Cubii JR1+ User manual

Owner’s Manual

TABLE OF CONTENTS
Before You Begin .......................................................................... 2
Safety Instructions
Consult Your Physician
Getting Started.............................................................................. 4
Product Size and Weight
What’s in the Box
Warning Labels
Serial Number Location
Assembling Your Unit ................................................................. 6
Using Your Cubii JR1+ ................................................................ 8
Positioning
Adjusting the Resistance
Charging Your Cubii Elliptical
Battery Life and Power
Reading the Display Console
Installing and Pairing with the Cubii App
Bluetooth® Related App Features
General Information ..................................................................17
Return Policy and Warranty
Troubleshooting
Sensors and Motors
Care and Maintenance
Important Health & Safety Instructions
Regulatory Notices

1
Welcome to the Cubii Communitii™!
Whether you are taking the rst step on your tness journey or
looking to get more exercise from the comfort of home, bringing
the Cubii JR1+ into your routine is a big stride toward a healthier,
more active life! Before you begin, we want you to be familiar
with important information on how to use the Cubii JR1+ safely so
that you and your loved ones get the most out of your experience.
Let’s review the safety notes and warnings now.
If you have any questions, please contact:
1-844-282-4401
[e-mail]
cubii.com/help

2
BEFORE YOU BEGIN
Safety Warnings & Instructions
WARNING Consult your physician before starting this or
any exercise program. This is especially important if you have
never exercised before, are pregnant, or suffer from any health
problems. If at any time during exercise you feel faint, dizzy, or
experience pain, stop and consult your physician.
WARNING Do not use when standing. Only use when sitting.
Failure to follow all warnings and instructions could result in
serious injury or death.
WARNING To reduce the risk of serious injury, read the
following Safety Instructions before using Cubii JR1+.
1. Read all warnings and cautions posted on the Cubii JR1+ unit.
2. Cubii JR1+ should only be used after a thorough review of the
Owner’s Manual.
3. We recommend that two people are available for assembly of
this product.
4. Do not allow children to use or play on Cubii JR1+. Keep
children and pets away from Cubii JR1+ when it is in use.
5. Set up and operate Cubii JR1+ on a solid, level surface. Do not
position Cubii JR1+ on loose rugs or uneven surfaces.
6. Make sure that adequate space is available for access to and
around Cubii JR1+.
7. Before using, inspect Cubii JR1+ for worn or loose
components. Securely tighten or replace any worn or loose
components prior to use.
8. Do not wear loose or dangling clothing while using Cubii JR1+.

3
I. Before You Begin
9. Follow your physician’s recommendations in developing your
own personal tness program.
10. Always choose a workout plan which best ts your tness and
ability level. Know your limits and train within them. Always use
common sense when exercising.
11. Be careful to maintain your balance on your chair while using,
mounting, dismounting, or assembling Cubii JR1+; loss of
balance may result in a fall and serious bodily injury.
12. Keep both feet rmly and securely on the pedals while
exercising.
13. Maximum recommended user weight is 300 pounds (136 kg).
Never stand on the pedals, no matter your weight.
14. Cubii JR1+ should be used by only one person at a time.
Consult Your Physician
It is always important to consult your physician before starting an
exercise program. This is particularly true if any of the following
apply to your current medical condition:
• Chest pain or pain in the neck and/or arm
• Shortness of breath
• A diagnosed heart condition
• Joint and/or bone problems
• Currently taking cardiac and/or blood pressure medications
• Have not previously been physically active
• Dizziness or blurred vision
• Those with physical handicaps
If you feel any of the physical symptoms listed above when you
start your exercise program, contact your physician right away.

4
What’s in the Box
JR1+ Main Body
Left Pedal
Right Pedal
Screwdriver
Screws (x4)
Charging Cable
AC Power Adapter
Chair Wheel Stoppers (x2)
GETTING STARTED
Product Size and Weight
The assembled Cubii JR1+ measures:
23.2”L x 17.6”W x 9.8”H (58.8cm x 44.6cm x 24.8cm)
The weight of the unit is approximately 25.7lb (11.6kg).

