CYP CPLUS-VHHE User manual

CPLUS-VHHE
4K UHD+ EDID Emulator
with HDCP Converter
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2017 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
VR0 07/09/16 Preliminary release
VS1 17/03/17 Added section 8.2 and
updated diagrams

CONTENTS
1. Introduction......................................................1
2. Applications.....................................................1
3. Package Contents ..........................................1
4. System Requirements......................................1
5. Features............................................................2
6. Operation Controls and Functions.................2
6.1 Front and Rear Panels .............................. 2
6.2 Top Panel ................................................... 3
6.3 Side Panel .................................................. 5
6.4 EDID Management ................................... 6
6.4.1 EDID Controller ................................. 6
6.4.2 EDID Analyzer ................................... 7
6.4.3 EDID Creator..................................... 7
6.4.4 System ............................................... 9
7. Connection Diagram ....................................10
8. Specications ................................................11
8.1 Technical Specications ........................ 11
8.2 Video Specications............................... 12
9. Acronyms .......................................................14

1
1. INTRODUCTION
This 4K UHD EDID Emulator with HDCP Converter is a handy device
to include in your HDMI signal tool box. With support for full HDMI 2.0
bandwidth (up to 6Gbits per channel), HDCP analysis and conversion,
EDID management, and YUV 4:2:0 color subsampling, this unit can
help solve or diagnose many common HDMI issues. This unit provides a
quick and easy way to view the status of an HDMI signal. Additionally,
this unit provides a robust EDID management system, allowing the user
to download or upload existing EDIDs, or to create a basic custom
EDID from scratch for use within the unit. The unit’s included hot keys
and simple LED design allows the user to quickly switch between
different congurations while viewing the HDMI status information.
2. APPLICATIONS
• Source and display signal status information
• EDID management
• HDCP verication
• 4K@50/60Hz (4:4:4) color subsampling to 4K@50/60Hz (YUV 4:2:0) for
display compatibility
3. PACKAGE CONTENTS
• 1×EDID Emulator with HDCP Converter
• 1×5V/2.6A DC Power Adaptor
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• The use of “Premium High Speed HDMI” cables is highly
recommended.

2
5. FEATURES
• HDMI input and output with 18Gbps (600MHz) 4K UHD support
• DVI 1.0 compliant with the use of an HDMI-DVI adapter
• HDCP 1.4 and 2.2 compliant
• Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit) &
4096×2160@60Hz (4:4:4, 8-bit)
• Supports pass-through of LPCM 2.0/5.1/7.1, Bitstream, and HD
Bitstream audio formats
• Video source signal and display EDID analysis
• HDCP 2.2 to 1.4 conversion
• EDID selectable between internal, external and user’s custom EDID
• PC-based EDID management tool support
• LED display with easy viewing of the current signal status
• Supports 18Gbps bandwidth bypass and 18Gbps color subsampling
to 10.2Gbps (4K@50/60Hz, 4:4:4 to 4K@50/60Hz, YUV 4:2:0)
• Supports rmware updates via USB
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front and Rear Panels
HDMI IN
DC
5V
SERVICE
HDMI OUT
1 2 3 4
1HDMI IN: Connect to HDMI source equipment such as a media
player, game console or set-top box. DVI sources are supported
with the use of an HDMI to DVI adapter.
Note: 4K UHD sources with HDR or equivalently high-bandwidth
signals require an appropriate compatible display and HDMI
cables in order to achieve the best image quality. The use of

3
“Premium High Speed HDMI” cables is highly recommended.
2DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.
3SERVICE: This slot is used for PC software control, EDID upload and
rmware updates (see section 6.4).
4HDMI OUT: Connect to an HDMI TV, monitor or amplier for digital
video and audio output.
6.2 Top Panel
SYNC
3G
6G
1.4
2.2
HDCP
INT
EXT
USER
EDID
PWR
YUV
420
USB
LINK
1
2
3
4
5
6
1PWR LED: The LED will illuminate to indicate the unit is on and
receiving power.
2SYNC LEDs: These LEDs will illuminate according to the HDMI input
and output signal’s current bandwidth. When the input signal is 6G,
and the “YUV420” feature is active, both LEDs will illuminate. When
the LED is blinking it indicates a problem with the signal.
3HDCP LEDs: These LEDs will illuminate according to the HDCP
encryption status of the HDMI source signal and the reported

