Quick Reference 931695B © 2019, CyberData Corporation, ALL RIGHTS RESERVED.
Installation Quick Reference
Syn-Apps Ceiling Tile Drop-In Speaker

011200
Parts
(1) 1 x 2 Ceiling Tile Speaker Assembly
FIts 12-inches x 24-inches and 24-inches x 48-inches ceiling tile
(1) Cross Tee
Dimensions
23.625 [600]
11.750 [298.5]
3.187 [81.0]
Dimensions are in
Inches [Millimeter]
Contacting Syn-Apps
Corporate Headquarters
Syn-Apps LLC
2812 N Norwalk
Suite 112
Mesa, AZ 85215

Phone: 480-664-6071 / 866-664-6071
Fax: 480-659-8999 / 866-659-8999
Website: www.syn-apps.com

Sales: [email protected]

Support: http://www.syn-apps.com/resources/support
Email: http://www.syn-apps.com/contact-us
© 2019, CyberData Corporation, ALL RIGHTS RESERVED. 931695B Quick Reference
Installation Procedure
To install the Syn-Apps Ceiling Tile Drop-In Speaker, complete the following steps while referencing the figure
below:
1. Remove the Ceiling Tile (Showing a 2 x 2 Grid) from the Ceiling Grid then Cut it in Half.
2. Place the Cross T in the Middle to Support the Weak Side of the Ceiling Tile.
3. Replace the Ceiling Tile on to the Ceiling Grid.
4. Use a Flat Blade Screwdriver to Pry Up the Seismic Tether Bracket(s) on the 1 x 2 Ceiling Tile Speaker
Assembly.
5. Install Eyebolt(s) or Nail(s) to the Joist.
6. Connect the Network Cable to the Network Port and Wire(s) to the Terminal Block, etc. to the 1 x 2 Ceiling Tile
Speaker Assembly.
7. Use Steel Wire(s) to Connect Seismic Tether Bracket(s) to the Eyebolt(s) or Nail(s).Place the 1 x 2 Ceiling Tile
Speaker Assembly on to the Ceiling Grid and the Cross T.
Installing the Syn-Apps Ceiling Tile Drop-In Speaker
Use a Flat Blade Screwdriver
to Pry Up the Seismic Tether Bracket
Joist
Eyebolt / Nail
Cross T
*
*
**
*
Speaker Assembly
2 x 2 Ceiling Tile
Steel Wire
1 x 2 Ceiling Tile
2
8
4
5
1, 3
6
7
