Cumberland G54SCL16GA Owner's manual

PNEG-1433
54" Galvanized Slantwall Fan
Model:
G54SCL16GA
Installation and Operation Manual
PNEG-1433
Date: 01-01-15

2PNEG-1433 54" Galvanized Slantwall Fan
Congratulations!
You have just purchased one of the best ventilation fans in the industry. It is designed to give years of high
velocity airflow while saving hundreds of dollars in electrical usage. Please take time to read through this
manual and familiarize yourself with the proper installation methods and operation of the fan.
FEATURES
• One year warranty on parts.
• Consistent airflow through flock grow out.
• Easy assembly and maintenance.
• On-site service and support.
Unpacking
Before beginning installation, check the condition of the fan. Remove the overwrap and packing materials
and examine all parts and components for shipping damage. Any damage incurred must be reported
immediately to the freight carrier.
Airstream Ventilation Systems
Model :G54SCL16GA
Size :54" Galvanized Housing and Cone
Voltage : 115V/230V
Amps :13.0/6.5
Frequency : 50/60 Hz Single Phase

Table of Contents
PNEG-1433 54" Galvanized Slantwall Fan 3
Contents
Chapter 1 Safety .....................................................................................................................................................4
Safety Guidelines ...................................................................................................................................4
Safety Instructions ..................................................................................................................................5
General Safety Information ....................................................................................................................7
Electrical Safety .....................................................................................................................................8
General Safety Statements ....................................................................................................................8
Chapter 2 Safety Decals and Locations ...............................................................................................................9
Chapter 3 Installation Specifications .................................................................................................................10
Chapter 4 Cone Panel Assembly ........................................................................................................................11
Chapter 5 Shutter Installation .............................................................................................................................12
Chapter 6 Electrical Wiring .................................................................................................................................13
Electrical Hook-Up ...............................................................................................................................13
Chapter 7 Operation and Maintenance ..............................................................................................................14
Start-Up and Operation of the Fan .......................................................................................................14
Chapter 8 Troubleshooting .................................................................................................................................15
Chapter 9 Parts List .............................................................................................................................................16
54" Slantwall Fan Parts (G54SCL16GA) (Nominal Version) ................................................................16
Replacement Parts List for Model G54SCL16GA (Nominal Version) ..................................................17
Chapter 10 Warranty ............................................................................................................................................19

4PNEG-1433 54" Galvanized Slantwall Fan
1. Safety
Safety Guidelines
This manual contains information that is important for you, the owner/operator, to know and understand.
This information relates to protecting personal safety and preventing equipment problems. It is the
responsibility of the owner/operator to inform anyone operating or working in the area of this equipment
of these safety guidelines. To help you recognize this information, we use the symbols that are defined
below. Please read the manual and pay attention to these sections. Failure to read this manual and its
safety instructions is a misuse of the equipment and may lead to serious injury or death.
DANGER
WARNING
CAUTION
CAUTION
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
This symbol indicates a potentially hazardous situation which,
if not avoided, may result in serious injury or death.
This symbol indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
This symbol indicates a potentially hazardous situation which,
if not avoided, may result in property damage.
This symbol indicates an imminently hazardous situation
which, if not avoided, will result in serious injury or death.

1. Safety
PNEG-1433 54" Galvanized Slantwall Fan 5
Safety Instructions
Our foremost concern is your safety and the safety of others associated with this equipment. We want to
keep you as a customer. This manual is to help you understand safe operating procedures and some
problems that may be encountered by the operator and other personnel.
As owner and/or operator, it is your responsibility to know what requirements, hazards, and precautions
exist, and to inform all personnel associated with the equipment or in the area. Safety precautions may be
required from the personnel. Avoid any alterations to the equipment. Such alterations may produce a very
dangerous situation where SERIOUS INJURY or DEATH may occur.
This equipment shall be installed in accordance with the current installation codes and applicable
regulations, which should be carefully followed in all cases. Authorities having jurisdiction should be
consulted before installations are made.
Install and Operate Electrical Equipment Properly
Electrical controls should be installed by a qualified electrician
and must meet the standards set by the National Electrical Code
and all local and state codes.
Disconnect and lock out all power sources before installing
wires/cables or servicing equipment.
Electric Shock Hazard
Keep Hands Away from Moving Parts
DO NOT put hand or arm in fan. Rotating parts can crush
and dismember.
DO NOT put any kind of tool inside fan to try and clear debris while
the fan is running. Damage to the equipment will result.
ALWAYS turn OFF and lock out all power sources before
servicing equipment.
Keep all shields and covers in place during operation. Rotating Fan Blade
Read and Obey Product Labels
Read and obey all labels and instructions for products used in
the fan.
Read ALL Labels

