CYP CPLUS-V4H1HP User manual

CPLUS-V4H1HP
4K UHD+ 4×1 HDMI Switcher
with IP Control
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2017 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 17/04/16 Preliminary release
VS0 04/07/17 Updated text/diagrams

CONTENTS
1. Introduction......................................................1
2. Applications.....................................................1
3. Package Contents ..........................................1
4. System Requirements......................................1
5. Features............................................................2
6. Operation Controls and Functions.................2
6.1 Front Panel ................................................. 2
6.2 Rear Panel.................................................. 3
6.3 Remote Control......................................... 3
6.4 IR Cable Pin Assignments ......................... 4
6.5 RS-232 Protocol.......................................... 4
6.6 RS-232 and Telnet Commands ................ 5
6.7 Telnet Control ............................................ 8
6.8 WebGUI Control ........................................ 9
6.8.1 Device Discovery APP ..................... 9
6.8.2 WebGUI Control Page .................. 10
7. Connection Diagram ....................................14
8. Specications ................................................15
8.1 Technical Specications ........................ 15
8.2 Video Specications............................... 16
9. Acronyms .......................................................17

1
1. INTRODUCTION
This 4×1 HDMI switcher is the most advanced HDMI solution for true
Ultra High-Denition signal routing. This unit allows for the switching
of any of four 18Gbps HDMI input signals to a single 18Gbps HDMI
display device. Resolutions up to 4096×2160@60Hz (4:4:4), 16-bit
Deep Color, HDR (High Dynamic Range), HD audio as well as other
features dened by the HDMI 2.0 specication are supported. Multiple
control interfaces are available including RS-232, Ethernet (WebGUI &
Telnet), IR remote and front-panel buttons making operation easy and
intuitive.
2. APPLICATIONS
• Entertainment Rooms & Home Theaters
• Showrooms & Demo Rooms
• Lecture Room & Hall Presentations
• Public Commercial Displays
3. PACKAGE CONTENTS
• 1×4 by 1 HDMI Switcher
• 1×Remote Control (CR-72)
• 1×IR Extender Cable
• 1×5V/2.6A DC Power Adaptor
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.

2
5. FEATURES
• HDMI 2.0 with 18Gbps 4K UHD support, single-link DVI 1.0 compliant
• HDCP 2.2 and 1.4 compliant
• 4 HDMI inputs and 1 HDMI output
• Supports HDTV resolutions up to 4K UHD (3840×2160@50/60Hz &
4096×2160@50/60Hz)
• Supports data rates up to 18Gbps and Deep Color (16-bit) up to
1080p
• Supports pass-through of LPCM 7.1, Bitstream and HD Bitstream
audio formats
• Remotely controllable via Ethernet (WebGUI & Telnet), RS-232 and
IR remote
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
HDCP2.2
+
POWER SYNC
UHD 4 TO 1 SWITCHER
INPUT 1234
1 2 53 4 6
1IR WINDOW: Accepts IR signals from the included IR remote for
control of this unit only.
2POWER: Press this button to power on the unit or place it into stand-
by mode.
Note: Ethernet and RS-232 remain active while the unit is in stand-
by mode.
3POWER LED: The LED will illuminate RED to indicate the unit is
receiving power but is in stand-by mode. It will illuminate GREEN to
indicate that the unit has been turned on.
4SYNC LED: This LED will illuminate GREEN when a stable connection
with an output device is detected.

3
5INPUT: Press this button to sequentially switch through the 4
available inputs.
6INPUT LED 1~4: These LEDs will illuminate GREEN to indicate which
of the 4 sources are currently selected.
6.2 Rear Panel
1234
HDMI IN HDMI OUT SERVICE CONTROL RS-232 IR IN DC 5V
21 3 4 5 6 7
1HDMI IN 1~4: Connect to HDMI source equipment such as a media
player, game console or set-top box. DVI source equipment may
be connected by using an HDMI to DVI adapter.
2HDMI OUT: Connect to HDMI TVs, monitors or ampliers for
digital video and audio output. DVI display equipment may be
connected by using an HDMI to DVI adapter.
3SERVICE: This slot (USB 2.0) is reserved for rmware update use only.
4CONTROL: Connect directly, or through a network switch, to your
PC/laptop to control the unit via Telnet/WebGUI.
5RS-232: Connect directly to your PC/laptop to send RS-232
commands to control the unit.
6IR IN: Connect to the provided IR Extender to extend the IR control
range of the unit. Ensure that the remote being used is within direct
line-of-sight of the IR Extender.
7DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.
6.3 Remote Control
1POWER: Press this button to power on the unit or place
it into stand-by mode.
2INPUT 1~4: Press 1 through 4 to select the input source. CR-72
POWER
INPUT
34
12
1
2

