CyberPower PDU83101 User manual

3-Phase
Power Distribution Unit
USER'S MANUAL
Copyright © 2019 Cyber Power Systems, Inc. All rights reserved. K01-0000699-00

Table of Contents
Model List .................................................................1
Input Plug Type .......................................................1
Safety Precautions ..................................................2
Introduction .............................................................3
Package Contents ...................................................................3
Product Features.....................................................................4
Switched Metered by Outlet/Switched
(16/20A Models)............................................................................4
Technical Specifications.............................................................5
Switched Metered by Outlet/Switched
(30/32/50/60A Models)............................................................6
Technical Specifications.............................................................7
Monitored (16/20A Models)......................................................9
Technical Specifications.............................................................10
Monitored (30/32/50/60A Models) ......................................11
Technical Specifications.............................................................12
Basic (16/20A Models)................................................................14
Technical Specifications.............................................................15
Basic (32/50A Models)...............................................................16
Technical Specifications.............................................................17
Installation Guide ....................................................18
PDU Installation ......................................................................18
Power Cord Direction Change - For Selected
PDU Models..............................................................................22
Locking Power Cord - For IEC Type PDU .....................23
Output Power Cord .....................................................................23
Electrical Installation.............................................................23
Network Installation..............................................................24
Operation..................................................................25
Remote Management...........................................................25
Local Management................................................................25
LED Indicators ........................................................................26
Environmental Monitoring (optional)............................26
Device Reset ...........................................................................26
Unattended/Automatic Shutdown .................................26
Firmware Upgrade...................................................27
Troubleshooting ......................................................31
Conformance Approvals.........................................31
FCC Warning...........................................................................31
Customer Service & Warranty ...............................32
Product Registration............................................................32
CyberPower International ..................................................32
Limited Warranty...................................................................32
Appendix A-Hyper Terminal ..................................33
Appendix B-Power Device Network Utility .........33
Overview...................................................................................33
Installation................................................................................33
Launch Program ....................................................................35
Getting Started ......................................................................35
Advanced Settings ...............................................................36
Appendix C-PDU Daisy-Chain Function...............38

1
Model List
Switched Metered by Outlet Series
PDU83101 PDU83105 PDU831 1 1
PDU83102 PDU83106 PDU83401
PDU83103 PDU83107 PDU83402
PDU83104 PDU83108 PDU83403
Switched Series
PDU43101 PDU43105 PDU431 1 1
PDU43102 PDU43106 PDU43401
PDU43103 PDU43107 PDU43402
PDU43104 PDU43108 PDU43403
Monitored Series
PDU33101 PDU33106 PDU331 1 1
PDU33102 PDU33107 PDU331 1 2
PDU33103 PDU33108 PDU33121
PDU33104 PDU33109 PDU33401
PDU33105 PDU331 1 0 PDU33402
Basic Series
PDU13101 PDU13103 PDU13401
PDU13102 PDU13104 PDU13402
Input Plug Type
NEMA L21-20P NEMA L21-30P NEMA L15-20P
NEMA L15-30P IEC 309 16A
3P+N+E
IEC 309 32A
3P+N+E
IEC 309 30A
3P+E
IEC 309 60A
3P+E
Hubbell
CS8365C
IEC 309 20A
3P+N+E
IEC 309 60A
3P+N+E

2
Safety Precautions
Read the following before installing or operating the Power
Distribution Units (PDU):
• Make sure to disconnect all power supply cords before attempting
to service or remove this unit.
• As for overcurrent protection, please be noted that all PDUs with
an input current rating greater than 20A are equipped with flush-
mount branch circuit breakers according to bank numbers.
• Use only the supplied hardware to attach the mounting brackets.
• The PDU must be plugged into a three-wire, grounded outlet
on a circuit that is protected by a fuse or circuit breaker. For
20A PDU series, please use a 20A circuit protector. For 30A
PDU series, please use a 30A circuit protector. For 50A PDU
series, please use a 50A circuit protector. For 60A PDU series,
please use a 60A circuit protector. Connection to any other
type of power outlet may result in a shock hazard.
• Do not use extension cords or adapters with this PDU.
• Never install a PDU or associated wiring or equipment during a
lightning storm.
• Ensure that the power cord, plug, and socket are in good
condition.
To prevent the risk of fire or electrocution, this PDU should be installed
in a temperature and humidity controlled indoor area free of conductive
contaminants. Do not install this PDU where excessive moisture or heat
is present.
This product can expose you to harmful chemicals, including Styrene,
which is known to the State of California to cause cancer; and
Bisphenol-A, which is known to the State of California to cause birth
defects or other reproductive harm.
For more information, please visit www.P65Warnings.ca.gov.
WARNING!!
CAUTION!!

