CTS MCT-3612 Series User manual

Trademarks
CTS is a registered trademark of Connection Technology
Systems Inc. Contents subject to revision without prior notice.
All other trademarks remain the property of their owners.
Copyright Statement
Copyright Connection Technology Systems Inc.
This publication may not bereproducedas awholeor in part, in
any way whatsoever unless prior consent has been obtained
from Connection Technology Systems Inc.
FCC Warning
The MCT-3612 Series converters have been tested and found
to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These standards are designed to
provide reasonable protection against harmful interference
whenthese devices are operated in a commercial environment.
These devices generate, use, and can radiate radio frequency
energy and may cause harmful interference to radio
communications unless installed in accordance with this
User’s Guide. Operation of these devices in a residential area
is likely to cause harmful interference which will make the user
responsible for the appropriate remedial action at his / her own
expense.
CE Mark Warning
These are Class A products. In a domestic environment these
products may cause radio interference in which case the user
will need to consider adequate preventative methods.
1. Checklist
The package should contain the following items:
-
MCT-3612 Converter
-
AC-DC Power Adapter
-
User’s Guide
Please notify your sales representative immediately if any
items are missing or damaged.
2. Overview
The MCT-3612 series media converter converts traditional
twisted-pair RJ-45 cable into various fiber media including
multi-mode, single-mode, SC connector, bi-directional WDM, or
a SFP slot for pluggable fiber transceiver, extending
transmission distance for the deployment to the household,
apartment or campus.
MCT-3612 series media converter is fully compliant with IEEE
802.3, 802.3u, 802.3ab & 802.3z standards.
Besides, it is equipped with some switching features including
store and forward. Operation status can be locally monitored
through a set of Diagnostic LED located in the front panel.
Major Features:
-
Auto-Negotiation in TP port
-
MDI/MDIX Auto-Crossover supported
-
Support Link Alarm
-
Support Jumbo Frame 9K bytes (under 10,100,1000Mbps)
-
Store and Forward Switching Mechanism
-
Support Auto & Force mode configuration
3. Installation
-
Attach fiber cable from the MCT-3612 to the fiber network.
The fiber connections must bematched –transmit socket to
receive socket.
-
Attach a UTP cable from the 10/100/1000BASE-T network
to the RJ-45 port on the MCT-3612.
-
Connect the power adapter to the MCT-3612 and check
that the PWR/STA LED lights up. The TP and F/O LEDs will
light up when all the cable connections are satisfactory.
Figure 1. MCT-3612 Dual Fiber Front Panel
Figure 2. MCT-3612 WDM & SFP Front Panel
Figure 3. MCT-3612 Converter Rear Panel
Figure 4. MCT-3612 Converter Side Panel
4. DIP SWITCH Setting
The default settings for PIN 1 through 6 are ON. The PIN 7 & 8
are OFF.
Pin NO.
Function
OFF
ON
1
TP Auto-Negotiation
Disable
Enable
2
Manual TP speed
10M
100M
3
Manual TP speed
N/A
1000M
4
Fiber Speed
Manual
Auto-Sensing
5
Fiber Manual Speed
100M
1000M
6
F/O mode
Force
Auto
7
Link Alarm
Disable
Enable
8
Config from DIP/Soft
Soft
DIP
NOTE:
1.Before changing TP speed, please make sure PIN 1 is set
to OFF.
2. When TP speed is set to 10M or 100M manually, PIN 3
needs to be turned OFF.
