Culligan 01036140 User manual

Culligan
Salt Free
Conditioner
Owner’s
Guide
01037540_RevB
DCO 190684 02/20 ©2020 Culligan International Company

2
Attention
Culligan
Customer
The installation, service and maintenance of this equipment should be rendered by a qualified and
trained service technician. Your local independently operated Culligan dealer employs trained service and
maintenance personnel who are experienced in the installation, function and repair of Culligan equipment.
We encourage Culligan users to learn about Culligan products, but we believe that product knowledge is
best obtained by consulting with your Culligan dealer. Untrained individuals who use this manual assume
the risk of any resulting property damage or personal injury.
NOTE: This system is not intended for use where water is microbiologically unsafe or
with water of unknown quality.
WARNING! If incorrectly installed, operated or maintained, this product can cause
severe injury. Those who install, operate, or maintain this product should be
trained in its proper use, warned of its dangers, and should read the entire
manual before attempting to install, operate, or maintain this product.
CAUTION! This product is not to be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, unless they have been given supervision or instruction.
CAUTION! Children should be instructed not to play with this appliance.
Products manufactured and marketed by Culligan International Company (Culligan) and its affiliates are
protected by patents issued or pending in the United States and other countries. Culligan reserves the
right to change the specifications referred to in this literature at any time, without prior notice. Culligan,
AquaSensor, Tripl-Hull, and SoftMinder are trademarks of Culligan International Company or its affiliates.
Culligan International Company
9399 West Higgins Road, Suite 1100
Rosemont, Illinois 60018
1-847-430-2800
www.culligan.com
01037540

3
Contents
01037540
About this Manual........................................................................................................................................4
Thank You....................................................................................................................................................5
Specications ..............................................................................................................................................6
Introduction..................................................................................................................................................7
Things to Check Before You Call for Service...............................................................................................8
When and How to Bypass Your Water Conditioner .....................................................................................9
Records and Data......................................................................................................................................10
Culligan Limited Warranty .........................................................................................................................11

401037540
This manual:
• Familiarizes the user with the equipment
• Explains how the Salt Free Conditioner operates
• Gives specifications and troubleshooting information
Read this Manual First
Before you operate the Culligan Salt Free Conditioner, read this manual to become familiar
with the device and its capabilities.
Installation or maintenance done on this system by an untrained service person can cause major
damage to equipment or property damage. Not adhering to the recommended service/maintenance
can cause damage to equipment or property damage.
Safe Practices
Throughout this manual there are paragraphs set off by special headings.
Notice (or Note) is used to emphasize installation, operation or maintenance information which
is important, but does not present any hazard. For example,
NOTICE The clamp and valve will be able to rotate on the tank until pressure is applied.
Caution is used when failure to follow directions could result in damage to equipment or property.
CAUTION! Disassembly while under water pressure can result in flooding.
Warning is used to indicate a hazard which could cause injury or death if ignored.
The CAUTION and WARNING paragraphs are not meant to cover all possible conditions and situations
that may occur. Understand that common sense, caution, and careful attention are conditions which
cannot be built into the equipment. These MUST be supplied by the personnel installing, operating,
or maintaining the system.
Be sure to check and follow the applicable plumbing codes and ordinances when installing this
equipment. Local codes may prohibit the discharge of sanitizing or descaling solutions to drain.
Use protective clothing and proper face or eye protection equipment when handling chemicals or tools.
NOTE: The Culligan Salt Free Conditioner is not intended for use with water that is
microbiologically unsafe or of unknown quality without adequate disinfection
either before or after the system.
NOTE: Check with your public works department for applicable local plumbing and
sanitation codes. Follow local codes if they differ from the standards used in
this manual. To ensure proper and efficient operation of the Culligan Salt Free
Conditioner to your full satisfaction, carefully follow the instructions in this manual.
About this
Manual

