Current REEF R24 User manual

Find additional instructions and support at www.current-usa.com
QUICK START
WHAT’S INCLUDED 95W R24 REEF LED Add-On Light
Each 95W R24 REEF LED includes:
Item Description Quantity
A 95W REEF LED Light Fixture 1
B 12V DC Power Supply, UL® Listed 1
C 2
1
D Extension Cable
Cable Wraps
Note:
If your R24 REEF LED is missing
any components, please contact
us directly at www.current-usa.com.
DO NOT RETURN TO RETAILER
A
B
C
D
INSTALLATION
11. Flex Arm Tank Mount
2. Flex Arm Stand Mount
3. Hanging Kit / SlotFrame
4. Swivel Bracket
2
FHigh Output R24 Light HUB 1
G
H
GHub Bracket w/Screws & Tape 1
HmicroUSB Cable 1
H
F
1. Connect the IC Extension Cable (D) to the LED light (A).
2. Mount the HUB Mounting Bracket (G) next to the existing controller using
included screws or tape.
3. Connect the HUB to the LOOP system/controller using the microUSB cable per diagram below.
Connect High Power HUB to
LOOP Mini BLUETOOTH Controller
4. Plug 12V power supply (B) into a GFCI outlet with drip loop, connect LED light and power supply to HUB.
CONNECT TO HUB and CONTROLLER
**This add-on light MUST be used with a LOOP controller (SOLD SEPARATELY). microUSB OUT
High Output
12VDC Power
95W
LED Lights
micoUSB IN
High Power
LED HUB
INST4441 4.25.22
*This ADD-ON LED light MUST be connected to a compatible
LED controller and mounting option (both sold separately).
MOUNT LED LIGHT USING (purchase separately):
Add-on
95W LED
Main
Controller
95W LED
Add-on
95W LED
DC Pump
HUB
Wave Pump
HUB
Connect HUBs via microUSB cable to main controller
52W LED
Add-on
95W LED
52W
LED
Add-on
95W LED
If connecting to an
existing 52W HUB
or controller, use
microUSB cable ONLY.
(DO NOT
plug-in directly)

GFCI Outlet
Drip Loop
P1P3 P2
Drip
Loop
DC
SAFETY WARNINGS / DISCLAIMERS
This product MUST be purchased from an authorized Current-USA
reseller. Visit our website for a list of unauthorized resellers.
Current USA, Inc. warrants this product against defects in
materials and worksmanship for ONE (1) YEAR from the date of
original retail purchase and is none transferable.
This product MUST be powered by a UL or ETL listed power supply.
To avoid possible electric shock, power supply MUST be plugged
into a GFCI wall outlet installed by a certified electrician in
accordance with all local codes. All products must have a drip loop.
WARRANTY
Register your product and nd additonal support at www.current-usa.com
SAVE THESE INSTRUCTIONS