3
Package Contents
PDU Mounting Brackets
with 6 (M4x5) Screws
6 (M5 x 12) Rack Mounting
Screws/Washers
Cord Retention Tray
6 (M3 x 6)
Cord Retention Tray
Mounting Screws
Cable Ties:
Qty. 40 (18 to 27 outlet PDU)
Qty. 50 (30 to 36 outlet PDU)
Qty. 70 (42 to 48 outlet PDU)
RJ45/DB9 Serial Port
Connection Cable
User's Manual, Registration Card,
and Software Download Card
U
s
e
rs
M
a
nu
a
l
Registration
Card
PowerPanel
Management Software
Introduction
Before using, please check to ensure the package contains all the
items shown above. If there are missing parts, please contact your local
CyberPower technical support team for assistance.
Check

4
Front/Rear Panel Description
NEMA Type IEC Type Rear Panel
Product Features:
Switched Metered by Outlet/Switched
(16/20A Models)
M
M
M
L21-20P
PDU83101
-Critical
-Warning
-Normal
Enter
Select
Tx/Rx In / ENV USB
Serial
Out
Link
67812345910 16 17 1811 12 13 14 15 19 20 26 27 2821 22 23 24 25 29 30
L1 L2 L3 L1 L2 L3
A
B
B
B
D
E
F
G
H
C
I
K
L
J
C
C
PDU83102
L21-20P
-Critical
-Warning
-Normal
Enter
Select
Tx/Rx In / ENV USB
Serial
Out
Link
1
23456789
10 11
12 13 14 15 16 17 18 19
2021
22 23242526272829
30
L1-L2 L2-L3 L3-L1 L1-L2 L2-L3 L3-L1
A
B
B
B
C
C
C
D
E
F
G
H
I
K
L
J

5
Product Features:
Switched Metered by Outlet/Switched
(16/20A Models)
Technical Specifications
Model Name PDU83101
PDU43101
PDU83102
PDU43102
PDU83103
PDU43103
PDU83111
PDU43111
PDU83401
PDU43401
Input
Nominal Voltage 208V 200-240V 346-415V
Frequency 50/60Hz
Maximum Input Current 16A UL (Derated) 16A CE
Plug Type NEMA L21-20P NEMA
L15-20P
IEC 309
20A Red
(3P+N+E)
IEC 309
16A Red
(3P+N+E)
Power Cord Type SR (12 AWG)
Power Cord Length 10 ft / 3.05 m
Output
Nominal Voltage 120V 200-240V
Maximum Output Current 16A UL (Derated) 16A CE
Outlet Type (30) NEMA
5-20R (24) IEC 320 C13 (6) IEC 320 C19
Outlet Number 30
Management and Communications
Multifunction LCD Readout Voltage, Frequency, Load, Current, HW/FW Version, Network Information
Software PowerPanel® Business Edition
Networking Yes
Serial Port RJ45
Sensor Capable Optional
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480ft / 3500m
Temperature 23oF to 140oF / -5oC to 60oC 23oF to 131oF /
-5oC to 55oC
Safety Approvals
Certifications UL60950-1, UL62368-1. FCC Class A.
CB, CE
EN55032/24
Class A
* All specifications are subject to change without notice
A. AC Inlet/ AC Power Cord - Used to connect PDU to utility
power or UPS.
B. Outlet Indicator (Switched Series only) - Indicates if the
outlet is providing power to connected equipment.
C. AC Output Receptacles - Provides power for connected
equipment.
D. Status Indicator - Indicates the condition of the PDU (eg.
load or environment status)
E. Multifunction LCD Readout - Displays various PDU
information such as power and load condition.
F. Ethernet Port – Used to connect PDU to the network.
G. ENVIROSENSOR/ Daisy Chain (In) Port (RJ45 modular port)
– Used for ENVIROSENSOR or chaining to previous PDU.
H. USB Port - Used to upgrade the firmware via a flash drive.
I. Serial Port (RJ45 modular port) - Used to connect to a PC
and control the PDU locally via SSH/Telnet.
J. Daisy Chain (Out) Port – Used for chaining to next PDU..
K. Select Button - Used to control the LCD screen and toggle
through the available information options
L. Enter Button - Used to choose selected items, enter to next
level menu or return to previous menu.
M. Bracket Screw Hole - Used to secure the Mounting Pegs (pre-
installed) or Mounting Brackets.

