Cumberland PNEG-2054 User manual

54" Galvanized Butterfly Panel
Fan
Installation and Operation Manual
PNEG-2054
Version 2.0
Date: 01-31-20
PNEG-2054

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2PNEG-2054 54" Galvanized Butterfly Panel Fan

Contents
Chapter 1 Safety Precautions ....................................................................................................................5
Safety Guidelines........................................................................................................................5
Cautionary Symbol Definitions......................................................................................................6
Safety Cautions...........................................................................................................................7
Safety Decals ........................................................................................................................... 11
Safety Sign-off Sheet.................................................................................................................12
Chapter 2 General Information ................................................................................................................13
General Description...................................................................................................................13
Main Assemblies.......................................................................................................................14
General Specification ................................................................................................................15
Chapter 3 Assembly ................................................................................................................................17
Framing and Positioning ............................................................................................................18
Fan Cabinet Assembly...............................................................................................................20
Motor and Belt Installation..........................................................................................................22
Tabbed Cone Panel Assembly....................................................................................................24
Butterfly Assembly ....................................................................................................................27
Grill Guard Assembly.................................................................................................................30
Inlet Grill Assembly....................................................................................................................31
Rest Shelf Assembly .................................................................................................................32
Electrical Connection.................................................................................................................33
Chapter 4 Operation and Maintenance ....................................................................................................35
Start-Up Operation ....................................................................................................................35
Maintenance.............................................................................................................................35
Chapter 5 Troubleshooting......................................................................................................................37
Troubleshooting Guide ..............................................................................................................37
Chapter 6 Parts List.................................................................................................................................39
54 in. Outside Mount Butterfly Panel Fan Parts............................................................................39
Limited Warranty - Protein Products .......................................................................................43
PNEG-2054 54" Galvanized Butterfly Panel Fan 3

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
4PNEG-2054 54" Galvanized Butterfly Panel Fan

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines
▪ Cautionary Symbol Definitions
▪ Safety Cautions
▪ Safety Decals
▪ Safety Sign-off Sheet
Safety Guidelines
Safety guidelines are general-to-specific safety rules that must be followed at all times. This manual is
written to help you understand safe operating procedures and problems that can be encountered by the
operator and other personnel when using this equipment. Read and save these instructions.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all
times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable regula-
tions, which must be carefully followed in all cases. Authorities having jurisdiction must be consulted
before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the
equipment.
ST-0001–4
PNEG-2054 54" Galvanized Butterfly Panel Fan 5

Chapter 1: Safety Precautions
Cautionary Symbol Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
Table 1-1 Description of the different cautionary symbols
Symbol Description
This symbol indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in serious injury or death.
This symbol indicates a potentially hazardous situation which, if not
avoided, can result in minor or moderate injury.
This symbol is used to address practices not related to personal
injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005–2
6PNEG-2054 54" Galvanized Butterfly Panel Fan

Chapter 1: Safety Precautions
Safety Cautions
Use Personal Protective Equipment
• Use appropriate personal protective equipment:
Eye
Protection
Respiratory
Protection
Foot
Protection
Hearing
Protection
Head
Protection
Fall
Protection
Hand
Protection
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004–1
Follow Safety Instructions
• Carefully read all safety messages in this manual and safety
signs on your machine. Keep signs in good condition.
Replace missing or damaged safety signs. Be sure new
equipment components and repair parts include the current
safety signs. Replacement safety signs are available from
the manufacturer.
• Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
• If you do not understand any part of this manual or need
assistance, contact your dealer.
ST-0002–1
PNEG-2054 54" Galvanized Butterfly Panel Fan 7

Chapter 1: Safety Precautions
Lifting Hazard
• Single person lift can cause injury.
• Use a mechanical lifting device to lift or move the equipment
during installation.
ST-0021–2
Explosion Hazard
• The fan is not designed for use in atmospheres where the
risk of explosion is present.
• Do not use the fan in enclosed areas of high dust concentra-
tions, flammable gas, vapors or fumes.
ST-0022–1
Keep Hands Away from Moving Parts
• Do not operate the fan with electrical or mechanical guards
removed. Serious injury or death can result.
• Do not put hand or arm in fan. Rotating parts can crush and
dismember.
• Do not put any kind of tool inside the fan to clear debris
while the fan is operating. Damage to the equipment will
result.
• Lock-out power source before making adjustments, clean-
ing, or maintaining equipment.
ST-0020–2
Install and Operate Equipment Properly
• The fan described in this manual is designed solely for the
purpose of ventilating agricultural buildings. Use of the fan in
any other way is a misuse of the equipment and may endan-
ger health and safety.
ST-0023–1
8PNEG-2054 54" Galvanized Butterfly Panel Fan