5
II. Getting Started
Warning Labels
The warning label is located on your Cubii JR1+ product here:
Serial Number Location
The serial number is located on your Cubii JR1+ product here:
Record your serial number
here for future reference:
Failure to follow all warnings and instructions could result in serious injury
or death. Before assembling or using this product, read and follow the
Owner’s Manual and all other instructions that accompany this product.
Replace this warning label if damaged, illegible, or removed.
Keep others including children and pets away from equipment.
Consult your physician before starting this or any exercise program. This is
especially important if you are over the age of 35 or have any preexisting
health condition. Always make sure all nuts and bolts are securely
tightened before using this product. The maximum weight that can be
applied is 300 lb or 136 kg.
DO NOT USE WHILE STANDING. USE ONLY WHEN SITTING.
STANDING ON THE UNIT MAY CAUSE SERIOUS INJURY.
WARNING
Product Label

6
ASSEMBLING YOUR UNIT
Follow the steps below to assemble your JR1+ compact elliptical.
Step 1 — Align
Align the right pedal with the right arm.
Insert the bottom of the pedal into the two small holes.
Step 2 — Flip
For maximum support, make sure you ip the pedal you are
assembling so it is at the bottom and close to the base.

7
III. Assembling Your Unit
Step 3 — Screw
With a screwdriver, screw in the pedal until tight.
Make sure it does not wobble.
Step 4 — Repeat
Repeat steps 1-3 with the left pedal, then get moving!

8
USING YOUR CUBII JR1+
Make sure to have followed all of the assembly steps in the Quick
Start guide before you begin using Cubii JR1+.
Positioning
The Cubii JR1+ can be used either in an upright position, such as
with an ofce chair, or in a more reclined position, such as when
used on a sofa.
• Cubii JR1+ occupies a oor area of 23.2” x 17.6” (0.59m x
0.45m). Please leave a clear zone behind the training area
that is at least 0.60m (24”). This zone must be clear of any
obstruction and provide the user a clear exit path.
• Find the seat conguration that suits you most. If you feel there
is not enough room between your knees and the desk, push
your Cubii JR1+ away from you and lower the chair height.
Keep your back straight, and do not slouch.
• If you are sitting on an ofce chair with wheels, use the chair
wheel stoppers. Place stoppers on the front casters to prevent
your chair from moving backwards when you pedal.
• For swiveling chairs with more than 4 casters, you may nd
it more convenient to use only one wheel stopper centered
close to the machine.

9
Adjusting the Resistance
Cubii JR1+ has 8 resistance levels. Adjust
your workout intensity by turning the
resistance control knob. Level 1 is the
lowest intensity and level 8 is the highest.
We recommend you begin at Level 1 and
increase the intensity gradually over time.
CHARGING YOUR CUBII ELLIPTICAL
Step 1 — Connect Wall Adapter
Connect the charging cable to the wall
adapter and ensure wall adapter is
plugged into power source.
Step 2 – Locate Charging Socket
Locate the charging port on your Cubii
elliptical and plug in the cable.
Step 3 – Check Display for
Charging Symbol
Once the charging cable is plugged in
and charging your elliptical, the screen
will power on and the lightning bolt
symbol will ash to indicate the charge in
progress. The lightning bolt symbol will
remain solid when it is fully charged.
IV. Using Your Cubii JR1+

10
IV. Using Your Cubii JR1+
Battery Life and Power
The screen on your JR1+ comes equipped with a rechargeable
lithium-ion battery. With normal use, your Cubii elliptical should
last about 30 days before you need to charge again. Charging
your JR1+ completely can take up to 6 hours. You can check the
battery level in the Cubii app or on the built-in screen.
READING THE DISPLAY CONSOLE
User Options
Your Cubii JR1+ elliptical can store data separately for User 1,
User 2, and Guest. Press the User button to switch Users. The
triangle indicates the selected User. You can also track each User’s
progress through the Cubii app.
Top Row
The top row displays your total
number of strides. A “stride” is the
equivalent of one full rotation of the
pedaling motion.
Bottom Row
The bottom row displays the
following metrics:
• Time (00:00:00-99:59:59
hour:min:sec) elapsed during
active workout
• Distance (000.00-999.99 mi or km)
pedaled during a workout
• Calories (000.00-999.9 kcal) during
a workout
• RPM (0-999 strides/min) rotations
per minute during a workout

