Cubii MOVE F5A1 User manual

Owner’s Manual
COMPACT SEATED ELLIPTICAL

Additional product information can be found online
Weitere Produktinformationen nden Sie online
Puede encontrar información adicional sobre el producto en línea
Des informations supplémentaires sur les produits sont
disponibles en ligne
Ulteriori informazioni sul prodotto sono disponibili online
Meer productinformatie vindt u online
manuals.cubii.com

TABLE OF CONTENTS EN
Before You Begin.......................................... 2
Safety Warnings & Instructions
Consult Your Physician
Getting Started............................................. 5
Product Size and Weight
What’s in the Box
Warning Labels
Serial Number Location
Assembling Your Unit .................................. 7
Using Your Cubii Move...............................11
Positioning
Adjusting the Resistance
Display Monitor
General Information....................................13
Troubleshooting
LCD Screen Battery Caution & Disposal
Care and Maintenance
Important Health & Safety Instructions
Regulatory Notices

1
Welcome to the Cubii Communitii®!
Whether you are taking the rst step on your tness journey or looking
to get more exercise from the comfort of home, bringing the Cubii Move
into your routine is a big stride toward a healthier, more active life! Before
you begin, we want you to be familiar with important information on how
to use the Cubii Move safely so that you and your loved ones get the most
out of your experience. Let’s review the safety notes and warnings now.
If you have any questions, please contact:
[phone]
[e-mail]
cubii.com/help

2
BEFORE YOU BEGIN
Safety Warnings & Instructions
WARNING Consult your physician before starting this or any exercise
program. This is especially important if you have never exercised before,
are pregnant, or suffer from any health problems. If at any time during
exercise you feel faint, dizzy, or experience pain, stop and consult your
physician.
WARNING Do not use when standing. Only use when sitting. Failure to
follow all warnings and instructions could result in serious injury or death.
WARNING To reduce the risk of serious injury, read the following
Safety Instructions before using Cubii Move.
WARNING Wear sturdy, closed-toed shoes when using any Cubii
elliptical.
BATTERY WARNING
KEEP OUT OF REACH OF CHILDREN. DO NOT SWALLOW. Battery can
cause serious injuries if swallowed or placed inside any part of the body.
Seek medical attention immediately if it is suspected the battery has been
swallowed or placed inside any part of the body.
1. Read all warnings and cautions posted on the Cubii Move unit.
2. Cubii Move should only be used after a thorough review of the Owner’s
Manual.
USE ONLY WHILE SITTING, DO NOT STAND
ON THE UNIT UNDER ANY CIRCUMSTANCE.

3
I. Before You Begin
3. We recommend that two people are available for assembly of this
product.
4. Do not allow children to use or play on Cubii Move. Keep children and
pets away from Cubii Move when it is in use.
5. Set up and operate Cubii Move on a solid, level surface. Do not
position Cubii Move on loose rugs or uneven surfaces.
6. Make sure that adequate space is available for access to and around
Cubii Move.
7. Before using, inspect Cubii Move for worn or loose
components. Securely tighten or replace any worn or loose
components prior to use.
8. Do not wear loose or dangling clothing while using Cubii Move.
9. Follow your physician’s recommendations in developing your own
personal tness program.
10. Always choose a workout plan which best ts your tness and ability
level. Know your limits and train within them. Always use common
sense when exercising.
11. Be careful to maintain your balance on your chair while using,
mounting, dismounting, or assembling Cubii Move; loss of balance
may result in a fall and serious bodily injury.
12. Keep both feet rmly and securely on the pedals while exercising.
13. Maximum recommended user weight is 300 pounds (136 kg). Never
stand on the pedals, no matter your weight.
14. Cubii Move should be used by only one person at a time.

4
I. Before You Begin
Consult Your Physician
It is always important to consult your physician before starting an exercise
program. This is particularly true if any of the following apply to your
current medical condition:
• Chest pain or pain in the neck and/or arm
• Shortness of breath
• A diagnosed heart condition
• Joint and/or bone problems
• Currently taking cardiac and/or blood pressure medications
• Have not previously been physically active
• Dizziness or blurred vision
• Those with physical handicaps
If you feel any of the physical symptoms listed above when you start your
exercise program, contact your physician right away.

