CYP CS-802D User manual

CS-802D
HD High Resolution Scaler
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 03/09/13 Preliminary Release
VS1 06/02/14 Updated text/Diagrams

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 1
6. Operation Controls and Functions....... 2
6.1 Front Panel.........................................2
6.2 Rear Panel .........................................3
6.3 Remote Control.................................4
6.4 RS-232 Protocols ................................5
6.5 RS-232 Commands............................5
6.6 OSD Menu..........................................7
7. Connection Diagram ............................ 9
8. Specications ...................................... 10
8.1 Technical Specications ................10
8.2 Input Resolution Supports...............11
8.3 Output Resolution Supports ...........13
9. Acronyms ............................................. 13

1
1. INTRODUCTION
This HD High Resolution Scaler can switch and convert Dual-Link
DVI, Mini-DisplayPort and PC/Component inputs to a HDMI output ,
along with their associated audio signals. With the ability to scale a
wide range of resolutions, the operation of all features can be easily
handled through on-panel controls, IR remote control, or by RS-232
protocol.
2. APPLICATIONS
• Scale Dual-Link DVI, Mini-DisplayPort and PC/Component inputs to
HDMI output
• Convert VGA, Component, Mini-DisplayPort and Dual-Link DVI
signals to HDMI
• Commercial presentation switcher/scaler
3. PACKAGE CONTENTS
• HD High Resolution Scaler
• D-sub 15-pin to 3 RCA Phono adaptor
• 5 V/2.6 A DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Dual-Link DVI/Mini-DisplayPort/PC sources and output to a HDMI
display.
5. FEATURES
• Supports Component Video input resolutions up to 1080p@50/60 Hz,
Dual-Link DVI and Mini-DisplayPort up to 2560×1600@60 Hz (RB) and
PC up to 1920×1200@60/75 Hz
• Supports digital and analog audio bi-directional conversion,
extraction and insertion for the audio signals from individual inputs
• Supports Component Video input with supplied D-sub 15-pin to 3
RCA phono adaptor

2
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
ENTER
MENU/
OPTICAL
OUT
IN
AUDIO HDMI OUT
DC 5V
POWER
OPTICAL AUDIO
XGA
720P
3
6
2 4
7
5 8 9 101
1MENU/ENTER Button: Press this button to ENTER the OSD menu. Press
again to conrm the selection.
 Note:Pressing'−'(MINUS)and'ENTER'simultaneouslywill
immediatelyswitchtheoutputresolutionofthedeviceto
720p@60Hz.Pressing'+'(PLUS)and'ENTER'simultaneouslywill
immediatelyswitchtheoutputresolutionofthedevicetoXGA.
2MINUS (-)/IN Button: When in the OSD menu, press this button
repeatedly to move down through the menu. When not in the OSD
menu, press this button to quickly select the required input.
3PLUS (+)/OUT Button: When in the OSD menu, press this button
repeatedly to move up through the menu. When not in the OSD
menu, press this button to quickly select the required output
resolution.
4OPTICAL IN: Digital audio Toslink input. Use this input to connect to
a source with an OPTICAL cable.
5AUDIO IN: Analog audio 3.5mm mini-jack input. Use this input to
connect to analog source with RCA cable.
6OPTICAL OUT: Digital audio TOSlink output. Use this output to
connect to an amplier or active speakers to an optical digital
input with an OPTICAL cable.
7AUDIO OUT: Analog audio 3.5mm mini-jack output. Use this output
to connect to active speakers or an amplier with an RCA cable.
8HDMI OUT: Connect to a HDMI equipped TV/monitor for display of
the source signal.

