Cubii JR1 User manual

Owner’s Manual
Owner’s Manual
Owner’s Manual
Manual del propietario
PEDALES ELÍPTICOS COMPACTOS
Manual del propietario
PEDALES ELÍPTICOS COMPACTOS
Manuel du propriétaire
ELLIPTIQUE EN POSITION ASSISE COMPACTE
Manuel du propriétaire
ELLIPTIQUE EN POSITION ASSISE COMPACTE

TABLE OF CONTENTS
Before You Begin..........................................................................2
Safety Instructions
Consult Your Physician
Getting Started.............................................................................. 4
Product Size and Weight
What’s in the Box
Warning Labels
Serial Number Location
Assembling Your Unit .................................................................6
Using Your Cubii JR1................................................................... 8
Positioning
Adjusting the Resistance
Display Monitor
General Information ................................................................. 10
Troubleshooting
Return Policy and Warranty
LCD Screen Battery Caution & Disposal
Care and Maintenance
Important Health & Safety Instructions
Regulatory Notices

1
Welcome to the Cubii Community!
Whether \RXDUHWDNLQJWKHƓUVWVWHSRQ\RXUƓWQHVVMRXUQH\RU
looking to get more exercise from the comfort of home, bringing
the Cubii JR1 into your routine is a big stride toward a healthier,
more active life! Before you begin, we want you to be familiar
with important information on how to use the Cubii JR1 safely
so that you and your loved ones get the most out of your
experience. Let’s review the safety notes and warnings now.
If you have any questions, please contact:
1-844-282-4401
[e-mail]
cubii.com/support

2
BEFORE YOU BEGIN
Safety Warnings & Instructions
WARNING Consult your physician before starting this or
any exercise program. This is especially important if you have
never exercised before, are pregnant, or suffer from any health
problems. If at any time during exercise you feel faint, dizzy, or
experience pain, stop and consult your physician.
WARNING Do not use when standing. Only use when sitting.
Failure to follow all warnings and instructions could result in
serious injury or death.
WARNING To reduce the risk of serious injury, read the
following Safety Instructions before using Cubii JR1.
1. Read all warnings and cautions posted on the Cubii JR1 unit.
2. Cubii JR1 should only be used after a thorough review of the
Owner’s Manual.
3. We recommend that two people are available for assembly of
this product.
4. Do not allow children to use or play on Cubii JR1. Keep
children and pets away from Cubii JR1 when it is in use.
5. Set up and operate Cubii JR1 on a solid, level surface. Do not
position Cubii JR1 on loose rugs or uneven surfaces.
6. Make sure that adequate space is available for access to and
around Cubii JR1.
7. Before using, inspect Cubii JR1 for worn or loose components.
Securely tighten or replace any worn or loose components
prior to use.
8. Do not wear loose or dangling clothing while using Cubii JR1.

3
I. Before You Begin
9. Follow your physician’s recommendations in developing your
RZQSHUVRQDOƓWQHVVSURJUDP
10. $OZD\VFKRRVHDZRUNRXWSODQZKLFKEHVWƓWV\RXUƓWQHVVDQG
ability level. Know your limits and train within them. Always use
common sense when exercising.
11. Be careful to maintain your balance on your chair while using,
mounting, dismounting, or assembling Cubii JR1; loss of
balance may result in a fall and serious bodily injury.
12. .HHSERWKIHHWƓUPO\DQGVHFXUHO\RQWKHSHGDOV
while exercising.
13. Maximum recommended user weight is 300 pounds (136 kg).
Never stand on the pedals, no matter your weight.
14. Cubii JR1 should be used by only one person at a time.
Consult Your Physician
It is always important to consult your physician before starting an
exercise program. This is particularly true if any of the following
apply to your current medical condition:
• Chest pain or pain in the neck and/or arm
• Shortness of breath
• A diagnosed heart condition
• Joint and/or bone problems
• Currently taking cardiac and/or blood pressure medications
• Have not previously been physically active
• Dizziness or blurred vision
• Those with physical handicaps
If none of these apply to you then start gradually and sensibly.
However, if you feel any of the physical symptoms listed above
when you start your exercise program, contact your physician
right away.