3. Under 1000Mbps, it supports full-duplex mode only.
4. PIN 4 & 5 are for dual rate model (MCT-3612-DR) only.

5. LED Description
6. Technical Specifications
Standards:
IEEE 802.3, 802.3u, 802.3ab,
802.3z
Interface:
1 X RJ-45 connector
1 X F/O port or SFP Slot
LED:
Power/Status, FDX, Speed,
F/O, TP
Power:
I/P AC 100-240V
O/P DC 3.3V
Power Consumption:
2.3W
Weight:
0.1Kg
Dimensions:
51mm(W)X74mm(D)X20mm(H)
Temperature:
Operating: 0o~50oC
Storage: -20o~60oC
Humidity:
5%~90% RH
Certification:
FCC/CE Class A
TP
EIA/TIA-568 CAT 5e, 1000M
Fiber
50/125, 62.5/125um multi-mode fiber
9/125, 10/125um single-mode fiber
Fiber Transceiver Information
Dual Rate
2 Wave-Length WDM
TYPE
W2A(SM-10)
W2B(SM-10)
Connector Type
SC
SC
Wavelength
1310/1550nm
1550/1310nm
Typical Distance
10 Km
10 Km
Min TX PWR
-10.0dBm
-10.0dBm
Max TX PWR
-3.0dBm
-3.0dBm
Sensitivity
-20.0dBm
-20.0dBm
Link Budget
10.0dB
10.0dB
1000M
Multi-Mode/Single-Mode
TYPE
BTFC
BTFC
(SM-10)
BTFC
(SM-20)
BTFC
(SM-30)
BTFC
(SM-50)
BTFC
(SM-80)
Connector
Type
SC
SC
SC
SC
SC
SC
Wavelength
850nm
1310nm
1310nm
1310nm
1550nm
1550nm
Typical
Distance
550m
10 Km
20 Km
30 Km
50 Km
80 Km
Min TX PWR
-9.5dBm
-9.5dBm
-9.0dBm
-5.0dBm
-5.0dBm
0dBm
Max TX
PWR
-1.5dBm
-3.0dBm
-2.0dBm
3.0dBm
3.0dBm
5.0dBm
Sensitivity
-17.0dBm
-20.0dBm
-23.0dBm
-24.0dBm
-24.0dBm
-24.0dBm
Link Budget
7.5dB
10.5dB
14.0dB
19.0dB
19.0dB
24.0dB
2 Wave-Length WDM
TYPE
W2A
(SM-10)
W2B
(SM-10)
W2A
(SM-20)
W2B
(SM-20)
W2A
(SM-40)
W2B
(SM-40)
Connector
Type
SC
SC
SC
SC
SC
SC
TX
Wavelength
1310nm
1550nm
1310nm
1550nm
1310nm
1550nm
RX
Wavelength
1550nm
1310nm
1550nm
1310nm
1550nm
1310nm
Typical
Distance
10 Km
10 Km
20 Km
20 Km
40 Km
40 Km
Min TX
PWR
-10.0dBm
-10.0dBm
-9.0dBm
-9.0dBm
-5.0dBm
-5.0dBm
Max TX
PWR
-3.0dBm
-3.0dBm
0dBm
0dBm
3.0dBm
3.0dBm
Sensitivity
-22.0dBm
-22.0dBm
-23.0dBm
-23.0dBm
-23.0dBm
-23.0dBm
Link Budget
12.0 dB
12.0 dB
14.0 dB
14.0 dB
18.0dB
18.0dB
NOTE: Specifications may change without prior notice.
Contact Information
Connection Technology Systems INC (CTS)
18F-6, No.79, Sec.1, Xintai 5th Rd., Xizhi Dist.,
New Taipei City 221, TAIWAN, R.O.C.
TEL: [phone] FAX: [phone]
E-Mail: [e-mail]
MCT-3612 SERIES
10/100/1000BASE-T to
1000BASE-X or
100/1000BASE-X
Managed Media Converter
User’s Guide
Version 1.0
LED
Color
Function
PWR/STA
Off
Power is not ready
Green
Lit when power is available.
Orange
Lit when power is being booted up.
Blink when new firmware is detected
and is available.
Green
&
Orange
Blinking
Firmware upgrade is currently
processing when the LED blinks green
& Orange in turn.
TP
Off
The TP port is link down
Green
Lit when TP cable connection with
remote device is good.
Blink when TP traffic is present.
F/O
Off
The fiber port is link down.
Green
Lit when Fiber cable connection at
100M with remote device is good.
Blink when F/O traffic is present.
(For dual rate model only)
Orange
Lit when Fiber cable connection at
1000M with remote device is good.
Blink when F/O traffic is present.
FDX
Off
TP works in Half-Duplex.
Green
Lit when TP works in Full-Duplex.
SPD
Off
The TP port is link down.
Green
Lit when TP works in 10M.
Lit when TP works in 100M.
Orange
Lit when TP works in 1000M.