11
IV. Using Your Cubii JR1+
Press the MODE button to switch which metric is displayed. You
can use the SCAN mode to automatically toggle between the
above metrics every 7 seconds. The triangle indicator shows
which view is selected.
BLUETOOTH® Wireless Technology Indicator
The Bluetooth symbol will ash when your JR1+ is available to
connect to your mobile device or tablet. The Bluetooth® symbol
will remain solid once your elliptical is connected to the Cubii
mobile app. Your elliptical must be charged in order to pair with
another device.
Battery Indicator
The number of bars in the battery symbol indicates the charge
left in the battery. When the battery symbol reaches 0 bars, it
will ash for 20 seconds, indicating that it requires charging. The
battery symbol will ash during charging when battery level is
below 100%. It will remain solid when charging is complete, but
still plugged in. The symbol will disappear when your elliptical is
not charging.
“Smart Reset”
All metrics are additive and counted throughout the day. Once
you have paired the mobile app with your Cubii, then the metrics
displayed on the console will automatically reset each evening at
midnight (as long as your Cubii battery does not deplete). If you
have not paired the mobile app with your Cubii, then the data
will continue to aggregate unless you manually reset the data
or manually setup the “smart reset” feature (see section below
entitled Manually Set a “Smart Reset”).
*The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by Fitness Cubed Inc is under license. Other trademarks and trade names are those of their respective owners.

12
IV. Using Your Cubii JR1+
Console Prole Reset
User 1 and User 2 proles can be reset from the console. Simply
select the relevant user prole then hold the User button for 3
seconds then release the button to complete the prole reset.
Resetting the user prole from the built-in console erases any data
stored for that prole and also delinks the prole from the app. The
prole can be easily re-established in the app if needed.
Manual Data Reset
Manually reset data for any prole on the console (User 1, User
2 or Guest) by selecting the relevant prole (see User Button
section above) and then holding the Mode button for 3 seconds
then release the button to complete the prole reset. This action
resets any data displayed on the screen for the selected prole.
Distance Metric Toggle
To switch from miles to kilometers (or kilometers to miles), use the
MODE button to select the Distance metric. Then, hold the MODE
button for 6 seconds. If you are using the Cubii app, this update will
also be reected there.
Manually Set a “Smart Reset”
If you do not pair your elliptical to the Cubii app, but still want
your console to reset each evening at midnight, follow the
instructions below to set the clock to the current time:
1. Simultaneously press the USER and MODE buttons 3 times in a
row to reset the clock. It should ash “00:00”.
2. Press the USER button to cycle through hours until you get to
the right hour. Note that the clock uses military time.
3. Press the MODE button to cycle through minutes until you get
to the right minute.

13
IV. Using Your Cubii JR1+
4. Once you have entered the current time, simultaneously press
the USER and MODE buttons 3 times in a row to save the time.
If there is no activity for more than 5 seconds during this process,
the reset will be cancelled.
The “smart reset” feature is ONLY activated if the user performs
the manual actions above to set the RTC on the console (or it will
automatically be applied if the user connects their app). If you do
not choose to manually set the clock following the instructions
above, and do not connect to the Cubii app, your console will
continue to add and display all data until you manually reset the
screen.
Please note the “smart reset” function and clock setting will only
remain while the battery retains enough capacity to power the
device. If the battery is depleted, the “smart reset” feature must
again be manually established using the above instructions.
Connecting with Devices
Your Cubii JR1+ is a connected Bluetooth® Low Energy device,
meaning it can pair directly with the Cubii mobile app to
automatically track your workouts. The app also supports many
other features such as viewing your workout history, setting goals
and tracking against them, creating or participating in group
leaderboards, chatting with friends and much more.
Supported Devices
Your JR1+ can sync with select mobile devices that support
Bluetooth® 4.0 technology. Currently, we support iPhone mobile
devices running iOS® 12.0 or higher. (Note that supported
versions are subject to change over time. After you’ve created an
account, Cubii will inform you if/when your device requires
an update).