4
What’s in the Box
JR1 Main Body
Left Pedal
Right Pedal
Screwdriver
Screws (x4)
Chair Wheel Stoppers (x2)
GETTING STARTED
Product Size and Weight
The assembled Cubii JR1 measures:
23.2”L x 17.6”W x 9.8”H (58.8 x 44.6 x 24.8cm)
The weight of the unit is approximately 25.4lb (11.5kg).

5
II. Getting Started
Warning Labels
The warning label is located on your Cubii JR1 product here:
Serial Number Location
The serial number is located on your Cubii JR1 product here:
Record your serial number
here for future reference:
Failure to follow all warnings and instructions could result in serious injury
or death. Before assembling or using this product, read and follow the
Owner’s Manual and all other instructions that accompany this product.
Replace this warning label if damaged, illegible, or removed.
Keep others including children and pets away from equipment when in
use.
Consult your physician before starting this or any exercise program. This is
especially important if you are over the age of 35 or have any preexisting
health condition. Always make sure all nuts and bolts are securely
tightened before using this product.
DO NOT USE WHILE STANDING. USE ONLY WHEN SITTING.
STANDING ON THE UNIT MAY CAUSE SERIOUS INJURY.
WARNING

6
ASSEMBLING YOUR UNIT
Follow the steps below to assemble your JR1 compact elliptical.
Step 1 — Align
Align the right pedal with the right arm.
Insert the bottom of the pedal into the two small holes.
Step 2 — Flip
)RUPD[LPXPVXSSRUWPDNHVXUH\RXŴLSWKHSHGDO\RXDUH
assembling so it is at the bottom and close to the base.

7
III. Assembling Your Unit
Step 3 — Screw
With a screwdriver, screw in the pedal until tight.
Make sure it does not wobble.
Step 4 — Repeat
Repeat steps 1-3 with the left pedal, then get moving!

8
USING YOUR CUBII JR1
Make sure to have followed all of the assembly steps in the
Quick Start guide before you begin using Cubii JR1.
Positioning
The Cubii JR1 can be used either in an upright position,
VXFKDVZLWKDQRIƓFHFKDLURULQDPRUHUHFOLQHGSRVLWLRQ
such as when used on a sofa.
• &XELL-5RFFXSLHVDŴRRUDUHDRIŐ[ŐP[
0.46m). Please leave a clear zone behind the training area
that is at least 0.60m (24”). This zone must be clear of any
obstruction and provide the user a clear exit path.
• )LQGWKHVHDWFRQƓJXUDWLRQWKDWVXLWV\RXPRVW,I\RXIHHO
there is not enough room between your knees and the desk,
push your Cubii JR1 away from you and lower the chair height.
Keep your back straight, and do not slouch.
• ,I\RXDUHVLWWLQJRQDQRIƓFHFKDLUZLWKZKHHOV\RXDUH
encouraged to use the chair wheel stoppers. Place stoppers
on the front casters to prevent your chair from moving
backwards when you pedal.
• )RUVZLYHOLQJFKDLUVZLWKPRUHWKDQFDVWHUV\RXPD\ƓQG
it more convenient to use only one wheel stopper centered
close to the machine.

9
Adjusting the Resistance
Cubii JR1 has 8 resistance levels. Adjust
your workout intensity by turning the
resistance control knob. Level 1 is the
lowest intensity and level 8 is the highest.
We recommend you begin at Level 1 and
increase the intensity gradually over time.
Display Monitor
You can track your workout using the LCD Screen.
It tracks the stats listed below:
1. Strides (0-9999)
2. Calories (0-999.9 kcal)
3. Distance (0-999.9 mi or km)
4. Time (0:00-99:59 hour:min)
5. RPM (0-999 strides/min)
• Press the silver button to switch
between stats. Select scan to alternate automatically.
• Screen turns on when the silver button is pressed or when you
start pedaling. Screen turns off after 4 minutes of inactivity.
• To reset stats, press and hold the silver button until all
segments turn black (about 3 seconds), then let go. Replacing
the battery will also reset the stats. When the stats reach
maximum values, they will reset to zero.
• To switch from Miles(M) to Kilometers(K), press and hold the
silver button for at least 6 seconds. All segments will turn
EODFNWZLFHGXULQJWKLVWLPH$IWHUWKHVHFRQGŴDVKRIEODFN
segments, release the button. When displaying distance,
you will see the M is now showing a K, or vice versa.
IV. Using Your Cubii JR1

