Cycle Torch Fire stick User manual

1
User Manual EN
FIRE STICK

2
Thank you for purchasing one of our products !
We are truly honored to be able to serve you and provide you with the best
Experience possible. If you’ve enjoyed our product, we would sincerely appreciate
your honest feedback.
To insure maximum experience and safety, familiarize yourself with ALL
aspects of your new Fire Stick and battery system:
I. Safety precaution ..........................................................................................3
II. How to mount Fire Stick ...............................................................................3
III. How to charge Fire Stick................................................................................4
IV. Switching the lighting modes ........................................................................5
V. Model Specifications......................................................................................5
VI. Warranty, Support and Customer Service ....................................................6
I.
II.
III.
IV.
V.
VI.
VII.
If for any reason you are not satisfied, please contact us as soon as
possible at: [e-mail] , so that we can work with you to
solve whatever issues!

3
I. Safety Precaution
1. Never look directly into Fire Stick;
2. Do not place it within children’s reach;
3. Before your trip, please make sure that the Fire Stick is firmly mounted to the
seat post, it lights up, and the light is not blocked by baggage;
5. This product is waterproof under normal daily use and can be used in the
rain. However, do not intentionally submerge it in water.
Failure to follow these cations may expose you to risks, can cause
damage to the light system and will void the warranty !
A lighting system can make riding safer and you more visible, but lights are no
substitute for common sense. Ride within your capability with consideration for
the riding environment.
This product contains components that must be recycled per EU Directive
2002/96/EC and may not be disposed as unsorted municipal waste!
ll. How to mount Fire Stick:
1. Attach the rubber strip to the side A of the Fire Stick’s clips;
2. Hold the Fire Stick with one hand and with another hand secure it with the rubber
strip across the seat post, and fix the rubber strip to the side B;
3. For further details, click the link and watch the VIDEO.
I.
II.
III.
IV.
V.
VI.
VII.
side (A)
side (B)

4
III. How to charge the Fire Stick
How to charge:
1. Remove the rubber cap at the bottom of the Fire Stick;
2. Connect the Fire Stick to your PC or a 5V USB battery charger with the USB
cable. The LED indicator lights up RED, and charging starts;
3. Whenthe LED indicator lights up GREEN, charging is complete. Remove the USB cable;
4. Full charging time: ~ 2 hours
Tips and tricks:
1. When your PC is in sleep state, the Fire Stick cannot be charged;
2. Flashing light of the LED indicator shows that a charging error has occurred.
Remove and reinsert the USB cable, then begin the recharge process again;
3. Charging and lighting times are approximate values, and will vary by
environmental and user conditions.
I.
II.
III.
IV.
V.
VI.
VII.
WARNING: The cable (or other accessories) supplied with the Cycle Torch bike
light MUST be used only to charge the Cycle Torch bike light. The Manufacture
or/and the Seller are not responsible for any damage caused by using the supplied
accessories with other devices, other than Cycle Torch bike lights.
micro USB port
Power Button

5
IV. Switching the lighting modes
Operation Modes: The initial short press on the power button turns on the Fire
Stick. The light will light on the last used mode.
Two short presses on the power button will switch the light between the Flash
Mode and the Steady Mode. Each additional short press on the button switches the
light's intensity in the following order: (1) High; (2) Medium; (3) Low.
To turn off the Fire Stick, press and hold the power button for about three
seconds.
Low Battery Level: The Fire Stick will automatically turn off when the
battery level is too low. This system protects the battery from damage, but since
it draws a small amount of current, and can drain the battery beyond the
minimum voltage for the battery.
Do not wait until the Fire Stick goes completely out as this will greatly
reduce the number of charge cycles that the battery can be used and can
render the battery unusable. It is highly recommended to recharge periodically
the Fire Stick.
Charge your bike light each 2-3 months when stored or not in use to
prevent battery degradation.
V. Model Specifications
Model range: Fire Stick
Water-resistant rear tail light brightness: 50 LM
Waterproof Grade: IP65
Operating modes:
High
Medium
Low
Steady Mode run time (in hours)
3
6
15
Flashing Mode run time (in hours)
6
15
25
Power (in lumens)
50
25
10
I.
II.
III.
IV.
V.
VI.
VII.

6
Light Source: COB LED ultra lumineux
LED lifespan: 50,000 hours
Low power consumption
Battery: lithium-polymère rechargeable
Charge time: ~ 2 hours
Material: high quality aluminum and top-class nylon plastic (ABS), weighing only 30g
Finish: grey
Included accessories:
-Silicone strap which fits all standard seat posts;
-Micro USB charging cable.
VII. Warranty, Support and Customer Service
To register you product please go to http://cycletorch.com and follow the steps.
Our product quality is controlled strictly in accordance within the standards
of CYCLE TORCH quality certification program.
To ensure that all users enjoy the product, we offer one year warranty
within one year from purchase date, under normal use, the consumer will be
provided free warranty service for any quality related problems!
When requesting warranty service, customer should present Order ID .
Warranty Service Exclusions:
A) Any damages that are caused by other than normal use, including, but not
limited to physical damages.
B) Any user modification, repairs or disassembly of the product without
factory authorization.
C) Missing warranty Registration.
I.
II.
III.
IV.
V.
VI.
VII.
For further information concerning warranty conditions or for any
additional issues, please e-mail us at: [e-mail]
