CP-255ID
Multi-Format to DVI Scaler
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 31/01/13 Preliminary Release
VS1 24/06/13 Updated Format and Diagrams

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 1
6. Operation Controls and Functions....... 2
6.1 Front Panel.........................................2
6.2 Rear Panel .........................................3
6.3 Remote Control.................................4
6.4 RS-232 Pin Assignment ......................5
6.5 RS-232 Commands............................6
6.6 OSD Menu..........................................9
6.7 Input Resolution Support ................13
6.8 Output Resolution Support.............14
7. Connection Diagram .......................... 15
8. Specications ...................................... 16
9. Acronyms ............................................. 17

1
1. INTRODUCTION
This Multi-Format to DVI Scaler is capable of scaling and source-
switching from Composite Video, S-Video, PC (VGA) and DVI input
signals to a DVI output. A corresponding analog stereo audio input
can be switched and sent to the stereo audio output with the video
source selection. It has the added benet of control through front
panel buttons, IR remote, or RS-232, and there is on-screen menu
(OSD) providing setting selection and system information. The device
provides a full range of output resolutions, up to 1080p for HDTV
resolutions, and WUXGA (RB) for PC resolutions.
2. APPLICATIONS
• Analog to Digital video signal conversion
• Analog and Digital Source Integration
• Upscaling Standard denition video for High-Denition displays
3. PACKAGE CONTENTS
• Multi-Format to DVI Scaler
• Remote Control (CR-118)
• 5 V/2.6 A DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Source equipment such as PC/Laptop or DVD Player with HDMI to DVI
adaptor, analog sources via standard cabling and DVI display with
active speakers and connection cables.
5. FEATURES
• Supports the conversion of multiple video and audio formats to DVI
• Supports synchronized output for input video and output audio
signals
• Supports 3D de-interlacing, noise reduction and Comb lter
• Supports frame rate conversion
• Supports control via RS-232, IR Remote handset and front panel

2
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
RETNEUNEMIVDCPVSVCREWOP - +
DIGITAL VIDEO SCALER CP-255ID XGA
720P
1 2 4 653
1POWER and LED
Press this button to switch the device ON or to put the device
into STANDBY mode. When the device is connected to an active
power supply, the LED will illuminate and the device will switch ON
automatically.
2IR Window
Receives only the IR signal from the supplied remote control.
3INPUT Buttons and LEDs
Press to directly select the required input. An LED will illuminate to
indicate the currently selected source.
4MENU
Press this button to enter into the on-screen menu (OSD).
5−/+ (Minus/Plus)
Use these buttons to navigate down and up in the on-screen
menu.
6ENTER
Press this button to conrm the selection.
 Note:Pressing'−'(MINUS)andENTERsimultaneouslywill
immediatelyswitchtheoutputresolutionofthedeviceto720p60.
Pressing'+'(PLUS)andENTERsimultaneouslywillimmediatelyswitch
theoutputresolutionofthedevicetoXGA.

3
6.2 Rear Panel
DVI OUT DVI PC SV CV
SERVICE
RS232
RLR/LTUOR/L
IN
DC 5V
1
3 5 6
2 4
1SERVICE
Reserved for manufacturer use only.
2RS-232
Connect to a PC or RS-232 control system to control the device
with RS232 commands (see Sections 6.5).
3DVI OUT
Connect to a DVI display (TV/monitor) for PC signal output or to an
HDMI display with an HDMI to DVI adaptor.
4L/R OUT (3.5mm Mini-jack)
Connect to an amplier or active speaker for audio output in
analog stereo with a 3.5 mm Mini-jack cable.
5INPUTS
DVI: Connect to DVI source such as PC or Laptop or to a HDMI
source with a HDMI to DVI adaptor.
PC: Connect to a PC or Laptop with a D-sub 15-pin cable.
CV and L/R: Connect to a source device such as video/DVD
player for both video and audio.
SV and L/R: Connect to a source device such as video/DVD player
for both S-Video and audio.
L/R: Connect to a source device's analog (L/R) output with a
3.5 mm Mini-jack cable.
6DC 5V
Connect the 5 V DC power supply to the device and plug the
adaptor into an AC wall outlet.