5
01037540
Welcome To Your New World of Better Living with Culligan Water.
The Culligan Salt Free Conditioner 9x16” Condo Unit; Salt Free
Conditioner 9x16” Standard Home; Salt Free Conditioner 9x36” Large
Home; Salt Free Conditioner 9x42” Twin Premium Home; Salt Free
Conditioner 14x65” Light Commercial systems are certified by WQA to
NSF/ANSI 372 for lead free compliance and to CSA B483.1 for material
safety and structural integrity. Not certified for contaminant reductions.
For installations in Massachusetts, the Massachusetts Plumbing Code 248 CMR shall be adhered
to. Consult your licensed plumber for installation of this system. This system and its installation
must comply with state and local regulations. The use of saddle valves is not permitted.
Congratulations on selecting one of Culligan’s Salt Free Conditioners. With Culligan’s many years of
knowledge and experience in water treatment, you can be confident that the model you selected has
been designed and engineered to provide years of service with a minimum of care and attention.
Some localities have corrosive water. A water conditioner cannot correct this problem and so its
written warranty disclaims liability for corrosion of plumbing lines, fixtures or appliances. If you
suspect corrosion, your Culligan Dealer has equipment to control the problem.
Thank You

601037540
System Operating and Regulatory Specifications
Culligan Salt Free Conditioner is approved for low lead as defined by NSF 372 and CSA B483.1
for material safety and structural integrity. In order to meet regulatory condition, some operational
parameters must be followed. They include:
1. Culligan recommends following the IAPMO Uniform Plumbing code section 806.2 by installing
a Pressure Regulating Valve if the water pressure is greater than 80 psi. Operating on
pressures above the UPC for extended periods of time can increase the service frequency
and failure of replacement parts. On a private water system, make sure the minimum pressure
(when the pump starts) is greater than 20 psi (140 kPa).
2. Operating temperature between 33° and 120°F or 1°–49°C.
3. Clear (non-turbid) water supplies (Less than 5 NTU).
4. A minimum of a 10 minute rinse of system with CullACT media
(using non-Culligan branded media or different amounts voids WQA certification).
Table 1. System Loading & Performance Information.
System Part
Number
Name CullACT Media
Loading (L)
Pre-filter Max Flow
Rating (gpm)
01036140 Salt Free Conditioner 9x16” Condo Unit 2.0 Not Included 8
01036141 Salt Free Conditioner 9x16” Standard
Home
3.0 Not Included 10
01036142 Salt Free Conditioner 9x36” Large
Home
4.0 5 micron
sediment filter*
15
01036143 Salt Free Conditioner 9x42” Premium
Home with Carbon Filter
4.5 9x42 carbon
filter*
15
01036144 Salt Free Conditioner 14x65” Light
Commercial
7.5 Not Included 20
*Included with System
Ideal Water Conditions Table 2. Ideal Water Conditions.
Flow Direction Uplow - All Salt-Free Conditoners¹
Low Temperature (through system) 41° F
Max Temperature (through water heater) 176° F
pH range 6.5 - 8.5
Max hardness (gpg) 75
Max iron (ppm) 0.3
Max manganese (ppm) 0.05
Max free chlorine (ppm) 3
Max copper (ppm) 1.3
Oil None
Hydrogen sulfide None
¹Activated Carbon Filter Tank included with Twin Premium Home system operates as a Downflow filter.
NOTE: Install systems in new residences/facilities with copper pipe after
six weeks of water use.
Specifications

