ARCH024-Lumination-Tetra-AL10-Series-Driver-Installation-Guide
WARNING/AVERTISSEMENT
Installation Guide
ARCH024
Product Code: 74913
Description Code: GE060/MV/V12T1-A
(Tetra®AL10 Series)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Risk of electrical shock. Disconnect power before servicing or
installing product.
Risque de choc électrique. Couper l’alimentation avant le dépannage
ou avant l’installation du produit.
Prepare Electrical WiringLED Driver Features
Electrical Requirements
• The LED driver must be supplied with 120/277V, 60Hz
or 240V, 50Hz and connected to an individual properly
grounded branch circuit, protected by a 15 or 20 ampere
circuit breaker.
Grounding Instructions
• The grounding and bonding of the overall system shall
be done in accordance with National Electric Code (NEC)
Article 600 and local codes.
• Class 2 wiring per NEC Article 725 (SELV)
• IP54: Dry or damp location rated
• Conforms to the following standards
This Class [A] RFLD complies with the Canadian standard ICES-005. Ce DEFR de la classe [A] est conforme à la NMB-005 du Canada.
Note: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.

LED.com
© 2023 Current Lighting Solutions, LLC. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
Page 2 of 2
(Rev 06/07/23)
ARCH024-Lumination-Tetra-AL10-Series-Driver-Installation-Guide
Lumination®(Tetra®AL10 Series) Installation Guide
LED Driver Installation
Technical Specications
Min Typical Max
Input Voltage (VAC) 108 120-277 305
Input Frequency (Hz) -50/60 -
Input Current (A) - - 0.6
Output Voltage (VDC) 11.5 12 12.5
Output Current (ADC) 0.8 - 5.0
Output Power (W) - - 60
Environmental Operating Temperature Range -40°C +25°C +60°C*
Environmental Humidity (non-condensing) 0% - 95%
Environmental Storage Temperature Range -40°C - +85°C
Enclosure Specication IP54: Dry or damp location rated
Dimensions 9.5 in. x 1.7 in. x 1.2 in. (240 mm x 43 mm x 30 mm)
Connect the supply wire that is attached to your LED
system to the red (+) and black (-) output wires of the
LED driver as outlined in the “Electrical Connections”
section of your LED system’s Installation Instructions.
To ensure the LED driver load and remote mounting
distances are within the ranges specied in the product
installation guide.
2
Input
White (neutral)
Black (line)
wires
AC line
Red (+)
LED system
Output
wires
Black (-)
Connect the AC line to the black (line) and white (neutral)
input wires of the LED driver using 18-14 AWG (0.82-2.08
mm2) twist-on wire connectors.
1
Input
White (neutral)
Black (line)
wires
AC line
Red (+)
LED system
Output
wires
Black (-)
Note: For remote mounting or loading information refer to the LED System Installation Instructions.
This product is intended to be used as a lamp control gear that is installed after the mains control switch.
Conforms to the following standards:
*Maximum case temperature is 90°C