1. Safety
6PNEG-1433 54" Galvanized Slantwall Fan
Prepare for Emergencies
Be prepared if fire starts.
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctors, ambulance service,
hospital, and fire department near your telephone. Keep Emergency Equipment
Quickly Accessible
Wear Protective Clothing
Wear close-fitting clothing and safety equipment appropriate
to the job.
Remove all jewelry.
Tie long hair up and back.
Wear safety glasses at all times to protect eyes from debris.
Wear gloves to protect your hands fromsharp edges on plastic
or steel parts.
Wear steel-toed boots to help protect your feet from falling
debris. Tuck in any loose or dangling shoestrings.
A respirator may be needed to prevent breathing potentially
toxic fumes and dust.
Wear a hard hat to help protect your head.
Wear appropriate fall protection equipment when working at
elevations greater than six feet (6').
Eye Protection
Gloves
Steel-Toed Boots
Respirator
Hard Hat
Fall Protection

1. Safety
PNEG-1433 54" Galvanized Slantwall Fan 7
General Safety Information
Users Manual
This manual contains information and instructions essential to the safe installation and use of the
54" Galvanized Slantwall Fan. Read this manual thoroughly before attempting any installation or use of
the fan. Keep this manual in a location that is readily accessible. Failure to read the manual and its safety
instructions constitutes a misuse of the product.
Safety in Handling this Fan
This unit should be installed and maintained by a qualified technician familiar with the use and function of
ventilation fans. This will help prevent damaged components and/or injury. Whenever possible, use
mechanicalliftingequipmentto liftandmove the fanduringinstallation.Whenmanualhandling isrequired,
seek assistance from others and follow safety precautions.
Correct Use of the Slantwall Fan
This fan is designed solely for the purpose of ventilating agricultural buildings. Use of the fan in any other
way is a misuse and may endanger the safety and health of you and others.
Use only genuine Cumberland parts for the installation and use of this fan. Use of other non-genuine parts
is a misuse and may lead to dangerous situations.
This fan is notdesigned for use in atmospheres wherethere is a risk of explosion.Such environments may
include but are not limited to: enclosed areas of high dust concentrations, gas, vapors and fumes. Use in
such an environments is prohibited. If in doubt, contact Cumberland or your dealer.
Safety Guards
This fan contains moving and electrical parts that can cause serious injury and even death if touched.
Guards are placed on the fan for the protection. Operating the fan at any time with guards removed or
incorrectly fitted is a serious misuse of the fan and seriously endangers the safety and the safety
of others.
Safety in Maintenance
While the fanis designed to keepmaintenance to a minimum,some actions such as greasing the bearings
and belt replacement will be required over the life of the fan. Do not attempt any maintenance or repairs
on the fan unless you are competent to do so. Remember that the fan may, in certain situations, operate
under automatic control and startwithout warning. Never attempt any work on the fan without first isolating
it from the power supply and locking out the isolator so that only you can turn the power back ON. For the
safety, follow the guidelines given in the maintenance section on Page 14 of this manual.
Before re-starting the fan, ensure that all electrical enclosures are closed, locked and all guards and other
safety measures are correctly fitted. If in doubt, contact your dealer or Cumberland for assistance.