Chapter 1: Safety Precautions
Install and Operate Fan Properly
• Electrical controls and wiring must be installed by a qualified
electrician and must meet the standards set by the National
Electric Code, Canadian Electrical Code, and all local and
state codes. The fan must be installed and maintained by a
qualified person familiar with the use and function of ventila-
tion fans.
• Lock-out power source before making adjustments, cleaning,
or maintaining equipment.
• Do not operate fan unless the motor is properly grounded.
Grounding can be achieved by wiring with a grounded con-
duit or a separate ground wire attached to the motor ground
lug.
• Do not operate the fan by bypassing any safety device on
the unit.
• Do not kink power cables and do not allow cables to come
into contact with oil, grease, hot surfaces or chemicals.
• Motor overload protection must be provided with each single
phase fan. A circuit breaker or slow blow motor type fuse
must be used. A safety cut-off switch must be located adja-
cent to each fan.
• Fans used to ventilate livestock buildings and other rooms
where continuous air movement is essential must be con-
nected to individual electrical circuits with a minimum of two
(2) circuits per room.
• Installation of supplementary natural ventilation, back-up
thermostat and an alarm system on at least one cooling
stage is recommended. See diagram on motor nameplate
and information provided with fan control (if used) for con-
nection requirements.
ST-0018–2
Sharp Edge Hazard
• This product has sharp edges, which can cause serious
injury.
• To avoid injury, handle sharp edges with caution and always
use proper protective clothing and equipment.
ST-0036–2
PNEG-2054 54" Galvanized Butterfly Panel Fan 9

Chapter 1: Safety Precautions
Maintain Equipment and Work Area
• Do not attempt maintenance or repairs on the fan unless you
are competent to do so. Understand service procedures
before doing work.
• Use only genuine Cumberland parts when maintaining the
fan. Use of other non-genuine parts is a misuse and can
lead to dangerous situations.
• Be aware that the fan may operate under automatic control
and may start without warning.
• Lock-out power source before making adjustments, cleaning,
or maintaining equipment.
• Keep area clean and dry.
• Keep hands, feet, and clothing away from moving parts.
• Keep the fan in proper working condition. Replace worn or
broken parts immediately.
• Keep the fan clean. Do not allow debris to collect around
motors, belts, pulleys or bearings.
• Make sure that all electrical enclosures and guards are
closed and locked before re-starting the fan.
ST-0019–2
10 PNEG-2054 54" Galvanized Butterfly Panel Fan

Chapter 1: Safety Precautions
Safety Decals
The safety decals on your equipment are safety indicators which must be carefully read and understood
by all personnel involved in the installation, operation, service and maintenance of the equipment.
Location Decal No. Decal Description
Left and right
middle, inside
and outside
DC-2180 Non-text fan Warnings
Left middle out-
side and right
middle inside
DC-1540
Danger High Voltage
Warning Stay Clear of Rotat-
ing Blade
Warning Flying Objects
Hazard
Left middle out-
side and right
middle inside
DC-995 Warning Shear Point
To replace a damaged or missing decal, contact us to receive a free replacement.
GSI Decals
1004 E. Illinois St.
Assumption, IL 62510
Tel: [phone]
PNEG-2054 54" Galvanized Butterfly Panel Fan 11

Chapter 1: Safety Precautions
Safety Sign-off Sheet
Below is a sign-off sheet that can be used to verify that all personnel have read and understood the safety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007
12 PNEG-2054 54" Galvanized Butterfly Panel Fan