14
IV. Using Your Cubii JR1+
Installing the Cubii App
To download the app for a device, search for “Cubii” in your
app store. Click “Install”/ “Get”. Once it’s nished installing, click
“Open.” Once you open the app, you will be prompted to create
an account. If you already have the Cubii app installed, check for
available updates to make sure you have the latest version.
Pairing your Cubii Elliptical with the Cubii App
In order to pair with the Cubii app, please follow these
instructions:
1. Start pedaling to trigger the Bluetooth® signal. You’ll see the
Bluetooth® symbol glow and start blinking.
2. Conrm that you’ve enable Bluetooth wireless technology in
your device’s settings.
3. Upon opening the Cubii app for the rst time, you will be
prompted to create an
account. Be sure to review/
accept the Terms of Use and
Privacy Policy.
4. Complete your prole and
follow the other in-app
instructions.
5. The app will detect your Cubii
elliptical via Bluetooth®. Select
your elliptical in the app.
6. Once successfully paired, the
Bluetooth® symbol on your
built-in screen will stop blinking.
7. The app will ask if you would
like to become User 1, User 2,
or proceed as Guest. Make a
selection.

15
IV. Using Your Cubii JR1+
8. Start your workout and enjoy your Cubii experience!
9. From here on, every time you launch the app, it will search
for all Cubii devices in your vicinity and automatically connect
with an elliptical that it has already paired with. If it does not
automatically reconnect, you can manually search and connect
it in the app.
In order to pair with a new Cubii elliptical in the same vicinity, you
must rst disconnect from the previous Cubii elliptical. This can
be done in the app. Your elliptical can also only pair to one app
user at a time. To allow another user to connect their app to the
elliptical, you must rst disconnect.
Ofine Mode
The Cubii app should remain open in the background in order
for Cubii to send data to your device. If the app is not open, then
the Cubii itself will store your workout data until the next time
your app is paired, at which point the data will be retrieved. The
exercise stats will be attributed to the date/time they occurred.
BLUETOOTH® Related App Features
In addition to the automated tracking and storing of your workout
data, the mobile app also offers a few other features specically
related to the Bluetooth® connectivity. Each of the capabilities
listed below are available when your elliptical is actively paired
with the app.
Distance Metric Toggle
Switch from miles to kilometers, or kilometers to miles, by
switching the setting in the mobile app. When this action is taken,
the app communicates the change to the elliptical console so it
displays the appropriate distance metric.

16
IV. Using Your Cubii JR1+
Resistance Level
The Cubii app will automatically retrieve the resistance level from
the elliptical. However, please note that the app CANNOT update
the resistance on the elliptical itself. The resistance is managed by
the elliptical and the app reads that information.
User 1, User 2 and Guest Proles
Your Cubii elliptical offers multiple user proles on the console
in the event that you plan on sharing your device. This means
that you can easily keep track of your data separately by simply
switching proles, so User 1, User 2 and Guest proles can
all have different sets of data. The prole on the console also
corresponds to the app. You will be prompted to select a prole
in the app when you set up your account and connect to the
elliptical for the rst time.
If you have selected the User 1 prole, then someone else can
become User 2 (and vice versa). From that point forward, the app
will check to make sure the console is toggled to the correct user
prole and will automatically send a command to the elliptical to
update the console prole as needed.
You will always have the option to proceed as Guest. Anyone can
connect to the elliptical as Guest. Any user connected as Guest
will have the data from the elliptical synced to their app.
NOTE – If you have opted to set your app as User 1 or User 2 but
decide to exercise without the app actively connected, then make
sure that the console is toggled onto the correct user prole.
Without an active connection with the app, the data will be
attributed to whichever User prole is selected on the console.