6
Product Features:
Switched Metered by Outlet/Switched
(30/32/50/60A Models)
Front/Rear Panel Description
IEC Type Rear Panel
N
N
N
L21-30P
-Critical
-Wa rning
-Normal
Enter
Select
Tx/Rx In/ ENV USB
Serial
Out
Link
BANK 3 (20A)BANK 2 (20A)BANK 1 (20A)
1
23456789
10 11
12 13 14 15 16 17 18 19
20 21
22 23 24 25 26 27 28 29
30
BANK 1 L1-L2 BANK 2 L2-L3 BANK 3 L3-L1 BANK 1 L1-L2 BANK 2 L2-L3 BANK 3 L3-L1
A
B
B
B
C
C
C
D
D
E
F
G
H
I
J
L
M
K

7
Product Features:
Switched Metered by Outlet/Switched
(30/32/50/60A Models)
Technical Specifications
Model Name PDU83104
PDU43104
PDU83105
PDU43105
PDU83106
PDU43106
Input
Nominal Voltage 200-240V
Frequency 50/60Hz
Maximum Input Current 24A UL (Derated)
Plug Type NEMA L21-30P NEMA L15-30P IEC 309 30A Blue
(3P+E)
Power Cord Type SR (10 AWG)
Power Cord Length 10 ft/3.05 m
Output
Nominal Voltage 200-240V
Maximum Output Current 24A UL (Derated)
Outlet Type (24) IEC 320 C13 (6) IEC 320 C19
Outlet Number 30
Management and Communications
Multifunction LCD Readout Voltage, Frequency, Load, Current, HW/FW Version, Network Information
Software PowerPanel® Business Edition
Networking Yes
Serial Port RJ45
Sensor Capable Optional
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480 ft/3500 m
Temperature 23oF to 140oF / -5oC to 60oC23oF to 131oF /
-5oC to 55oC
Safety Approvals
Certifications UL60950-1, UL62368-1. FCC Class A
* All specifications are subject to change without notice.
A. AC Inlet/ AC Power Cord - Used to connect PDU to utility
power or UPS.
B. Circuit Breaker – Provides overload protection.
C. Outlet Indicator (switched series only) – Indicates if the
outlet is providing power to connected equipment.
D. AC Output Receptacles - Provides power for connected
equipment.
E. Status Indicator - Indicates the condition of the PDU (eg.
load or environment status).
F. Multifunction LCD Readout - Displays various PDU
information such as power and load condition.
G. Ethernet Port – Used to connect PDU to the network.
H. ENVIROSENSOR/ Daisy Chain (In) Port (RJ45 modular port)
– Used for ENVIROSENSOR or chaining to previous PDU.
I. USB Port - Used to upgrade the firmware via a flash drive.
J. Serial Port (RJ45 modular port) - Used to connect to a PC
and control the PDU locally via SSH/Telnet.Select Button
- Used to control the LCD screen and toggle through the
available information options.
K. Daisy Chain (Out) Port – Used for chaining to next PDU.
L. Select Button - Used to control the LCD screen and toggle
through the available information options.
M. Enter Button - Used to choose selected items, enter to next
level menu or return to previous menu.
N. Bracket Screw Hole - Used to secure the Mounting Pegs
(pre-installed) or Mounting Brackets.