4
6.3 Remote Control
1POWER
Press this button to switch the device
ON or to put the device into STANDBY
mode.
2CV/SV/PC/DVI
Press to directly select the required
input.
3EXIT
Press this button to exit the menu or
the current selection in the on-screen
menu.
4MENU
Press this button to enter the on-
screen menu.
5RESET
Press this button to return the device
to the factory default settings.
6AUTO ADJUST
Press the button to optimize the positioning of the picture (picture
centering) on the screen.
7 ▲▼◄► and OK
Press OK to conrm the selection or use the directional buttons to
navigate the on-screen menus.
CR-118
POWER
CV
SV
PC
EXIT MENU
OK
RESET AUTO
ADJUST
DVI
1
2
4
6
7
3
5

5
6.4 RS-232 Pin Assignment
MULTI-FORMAT TO
DVI SCALER
►
◄
REMOTE CONTROL
PIN Assignment PIN Assignment
1 NC 1 NC
2Tx 2Rx
3Rx 3Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 9600bps
Data bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1

6
6.5 RS-232 Commands
COMMAND DESCRIPTION
S SOURCE 1~4 1=DVI
2=VIDEO
3=S-VIDEO
4=PC
R SOURCE Reports the numerical equivalent for
SOURCE setting (as above)
S OUTPUT 0~25 0=Native
1=640×480
2=800×600
3=1024×768
4=1280×768
5=1360×768
6=1280×720
7=1280×800
8=1280×1024
9=1440×900
10=1400×1050
11=1680×1050
12=1600×1200
13=1920×1080
16=1920×1200
17=480p
18=720p@60
19=1080p@60
20=1080i@60
22=576p
23=720p@50
24=1080p@50
25=1080i@50
R OUTPUT Reports the numerical equivalent for
OUTPUT setting (as above)
S SIZE 0~6 0=OVERSCAN
1=FULL
2=BEST FIT
3=PAN SCAN
4=LETTER BOX
5=UNDER 2
6=UNDER 1
R SIZE Reports the numerical equivalent for SIZE
setting (as above)
S PC AUTO 1 Turn on (1) or off (0) the PC AUTO feature.
S CONTRAST 0~60 Setups the numerical equivalent for
CONTRAST setting (as left)
R CONTRAST Reports the numerical equivalent for
CONTRAST setting

7
COMMAND DESCRIPTION
S BRIGHTNESS 0~60 Setups the numerical equivalent for
BRIGHTNESS setting (as left)
R BRIGHTNESS Reports the numerical equivalent for
BRIGHTNESS setting
S HUE 0~60 Steups the numerical equivalent for HUE
setting (as left)
R HUE Reports the numerical equivalent for HUE
setting
S SATURATION 0~60 Setups the numerical equivalent for
SATURATION setting (as left)
R SATURATION Reports the numerical equivalent for
SATURATION setting
S SHARPNESS 0~30 Setups the numerical equivalent for
SHARPNESS setting (as left)
R SHARPNESS Reports the numerical equivalent for
SHARPNESS setting
S NR 0~3 0=OFF
1=LOW
2=MIDDLE
3=HIGH
R NR Reports the numerical equivalent for the
NOISE REDUCTION setting (as above)
S AUDIO DELAY 0~3 0=OFF
1=40ms
2=110ms
3=150ms
R AUDIO DELAY Reports the numeric equivalent for AUDIO
DELAY setting (as above)
S AUDIO MUTE 0/1 0=ON 1=MUTE
R AUDIO MUTE Reports the numeric equivalent for AUDIO
MUTE setting (as above)
S KEY LOCK 0/1 0=ENABLE 1=DISABLE
R KEY LOCK Reports the numeric equivalent for KEY
LOCK setting (as above)
FW Checks the FIRMWARE version

8
COMMAND DESCRIPTION
S RESET 1 Setups the numerical equivalent for RESET
setting (as left)
S POWER 0/1 0=OFF 1=ON
R POWER Reports the numeric equivalent for POWER
setting (as above)
Note:RS-232commandswillbenotexecutedunlessfollowedwitha
carriagereturnandLF.Commandsarecase-insensitive.

