Croydex AP130422 User manual

1
Thank you for purchasing this Croydex product. Please follow the xing and care instructions to ensure
your adjustable seat is tted safely and retains its high quality nish.
Please retain this leaet for future reference.
This installation guide applies to the following product:
AP130422 - White Adjustable Seat with Arms
Tools required - not supplied
Screwdriver appropriate to xings.
KEEP DIY TOOLS OUT OF THE REACH OF CHILDREN
Product Care
To retain the best quality nish, clean product regularly with a soft damp cloth.
Do not use abrasive or chemical cleaners as these will damage the product.
Dry the adjustable seat after use.
Do not strike the product with hard or sharp objects.
Product Location
The adjustable seat must sit at within the bathroom or within a shower tray.
Curved surfaces of the bathtubs are not acceptable.
Cautionary Note
Please ensure all legs are equal length, the seat is level and all pins are secured in position.
Take care not to extend leg beyond its furthest extension. If the leg is extended beyond this point please
note that spring tenstion will propel the pin from the seat, so take care when adjusting the height.
If the pin and spring are removed from the leg, re-insert these components as shown in Fig.A.
Please note that the spring and pin need to be compressed in order to re-insert the leg into the seat.
S&H 046 R02
White Adjustable Seat with Arms
Fig.A

Fitting Instruction
1. Flip the adjustable seat to reveal its underside.
2. Using the screws supplied secure the two aluminium backrest frames and the aluminium armrest frame
into position on the underside of the seat. DO NOT OVER TIGHTEN - See Fig.1
3. Insert the seat legs into the housing by compressing the small pins - See Fig.2
4. The small pins will ‘Click’ into the housing securing the legs in position - See Fig.2
5. Once all four legs are secured, ip the seat into its usable position to t the armrests - See Fig.3
6. Locate the armrests onto the aluminium frames and secure into position - See Fig.3
7. Locate the backrest onto the aluminium frames and using the remaining screws supplied secure the
backrest into position to complete the assembly - See Fig.4
Additional Information
Maximum safe working load for the adjustable seat is 100kg
For details of the other items in the Croydex range please visit our website: www.croydex.com
Croydex Ltd, Central Way, Andover, Hants, SP10 5AW, UK
Tel: [phone]
Fax: [phone]
Email: [email protected]
2S&H 046 R02
Fig.1 Fig.2
Fig.3 Fig.4
