Culligan Medallist Plus Iron-OX5 User manual

Culligan
Medallist
Plus®
Iron-OX5™
Filter Owners
Guide
01035155_A
DCO 190572 09/19

201035155 A 09/19
Attention
Culligan
Customer
We encourage Culligan users to learn about Culligan products, but we believe that product knowledge
is best obtained by consulting with your Culligan dealer. Untrained individuals who use this manual
assume the risk of any resulting property damage or personal injury.
WARNING! Electrical shock hazard! Prior to servicing equipment, disconnect
power supply to prevent electrical shock.
CAUTION! This system is not intended for use where water is microbiologically unsafe or
with water of unknown quality.
WARNING! If incorrectly installed, operated or maintained, this product can cause
severe injury. Those who install, operate, or maintain this product should
be trained in its proper use, warned of its dangers, and should read
the entire manual before attempting to install, operate, or maintain this
product.
CAUTION! To reduce the risk of fire, use only No. 26 AWG or larger
telecommunications line cord.
CAUTION! This product is not to be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, unless they have been given supervision or instruction.
CAUTION! Children should be instructed not to play with this appliance.
CAUTION! If the power cord from the power supply to the unit looks or
becomes damaged, the cord and transformer should be replaced
by a Culligan Service Agent or similarly qualified person in order to
avoid a hazard.
Products manufactured and marketed by Culligan International Company (Culligan) and its affiliates are
protected by patents issued or pending in the United States and other countries. Culligan reserves the
right to change the specifications referred to in this literature at any time, without prior notice. Culligan,
AquaSensor, Tripl-Hull, and SoftMinder are trademarks of Culligan International Company or its affiliates.
Culligan International Company
9399 West Higgins Road, Suite 1100
Rosemont, Illinois 60018
1-847-430-2800
www.culligan.com

3
Contents
01035155 A 09/19
The filter warranty is located on page 17 of this Owner’s Guide.
About This Manual.......................................................................................................................................4
Thank You....................................................................................................................................................5
Specications ..............................................................................................................................................6
Application...................................................................................................................................................7
Operation.....................................................................................................................................................8
Programming...............................................................................................................................................9
Error Codes ...............................................................................................................................................11
When & How to Bypass Your Water Filter .................................................................................................12
Things to Check Before You Call For Service ...........................................................................................13
Care and Cleaning of Your Water Filter.....................................................................................................14
Performance Data Sheet...........................................................................................................................15
Records and Data......................................................................................................................................16
Culligan Limited Warranty .........................................................................................................................17

About This
Manual
This manual:
• familiarizes the operator with the equipment
• explains installation and setup procedures
• provides basic programming information
• explains the various modes of operation
• gives specifications and troubleshooting information
Read this Manual First
Before you operate the Culligan Medallist Plus Iron-OX5™ water filter system, read this manual
to become familiar with the device and its capabilities.
Installation or maintenance done on this system by an untrained service person can cause major damage
to equipment or property damage. Not adhering to the recommended service/maintenance
can cause damage to equipment or property damage.
Safe Practices
Throughout this manual there are paragraphs set off by special headings.
Notice (or Note) is used to emphasize installation, operation or maintenance information which
is important, but does not present any hazard. For example,
NOTICE The nipple must extend no more than 1 inch above the cover plate.
Caution is used when failure to follow directions could result in damage to equipment or property.
CAUTION! Disassembly while under water pressure can result in flooding.
Warning is used to indicate a hazard which could cause injury or death if ignored.
WARNING! Electrical shock hazard! Unplug the unit before
removing the timer mechanism or cover plates!
The CAUTION and WARNING paragraphs are not meant to cover all possible conditions and situations
that may occur. Understand that common sense, caution, and careful attention are conditions which
cannot be built into the equipment. These MUST be supplied by the personnel installing, operating, or
maintaining the system.
Be sure to check and follow the applicable plumbing codes and ordinances when installing this equipment.
Local codes may prohibit the discharge of sanitizing or descaling solutions to drain.
Use protective clothing and proper face or eye protection equipment when handling chemicals or tools.
CAUTION! The Culligan Medallist Plus Iron-OX5™ water filter system is not intended for
use with water that is microbiologically unsafe or of unknown quality without
adequate disinfection either before or after the system.
NOTE: Check with your public works department for applicable local plumbing and sanitation
codes. Follow local codes if they differ from the standards used in this manual. To
ensure proper and efficient operation of the Culligan Medallist Plus Iron-OX5™ water
filter system to your full satisfaction, carefully follow the instructions in this manual.
401035155 A 09/19

