CyberData InformaCast 011521 Manual

Quick Reference 931744A © 2020, CyberData Corporation, ALL RIGHTS RESERVED.
Parts
FIts 24-inches x 24-inches and 24-inches x 48-inches ceiling tile
(1) InformaCast Enabled 2 x 2 Ceiling Tile Drop-In Speaker Assembly
Dimensions
23.8 [605]
3.0 [77]
23.8 [605]
Dimensions are in Inches [Millimeter]
Contacting CyberData
Sales: [phone] ext. 334
Support: 831-373-2601 ext. 333
Support Website: http://support.cyberdata.net/
RMA Department: [phone] ext. 136
RMA Email: [email protected]
RMA Status: http://support.cyberdata.net/
Warranty Information: http://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA

Phone: [phone]
Fax: [phone]
http://www.cyberdata.net/
The IP Endpoint Company
Installation Quick Reference
InformaCast Enabled 2 x 2 Ceiling Tile Drop-In Speaker 
011521

© 2020, CyberData Corporation, ALL RIGHTS RESERVED. 931744A Quick Reference
Installation Procedure
To install the InformaCast Enabled 2 x 2 Ceiling Tile Drop-In Speaker, complete the following steps while referencing
the figure below:
1. Remove the Ceiling Tile (Below Figure Showing a 2 x 2 Grid) from the Ceiling Grid. Cut the 2 x 4 Ceiling Tile in
Half if using a 2 x 4 Grid.
2. Place the Cross T* in the Middle for Support (Only on a 2 x 4 Grid).
3. Use a Flat Blade Screwdriver to Pry the Seismic Tether Bracket(s) on the 2 x 2 Ceiling Tile Speaker Assembly.
4. Install Eyebolt(s) or Nail(s) to the Joist.
5. Connect the Network Cable to the Network Port and Wire(s) to the Terminal Block, etc. to the 2 x 2 Ceiling Tile
Speaker Assembly.
6. Use Steel Wire(s) to Connect Seismic Tether Bracket(s) to the Eyebolt(s) or Nail(s). Place the 2 x 2 Ceiling Tile
Speaker Assembly on to the Ceiling Grid and the Cross T* (see Step 2).
Installing the InformaCast Enabled 2 x 2 Ceiling Tile Drop-In Speaker
Use a Flat Blade Screwdriver
to Pry Up the Seismic Tether Bracket
Joist
Eyebolt / Nail
*
*
*
*
Speaker Assembly
2 x 2 Ceiling Tile
Steel Wire
*
Remove
Ceiling Tile
Install Cross T (Not Included)
Only on a 2 x 4 Grid
1
2
Drop-in the 2 x 2 Ceiling Tile Speaker Assembly
6
3
4
5
Cross T