7
01037540
System Overview
The Culligan Salt Free Conditioner uses Culligan’s CullACT media to help reduce scale build up in hot
water heaters and pipes and on household surfaces and appliances. The Salt Free Conditioner is
an alternative technology to traditional ion-exchange water softeners that use salt. Unlike a water
softener, the Salt Free Conditioner will not remove hardness minerals from the water.
The CullACT media serves as a catalyst to change the physical structure of the hardness minerals in
water that can cause scaling. This process is known as Template Assisted Crystallization (TAC) and it
changes the chemical structure of hardness minerals to a crystallized micro-structure that is resistant
to scale formation. The result is that the water contains the same amount of minerals, but in a form that
is much less likely to cause scaling. Because the mineral content of the water remains unchanged, water
spots can still be present on fixtures and glassware but they will be will be much easier to wipe off
and remove after being treated by the Culligan Salt Free Conditioner.
Frequently Asked Questions
1. Q: Can I test my water for hardness minerals to determine if my Salt Free Conditioner
is working correctly?
A: No. Since Salt Free Conditioners do not remove hardness the test results will be the same.
2. Q: How do I know if my Salt Free Conditioner is working properly?
A: After installation you should notice that water spots on shower walls and fixtures
are easier to wipe off.
3. Q: Will my water taste different after Salt Free Conditioning?
A: No. The Salt Free Conditioner will not change the taste of the water.
If your system includes an Activated Carbon Filter and your water contains chlorine
you will notice an improvement in taste and the elimination of odors associated with chlorine.
4. Q: Is there any maintenance to be done to my Salt Free Conditioner?
A: No regular maintenance needs to be done to the Salt Free Conditioner. If your system
includes a cartridge type pre-filter the cartridge should be changed when water pressure
is reduced or at least every six months.
5. Q: What is the expected service life of the CullACT media used in the Salt Free Conditioner?
A: The CullACT media life expectancy is 3 to 5 years for most water supplies when all
application guidelines are followed.
6. Q: What indicates the CullACT media is near the end of its service life?
A: When it becomes more difficult to clean water spots from shower walls and fixtures
it is most likely time for media replacement. Call your local Culligan dealer for service.
Introduction

801037540
Things to
Check Before
You Call for
Service
If you unexpectedly experience changes in your water, make these simple checks before calling your
Culligan dealer. One of the following conditions may be the reason for your interruption of service.
Bypass Valves
Check to see if they are in the proper position. Cul-Flo-Valv®Bypass, if used, should be in the
“Service” position (see page 9). If hand valves are used, see that inlet and outlet valves are
opened and that the bypass valve is closed.
No Water
If you aren’t getting any water flow at all, make sure your water supply is working. Open a tap ahead of the
conditioner (outside tap) to see if you have any water pressure. If you have water pressure, check the bypass
valve. If it is in the Service position, put it into the Bypass position and call your Culligan dealer for service.
If You Have A Cartridge Filter Installed
If your system has a cartridge type filter installed prior to the Salt Free Conditioner make sure the
cartridge is not clogged as this can be the cause of low water pressure. Replace the filter cartridge
with a new one and check to see if water pressure returns.

9
01037540
Normally, all water except outside lines passes through the water conditioner. There are times when
the water conditioner should be bypassed, using the Cul-Flo-Valv®Bypass, or a three-way bypass
valve. You should bypass:
1. If lines to outside faucets do not bypass the water conditioner, and you do not want to waste
conditioned water on lawn sprinkling or other outside uses.
2. If you are going away on vacation.
Bypass Valve
In the back of Culligan water filter is a Cul-Flo-Valv® Bypass valve. To bypass the unit, turn
the blue knob clockwise. To return to filtered water service, turn the blue knob counter-clockwise.
About 3/8”
Figure 1. Bypass Position.
Bypassed
To BYPASS, turn the blue knob clockwise (see directional arrow on end of knob) until the knob stops as
shown in Figure 1. DO NOT OVERTIGHTEN!
About
1-1/4”
A screwdriver shank
may be used in the
slot as a lever for extra
turning force if needed
Figure 2. Service Position.
Filtered Water
To return to SERVICE, turn the blue knob counter-clockwise (see directional arrow on end of knob) until
the knob stops as shown in Figure 2. DO NOT OVERTIGHTEN!
When and
How to Bypass
Your Water
Conditioner

10 01037540
Records
and Data
Important Data on Your Water Conditioner
It is advisable to have the salesperson or installer fill in the information below for your future reference.
If this has not been done, please ask for it, as it is necessary if you contact your dealer.
Identification
Model Name _________________________________ Catalog No. ____________________________
In & Out Valve Model No. _______________________ In & Out Valve Serial No. __________________
(if applicable)
Date of Installation _____________________________ Tank Serial No. _________________________
Settings
Number of people in household __________________
Tank Size ___________________________________ inches
Water Analysis
Total Hardness _______________________________ (gpg)
Total Iron ____________________________________ (ppm)
pH (acidity) __________________________________
Other ______________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