Thank You
Welcome To Your New World of Better Living with Culligan Water.
The Culligan® Medallist Plus Iron-OX5™ filter system has been tested
and certified by WQA against NSF/ANSI Standard 372, CSA B483.1,
and NSF/ANSI Standard 42 for the effective reduction of iron up to
500 gallons as verified and substantiated by test data.
Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection before or after the system.
CAUTION! This system is to be supplied with cold water only.
Installation or maintenance done on this system by an untrained service person can cause major
damage to equipment or property damage. Not adhering to the recommended service/maintenance can
cause damage to equipment or property damage.
For installations in Massachusetts, the Commonwealth of Massachusetts Plumbing Code
248 CMR shall be adhered to. Consult your licensed plumber for installation of the system.
This system and its installation must comply with state and local regulations.
The use of saddle valves are not permitted.
If this is your first experience having filtered, conditioned water in your home, you’ll be amazed
at the marvelous difference it makes. We promise that you’ll never want to be without it again.
Congratulations, too, on selecting one of the “first family” of water filters in the prestigious
Culligan Medallist Series. With Culligan’s many years of knowledge and experience in water
treatment, you can be confident that the model you selected has been designed and
engineered to provide years of service with a minimum of care and attention.
Products manufactured and marketed by Culligan International Company (Culligan)
and its affiliates are protected by patents issued or pending in the United States and
other countries. Culligan reserves the right to change the specifications referred to in
this literature at any time, without prior notice. Culligan, Culligan Medallist Series, Cullar,
Filtr-Cleer, Cullneu, AccuSoft, Culligan Man and www.culligan.com are trademarks
of Culligan International Company or its affiliates.
5
01035155 A 09/19

Specifications Culligan Medallist Plus Iron-OX5 Filter
10" Iron-OX5
Control Valve 1" reinforced thermoplastic
Overall Conditioner Height 67"
Media Tank Dimensions (D x H) 10" x 54" tank
Filter Media Type 1.0 cu. ft. Birm
Underbedding
G-50 35 lbs.
Cullsan U 25 lbs.
Capacity¹ 500 gallons
Freeboard² 21"
Max. Clear Water (Soluble) Iron 5 ppm
Minimum Alkalinity 100 ppm
pH for Iron Removal³ 7.0 - 8.5
Service Flow @ Pressure Drop (Clean Bed)
Normal 4 gpm @ 5 psi
Maximum⁴ 6 gpm @ 9 psi
Operating Pressure 20-60 psi
Operating Temperature 33-120° F (1-48° C)
Electrical Requirements 28 Volts/50-60 Hz
Power Consumption, Continuous/Maximum 3 Watts/21.6 Watts
Drain Flow 5.5 gpm
Reconditioning Time
Backwash 15 minutes
Air Draw 40 minutes
Fast Rinse 5 minutes
¹ Capacity based on 4 gpm and 5 mg/L of dissolved iron.
² Measure from top of media bed to top of inlet fitting.
³ Not recommended for Hydrogen Sulfide removal.
⁴ Max flow rates and pressure drop characteristics have not been validated by the Water Quality Association.
The maximum specified flow rate at which the system will deliver treated water, as validated by the
Water Quality Association, is defined as service flow.
601035155 A 09/19

