CTS CVT-3512 Series User manual

Trademarks
CTS is a registered trademark of Connection Technology
Systems Inc. Contents subject to revision without prior notice.
All other trademarks remain the property of their owners.
Copyright Statement
Copyright Connection Technology Systems Inc.
This publication may not bereproducedas awholeor in part, in
any way whatsoever unless prior consent has been obtained
from Connection Technology Systems Inc.
FCC Warning
The CVT-3512 Series have been tested and found to comply
with the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These standards are designed to provide
reasonable protectionagainst harmful interference when these
devices are operated in a commercial environment. These
devices generate, use, and can radiate radio frequency energy
that may cause harmful interference to radio communications
unless installed in accordance with this User’s Guide.
Operation of these devices in a residential area is likely to
cause harmful interference which will make the user
responsible for the appropriate remedial action at his / her own
expense.
CE Mark Warning
These are Class A products. In a domestic environment these
products may cause radio interference in which case the user
will need to consider adequate preventative methods.
This is a lead-free and RoHS-compliant product.
1. Checklist
The package should contain the following items:
-
CVT-3512 Converter
-
AC-DC Power Adapter
-
CD (User’s Guide & MIB file)
Please notify your sales representative immediately if any items
are missing or damaged.
2. Overview
CVT-3512 Series are designed to meet the increasing needs for
Gigabit network deployment and are able to extend a
copper-based Gigabit network via fiber cable to a maximum
distance up to 80KM.
CVT-3512 Series are fully compliant with IEEE 802.3, 802.3u,
802.3ab & 802.3z standards. It can be installed into a CVT
Converter RACK. The installation and operation procedures are
simple and straightforward. Operation status can be locally
monitored through a set of Diagnostic LED indicators located in
the front panel.
Major Features:
-
Auto-Negotiation in TX port
-
MDI/MDIX Auto-Crossover supported
-
Support Flow Control
-
Support Link Alarm
-
Support Jumbo Frame 9K bytes (under 10,100,1000Mbps)
-
Support Selectable ISP Ethernet Tag Type
-
Q-in-Q Double Tag configuration
-
Support DHCP Client
-
Support SNMP / Web Management interface
-
Support SNMP v1 and v2c
-
Support HTTP Firmware Upgrade
-
Support Power Down Trap Management
3. Installation
-
Attach fiber cable from the CVT-3512 to the fiber network.
The fiber connections must bematched –transmit socket to
receive socket.
-
Attach a UTP cable from the 10/100/1000BASE-T network
to the RJ-45 port on the CVT-3512.
-
Connect the power adapter to the CVT-3512 and check
whether the Power LED indicator lights up. The TX Link/Act
and FO Link/Act LED indicator will light up when all the
cable connections are satisfactory.
4. DIP SWITCH Setting
The factory default setting for PIN 1 and PIN 5 is ON. The rest of
Pins are OFF.
Pin NO.
Function
OFF
ON
1
TX
Auto-Negotiation
Disable
Enable
2
Manual TX Data
Rate 10M/100M
10M
100M
3
Manual TX Data
Rate 1000M
10M or 100M
1000M
4
Flow Control
Disable
Enable
5
Fiber
Auto-Negotiation
Force
Enable
6
Reserve
Always OFF
7
Link Alarm
Disable
Enable
8
TP Configuration
From S/W
From DIP
Diag
button
Press once for Loopback test.
Press for 10 seconds to restore factory default
setting.
NOTE: Before changing Data Rate and Duplex mode setting,
please make sure Auto-Negotiation is disabled.
Figure 1. CVT-3512 Dual-Fiber Front Panel
Figure 3. CVT-3512 Series Rear Panel
Figure 2. CVT-3512 Single-Fiber & SFP Front Panel
Diag
Diag

5. LED Description
6. Technical Specifications
Standards:
IEEE 802.3, 802.3u, 802.3ab,
802.3z
Interface:
1 x RJ-45 LAN connector
1 x SC connector or SFP Slot
1 x Diag button
LED:
Power, FDX, Status, Speed,
FO Link/ACT, TX Link/ACT
Power:
I/P AC 100-240V
O/P DC 5V, 1.6A
Power Consumption:
3.4W
Shipping Weight:
0.6KG
Dimensions:
71mm(W)X94mm(D)X26mm(H)
Temperature:
Operating: 0o~50oC
Storage: -20o~60oC
Humidity:
5%~90% RH
Certification:
FCC/CE Class A
*Please contact us for further reports and updates.
Media:
TP
EIA/TIA-568 CAT 5e, 1000M
Fiber
50/125, 62.5/125um multi-mode fiber
9/125, 10/125um single-mode fiber
Fiber Transceiver Information
1000M
Multi-Mode
TYPE
BTFC
Connector Type
SC
Wavelength
850nm
Typical Distance
550m
Min TX PWR
-9.5dBm
Max TX PWR
-1.5dBm
Sensitivity
-17.0dBm
Link Budget
7.5dB
Single-Mode
TYPE
BTFC(SM-10)
BTFC(SM-20)
BTFC(SM-30)
Connector Type
SC
SC
SC
Wavelength
1310nm
1310nm
1310nm
Typical Distance
10Km
20Km
30Km
Min TX PWR
-9.5dBm
-9.0dBm
-5.0dBm
Max TX PWR
-3.0dBm
-2.0dBm
3.0dBm
Sensitivity
-20.0dBm
-23.0dBm
-24.0dBm
Link Budget
10.5dB
14.0dB
19.0dB
Wave-Length WDM
TYPE
W2A(SM-10)
W2B(SM-10)
W2A(SM-20)
W2B(SM-20)
Connector Type
SC
SC
SC
SC
TX Wavelength
1310nm
1550nm
1310nm
1550nm
RX Wavelength
1550nm
1310nm
1550nm
1310nm
Typical Distance
10 Km
10 Km
20 Km
20 Km
Min TX PWR
-10.0dBm
-10.0dBm
-9.0dBm
-9.0dBm
Max TX PWR
-3.0dBm
-3.0dBm
0dBm
0dBm
Sensitivity
-22.0dBm
-22.0dBm
-23.0dBm
-23.0dBm
Link Budget
12.0 dB
12.0 dB
14.0 dB
14.0 dB
NOTE: Specifications may change without prior notice.
Contact Information
Connection Technology Systems INC (CTS)
18F-6, No.79, Sec.1, Xintai 5th Rd., Xizhi Dist.,
New Taipei City 221, TAIWAN, R.O.C.
TEL: [phone] FAX: [phone]
E-Mail: [email protected]om
CVT-3512 SERIES
10/100/1000BASE-T to
1000BASE-X Standalone
Managed Media Converter
with 802.3ah OAM
Compliance
User’s Guide
Version 1.0
LED
Color
Function
Power
Green
Lit when power is available.
TX
Link/Act
Green
Lit when TX cable connection with the
remote device is good.
Blink when TX traffic is present.
Orange
Blink when Fiber or Copper link is
down in Link Alarm enabled mode.
FO
Link/Act
Green
Lit when Fiber cable connection with
the remote device is good.
Blink when FO traffic is present.
Orange
Blink when Fiber or Copper link is
down in Link Alarm enabled mode.
FDX
Green
Lit when TX works in Full-Duplex.
Not-Lit when TX works in Half-
Duplex.
Speed
Green
Lit when TX works in 100M.
Not-Lit whenTX works in 10M or is not
linked.
Orange
Lit when TX works in 1000M.
Status
Green
Lit when TX and FO link is up.
Blink when Loopback test is
performed.
Orange
Lit when TX or FO link is down.
Blink when diagnostic testing fails.