4
capability of the connected display. When both input and output
support HDCP 2.2, the “2.2” LED will illuminate. When the input
signal is HDCP 2.2 encrypted but the display only supports HDCP
1.4, both LEDs will illuminate. If an LED is blinking it indicates that the
HDCP link has failed. When the LEDs are not illuminated it indicates
that HDCP is not active. Please reference the chart below for more
detail.
Input's HDCP Output's HDCP Unit's HDCP LEDs
1.4 2.2 Non 1.4 2.2 Non 1.4 LED 2.2 LED
Illuminated
Not
illuminated
  Illuminated
  Blinking
Illuminated Illuminated
  Not
illuminated
Illuminated
  Blinking
 
Not
illuminated
Not
illuminated

 
4EDID LEDs: The LED indicating the currently selected EDID source
will be illuminated.
5YUV420 LED: This LED will illuminate if the YUV420 (4K (4:4:4) to 4K
(YUV 4:2:0)) function is active.
6USB LINK LED: This LED will illuminate when the unit has an active
connection with the PC Control Software via the Micro-USB port.

5
6.3 Side Panel
YUV420 EDID ACTIVE SRC
1 2 3 4
1YUV420: Press this button to enable or disable the YUV 4:2:0 color
subsampling function. When enabled, a 4K (4:4:4) source will be
converted to a 4K (YUV 4:2:0) output signal with the same refresh
rate.
2EDID: Press this button to select the EDID to send to the HDMI
source. The available choices are: Internal, External, and User. The
internal EDID is set to 1080p60 with LPCM 2.0 audio. The External
EDID setting passes the EDID directly from the connected display
to the source. The User EDID is a customized EDID that has been
uploaded to the unit from the PC software. By default, the User
EDID is set to 4K@60 (YUV 4:2:0) with LPCM 2.0 audio.
3ACTIVE SRC: Press this button to force the connected HDMI display
to switch to the input the unit is connected to.
Note: The HDMI display must support CEC in order to perform this
function.
4PINHOLE: This recessed button is reserved for factory use only.

6
6.4 EDID Management
This unit uses an EDID Manager application which allows the user to
copy the EDID from an attached display, edit an existing EDID le
stored on the PC or create a basic EDID from scratch. The EDID can
then be uploaded to the unit for use. Please obtain the EDID Manager
software from your authorized dealer and save it in a directory where
you can easily nd it. Once the le has been downloaded successfully,
double click to execute the application and the EDID Manager’s
window will pop- up.
After launching the software, power the unit on and then connect it
to the PC/laptop using a USB cable. Click on the “Search” button to
detect and connect to the unit. If the unit is successfully connected
the “Search” button will become greyed out and the circle within
the “Link” section will turn green with the connected model’s name
displayed next to it. When you are nished controlling the unit please
press the “Disconnect” button.
6.4.1 EDID Controller
Within the “EDID Controller” tab, the user may select the EDID for the
unit to use (Internal, External or User). The selection will immediately
occur on the unit and the unit’s LED lights will change accordingly.
A stored User EDID may be uploaded from the local PC by rst
clicking the “Open” button to load the EDID’s .bin le from your PC
into the software, and then pressing the “Upload” button to upload

7
the User EDID to the connected unit. Prior to being uploaded, the
software automatically veries that the EDID’s header and checksum
information is correct. Once the upload is successful, the unit’s EDID
mode will automatically switch to User.
It is also possible to download any of the EDIDs currently stored on the
unit. Simply click on the “Internal”, “External” or “User” buttons and the
selected EDID can be downloaded and saved to your connected PC.
6.4.2 EDID Analyzer
Click on the “EDID Analyzer” tab to view the basic EDID details of a
selected EDID. Available EDIDs to view are the Internal, External, or
User EDIDs stored in the unit, or you can view an EDID loaded from a
*.bin le on the PC.

8
6.4.3 EDID Creator
Click on the “EDID Creator” tab to begin designing a new EDID from
scratch (select “Brand New”) or to modify an existing EDID stored on
the PC as a *.bin le (select “Bin Modify”). Selecting “Brand New” will
automatically populate the various EDID elds with basic information
that can be easily edited to match the user’s preferences. Selecting
“Bin Modify” will open a le load window and after the le has been
selected and loaded the EDID elds will be populated with the
information from that le.
The following tabs provide access to a wide range of EDID information
which can be edited:
• Descriptor: This tab allows for the editing of various description and
information elds within the EDID le such as Manufacturer Name,
Monitor Name, etc.
• PC Timing & SD/HD/UHD: These tabs allow for the selection of the
resolutions and refresh rates that the EDID will report as supported.
• Audio1 & Audio2: These tabs allow for the selection of which audio
formats, audio frequencies, channels and speaker locations are
supported.
• Color Space: This tab allows for the selection of which color formats
and bit depths are supported, including BT.2020 and HDR support
options.
• Others: This tab contains options for supporting 3D and dening the