8
Product Features:
Switched Metered by Outlet/Switched
(30/32/50/60A Models)
Technical Specifications
Model Name PDU83402
PDU43402
PDU83403
PDU43403
Input
Nominal Voltage 346-415 V
Frequency 50/60Hz
Maximum Input Current 32A CE 35A CE
Plug Type IEC 309 32A Red (3P+N+E) IEC-309 60A Red (3P+N+E)
Power Cord Type SR (10 AWG) SR (8 AWG)
Power Cord Length 10 ft/3.05 m
Output
Nominal Voltage 200-240V
Maximum Output Current 32A CE 35A CE
Outlet Type (24) IEC 320 C13 (6) IEC 320 C19
Outlet Number 30
Management and Communications
Multifunction LCD Readout Voltage, Frequency, Load, Current, HW/FW Version, Network Information
Software PowerPanel® Business Edition
Networking Yes
Serial Port RJ45
Sensor Capable Optional
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480 ft/3500 m
Temperature 23oF to 131oF / -5oC to 55oC
Safety Approvals
Certifications CB, CE EN55032/24 Class A
* All specifications are subject to change without notice.
Technical Specifications
Model Name PDU83107
PDU43107
PDU83108
PDU43108
Input
Nominal Voltage 200-240V
Frequency 50/60Hz
Maximum Input Current 35A UL (Derated)
Plug Type Hubbell CS8365C IEC 309 60A Blue (3P+E)
Power Cord Type SR (8 AWG)
Power Cord Length 10 ft/3.05 m
Output
Nominal Voltage 200-240V
Maximum Output Current 35A UL (Derated)
Outlet Type (24) IEC 320 C13 (6) IEC 320 C19
Outlet Number 30
Management and Communications
Multifunction LCD Readout Voltage, Frequency, Load, Current, HW/FW Version, Network Information
Software PowerPanel® Business Edition
Networking Yes
Serial Port RJ45
Sensor Capable Optional
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480 ft/3500 m
Temperature 23oF to 140oF / -5oC to 60oC 23oF to 131oF / -5oC to 55oC
Safety Approvals
Certifications UL60950-1, UL62368-1. FCC Class A
* All specifications are subject to change without notice.

9
Product Features:
Monitored (16/20A Models)
Front/Rear Panel Description
NEMA Type IEC Type Rear Panel
L
L
L
L21-20P
PDU33101
-Critical
-Wa rning
-Normal
Enter
Select
Tx/Rx In/ ENV USB
Serial
Out
Link
123456789101112 13 14 15 16 17 18 19 20212223242526272829303132 33 34 35 36
A
B
C
D
E
F
G
B
B
H
J
K
I
PDU33401
IEC309 16A 3P+N+E
-Critical
-Wa rning
-Normal
Enter
Select
Tx/Rx In/ ENV USB
Serial
Out
Link
A
B
C
D
E
F
G
B
B
H
J
K
I

10
Product Features:
Monitored (16/20A Models)
Technical Specifications
Model Name
PDU33101
PDU33104
PDU33121
PDU33401
PDU33102
PDU33103
Input
Nominal Voltage 208V 200-240V 346-415 V
Frequency 50/60Hz
Maximum Input Current 16A UL (Derated) 16A UL (Derated)
16A CE
Plug Type NEMA L21-20P NEMA L15-20P IEC 309 16/20A Red
(3P+N+E)
Power Cord Type SR (12 AWG)
Power Cord Length 10 ft/3.05 m
Output
Nominal Voltage
120V
200-240V120/208V
120/208V
Maximum Output Current 16A UL (Derated) 16A UL (Derated)
16A CE
Outlet Type
(36)NEMA 5-20R
(30) IEC 320 C13 (6) IEC 320 C19
(24) NEMA 5-20R (6)
NEMA L6-20R
(2) NEMA 5-20R (36)
IEC 320 C13 (6) IEC 320
C19
Outlet Number
36
36
30
44
Management and Communications
Multifunction LCD Readout Voltage, Frequency, Load, Current, HW/FW Version, Network Information
Software PowerPanel® Business Edition
Networking Yes
Serial Port RJ45
Sensor Capable Optional
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480 ft/3500 m
Temperature 23oF to 140oF / -5oC to 60oC23oF to 131oF /
-5oC to 55oC
Safety Approvals
Certifications UL 60950-1, UL62368-1, FCC Class A
UL 60950-1, UL62368-1,
FCC Class A
CB, CE EN55032/24
Class A
* All specifications are subject to change without notice.
A. AC Inlet/ AC Power Cord - Used to connect PDU to utility
power or UPS.
B. AC Output Receptacles - Provides power for connected
equipment.
C. Status Indicator - Indicates the condition of the PDU (eg.
load or environment status).
D. Multifunction LCD Readout - Displays various PDU
information such as power and load condition.
E. Ethernet Port – Used to connect PDU to the network.
F. ENVIROSENSOR/ Daisy Chain (In) Port (RJ45 modular port)
– Used for ENVIROSENSOR or chaining to previous PDU.
G. USB Port - Used to upgrade the firmware via a flash drive.
H. Serial Port (RJ45 modular port) - Used to connect to a PC
and control the PDU locally via SSH/Telnet.
I. Daisy Chain (Out) Port – Used for chaining to next PDU.
J. Select Button - Used to control the LCD screen and toggle
through the available information options.
K. Enter Button - Used to choose selected items, enter to next
level menu or return to previous menu.
L. Bracket Screw Hole - Used to secure the Mounting Pegs (pre-
installed) or Mounting Brackets.

