; 8mm Drill Bit
(Ceramic drill bit optional).
KEEP DIY TOOLS OUT OF THE REACH OF CHILDREN
Home Safety Advice
.
- Always take care when using power tools, particularly in the bathroom.
- Always check for hidden cables and pipework before drilling and take extreme care if there is any
water in the working area.
- It is advisable to use a residual current circuit breaker (RCCB).
- Always wear suitable eye protection when drilling.
- Always ensure that the drill hole passes through the central tiled area rather than through the grouted
area. To prevent damage to the tile, mask the area around the hole with tape before drilling.
- Do not strike the product with hard or sharp objects.
Product Care
Do not use abrasive or chemical cleaners as these will damage the product.
Product Location
of the wall.
The addition of backboards on the outside of the wall or appropriate strengthening of internal structures
may be required to provide adequate wall strength.
NOTE: If the wall is made of lightweight thermal blocks, aerated hollow brickwork or prefabricated
suddenly applied to the vanity unit.
CAB 095 R03

2CAB 095 R03
Vanity Unit Components
Vanity Unit Fixing Components
B. Support Leg Screws
(H002) x 8
A. Glue Pack
(H001) x 1 C. Draw Handle Screws
(H003) x 4
D. Countersink Screw
(H004) x 12
E. Runner Screws
(H005) x 4
A. Vanity Unit Base
(P001) x 1
E. Front Panel
(P005) x 1
I. Draw Front
(P009) x 2
M. Concealed Runner
(P013) x 1
N. Concealed Runner
(P014) x 1
B. Vanity Unit Side Panel
(P002) x 1
F. Rear Top Panel with
Hanging Baton
(P006) x 1
J. Top Drawer Panel
(P010) x 1
O. Draw Handle
(P015) x 2
C. Vanity Unit Side Panel
(P003) x 1
G. Lower Draw Panel
(P007) x 1
K. Draw Side Panel
(P011) x 4
P. Support Leg
(P016) x 2
D. Rear Panel
(P004) x 1
H. Lower Draw Base
(P008) x 1
L. Top Draw Base
(P012) x 1
Q. Support Brace
(P017) x 2
G. Wall Plugs
(H007) x 2
F. Fixing Screws
(H006) x 2
H. Support Brace Screws
(H008) x 4
Hang’N’Lock Bracket
(See Step 19)
(Image for reference only)

CAB 095 R03
3
Installation
Step 2
Installation
Step 1
Click!
A. Vanity Unit Base
(P001) x 1
B. Vanity Unit Side Panel
(P002) x 1
B. Vanity Unit Side Panel
(P002) x 1
C. Vanity Unit Side Panel
(P003) x 1
M. Concealed Runner
(P013) x 2
N. Concealed Runner
(P014) x 2
D. Countersink Screw
(H004) x 4
D. Countersink Screw
(H004) x 4

CAB 095 R03
4
Installation
Step 3
Click!
C. Vanity Unit Side Panel
(P003) x 1

Installation
Step 4
Installation
Step 5
CAB 095 R03
5
Click!
Click!
E. Front Panel
(P005) x 2
F. Rear Top Panel with
Hanging Baton
(P006) x 1
D. Rear Panel
(P004) x 1
D. Rear Panel
(P004) x 1
E. Front Panel
(P005) x 1
F. Rear Top Panel with
Hanging Baton
(P006) x 1
D. Rear Panel
(P004) x 1
E. Front Panel (P005) x 2
F. Rear Top Panel with Hanging
Baton (P006) x 1
AB

Installation
Step 6
Installation
Step 7
Installation
Step 8
CAB 095 R03
6
Click!
Click!
G. Lower Draw Panel
(P007) x 1
K. Draw Side Panel
(P011) x 2
H. Lower Draw Base
(P008) x 1
I. Draw Front
(P009) x 1
LOW
DRAWER
HIGH
DRAWER

Installation
Step 9
Installation
Step 10
CAB 095 R03
7
Click!
C. Draw Handle Screws
(H003) x 2
N. Draw Handle
(P015) x 1
J. Top Drawer Panel
(P010) x 1
K. Draw Side Panel
(P011) x 2
A B
C

Installation
Step 11
Installation
Step 12
Installation
Step 13
CAB 095 R03
8
Click!
A. Glue Pack
(H001) x 1
L. Top Draw Base
(P012) x 1
M. Draw Front
(P013) x 1
A
B

Installation
Step 14
Installation
Step 15
Installation
Step 16
CAB 095 R03
9
C. Draw Handle Screws
(H003) x 2
N. Draw Handle
(P015) x 1
D. Countersink Screw
(H004) x 4
H. Support Brace Screws
(H004) x 4
P. Support Brace
(P017) x 2

Installation
Step 17
Installation
Step 18
CAB 095 R03
10
Stand Vanity Unit Upright!
Installation
Step 19
A. Hang ‘N’ Lock Bracket x 1
D. Hang ‘N’ Lock Cam x 2
G. Wall Plugs x 2
B. Hang ‘N’ Lock Bracket x 1 C. Hang ‘N’ Lock Spacer x 2
E. Countersink Fixing Screws
x 2 (Optional)
F. Fixing Screws x 2 (Optional)
Only 2 x screws are required to install the Hang ‘N’ Lock
bracket. Please use either the countersink or dome head
B. Support Leg Screws
(H002) x 8
P. Support Leg
(P016) x 2
Assemble the Hang ‘N’ Lock bracket
sections making sure all parts are slotted
tightly together.
Image for reference only.

CAB 095 R03
11
Installation
Step 20
Installation
Step 21
Installation
Step 22
Installation
Step 23
Drill the marked holes to a depth of 45mm.
Insert the wall plugs and loosely screw the
Hang ‘N’ Lock into position through the
Hang ‘N’ Lock cams.
Determine the desired location for the vanity unit.
Place the Hang ‘N’ Lock bracket underneath the panel at the
rear of the vanity unit.
With a pencil mark through the screw hole positions in each
cam recess and draw a reference line under the Hang ‘N’ Lock
bracket.
Remove the vanity unit and the Hang ‘N’ Lock bracket from the
wall surface prior to drilling.
With the Hang ‘N’ Lock bracket loosely
attached to the wall, adjust for height and
screwdriver and align the bottom of the
Hang ‘N’ Lock bracket with the reference
line. Once level fully tighten using a philips
screwdriver.
Hang the vanity unit onto the Hang ‘N’ Lock bracket, checking
the unit is level and the support feet sit accurately in position.
Using a pencil mark through the support braces and remove the
vanity unit.
IMPORTANT!
The support braces provide additional reinforcement to support
the weight of the vanity unit and basin. Reinforcement screws
must be secured through the support braces to provide
additional strength.
Ø8

Installation
Step 24
CAB 095 R03
12
Installation
Step 25
+
_3
Ø8
A
B
CD
Using an 8mm drill, drill the marked holes through the
support braces.
Insert wall plugs and re-hang the vanity unit in
position aligning the holes in the support braces.
Using a philips screwdriver screw through the
braces to reinforce the vanity unit on the wall surface.
E. Runner Screws
(H005) x 4
G. Wall Plugs
(H007) x 2
F. Fixing Screws
(H006) x 2

CAB 095 R03
13