9
CEC address.
Once the user is nished editing or creating an EDID it can be saved
to a *.bin le locally or uploaded directly to the unit using the “Save”
and “Upload” icons respectively.
6.4.4 System
Click on the “System” tab to view the unit’s current rmware version. If
a rmware update is required, please contact your authorized dealer
for the appropriate update le and instructions on how to perform the
update.

10
7. CONNECTION DIAGRAM
HDMI IN
DC
5V
SERVICE
HDMI OUT
POWER
ENTER
PRESET
MENU
/CANCEL
LOCK
ABCDE
FGHIJ
12345
6789
10
+
-
IN
OUT
2.2
isolated
+
70M
4K Source Device
Power Supply
HDMI Input
(4K@50/60Hz, 4:4:4 & HDCP 2.2)
HDMI Output
(4K@50/60Hz, 4:2:0 & HDCP 1.4)
4K Display
HDMI Matrix System
OR
PC/Laptop for
EDID Management
USB

11
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 600MHz/18Gbps
Input Port 1×HDMI
Output Port 1×HDMI
Control Interface 1×USB Micro-B
Supported Resolutions 480i@60Hz - 4K@60Hz (4:4:4, 8-bit)
VGA@60Hz - WUXGA@60Hz (RB)
HDMI Cable Length 10m (1080p@60Hz, 8-bit)
10m (1080p@60Hz, 12-bit)
5m (4K@60Hz, 4:2:0, 8-bit)
3m (4K@60Hz, 4:4:4, 8-bit)
Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human Body Model:
±12kV (Air Discharge)
±8kV (Contact Discharge)
Dimensions 50mm×22.5mm×85mm (W×H×D)
[Case Only]
51mm×22.5mm×97mm (W×H×D)
[All Inclusive]
Weight 58g
Chassis Material Plastic
Silkscreen Color Black
Operating Temperature 0˚C - 40˚C/32˚F - 104˚F
Storage Temperature −20˚C - 60˚C/−4˚F - 140˚F
Relative Humidity 20 - 90% RH (Non-condensing)
Power Consumption 3.3W

12
8.2 Video Specications
Supported PC Resolutions (Hz) Input Output
640×480@60/72/75/85  
720×400@85  
800×600@56/60/72/75/85  
1024×768@60/70/75/85  
1280×720@60  
1280×768@60/75/85  
1280×800@60  
1360×768@60  
1440×900@60  
1600×900@60  
1600×1200@60  
1920×1080@60  
1920×1200@60  
Supported TV Resolutions (Hz) Input Output
720×576i@50  
720×[email protected]/60  
720×[email protected]/60  
720×576p@50  
1280×720p@50/59.94/60  
1920×1080i@50/59.94/60  
1920×[email protected]/24/25/29.97/30/50/59.94/60  
3840×2160p@24/25/30/50/60 (YUV 4:4:4)  
4096×2160p@24/25/30/50/60 (YUV 4:4:4)  
3840×2160p@50/60 (YUV 4:2:0)  
4096×2160p@50/60 (YUV 4:2:0)  

13
Resolutions (Hz)
Input Output
Color
Space
Bit
Depth
Bypassed
Output
YUV 4:2:0
Conversion
2160p@50/60 RGB 4:4:4 8-bit  
10-bit
12-bit
YUV 4:4:4 8-bit  
10-bit
12-bit
YUV 4:2:0 8-bit 
10-bit 
12-bit 
2160p@24/25/30 RGB 4:4:4 8-bit 
10-bit 
12-bit 
YUV 4:4:4 8-bit 
10-bit 
12-bit 

14
9. ACRONYMS
ACRONYM COMPLETE TERM
CEC Consumer Electronics Control
DVI Digital Visual Interface
EDID Extended Display Identication Data
HD High-Denition
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDR High Dynamic Range
LPCM Linear Pulse-Code Modulation
PC Personal Computer
UHD Ultra-High-Denition
USB Universal Serial Bus
VGA Video Graphics Array (640×480@60Hz)
WUXGA Wide Ultra Extended Graphics Array
(1920×1200@60Hz)

CYPRESS TECHNOLOGY CO., LTD.
www.cypress.com.tw