4
6.4 IR Cable Pin Assignments
3
1
2
IR Signal
Power
Ground
IR Extender
6.5 RS-232 Protocol
UNIT
►
◄
REMOTE SYSTEM
Pin Denition Pin Denition
1 NC 1 NC
2TxD 2RxD
3RxD 3TxD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rates: 115200bps
Data Bits: 8
Parity Bits: None
Stop Bit: 1
Flow Control: None

5
6.6 RS-232 and Telnet Commands
COMMAND DESCRIPTION AND PARAMETERS
HELP Displays all available commands.
?Displays all available commands.
P0 Turn unit’s power off. (Stand-by mode)
P1 Turn unit’s power on.
INNAME N1 N2 Set the name of input N1 to N2.
N1 = 1~4 [Input number]
N2 = {name} [8 characters max]
INNAME N1 Show the input name of N1.
N1 = 1~4 [Input number]
INNAME Show the names of all inputs.
OUTNAME N1 Set the output name to N1.
N1 = {name} [8 characters max]
OUTNAME Show the current output name.
OUT N1 Set the input to be routed to the output.
N1 = 1~4 [Input number]
OUT Show the current input routing.
SOURCEDET Show all source information.
SINKINFO Show all sink information.
HDCPIN N1 N2 Set the HDCP mode for input N1.
N1 = 1~4 [Input number]
Available values for N2:
0 [Standard]
1 [Apple Mode]
HDCPIN N1 Show the HDCP settings for input N1.
N1 = 1~4 [Input number]
HDCPIN Show all current HDCP input settings.

6
COMMAND DESCRIPTION AND PARAMETERS
EDIDMODE N1 Set the EDID mode.
Available values for N1:
0 [Appoint]
1 [All]
EDIDMODE Show the current EDID mode setting.
EDIDALL N1 Set the EDID to use in “All” mode.
Available values for N1:
0 [SINK]
1 [720P]
2 [1080P]
3 [4K_3G]
4 [4K_Y420]
5 [4K_6G]
EDIDALL Show the current EDID selection for “All”
mode.
EDIDIN N1 N2 Set the EDID to use on input N1 in “Appoint”
mode.
N1 = 1~4 [Input number]
Available values for N2:
0 [SINK]
1 [720P]
2 [1080P]
3 [4K_3G]
4 [4K_Y420]
5 [4K_6G]
EDIDIN N1 Show the current EDID selection for input N1
in “Appoint” mode.
EDIDIN Show the current EDID selections for all inputs
in “Appoint” mode.

7
COMMAND DESCRIPTION AND PARAMETERS
AUTO_SWITCH N1 Enable or disable auto switching mode.
Available values for N1:
0 [Disabled]
1 [Enabled]
AUTO_SWITCH Show current auto switching mode status.
FADEFAULT Reset the unit to the factory defaults.
REBOOT Reboot the unit.
VER Show the unit’s current rmware version.
IPCONFIG Show the current IP conguration.
SIPADDR N1 Set the static IP Address.
N1 = X.X.X.X [X = 0~255]
SNETMASK N1 Set the Ethernet netmask.
N1 = X.X.X.X [X = 0~255]
SGATEWAY N1 Set the Ethernet gateway.
N1 = X.X.X.X [X = 0~255]
HTTPPORT N1 Set the HTTP port.
N1 = 0~65535
TELNETPORT N1 Set the Telnet port.
N1 = 0~65535
IPMODE N1 Set the current IP address mode.
Available values for N1:
0 [Static IP]
1 [DHCP]
READMAC Show the unit’s MAC address.
UPDATE Update rmware.
Note: Commands will not be executed unless followed by a carriage
return. Commands are not case-sensitive.

8
6.7 Telnet Control
Before attempting to use Telnet control, please ensure that both the
unit and the PC/Laptop are connected to the same active networks.
To access Telnet in Windows 7, click on the “Start” menu and type
“cmd” in the search eld, then press “Enter”. Under Windows XP go to
the “Start” menu, click on “Run”, type “cmd” then press “Enter”. Under
Mac OS X, go to “Go→Applications→Utilities→Terminal”. See below
for reference.
Once in the CLI (Command Line Interface) type “Telnet” followed by
the IP address of the unit and “23”, then hit “Enter”.
This will connect us to the unit we wish to control. Type “help” to list the
available commands.
Notes:
• Commands will not be executed unless followed by a carriage
return. Commands are not case-sensitive.
• If the IP address is changed then the IP address required for Telnet
access will also change accordingly.

9
6.8 WebGUI Control
6.8.1 Device Discovery APP
Please obtain the “Device Discovery” software from your authorized
dealer and save it in a directory where you can easily nd it.
Connect the unit and your PC/Laptop to the same active network
and execute the “Device Discovery” software. Click on “Find Devices
on Network” and a list of devices connected to the local network
will show up indicating their current IP address. (The unit’s default IP
address is 192.168.1.50)
By clicking on one of the listed devices you will be presented with the
network details of that particular device.
• IP Mode: If you choose, you can alter the static IP network settings
for the device, or switch the unit into DHCP mode to automatically
obtain proper network settings from a local DHCP server. To switch
to DHCP mode, please select DHCP from the IP mode drop-down,
then click “Save” followed by “Reboot”.
• WebGUI: Once you are satised with the network settings, you may
use them to connect via Telnet or WebGUI. The network information
window provides a convenient link to launch the WebGUI directly.