9
6.6 OSD Menu
MAIN MENU SUBMENU 3RD MENU 4TH MENU
DISPLAY OUTPUT Native
640×480 60
800×600 60
1024×768 60
1360×768 60
1280×720 60
1280×800 60
1280×1024 60
1440×900 60
1400×1050 60
1680×1050 60
1600×1200 60
1920×1080 60
1920×1200 60
720×480P 60
1280×720P 60*
1920×1080I 60
1920×1080P 60
720×576P 50
1280×720P 50
1920×1080I 50
1920×1080P 50

10
MAIN MENU SUBMENU 3RD MENU 4TH MENU
DISPLAY SIZE
(For VIDEO input)
OVER SCAN
FULL*
BEST FIT
PAN SCAN
LETTER BOX
SIZE
(For VIDEO input)
UNDER 2
UNDER 1
MODE INFO INFO*
ON
OFF
PC
(For PC input)
AUTO SETUP No
YES
H_POSITION 0~60 (30)
V_POSITION 0~60 (30)
PHASE
CLOCK
WXGA/XGA XGA*
WXGA
RESET NO
YES

11
MAIN MENU SUBMENU 3RD MENU 4TH MENU
COLOR COLOR R 0~1023 (512)
G 0~1023 (512)
B 0~1023 (512)
R OFFSET 0~1023 (512)
G OFFSET 0~1023 (512)
B OFFSET 0~1023 (512)
CONTRAST 0~60 (30)
BRIGHTNESS 0~60 (30)
HUE
(For VIDEO input)
0~60 (30)
SATURATION
(For VIDEO input)
0~60 (30)
SHARPNESS
(For VIDEO input)
0~30 (0)
NR.
(For VIDEO input)
OFF*
LOW
MIDDLE
HIGH
AUDIO VOLUME 0~100
DELAY
(For L/R output)
OFF*
40 ms
110 ms
150 ms
SOUND ON*
MUTE

12
MAIN MENU SUBMENU 3RD MENU 4TH MENU
SETUP FACTORY RESET NO*
YES
KEY LOCK OFF*
ON
POWER SAVE OFF*
ON
INFORMATION INPUT
OUTPUT
REVISION
Note:
• ItemswithAsterisk(*)aretheFactorydefaultsettings.
• Itemsinbracketsarethedefaultvaluesforthosesettings

13
6.7 Input Resolution Support
INPUT RESOLUTION PC DVI/HDMI CV/SV
NTSC - - 
PAL - - 
640×480@60/72/75 Hz (VGA)   -
800×600@56/60/72/75 Hz (SVGA)   -
1024×768@60/70/75 Hz (XGA)   -
152×864 @75 Hz (XGA+ )   -
1280×720@60 Hz   -
1280×768@60 Hz   -
1280×800@60 Hz   -
1280×960@60 Hz   -
1280×1024@60/75 Hz   -
1360×768@60 Hz   -
1400×1050@60 Hz (SXGA+)   -
1440×900@60 Hz (WXGA+)   -
1600×1200@60 Hz (UXGA)   -
1680×1050@60 Hz (RB) (WUXGA)   -
1920×1080@60 Hz   -
1920×1200@60 Hz (RB)   -
480i/576i --
480p/576p --
720p@50/60 Hz --
1080i@50/60 Hz --
1080p@24/30/50/60 Hz --

14
6.8 Output Resolution Support
OUTPUT RESOLUTION DVI/HDMI
Native 
640×480@60 Hz 
800×600@60 Hz 
1024×768@60 Hz 
1360×768@60 Hz 
1280×720@60 Hz 
1280×800@60 Hz 
1280×1024@60 Hz 
1440×900@60 Hz 
1400×1050@60 Hz 
1680×1050@60 Hz 
1600×1200@60 Hz 
1920×1080@60 Hz 
1920×1200@60 Hz 
480p 
576p 
720p@50/60 Hz 
1080i@50/60 Hz 
1080p@50/60 Hz 

15
7. CONNECTION DIAGRAM
DVI OUT DVI PC SV CV
SERVICE
RS232
RLR/LTUOR/L
IN
DC 5V
RS-232 Equipped
PC or Laptop
PC or
Laptop
PC or
Laptop
DVD Player
Analog
Stereo
Input
VGA &
Analog
Stereo
InputDVI Input
DVI
Output
TV or Monitor
AV Receiver
RS-232
Analog Stereo Output S-Video
Input
Power
Supply
Composite
Video
Input
