CYP CPLUS-V3H1H-TB User manual

CPLUS-V3H1H-TB
UHD+3×1 HDMI Switcher Table Box
Operation Manual
Operation Manual

®
registered trademarks of HDMI licensing Administrator, Inc.

DISCLAIMERS
The information in this manual has been carefully checked and is believed
to be accurate. Cypress Technology assumes no responsibility for any
infringements of patents or other rights of third parties which may result from
its use.
Cypress Technology assumes no responsibility for any inaccuracies that
may be contained in this document. Cypress also makes no commitment to
update or to keep current the information contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express written
permission and consent from Cypress Technology.
© Copyright 2018 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document are trademarks of
the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply. Please keep the
following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture
or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings
or empty slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it
is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to
be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings
in the unit housing that provide ventilation and allow for su󰀩cient space
for air to circulate around the unit.
• Please completely disconnect the power when the unit is not in use to
avoid wasting electricity.
VERSION HISTORY
REV. DATE SUMMARY OF CHANGE
RDV1 2019/09/19 Preliminary release

CONTENTS
1. Introduction...................................................... 1
2. Applications ..................................................... 1
3. Package Contents ........................................... 1
4. System Requirements..................................... 1
5. Features............................................................ 2
6. Operation Controls and Functions ................ 3
6.1 Front Panel.................................................. 3
6.2 Rear Panel................................................... 4
6.3 Side Panel ................................................... 4
6.4 RS-232 Pinout and Defaults........................ 5
6.5 Serial Commands........................................ 6
7. Connection Diagram ....................................... 9
8. Specications ................................................ 10
8.1 Technical Specications ............................ 10
8.2 Video Specications .................................. 11
8.3 Audio Specications .................................. 13
8.3.1 Digital Audio ..................................... 13
8.4 Cable Specications.................................. 13
9. Acronyms ....................................................... 14

1
1. INTRODUCTION
This UHD+ 3×1 HDMI Switcher Table Box features three HDMI inputs and
one HDMI output with manual or automatic source switching. Every input and
output supports full bandwidth 4K@60Hz (4:4:4, 8-bit) HDMI 2.0 with HDCP
2.2 signals. Automatic source management allows for hands-free switching
based on input signal and hot plug detection with a “Last Memory” switching
feature upon signal loss. This switch is an ideal addition to any conference
room, lecture hall or home entertainment setup with its portable and easy to
install design. The table box is designed to be placed on a table, or mounted
to any typical table edge using a clamp. Control is via a front panel button
and RS-232.
2. APPLICATIONS
• Conference rooms and boardrooms
• Lecture halls, auditoriums and classrooms
• Household entertainment sharing and control
• Hotel event spaces
3. PACKAGE CONTENTS
• 1× UHD+ 3×1 HDMI Switcher Table Box
• 1× 5V/1A DC Power Adapter (2-pin Terminal Block)
• 1× Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game consoles or
set-top boxes.
• HDMI receiving equipment such as an HDTV, monitor or audio amplier.
• The use of Premium High Speed HDMI cables is highly recommended.

2
5. FEATURES
• HDMI 2.0 and DVI 1.0 compatible
• HDCP 1.x and HDCP 2.2 compliant
• 3 HDMI inputs, 1 HDMI output
• Supports up to 4K UHD+ (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input
and output
• Supports Deep Color input and output up to 12-bit
• Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output
• Supports pass-through of many audio formats including 8 channel LPCM,
Bitstream, and HD Bitstream
• Supports manual input selection or automatic input selection with hot plug
detection and “Last Memory” feature
• Sophisticated EDID management ensures optimal compatibility
• LED indicators provide input selection as well as automatic switch status
information
• Convenient table box design
• Control via front panel button and RS-232

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
HDMI 1 HDMI 2 HDMI 3 IN SEL.
AUTO1 2
HDMI
3
3 x 1 HDMI SWITCHER
1 2
3 4
1HDMI 1~3 Ports:Connect to HDMI source equipment such as media
players, game consoles or set-top boxes.
2IN SEL. Button: Press this button to sequentially switch through the
available inputs or select auto switch. This button will also illuminate to
indicate the unit is on and receiving power.
Note: The sequence is: HDMI 1 > HDMI 2 > HDMI 3 > Auto > HDMI 1
3AUTO LED: This LED will illuminate when the auto switch function is
active. While active, the input source will be selected based on the most
recently connected live source.
4HDMI 1~3 LEDs: The LED of the currently selected input will illuminate
green. When an input has an active source, but is not currently selected,
it will illuminate red. When no source is detected the LED will remain o󰀨.