3
9IR Window: Receives the IR signal from the supplied IR Remote only.
10 DC 5V and POWER LED: Connect the 5V DC power supply into the
unit and plug the adaptor to AC wall outlet. Once the system turns
on the LED will turn RED.
6.2 Rear Panel
RS232
SERVICE MDP
Dual-Link DVI PC/COMP
IN
21 3 4 5
1RS232: Connect to a PC or RS-232 control system with a D-Sub 9-pin
cable for RS-232 control.
2SERVICE: Manufacturer use only.
3MDP IN: Connect to a DisplayPort source device such as a PC or
laptop with a mini-DisplayPort cable.
4Dual-Link DVI IN: Connect to a DVI source device such as a PC or
Laptop with a DVI cable.
5PC/COMP IN: Connect to a VGA source such as a PC/Laptop
source equipment with D-Sub 15-pin cable or to a Component
source with the supplied D-Sub 15-pin to 3 RCA phono adaptor for
component signal input.

4
6.3 Remote Control
1POWER: Press to turn the system ON/
OFF.
2VIDEO IN: Press the required key to
directly select the video source (DVI/
MDP/PC/COMP).
3AUDIO IN: Press the required key
to directly select the audio source
(AUDIO/OPTICAL/MDP) or to MUTE
the system.
4MENU: Press this button to ENTER the
OSD menu.
5EXIT: Press the EXIT the OSD menu.
6 ENTER and ▲/▼/◄/►: Press ENTER to conrm the selection. Press
the arrow keys to navigate the OSD menu.
7INFO: Press to show the input and output resolution information.
8OUTPUT: Press to show the output resolution table.
9NATIVE: Press to switch to the native resolution.
MDP
MENU
OUTPUTINFO
DVI
PC
AUDIO
MUTE
EXIT
NATIVE
MDP
COMP
OPTICAL
ENTER
CR-123
AUDIO IN
VIDEO IN
2
3
4
8
9
5
1
7
6

5
6.4 RS-232 Protocols
SCALER REMOTE CONTROLLER
Pin Denition Pin Denition
1 NC
►
◄
1 NC
2TxD 2RxD
3RxD 3TxD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200 bps
Data Bit: 8 bits
Parity: None
Stop Bit: 1 bit
Flow Control: None
6.5 RS-232 Commands
COMMAND DESCRIPTION
POWER ? Power Status
POWER ON Power On
POWER OFF Power Off
VIDEO ? Video Input Source
DVI Video Input in DVI
MDP Video Input in Mini-DisplayPort

6
COMMAND DESCRIPTION
PC Video Input in PC
COMP Video Input in Component
AUDIO ? Audio Input Source
AUDIO Audio Input in AUDIO
OPTICAL Audio Input in OPTICAL
MDPA Audio Input in MDP
MUTE ? Mute Status
MUTE ON Mute On
MUTE OFF Mute Off
INFO ? Info.OSD Status
INFO ON Info.OSD On
INFO OFF Info.OSD Off
INFO DISPLAY Info.OSD On/Off
OUTPUT ? Output Status
480P Output in 480P
720P Output in 720P
1080P Output in 1080P
VGA Output in VGA (640x480)
SVGA Output in SVGA (800x600)
XGA Output in XGA (1024x768)
SXGA Output in SXGA (1280x1024)
UXGA Output in UXGA (1600x1200)
WUXGA Output in WUXGA (1920x1200)
WXGA Output in WXGA (1280x800)
NATIVE Output by Native
EDID ? EDID Status

7
COMMAND DESCRIPTION
EDID INT EDID By Internal
EDID EXT EDID By External
FEEDBACK ? Key Feedback Status
FEEDBACK ON Key Feedback Enable
FEEDBACK OFF Key Feedback Disable
STATE ? Video Input Signal Status
VERSION ? Firmware Version
DEFAULT Reset to Factory Default
About ? About CS-802D
Note:Anycommandswillnotbeexecutedunlessfollowedbya
carriagereturn.Commandsarenotcase-sensitive.
6.6 OSD Menu
FIRST LEVEL SECOND LEVEL THIRD LEVEL
Input Video PC
COMP
DVI
MDP
Exit
Input Audio AUDIO
Optical
MDP
Mute
Exit