5
II. Getting Started
Move Main Body
Left Pedal Tube
Right Pedal Tube
Left Pedal
Right Pedal
Base Frame
Screws (x10)
Allen Key
GETTING STARTED
Product Size and Weight
The assembled Cubii Move measures:
21.7” x 19.7” x 9.7”H (55cm x 50cm x 24.5cm).
The weight of the unit is approximately 17.6lbs (8kg).
What’s in the Box
A
B C
A
B
C
A B
C
Screw Key

6
II. Getting Started
Warning Labels
The warning label is located on your Cubii Move product here:
Serial Number Location
The serial number is located on your Cubii Move product label and the
content panel of the box.
Record your serial number here
for future reference:
WARNING
PRODUCT LABEL
Failure to follow all warnings and instructions could result in serious
injury or death. Before assembling or using this product, read and
follow the Owner’s Manual and all other instructions that accompany
this product. Replace this warning label if damaged, illegible, or
reMoved. Keep children and pets away from equipment. Consult
your physician before starting this or any exercise program. This
is especially important if you are over the age of 35 or have any
pre-existing health condition. Always make sure all nuts and bolts
are securely tightened before using this product. The maximum
weight that can be applied is 300 lb or 136 kg. DO NOT STAND ON
UNIT UNDER ANY CIRCUMSTANCE. USE ONLY WHEN SITTING.
STANDING ON THE UNIT MAY CAUSE SERIOUS INJURY.

7
III. Assembling Your Unit
ASSEMBLING YOUR UNIT
Follow the steps below to assemble your Move compact elliptical.
Step 1 — Align Base Frame
Flip your Move unit upside down
Align the holes of the base frame with the holes on the bottom of the
unit. NOTE: Make sure the rubber pads on top of the base frame are
underneath the resistance knob
Screw in the four screws matching A screw images

8
III. Assembling Your Unit
Step 2 — Add Arms
Flip your Move unit rightside up.
Align the right pedal arm with the right crank arm hole.
Push the tube all the way into the hole in the crank arm.
Make sure it is completely secure before moving to the next step

9
III. Assembling Your Unit
Once completely secure, use your allen key to tighten the fastner bolts on
top of the crank arm.
Step 3 — Flip
For maximum support, make sure you ip the pedal arm you are
assembling so it is at the bottom and close to the base.

10
III. Assembling Your Unit
Step 4 — Screw
With an allen key, screw in the pedal until tight. Make sure it does not
wobble.
Step 5 — Repeat
Repeat steps 2-4 with the left pedal, then get moving!

11
IV. Using Your Cubii Move
USING YOUR CUBII Move
Make sure to have followed all of the assembly steps in the Owner’s
Manual before you begin using Cubii Move.
Positioning
The Cubii Move can be used either in an upright position, such as with an
ofce chair, or in a more reclined position, such as when used on a sofa.
• Cubii Move occupies a oor area of 21.7” x 19.7” (55cm x 50cm). Please
leave a clear zone behind the training area that is at least 24” (61 cm).
This zone must be clear of any obstruction and provide the user a clear
exit path.
• Find the seat conguration that suits you most. If you feel
there is not enough room between your knees and the desk, push your
Cubii Move away from you and lower the chair height. Keep your back
straight, and do not slouch.
TRAINING AREA FREE AREA
0.6M (2FT)

12
Adjusting the Resistance
Cubii Move has 6 resistance levels. Adjust your
workout intensity by turning the resistance
control knob. Level 1 is the lowest intensity
and level 6 is the highest. We recommend
you begin at Level 1 and increase the intensity
gradually over time.
Display Monitor
You can track your workout using the LCD
Screen.
It tracks the stats listed below:
1. Strides (0-9999)
2. Calories (0-999.9 kcal)
3. Distance (0-999.9 mi or km)
4. Time (0:00-99:59 hour:min)
5. RPM (0-999 strides/min)
• Press the blue button to switch between stats. Select scan to alternate
automatically.
• Screen turns on when the silver button is pressed or when you start
pedaling. Screen turns off after 4 minutes of inactivity.
• To reset stats, press and hold the silver button until all segments turn
black (about 3 seconds), then let go. Replacing the battery will also
reset the stats. When the stats reach maximum values, they will reset to
zero.
• To switch from Miles (M) to Kilometers (K), press and hold the silver
button for at least 6 seconds. All segments will turn black twice during
this time. After the second ash of black segments, release the button.
When displaying distance, you will see the M is now showing a K, or
vice versa.
IV. Using Your Cubii Move