4
6.2 Rear Panel
HDMI OUT
RS-232
DC 5V
+
-
123
1HDMI OUT Port: Connect to an HDMI TV, monitor, or amplier for digital
video and audio output.
2RS-232 Port: Connect directly to a PC, laptop, or other serial control
device with a 3.5mm mini-jack adapter cable to send RS-232 commands
to control the unit.
3DC 5V 2-pin Terminal Block: Connect a 5V DC power adapter into this
terminal block and connect it to an AC wall outlet for power.
6.3 Side Panel
1
1Micro USB Port: This port is reserved for rmware update use only.

5
6.4 RS-232 Pinout and Defaults
Serial Port Default Settings
Baud Rate 19200
Data Bits 8
Parity Bits None
Stop Bits 1
Flow Control None
3.5mm to DE-9
A
dapter Cable
RxD
TxD
GND
1
2
3

6
6.5 Serial Commands
COMMAND
Description and Parameters
?
Show the full command list.
help
Show the full command list.
set factory default
Reset the unit to the factory defaults.
get command ver
Show the unit’s current command version.
get fw ver
Show the unit’s current rmware version.
get model name
Show the unit’s model name.
get model type
Show the unit’s product type.
set out A route N1
Route the specied input to the HDMI output.
N1 = 1~3 [HDMI input number]
get out A route
Show which input is currently routed to the HDMI output.
set out auto mode N1
Set the auto switching/scanning behavior of the unit.
Available values for N1:
0 [O󰀨]
1[Auto switch]

7
COMMAND
Description and Parameters
get out auto mode
Show the current auto switching/scanning mode of the unit.
get in type list
List the port type of all inputs on the unit.
get out type list
List the port type of all outputs on the unit.
get in port number
Show the total number of inputs on the unit.
get out port number
Show the total number of outputs on the unit.
set in N1 edid N2
Set the EDID to use on the specied input.
N1 = 1~3 [HDMI input number]
Available values for N2:
1 [Internal FHD, 2 channel audio]
2[Internal FHD, multi-channel audio]
3[Internal UHD, 2 channel audio]
4[Internal UHD, multi-channel audio]
5[Internal UHD+, 2 channel audio]
6[Internal UHD+, multi-channel audio]
7[User EDID 1]
8 [User EDID 2]
9[User EDID 3]
10 [Copy output’s EDID]
get in N1 edid
Show the EDID currently being used on the specied input.
N1 = 1~3 [HDMI input number]
get in edid list
List all available EDID selections.

8
COMMAND
Description and Parameters
set user N1 edid data N2
Upload a new EDID (in ASCII hex format) for use as the specied User
EDID.
N1 = 1~3 [User EDID number]
N2 = {Comma delimited hex pairs} [EDID data]
get user N1 edid data
Show the current contents of the specied User EDID as HEX data.
N1 = 1~3 [User EDID number]
Note: Commands will not be executed unless followed by a carriage return.
Commands are not case-sensitive.

9
7. CONNECTION DIAGRAM
HDMI OUT
RS-232
DC 5V
+
-
HDMI 1 HDMI 2 HDMI 3 IN SEL.
AUTO1 2
HDMI
3
3 x 1 HDMI SWITCHER
4K TV Monitor Projector
oror
HDMI
Input
HDMI
Output
PC/LaptopBlu-ray PlayerGame Console