11
Product Features:
Monitored (30/32/50/60A Models)
Front/Rear Panel Description
IEC Type Rear Panel
M
M
M
IEC 309 30A 3P+E
PDU33107
-Critical
-Wa rning
-Normal
Enter
Select
Tx/Rx In/ ENV USB
Serial
Out
Link
BANK 1 (20A) BANK 2 (20A) BANK 3 (20A)
A
C
B
D
E
F
G
H
C
C
B
B
I
K
L
J

12
Product Features:
Monitored (30/32/50/60A Models)
* All specifications are subject to change without notice.
Technical Specifications
Model Name PDU33105 PDU33106 PDU33107
PDU33108
PDU33109
Input
Nominal Voltage 208V 200-240V
Frequency 50/60Hz
Maximum Input Current 24A UL (Derated) 35A UL
(Derated)
Plug Type NEMA L21-30P NEMA L15-30P IEC 309 30A
Blue (3P+E)
Hubbell
CS8365C
Power Cord Type SR (10 AWG) SR (8 AWG)
Power Cord Length 10 ft/3.05 m
Output
Nominal Voltage 120/208V 200-240V
Maximum Output Current 24A UL (Derated) 35A UL
(Derated)
Outlet Type
(2) NEMA
5-20R (36) IEC
320 C13 (6) IEC
320 C19
(36) IEC 320
C13 (6) IEC 320
C19
(42) IEC 320
C13 (6) IEC 320
C19
(36) IEC 320
C13 (6) IEC 320
C19
(42) IEC 320
C13 (6) IEC 320
C19
Outlet Number 44 42 48 42
48
Management and Communications
Multifunction LCD Readout Voltage, Frequency, Load, Current, HW/FW Version, Network Information
Software PowerPanel® Business Edition
Networking Yes
Serial Port RJ45
Sensor Capable Optional
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480 ft/3500 m
Temperature 23oF to 140oF / -5oC to 60oC23oF to 131oF /
-5oC to 55oC
23oF to 140oF /
-5oC to 60oC
Safety Approvals
Certifications UL60950-1, UL62368-1. FCC Class A
A. AC Inlet/ AC Power Cord - Used to connect PDU to utility
power or UPS.
B. Circuit Breaker – Provides overload protection.
C. AC Output Receptacles - Provides power for connected
equipment.
D. Multifunction LCD Readout - Displays various PDU
information such as power and load condition.
E. Multifunction LCD Readout - Displays various PDU
information such as power and load condition.
F. Ethernet Port – Used to connect PDU to the network.
G. ENVIROSENSOR/ Daisy Chain (In) Port (RJ45 modular port)
– Used for ENVIROSENSOR or chaining to previous PDU.
H. USB Port - Used to upgrade the firmware via a flash drive.
I. Serial Port (RJ45 modular port) - Used to connect to a PC
and control the PDU locally via SSH/Telnet.
J. Daisy Chain (Out) Port – Used for chaining to next PDU.
K. Select Button - Used to control the LCD screen and toggle
through the available information options.
L. Enter Button - Used to choose selected items, enter to next
level menu or return to previous menu.
M. Bracket Screw Hole - Used to secure the Mounting Pegs
(pre-installed) or Mounting Brackets.

13
Product Features:
Monitered (30/32/50/60A Models)
Technical Specifications
Model Name
PDU33110
PDU33402PDU3311 1
PDU33112
Input
Nominal Voltage 200-240V 346-415V
Frequency 50/60Hz
Maximum Input Current
48A UL (Derated)
32A CE48A UL (Derated)
35A UL (Derated)
Plug Type IEC 309 60A Blue
(3P+E)
IEC 309 32A Red
(3P+N+E)
Power Cord Type
SR (6 AWG)
SR (10 AWG)SR (6 AWG)
SR (8 AWG)
Power Cord Length 10 ft/3.05 m 10 ft/3.05 m
Output
Nominal Voltage 200-240V
Maximum Output Current
48A UL (Derated)
32A CE48A UL (Derated)
35A UL (Derated)
Outlet Type
(6) IEC 320 C13 (12) IEC 320 C19
(30) IEC 320 C13
(6) IEC 320 C19
(30)IEC 320 C13
(42) IEC 320 C13 (6) IEC 320 C19
Outlet Number
18
3630
48
Management and Communications
Multifunction LCD Readout Voltage, Frequency, Load, Current, HW/FW Version, Network Information
Software PowerPanel® Business Edition
Networking Yes
Serial Port RJ45
Sensor Capable Optional
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480 ft/3500 m
Temperature 23oF to 131oF / -5oC to 55oC
Safety Approvals
Certifications UL 60950-1, UL62368-1, FCC Class A CB, CE EN55032/24 Class A
* All specifications are subject to change without notice.

