CyberData 011402 Manual

Quick Reference 931268B © 2018, CyberData Corporation, ALL RIGHTS RESERVED.
The Singlewire/SIP Ceiling Tile Drop-In Speaker is an adapter that is built for a CyberData SIP Speaker.
Parts
(1) Perforated Faceplate (24" [610mm] L x 12" [305mm] W)
FIts 12-inches x 24-inches and 24-inches x 48-inches ceiling tile
(1) Cross Tee
Dimensions
12.00 [304.80]
12.23 [310.76]
23.75 [603.25]
23.98 [609.21]
3.32 [84.4]
23.98 [609.21]
23.75 [603.25]
12.00 [304.80] 12.23 [310.76]
3.32 [84.4]
DIMENSIONS ARE IN
INCHES [MILLIMETERS]
with screws, dimensions
are approximate
The IP Endpoint Company
Installation Quick Reference
Singlewire/SIP Ceiling Tile Drop-In Speaker 
011402

© 2018, CyberData Corporation, ALL RIGHTS RESERVED. 931268B Quick Reference
Procedure
To install the Singlewire/SIP Ceiling Tile Drop-In Speaker, refer to the drawing in the "Installing the Singlewire/SIP
Ceiling Tile Drop-In Speaker" section on the other side of this document. Complete the following steps:
1. Remove the ceiling tile from the ceiling (T-tracks).
2. For 2ft. x 4 ft. tile space, cut the ceiling tile to 35-1/2" long or for a 2 ft. x 2ft. tile space, cut to 11-1/2" long.
3. Place the speaker in the ceiling with the tile support rail crossbar facing the ceiling tile opening.
4. Drop in the tile.
Installing the Singlewire/SIP Ceiling Tile Drop-In Speaker
To Joist
Support
Additional
Eyebolt
Wire
Joist
Joist
OR
Eyebolt
Wire
to
Ceiling/Joist
byUsing Included
Mounting Strap)
Ceiling Tile
Ceiling Grid
Ceiling Grid
Cross Tee
(Included) Opening (See
Quick Reference Guide)
(*Eyebolt & Wire
are Not Provided)