10
8. SPECIFICATIONS
8.1 Technical Specications
HDMI Bandwidth 18Gbps
Input Ports 3×HDMI (Type-A)
Output Port 1×HDMI (Type-A)
Control Port 1×RS-232 (3.5mm)
Service Port 1×USB 2.0 (Mini B)
Baud Rate 19200
Power Supply 5V/1A DC
(US/EU standards, CE/FCC/UL certied)
ESD Protection (HBM) ±8kV (Air Discharge)
±4kV (Contact Discharge)
Dimensions (W×H×D) 125mm×55mm×34mm [Case Only]
125mm×55mm×40mm [All Inclusive]
Weight 230g
Chassis Material Metal (Aluminum)
Chassis Color Black
Operating Temperature 0˚C – 40˚C/32˚F – 104˚F
Storage Temperature -20˚C – 60˚C/-4˚F – 140˚F
Relative Humidity 20 – 90% RH (Non-condensing)
Power Consumption 2.53W

11
8.2 Video Specications
Supported Resolutions (Hz)
Input Output
HDMI HDMI
720×400p@70/85  
640×480p@60/72/75/85  
720×480i@60  
720×480p@60  
720×576i@50  
720×576p@50  
800×600p@56/60/72/75/85  
848×480p@60  
1024×768p@60/70/75/85  
1152×864p@75  
1280×720p@50/60  
1280×768p@60/75/85  
1280×800p@60/75/85  
1280×960p@60/85  
1280×1024p@60/75/85  
1360×768p@60  
1366×768p@60  
1400×1050p@60  
1440×900p@60/75  
1600×900p@60RB  
1600×1200p@60  
1680×1050p@60  
1920×1080i@50/60  
1920×1080p@24/25/30  
1920×1080p@50/60  
1920×1200p@60RB  

12
Supported Resolutions (Hz)
Input Output
HDMI HDMI
2560×1440p@60RB  
2560×1600p@60RB  
2048×1080p@24/25/30  
2048×1080p@50/60  
3840×2160p@24/25/30  
3840×2160p@50/60 (4:2:0)  
3840×2160p@24, HDR10  
3840×2160p@50/60 (4:2:0),HDR10  
3840×2160p@50/60  
4096×2160p@24/25/30  
4096×2160p@50/60 (4:2:0)  
4096×2160p@24, HDR10  
4096×2160p@50/60 (4:2:0),HDR10  
4096×2160p@50/60  

13
8.3 Audio Specications
8.3.1 Digital Audio
HDMI Input / Output
LPCM
Max Channels 8 Channels
Sampling Rate (kHz) 32, 44.1, 48, 88.2, 96, 176.4, 192
Bitstream
Supported Formats Standard & High-Denition
8.4 Cable Specications
Cable Length
1080p 4K30 4K60
8-bit 12-bit
(4:4:4)
8-bit
(4:4:4)
8-bit
High Speed HDMI Cable
HDMI Input 15m 10m 5m 3m
HDMI Output 15m 10m 5m 3m
Bandwidth Category Examples:
• 1080p (FHD Video)
- Up to 1080p@60Hz, 12-bit color
- Data rates lower than 5.3Gbps or below 225MHz TMDS clock
• 4K30 (4K UHD Video)
- 4K@24/25/30Hz & 4K@50/60Hz (4:2:0), 8-bit color
- Data rates higher than 5.3Gbps or above 225MHz TMDS clock but
below 10.2Gbps
• 4K60 (4K UHD+Video)
- 4K@50/60Hz (4:4:4, 8-bit)
- 4K@50/60Hz (4:2:0, 10-bit HDR)
- Data rates higher than 10.2Gbps

14
9. ACRONYMS
ACRONYM COMPLETE TERM
ASCII American Standard Code for Information Interchange
AV Audio/Video
CEC Consumer Electronics Control
CLI Command-Line Interface
DVI Digital Visual Interface
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDR High Dynamic Range
HDTV High-Denition Television
LED Light-Emitting Diode
LPCM Linear Pulse-Code Modulation
4K UHD 4K Ultra-High-Denition (10.2Gbps max)
4K UHD+4K Ultra-High-Denition (18Gbps max)
UHDTV Ultra-High-Denition Television
USB Universal Serial Bus

CYPRESS TECHNOLOGY CO., LTD.
www.cypress.com.tw