Water Quality
Verify that raw water iron, pH level and alkalinity are within recommended limits.
Iron—A Common Water Problem
The chemical/physical nature of iron found in natural water supplies is exhibited in four general types:
1. Ferrous Iron—Also referred to as “dissolved iron” or “clear water” iron. The Iron-OX5 is rated
to remove up to 5 ppm of this type of iron. If a glass is filled with water containing ferrous iron
the water will initially be clear. Upon standing and being exposed to air the water will gradually
turn cloudy and colored as the ferrous iron oxidizes to ferric iron.
2. Particulate Iron—Also called ferric iron. This type of iron is an undissolved particle of iron.
The Iron-OX5 filter will effectively remove these particles but it is not the intended design
of the system. If there is a significant amount of ferric iron additional filtration treatment
may be required prior to the Iron-OX5.
3. Organic Bound Iron—This type of iron is strongly attached to an organic compound in the water.
The oxidation / filtration process used in the Iron-OX5 will not remove this type of iron.
4. Bacterial Iron and Colloidal Iron—These types of iron, like organic bound iron, will not be removed
by the Iron-OX5 filter.
Principles of Operation - Iron-OX5 Aeration System
The Culligan Iron-OX5 system utilizes the principle of oxidation to convert ferrous iron to ferric iron,
resulting in removal of the iron as a filterable particle. The process is accomplished by water entering
|the filter tank being immediately exposed to an “airhead” at the top of the filter tank to begin the
oxidation process. The filter media acts a catalyst to help complete the oxidation reaction and retain
the precipitated iron. Periodic backwashing purges the accumulated iron particles from the filter tank
and re-classifies the media bed.
After the backwash cycle the Iron-OX5 control valve replenishes the airhead in the filter tank
during the “Air Draw” cycle. During this cycle Air is educted into the filter tank in sufficient volume
for the required airhead. During the “Rinse”cycle the air charge is compressed and stored within
the filter tank and the filter media is rinsed prior to the system returning to the service cycle.
CAUTION! Do not use where the water is microbiologically unsafe or with water
of unknown quality adequate disinfection before or after the unit.
Pressure - Although the system is designed and tested to operate at a maximum pressure of 60
psi, it is not expected that the system should be exposed to such pressure for extended operation.
Culligan recommends following the IAPMO Uniform Plumbing code section 806.2 by installing a
Pressure Regulating Valve if the water pressure is greater than 60 psi. Operating on pressures
above the UPC for extended periods of time can increase the service frequency and failure of
replacement parts. On a private water system, make sure the minimum pressure (when the pump
starts) is greater than 20 psi (140 kPa).
CAUTION! The use of a pressure reducing valve may
limit the flow of water in the household.
Temperature - Do not install the unit where it might freeze, or next to a water heater or furnace
or in direct sunlight. Outdoor installation is not recommended, and voids the warranty and UL Certifications.
Application
7
01035155 A 09/19

Power Loss
The AccuSoft®circuit board is equipped with a Hi-Cap Capacitor and EEPROM memory chip.
The capacitor is capable of maintaining the time, for at least two days, in the event of a
power outage. The EEPROM ensures that the individual programming parameters of your
filter are not lost.
If the power outage lasts long enough to drain the Hi-Cap Capacitor, the control will flash “12:00 PM”
when power is returned to the control. The unit will continue to keep time from the moment power is
restored, and will initiate a full reconditioning cycle at the preset reconditioning cycle time. The time of day
will need to be reset in order to return the reconditioning cycle to its preset time.
If you live in an area where power outages occur with a regular frequency, a battery backup
option is available for ensuring that the time of day is properly maintained. Contact your
Culligan Dealer for more information.
Reconditioning
To initiate a reconditioning cycle at the preset time, press the “REGEN” button. The “REG” light
will light. To initiate an immediate reconditioning cycle, press and hold the “REGEN” button for
at least five seconds. The “REG” will light and blink. An immediate reconditioning cycle will also
occur if a power outage has lasted for more than three hours and the "Immediate" programming
option has been selected. Ask your Culligan Dealer about this feature.
A reconditioning cycle will occur at the programmed Time of Reconditioning if signaled by the flow meter.
The “REG” enunciator on the display will also be lit.
Service
The Culligan Medallist Series® water filter is equipped with a self diagnostic program
to insure optimal operation of your water filter. Should service become necessary,
a phone icon will appear in the display. If this condition occurs, call your local
Culligan Dealer for assistance. The phone icon and error code will be the only
items displayed when service is required on the control.
Operation
801035155 A 09/19