10
6.8.2 WebGUI Control Page
All functions, including power, input selection, EDID management,
HDCP management, port naming, Ethernet settings, and reset/
rmware functions, are presented on a single web page to allow
for simple and intuitive operation. The individual functions will be
explained in the following sections.
1. Power
The unit can be powered on or off (stand-by mode) from this tab.
2. Routing
This tab allows for the selection of the input source. Four HDMI inputs
are available for selection.

11
3. EDID
This tab controls EDID management for the unit. All inputs can share
the same assigned EDID, or each input can have a discrete EDID
assigned to it.
• ALL: Selecting the “ALL” mode will send the selected EDID to all
inputs.
• APPOINT: Selecting the “APPOINT” mode allows for each input to
have a different EDID assigned to it.
The available EDID options are:
• SINK: EDID is passed from the currently connected display
• 8/2D/PCM/720p: 720p@60Hz, 8-bit & LPCM 2.0
• 8/2D/PCM/1080p: 1080p@60Hz, 8-bit & LPCM 2.0
• 8/2D/PCM2/4K 3G: 4K@30Hz, 8-bit & LPCM 2.0
• 8/2D/PCM2/4K Y420: 4K@60Hz (4:2:0), 8-bit & LPCM 2.0
• 8/2D/PCM/4K 6G: 4K@60Hz (4:4:4), 8-bit & LPCM 2.0
4. HDCP Control
This tab allows for the HDCP mode to be switched between “Standard”
and “Apple” mode. “Apple” mode allows for the display of non-HDCP
required content from Apple devices on non-HDCP displays. This
setting can be assigned individually to each input.

12
5. Naming
This tab allows for the renaming of the four HDMI input ports and
the HDMI output port. Please click the “SAVE” button to store the
changes.
6. Network Setting
This tab provides control over the unit’s network settings. The IP mode
can be set to “DHCP” for automatic IP conguration, if your local
network supports it, or it can be placed in “Static” mode and the IP
address, netmask and gateway can be dened manually. The HTTP
and Telnet ports can also be changed from their defaults here.
7. Source Detect
When a live input source is connected one of the 4 HDMI inputs the
corresponding input port in this tab will display “ON”. If no source is
detected on that input, it will display “OFF”.

13
8. Status
This tab displays the currently selected HDMI input source and the
unit’s rmware version as well as allowing for resetting or rebooting the
unit.
• RESET: To perform a factory reset on the unit, please click the “RESET”
button.
• REBOOT: To reboot the unit, please click “REBOOT” button.
9. Firmware Update
This tab provides a way to update the rmware of the unit.
• BROWSE: Click the “BROWSE” button to select the rmware update
*.bin le which is located on your local PC.
• UPDATE: Click the “UPDATE” button to begin the rmware update
process.
10. HDMI Out Info
The HDMI output display’s detected information is listed here, including
type, manufacturer name, native resolution, color depth, 3D support,
4K support and audio format support.

14
7. CONNECTION DIAGRAM
1234
HDMI IN HDMI OUT SERVICE CONTROL RS-232 IR IN DC 5V
CR-72
POWER
INPUT
34
12
7m3m 3m
60°
UHDTV Remote
Control
Blu-ray Player
Satellite Receiver
Power
Supply
HDMI
Inputs
HDMI
Output
LAN
Connection
IR
Input
RS-232
RS-232 Control
System
Internet
Connected
Router
Set-top Box
Game Console

15
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 600MHz/18Gbps
Input Ports 4×HDMI
Output Ports 1×HDMI
Control Interfaces 1×IR Extender (3.5mm)
1×RS-232 (9-pin D-sub)
1×IP Control (RJ45)
Supported Resolutions 480i@60Hz - 4K@60Hz (4:4:4, 8-bit)
VGA@60Hz - WUXGA@60Hz (RB)
HDMI Cable Length 10m (1080p@60Hz, 12-bit)
5m (4K@60Hz, 4:4:4, 8-bit)
IR Frequency 30 - 50kHz (30 - 60kHz under ideal
conditions)
Baud Rate 115200bps
Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human Body Model:
±12kV (Air Discharge)
±8kV (Contact Discharge)
Dimensions 240mm×43mm×104mm (W×H×D)
[Case Only]
240mm×48mm×112mm (W×H×D)
[All Inclusive]
Weight 850g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0˚C - 40˚C/32˚F - 104˚F
Storage Temperature −20˚C - 60˚C/−4˚F - 140˚F
