CYP CMDPH-1A User manual

CMDPH-1A
Mini-DisplayPort to HDMI
Converter
Operation Manual
CMDPH-1A
DRAFT MANUAL

Disclaimers
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes
no commitment to update or to keep current the information
contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright Notice
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2009 by Cypress Technology. All Rights Reserved.
Version 1.0 October 2009
Trademark Acknowledgments
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:

Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.

To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.

Never spill liquid of any kind on or into this product.

Never push an object of any kind into this product through module
openings or empty slots, as you may damage parts.

Do not attach the power supply cabling to building surfaces.

Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.

To protect the equipment from overheating, do not block the slots
and openings in the module housing that provide ventilation.
Revision History
Version No Date Summary of Change
V1 20100607 Preliminary release

Table of Contents
1. Introduction..................................................................................1
2. Application..................................................................................1
3. PackageContent........................................................................1
4. SystemRequirements..................................................................1
5. Features........................................................................................1
6. Specifications..............................................................................2
7. OperationControlandFunctions..............................................3
7.1 Front Panel .......................................................................... 3
7.2 Rear Panel .......................................................................... 3
7.3 Top Panel ............................................................................ 4
8. ConnectionandInstallation..................................................... 5
9. Acronyms......................................................................................6

1
1. Introduction
The external Mini-DisplayPort to HDMI Converter is a high-speed device
that can be congured into 1 or 2 lanes and has a 1.62/2.7 Gbit/s data
rate. This device features differential input signals to HDMI, current-steering
differential output signals and the ability for both PCIe and Mini DisplayPort
to use the same I/O because they are electrically compatible. Also because
this converter has level-shifting it is able to convert signals directly from Mini-
DisplayPort to HDMI.
2. Application
• Mini DP to HDMI signal conversion
• Display PC content on an HDTV
3. Package Content
• Mini DP to HDMI Signal Converter
• Operation Manual
4. System Requirements
Input DP source equipment with USB output and an output HDTV or monitor.
5. Features
• Compliant with HDMI v1.2, HDCP1.1 and DVI1.0
• Supports EDID bypass
■ Link rate: either 2.7Gbit/s or 1.62 Gbit/s per lane, based on link quality
■ Flexible number of lanes, 1 or 2 depending on device capability
■ Freely trade pixel depth with resolution and frame rate
• Supports pixel rates from 25MHz to 165MHz
■ DTV resolutions: 480p ~ 1080p@60 & VGA ~ WUXGA 8 bits
■ PC resolutions: 480p ~ 1080p@60 & VGA ~ WUXGA 8 bits
• Supports 8/10 bits per color RGB color format
• Supports 8/10 bits YCbCr 4:4:4 & YCrCb 4:2:2
• Supports audio sample rate from 32 ~ 192 kHz and sample size from 16 ~
24 bits
• Supports hot plug detection
• Supports HDCP
• Fail safe outputs for backdrive protection
• No re-timing or conguration required
• Integrated display data channel (DDC) level shifters

2
• Level shifter and congurable output for HPD signals received through the
HDMI/DVI connector
• Power and audio sent and received through the USB port, no power supply
is required
• Easy to install and operate
6. Specications
TMDS Clock Frequency 2.7Gbps
Input ports 1 x Mini-DisplayPort (Male type), 1 x USB
Output port 1 x HDMI (Female type)
Input Resolution 480i ~1080p, VGA ~ UXGA
Output Resolution 480i ~1080p, 1920 x 1200@60Hz, VGA~WUXGA
I/O Audio Sample Rate 32 ~ 192 kHz
I/O Audio Support PCM 2CH
ESD Protection Human Body model: ± 8kV (air-gap discharge)
± 4kV (contact discharge)
Dimensions (mm) 81(W) x 25(D) x 11(H)
Weight(g) 22
Chassis Material Plastic
Silkscreen Color Black
Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F
Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (non-condensing)

3
7. Operation Control and Functions
7.1FrontPanel
1
INPUT
① MDP & USB INPUT: Connect these cables to your input sources output
ports in order to send and receive a signal as well as receive power.
7.2RearPanel
1
HDMI OUT
① HDMI OUT: This slot is to connect to the output display such as an HDTV or
a monitor with an HDMI cable.

4
7.3TopPanel
Reset
Dual Mode MDP to HDMI
with USB Audio
1
① RESET: Press this key only when the image is not displayed. Press it
repeatedly until the image turns off.

5
8. Connection and Installation
Apple Apple NB
or
HDTV

6
Acronyms A
Acronym Complete Term
HDCP High-bandwidth Digital Content Protection
MDP Mini DisplayPort

A