10
GENERAL INFORMATION
Return Policy and Warranty
The warranty for the Cubii JR1 is 1 year from date of purchase.
To register for your warranty, visit: cubii.com/pages/register
Cubii JR1 Return Policy can be found online at:
cubii.com/policies/refund-policy
Troubleshooting
For troubleshooting and assistance with your Cubii JR1,
you can email us at: [e-mail]
LCD Screen Battery Caution & Disposal
To replace battery, gently remove the screen from the
housing to access the back panel.
• For best results, use 1.5V LR44H Alkaline Zinc-Manganese
Dioxide Button Cell.
• Only install a new battery of the same type.
• 'RQRWGLVSRVHRIEDWWHU\LQƓUH
• Battery should be recylced or disposed of as per state and
local guidelines.
• Failure to insert battery in the correct polarity may shorten
the life of the battery or cause the battery to leak.
Correct Orientation Below

11
Care and Maintenance
The safety and integrity designed into Cubii JR1 can only be
maintained when Cubii JR1 is regularly examined for damage
and wear. It is the sole responsibility of the user/owner to
ensure that regular maintenance is performed.
Special attention should be given to the following:
• Periodically wipe the unit down with a damp cloth, paying
special attention to the rubber padding on the wheel tracks.
This will help reduce any noise between the wheels
and the wheel track.
• Pay special attention to how tightly the pedals are screwed
to the pedal arms. Tighten regularly using a screwdriver.
• Worn or damaged components shall be replaced immediately
or Cubii JR1 removed from service until repair is made.
Email Fitness Cubed, Inc at suppor[email protected]
to request replacement parts.
• Only Fitness Cubed, Inc supplied components shall be used
to maintain/repair Cubii JR1.
USE ONLY WHILE SITTING, DO NOT STAND
ON THE UNIT UNDER ANY CIRCUMSTANCE.
V. General Information

12
V. General Information
Important Health & Safety Instructions
Consult your physician before starting this or any exercise
program. This is especially important if you are over the age
of 35 or have any preexisting health conditions. If you feel faint
or dizzy, immediately discontinue use of this equipment.
Serious bodily injury can occur if this equipment is not
assembled and used correctly. Serious bodily injury can also
occur if all instructions are not followed. Keep others and pets
away from equipment when in use.
Read and follow these instructions:
• Cubii JR1 has been designed to be used only while sitting.
Do not stand on the pedals as it was not designed to be used
while standing.
• Make sure the pedals on Cubii JR1 are tight before use.
Loose pedals will slowly come undone, create noise, and
cause risk of damage and injury.
• Do not subject Cubii JR1 to heavy shock or treat it with
excessive force. Do not attempt to disassemble or modify it.
• Use Cubii JR1 indoors on a level surface. Keep it away from
moisture and dust.
• Do not expose Cubii JR1 to extremely high or low
temperatures. Do not leave Cubii JR1 in direct sunlight
for an extended period of time.
• Do not place Cubii JR1 in a location where it may
cause an obstruction.
• Do not use cleaners or solvents to clean Cubii JR1.
• Do not use any lubricants. They can damage the unit.

13
V. General Information
Regulatory Notices
EU (European Union)
Declaration of Conformity with Regard to the EU Directive
2014/53/EU Fitness Cubed Inc is authorized to apply the CE Mark
on Cubii JR1, Model F3A2, thereby declaring conformity to the
essential requirements and other relevant provisions of Directive
2014/53/EU Compliant with the standard R&TTE 2014/53/EU
Conforme à la norme R&TTE 2014/53/EU
U.S. Patent No. D793,494
U.S. 9713739 B2
Version: JR1OMRD1

TABLE DES MATIÈRES
Avant de commencer........................................................ 2
Consignes de sécurité
Consultez votre médecin
Commencer........................................................................ 4
Taille et poids du produit
Contenu de la boîte
Étiquettes d’avertissement
Emplacement du numéro de série
Assemblage de votre appareil........................................ 6
Utilisation de votre Cubii JR............................................ 8
Positionnement
Réglage de la résistance
 0RQLWHXUGōDIƓFKDJH
Renseignements généraux............................................ 10
Dépannage
Politique de retour et garantie
Mise en garde et destruction de la batterie à écran ACL
Entretien et maintenance
Consignes importantes de santé et de sécurité
Avis réglementaires