14
Product Features:
Basic (16/20A Models)
Front/Rear Panel Description
NEMA Type IEC Type Rear Panel
A. AC Inlet/ AC Power Cord - Used to connect PDU to utility
power or UPS.
B. AC Output Receptacles - Provides power for connected
equipment.
C. Bracket Screw Hole - Used to secure the Mounting Pegs (pre-
installed) or Mounting Brackets.
C
C
C
A
B
B
B

15
Technical Specifications
Model Name
PDU13101
PDU13401
PDU13102
PDU13103
Input
Nominal Voltage
208V
346-415V
208V
200-240V
Frequency 50/60Hz
Maximum Input Current 16A UL (Derated) 16A CE
Plug Type NEMA L21-20P IEC 309 16A Red
(3P+N+E)
Power Cord Type SR (12 AWG)
Power Cord Length 10 ft/ 3.05 m
Output
Nominal Voltage
120V
200-240 V
120/208V
200-240V
Maximum Output Current 16A UL (Derated) 16A CE
Outlet Type
(42)NEMA 5-20R
(36) IEC 320 C13
(6) IEC 320 C19
(21) NEMA 5-20R
(6) NEMA L6-20R
(36) IEC 320 C13
(6) IEC 320 C19
Outlet Number
42
4227
42
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480 ft/ 3500 m
Temperature 23oF to 140oF / -5oC to 60oC 23oF to 131oF / -5oC to 55oC
Safety Approvals
Certifications UL 60950-1, FCC Class A CB, CE EN55032/24 Class A
* All specifications are subject to change without notice.
Product Features:
Basic (16/20A Models)

16
Product Features:
Basic (32/50A Models)
Front/Rear Panel Description
IEC Type Rear Panel
A. AC Inlet/ AC Power Cord - Used to connect PDU to utility
power or UPS.
B. Circuit Breaker – Provides overload protection.
C. AC Output Receptacles - Provides power for connected
equipment.
D. Bracket Screw Hole - Used to secure the Mounting Pegs (pre-
installed) or Mounting Brackets.
D
D
D
CS8365C
BANK 1 (20A) BANK 2 (20A) BANK 3 (20A)
A
B
C
B
B
C
C

17
* All specifications are subject to change without notice.
Technical Specifications
Model Name PDU13104 PDU13402
Input
Nominal Voltage 200-240V 346-415V
Frequency 50/60Hz
Maximum Input Current 35A UL (Derated) 32A CE
Plug Type Hubbell CS8365C IEC 309 32A Red
(3P+N+E)
Power Cord Type SR (8 AWG) SR (10 AWG)
Power Cord Length 10 ft/ 3.05 m
Output
Nominal Voltage 200-240V
Maximum Output Current 35A UL (Derated) 32A CE
Outlet Type (30) IEC 320 C13
(6) IEC 320 C19
(36) IEC 320 C13
(6) IEC 320 C19
Outlet Number 36 42
Physical
Dimensions (H x W x D) 70.5" x 2.2" x 2.2" / 1790mm x 56mm x 55mm
Environmental
Humidity 0 to 95% Non-condensing
Altitude 11480 ft/ 3500 m
Temperature 23oF to 140oF / -5oC to 60oC 23oF to 131oF / -5oC to 55oC
Safety Approvals
Certifications UL 60950-1, FCC Class A
CB,
CE E55032/
24 Class A
Product Features:
Basic (32/50A Models)

18
Installation Guide
PDU Installation
Step 1. PDU Mounting
Align the Keyhole Mounts to the Keyhole Slots on the rack.
Insert and slide down to lock firmly into the place.
If there is no Keyhole Slot on your rack, please choose from the
following methods that is best for your rack deployment to secure
the PDU.
Use the supplied Washers and Rack Mounting Screws to attach the
Mounting Brackets to your existing rack system.
Align the Keyhole Mounts to the Keyhole Slots on the Mounting
Brackets. Insert and slide down to lock firmly into the place.
Method 1
