Cudy GS105D User manual

Quick Installation Guide
5-Port 10/100/1000Mbps Desktop Switch
Model: GS105D
For support and warranty, please visit: http://www.cudytech.com/.
Specifications are subject to change without notice. Cudy is a
registered trademark of Shenzhen Cudy Technologies Co., Ltd. Other
brands and product names are trademarks or registered trademarks
of their respective holders.Copyright©2019 Shenzhen Cudy
Technology Co., Ltd. All rights reserved.
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The
original EU declaration of conformity may be found at http://
www.cudytech.com/en/ce
810600031
Main Features
3
CE Mark Warning
This is a class B product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take adequate measures.
Standards
Number of Ports
LED Indication
Transfer Method
Switching Capacity
MAC capacity
Dimensions
Environment
Frame Filtering
and Forward Rate
Power Supply
Consumption
Network Media
(Cable)
IEEE802.310Base-T,IEEE802.3u 100Base-TX,
IEEE802.3ab 1000Base-T,IEEE802.3az
5 x 10/100/1000Mbps Auto-Negotiation ports
Power, Link/Act LEDs
Store-and-Forward
10Gbps
2K
90*72*25 mm (L x W x H)
10Mbps: 14880pps
100Mbps: 148800pps
1000Mbps: 1488000pps
Input: DC 5V /1A(adapter)
Consumption: 2.75W
Operating Temperature: 0℃ - 40℃
Storage Temperature: -10℃ - 70℃
Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
10BASE-T: UTP category 3,4,5 cable (maximum 100m)
100BASE-Tx: UTP category 5, 5e cable (maximum 100m)
1000BASE-T: UTP category 5e, 6 cable (maximum 100m)

On: Power on
Off: Power off
On: Link present but no activity
Flashing: Transmitting/receiving data
Off: No link
Router
GS105D
PC
WAN Port LAN Port
Wi-Fi Printer
Power Cord
LAN4
LAN2
LAN5
LAN3
LAN1
LED Indication
2
Physical Connection
1
Internet
Power
Link / Act
(port 1-5)