13
GENERAL INFORMATION
Return Policy and Warranty
For more information about how to register your unit and our warranty and
return policy, scan the QR code at the beginning of the manual, call our
Customer Service number [phone] or visit Cubii.com.
We strongly recommend keeping the original box in the event of a return
or warranty claim.
Troubleshooting
For troubleshooting and assistance with your Cubii Move, you can email us
at: suppor[email protected]
LCD Screen Battery Caution & Disposal
To replace battery, gently reMove the screen from the housing to access
the back panel. Gently unscrew the fastener to gain access to the battery
housing.
Carefully reattach the battery cover with the two screws. Press down on the
top of the screen until you hear it click. The screen is now secure in the unit.
• For best results, use 1.5V LR44H Button Cell.
• Only install a new battery of the same type.
• Do not dispose of battery in re.
• Battery should be recycled or disposed of as per state and local
guidelines.
• Failure to insert battery in the correct polarity may shorten the life of
the battery or cause the battery to leak.
• For assistance with replacing the battery, please email us at support@
mycubii.com
Correct Orientation Below
V. General Information
+
—
TOP
BOTTOM

14
Care and Maintenance
The safety and integrity designed into Cubii Move can only be maintained
when Cubii Move is regularly examined for damage and wear. It is the
sole responsibility of the user/owner to ensure that regular maintenance is
performed.
Special attention should be given to the following:
• Periodically wipe the unit down with a damp cloth, paying special
attention to the rubber padding on the wheel tracks. This will help
reduce any noise between the wheels and the wheel track.
• Pay special attention to how tightly the pedals are screwed to the
pedal arms. Tighten regularly using an allen key.
• Worn or damaged components shall be replaced immediately or Cubii
Move reMoved from service until repair is made.
Email Fitness Cubed, Inc at suppor[email protected]
to request replacement parts.
• Only Fitness Cubed, Inc supplied components shall be used to
maintain/repair Cubii Move.
• Make sure crank arm fastener screws are tightly secured or else pedals
could come unscrewed from unit and create noise, and cause risk of
damage and injury.
Important Health & Safety Instructions
Consult your physician before starting this or any exercise program. This is
especially important if you are over the age of 35 or have any preexisting
health conditions. If you feel faint or dizzy, immediately discontinue use
of this equipment. Serious bodily injury can occur if this equipment is not
assembled and used correctly. Serious bodily injury can also occur if all
instructions are not followed. Keep others and pets away from equipment
when in use. Read and follow these instructions:
• Cubii Move has been designed to be used only while sitting.
Do not stand on the pedals as it was not designed to be used while
standing.
• Make sure the pedals on Cubii Move are tight before use.
V. General Information

15
Loose pedals will slowly come undone, create noise, and cause risk of
damage and injury.
• Do not subject Cubii Move to heavy shock or treat it with excessive
force. Do not attempt to disassemble or modify it.
• Use Cubii Move indoors on a level surface. Keep it away from moisture
and dust.
• Do not expose Cubii Move to extremely high or low temperatures. Do
not leave Cubii Move in direct sunlight for an extended period of time.
• Do not place Cubii Move in a location where it may cause an
obstruction.
• Do not use cleaners or solvents to clean Cubii Move.
• Do not use any lubricants. They can damage the unit.
• Make sure base screws are tightly secured.
• Make sure pedal tubes are as tightly secured to the crank arms.
Regulatory Notices
1. This device complies with Part 15 of FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
2. Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
V. General Information

16
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure conditions without
restriction.
Fitness Cubed, Inc. is authorized to apply the CE Mark on Cubii, Model F5A1,
thereby declaring conformity to the essential requirements and other relevant
provisions of:
EMC: EMC Directive 2014/30/EU
Safety: General Product Safety Directive 2001/95/EC
ROHS: European Council Directive 2011/65/EU
WEEE: WEEE Directive 2012/19/EU
Reach: Reach Regulation (EC) No. 1907/2006
® TRADEMARK OF FITNESS CUBED INC. REGISTERED IN THE IN THE US AND
CANADA.
V. General Information