2General Information
Topics Covered in this Chapter
▪ General Description
▪ Main Assemblies
▪ General Specification
General Description
The structure of the butterfly shutter on the Butterfly Panel Fan improves fan stability and eliminates small
blades that are prone to dust and build-up that reduce air flow. The butterfly shutter also provides protec-
tion against harsh weather conditions such as wind and moisture while the fan is not in use.
During operation, air from the fan forces the shutter doors to open. A magnetic shutter panel ring is used
to stop the shutters from moving when the fan is off.
The Butterfly Panel Fan is belt driven and has a spring loaded belt tensioner to ensure proper belt
tension.
PNEG-2054 54" Galvanized Butterfly Panel Fan 13

Chapter 2: General Information
Main Assemblies
Figure 2-1 54 in. Galvanized Butterfly Panel Fan Main Assemblies
14 PNEG-2054 54" Galvanized Butterfly Panel Fan

Chapter 2: General Information
General Specification
Unpacking
Before beginning installation, check the condition of the fan. Remove the overwrap and packing materials
and examine all parts and components for shipping damage. Any damage incurred must be reported
immediately to the freight carrier.
Models 77-0173, 77-0174 and 77-0175
Size 54 in. Galvanized Butterfly Panel Fan Housing and Cone
Voltage 230V
Amps 8.0
Frequency 50/60 Hz Single Phase
New Fan Model
Part Number
Cabinet
Assembly
Model Part
Number
Description
Bess
Labs Test
Number
Prop RPM @ 0.10 SP
77-0173 12-0621 54" PF Galvanized UE Mega Flow
Butterfly (1 PH / 60 Hz-A) 15334 581
77-0174 12-0622 54" PF Galvanized HF Mega Flow
Butterfly (1 PH / 60 Hz-A) 15335 630
77-0175 12-0623 54" PF Galvanized HE Mega Flow
Butterfly (1 PH / 60 Hz-A) 15336 592
PNEG-2054 54" Galvanized Butterfly Panel Fan 15

NOTES
16 PNEG-2054 54" Galvanized Butterfly Panel Fan

3Assembly
Topics Covered in this Chapter
▪ Framing and Positioning
▪ Fan Cabinet Assembly
▪ Motor and Belt Installation
▪ Tabbed Cone Panel Assembly
▪ Butterfly Assembly
▪ Grill Guard Assembly
▪ Inlet Grill Assembly
▪ Rest Shelf Assembly
▪ Electrical Connection
PNEG-2054 54" Galvanized Butterfly Panel Fan 17

Chapter 3: Assembly
Framing and Positioning
Before You Begin
Make sure that you have enough rough opening and there is enough space so that the fan flanges do not
overlap.
1. Construct the frame opening with a maximum height 60–1/2 in. x maximum width 58–1/2 in. and
minimum height 56–25/32 in. x minimum width 54–5/8 in.
NOTE: Remember that the framing must be able to support the weight of the fan assembly. Ensure
the load bearing portion of the bottom sill is rigid and properly supported.
2. Plan the layout and spacing of fans with cones; spacing fans too close together will cause
interference with the cones.
Figure 3-1 Minimum 54 in. Framed rough opening
NOTE: 3/4 in. has been added for fan clearance.
18 PNEG-2054 54" Galvanized Butterfly Panel Fan

Chapter 3: Assembly
Figure 3-2 Center to center fan spacing with cone
IMPORTANT: The cone diameter is normally 74 in. diameter but the “Arches” in the side cone
panels can be flattened giving a total of 64 in. side to side. See tabbed cone panel
assembly for details. If not sure of sufficient clearance, contact your local distribu-
tor for more information.
PNEG-2054 54" Galvanized Butterfly Panel Fan 19

Chapter 3: Assembly
Fan Cabinet Assembly
1. Install the vertical braces (B) to the venturi (A) with the bolts (C) and nuts (D).
Figure 3-3 Assemble the vertical braces
AVenturi (12–0612–HH) C Bolts (S-7485)
BVertical braces (12–0210–HH) DNuts (S-968)
2. Install the bearing bracket (E) to the vertical braces (G) with the bolts (C) and nuts (D).
Figure 3-4 Assemble the bearing bracket
BVertical braces (12–0210–HH) DNuts (S-968)
C Bolts (S-7485) EBearing bracket (12–0212–HH)
20 PNEG-2054 54" Galvanized Butterfly Panel Fan