1. Safety
8PNEG-1433 54" Galvanized Slantwall Fan
Electrical Safety
Provisions for an adequate and safe power supply to the fan unit is essential for the safety and the safety
of others associated with this equipment. Cumberland recommends that a qualified electrician perform all
electricalwiring.All wiring must be installed to in accordance with national, state andlocal electrical
codes. Fans used to ventilate livestock buildings and other rooms where continuous air movement is
essential, should be connected to individual electrical circuits with a minimum of two circuits per room.
Cumberland also strongly recommends the installation of supplementary natural ventilation as well as a
back-up thermostat. There should also be an alarm system on at least one cooling stage. For connection
requirements, refer to the diagram on the motor nameplate and also to the information enclosed with the
AVS fan control used.
For single phase fans, motor overload protection should be provided for each fan. A circuit breaker or slow
blowmotortypefusemustbeused.Asafetycut-offswitch shouldbelocatedadjacentto each fan. Contact
your local distributor for the correct cut-off switch.
The motor must be securely and adequately grounded. This can be accomplished by wiring with a
grounded conduit or a separate ground wire attached to the motor’s ground lug. Do not attempt operation
unless the motor is sufficiently grounded.
Do not kink power cable and never allow cable to come in contact with oil, grease, hot surfaces
or chemicals.
Remember, electrical safety is your responsibility.
General Safety Statements
READ THESE INSTRUCTIONS BEFORE INSTALLATION, OPERATION AND SERVICE
SAVE FOR FUTURE REFERENCES
1. Read and understand this operating manual before installing or operating the 54" Slantwall Fan.
2. Powersupplyshould be OFF andLOCKEDOUTforservice of electrical components. UseCAUTION
in checking voltage or other procedures requiring power to be ON.
3. Never attempt to operate the fan by jumping or otherwise bypassing any safety devices on the unit.
4. Keep the fan clean. Do not allow debris to collect around motors, belts, pulleys or bearings.
5. Use CAUTION in working around the fan’s moving parts.

PNEG-1433 54" Galvanized Slantwall Fan 9
2. Safety Decals and Locations
DC-995 - 2.0" x 4-1/2"
WARNING Shear Point
Located lower right corner inside
lower right corner outside.
DC-1540 - 5-3/4" x 3-3/4"
DANGER High Voltage
WARNING Stay Clear of Rotating Blade
WARNING Flying Objects Hazard
Located lower right corner inside
lower right corner outside.
WARNING
SHEAR POINT
Keep hands clear of moving
parts. Do not operate with
guard removed. Disconnect
and lockout power before
servicing.
DC-995GSI Group Inc. 217-226-4421
Lockout power
before servicing.
HIGH VOLTAGE
Will cause serious
injury or death.
STAY CLEAR OF
ROTATING BLADE
May cause serious injury.
Blade may start
automatically.
Disconnect and
lockout power sources
before servicing.
FLYING OBJECTS
HAZARD
Danger of eye injury.
Wear eye protection.
DANGER
DANGER
WARNING
WARNING
DC-1540The GSI Group 217-226-4421

10 PNEG-1433 54" Galvanized Slantwall Fan
3. Installation Specifications
Construct the opening frame to the correct size (63-3/4" L x 61-3/4" W) as illustrated in the Figure 3A.
Figure 3A
The framing must be able to support the weight of the fan assembly. Ensure the load-bearing portion of
thebottomsillisrigid and properly supported.Positionthefanin front of the openingfromtheinside.Using
at least two (2) people, lift fan housing into the opening. Fasten flanges to framework with the wood
mounting screws provided. Check the fan for vertical position before screwing flanges down. The fan
housing should be flush and level inside of the framing.
IMPORTANT: When installing more than one fan, maintain a minimum of 13" between rough openings to
ensure clearance of cones outside the buildings. The cone’s largest diameter is 68" and
allowances must be made to keep the cones separated. If not sure of sufficient clearance,
contact your local dealer for more information. (See Figure 3B.)
Figure 3B
63-3/4" Tall
61-3/4" Wide
13"
Minimum