8
FIRST LEVEL SECOND LEVEL THIRD LEVEL
Output Resolution 720x480P
1280x720P
1920x1080P
640x480
800x600
1024x768
1280x1024
1600x1200
1920x1200
1280x800
By Native
Exit
Misc. Setup EDID Mode Internal
External
Exit
Info. OSD Mode Off
On
Exit
About CS-802D FW Ver.
Factory Reset System Reset
Exit
Exit

9
7. CONNECTION DIAGRAM
ENTER
MENU/
OPTICAL
OUT
IN
AUDIOHDMI OUT
DC 5V
POWER
OPTICALAUDIO
XGA
720P
RS232
SERVICE MDP
Dual-Link DVI PC/COMP
IN
Laptop
RS-232
DVI
Input
VGA Input
(D-sub15-pin)
Digital Audio
Input
(Optical)
Analog Stereo
Input (3.5mm
Mini-jack)
HDMI
Output
Power
Supply
Mini
DisplayPort
Input
PCPC
HDTVAmplier
Digital Audio
Output
(Optical)
Analog Stereo
Output (3.5mm
Mini-jack)

10
8. SPECIFICATIONS
8.1 Technical Specications
Mini DisplayPort Video
Bandwidth
2.7 Gbps & 1.62 Gbps/Lane
Input Ports 1×Dual-Link DVI, 1×Mini DisplayPort,
1×D-sub 15-pin, 1×Optical, 1×3.5mm Mini-
jack
Output Ports 1×HDMI, 1×Optical, 1×3.5mm Mini-jack
Power Supply 5V/2.6 A DC (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Dimensions 141 mm (W)×179 mm (D)×38 mm (H)
Weight 700 g
Chassis Material Aluminum
Color Black
Operating Temperature 0 ˚C ~ 40 ˚C / 32 ˚F ~ 104 ˚F
Storage Temperature −20 ˚C ~ 60 ˚C / −4 ˚F ~ 140 ˚F
Relative Humidity 20 ~ 90 % RH (non-condensing)
Power Consumption 9 W

11
8.2 Input Resolution Supports
INPUT RESOLUTION DVI MDP PC COMP
640x350@85   
640x400@85   
720x400@85   
VGA640x480@60/72/75/85   
SVGA800x600@56/60/72/75/85/120RB   
848x480@60Hz   
XGA1024x768@43i/60/75/85/120R   
1280x720@60   
1280x768@60R/60/75/85/120R   
1280x800@60R/60/75/85/120R   
1280x960@60/85   
1280x1024@60/75/85   
1360x768@60/120R   
1366x768@60/60R   
SXGA+1400x1050@60R/60/75   
WXGA+1440x900@60R/60/75/85   
1600x900@60R   
UXGA1600x1200@60   
WSXGA1680x1050@60/60RB   
1792x1344@60/75  
1856x1392@60/75 
1920x1080@60   

12
INPUT RESOLUTION DVI MDP PC COMP
1920x1200@60/60RB   
(60RB only)
1920x1440@60  
720x480I/P 
720x576I/P 
720I/P@24/25/30/50/60 
1080I@50/60 
1080P@24/30/50/60 
2048x1080@@50/60   
2048x1152@@60R  
2560x1600@60R  

13
8.3 Output Resolution Supports
OUTPUT RESOLUTION HDMI
640x480 
800x600 
1024x768 
1280x1024 
1600x1200 
1920x1200@60 
1280x800 
720x480P 
1280x720P (Default)
1920x1080P 
Note:Whentheoutputresolutionissetto'ByNative'butitdoesnot
matchthebuilt-insupportedresolution,theoutputresolutionwill
automaticallybesettothedefaultof1280×720p.
9. ACRONYMS
ACRONYM COMPLETE TERM
COMP Component Video
DVI Digital Visual Interface
HDMI High-Denition Multimedia Interface
MDP Mini DisplayPort

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
20121217 MPM-CS802D