Programming
The timer uses four buttons:
Button Description
Set-up / Enter Key (Status) Advance timer through display options
Reconditioning Key (REGEN) Initiate a reconditioning cycle
Toggle Down Key (“-”) Decrease the setting
Toggle Up Key (“+”) Increase the setting
Time of Day
This setting is used to program the current time of day.
When in this step the display will first show “tod” for two
seconds.
After “tod” is displayed, “12:00 PM” will display (or the
current set time if already programmed) and the minutes
will flash.
The minutes are adjusted with the “+” or “-” key until the
correct value is displayed.
Press the “Regen” key to flash the hours. Adjust with the “+”
or “-” key until the correct time is displayed.
Pressing the “Status” key will move to the next
programming step. Pressing “Regen” will move back to
the minutes adjust.
Time of Reconditioning
This setting is used to program the time at which a
reconditioning cycle is to occur in the delay mode, or in
immediate mode with time clock backup on. The display
will first show “tor” for two seconds.
After “tor” is shown the display will then show the default of
2:00 AM (or the current programmed time of reconditioning
if already set). The time can be adjusted in 30 minute
increments by pressing the “+” or “-” keys.
Pressing the “Status” key will save the setting and
move to the next programming step.
Reconditioning Cycle Interval
This setting is used to set the days between reconditioning
in time clock mode.
The display will show “REG” icon and “dAY” for two seconds and
then display the numbers to change. Adjust the value with the “+” or
“-” keys.
Pressing the “Status” key will save the setting and move to the next
programming step. The reconditioning cycle interval is 3 days for the
Iron-OX5 filter system.
9
01035155 A 09/19

Backwash Time
This setting is used to program the cycle 1 time that
is the backwash cycle. The time of the cycle is kept in
minutes. The display will show “buu” in the display for
two seconds and then the cycle time in the right most
digits. Adjust the value with the “+” or “-” keys.
Pressing the “Status” key will save the setting and
move to the next programming step.
Air Draw Time
This setting is used to set the time in minutes for cycle 2.
This cycle is for the Air Draw cycle that replenishes the
air charge in the Iron-OX5 filter. The display will show
“br” in the left most digits and the cycle time in the right most
digits. Adjust the value with the “+” or “-” keys.
Pressing the “Status” key will save the setting and move
to the next programming step.
Fast Rinse Time
This setting is used to set the time in minutes for cycle 3. The
display will show “Fr” in the left most digits and then
the cycle time in the right most digits. Adjust the value
with the “+” or “-” keys. Pressing the “Status” key will save the
setting and move to the next programming step.
Gallons Capacity Setting
The default gallons capacity setting is 870 gallons. The Iron-OX5
system is rated to remove 5 ppm for up to 500 gallons before
requiring a reconditioning cycle. Average water usage is estimated
to be 50 gallons-per-day for each occupant in a residence. Adjust
the gallons capacity setting accordingly based on the number of
occupants for high iron levels if the rated capacity will be exhausted
prior to the 3-day interval.
Blank Display
After the last programming menu is displayed (menu will vary
depending on mode of operation), pressing status will move to a
blank display screen.
From the ‘blank display’, pressing the “+” key from the blank display
will enter the diagnostics menu.
From the ‘blank display’, pressing the “-” key will enter the statistics menu.
From the ‘blank display’, pressing the “Status” key will exit programming mode
and return to the service mode time display.
The “regen” key is ignored while in the ‘blank display’.
10 01035155 A 09/19
