CYP CLUX-41AP User manual

CLUX-41AP
CLUX-41AP
4x1 HDMI
v1.3 Switcher
Operation Manual
1. Introduction
The is a high performance HDMI v1.3 Switcher with remote control. It allows your
various HDMI source to share one HDTV display. Simply pressing one button to
select your desired HDMI source for display on the HDTV.
2. Features
 HDMI 1.3, HDCP1.1 and DVI1.0 compliant.
 Supports 30/36 bit color depth display.
 Supports High Definition audio-Dolby Digital TrureHD and DTS-HD.
 Auto Signal Enhancement feature can improve signal quality after long
distance transmission.
 Signal Enhancement feature allows you to improve signal quality after long
distance transmission.
 Supports high resolution input:
PC: VGA, SVGA, XGA, SXGA, UXGA and 1920 x 1200.
HDTV: 480i, 480p, 576i, 576p, 720p, 1080i and 1080p.
 Remote control.
 Ideal for home theater integration.
 Easy to install and simple to operate.
1 4
Frequency bandwidth
Input ports
Output port
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silk Skin Color
Operating Temperature
2.25Gbps (single link)
4 x HDMI female ports (Type A connector)
1 x HDMI female port
5VDC/1A (US/EU standards, CE/FCC/UL certified)
206(W) x 111(D) x 32(H)
250
Plastic
Black
Operating from 0°C ~ 48°C
5. Specifications
4. Remote Control
5. Connection and Installation
LCD TV
DVD 3 STBDVD 2DVD 1
1. Power: Press the button to turn on/off the unit.
2. Direct input selector: Press 1, 2, 3 or 4 to select the
desired input source.
1
2
2
3. Operation Controls and Functions
3.1 Front Panel
1 Remote control sensor.
2 Input select/Indicators: Press the “INPUT” button repeatedly to switch to
your desired input source and the LED will illuminate to indicate which
input source is selected.
3 Signal Enhancement/Indicator: Press the “Signal Enhance” button to turn
on this feature to improve signal quality after long distance transmission.
Press again to turn off. The LED will illuminate when the signal is enhanced.
4 POWER Switch/Indicator: When the power supply connected to the
system, the system will automatically to turn on and the power LED will
illuminate. Press the "POWER" button to turn on/off the system.
1 2 3 4
1 2 3 4 INPUT ENHANCE POWER
CLUX-41AP
3
3.2 Rear Panel
1 HDMI output: Connect the HDMI out of the unit to the HDMI input of your
display using HDMI cable.
2 HDMI Inputs: Connect each of the input ports to the HDMI or DVI output
of your source equipment such as DVD player or set-top-box.
3 Power: Plug the 5V DC power supply into this unit and connect the
adaptor to AC wall outlet.
1 2 3
IN 1IN 2IN 3IN 4OUTPUT
DC 5V

1. Introduction................................................................................
2. Features......................................................................................
3. Operation Controls and Functions..........................................
3.1 Front Panel...........................................................................
3.2 Rear Panel............................................................................
4. Connection and Installation.....................................................
5. Specifications............................................................................
6. Cypress HDMI v1.3 Series........................................................
TABLE OF CONTENTS
1
1
2
2
2
3
3
6
2
3. Operation Controls and Functions
3.1 Front Panel
1 Remote control sensor.
2 Input select/Indicators: Press the “INPUT” button repeatedly to switch to
your desired input source and the LED will illuminate to indicate which
input source is selected.
3 Signal Enhancement/Indicator: Press the “Signal Enhance” button to turn
on this feature to improve signal quality after long distance transmission.
Press again to turn off. The LED will illuminate when the signal is enhanced.
4 POWER Switch/Indicator: When the power supply connected to the
system, the system will automatically to turn on and the power LED will
illuminate. Press the "POWER" button to turn on/off the system.
1 2 3 4
1 2 3 4 INPUT ENHANCE POWER
CLUX-41AP
3
3.2 Rear Panel
1 HDMI output: Connect the HDMI out of the unit to the HDMI input of your
display using HDMI cable.
2 HDMI Inputs: Connect each of the input ports to the HDMI or DVI output
of your source equipment such as DVD player or set-top-box.
3 Power: Plug the 5V DC power supply into this unit and connect the
adaptor to AC wall outlet.
1 2 3
IN 1IN 2IN 3IN 4OUTPUT
DC 5V

1. Introduction
The is a high performance HDMI v1.3 Switcher with remote control. It allows your
various HDMI source to share one HDTV display. Simply pressing one button to
select your desired HDMI source for display on the HDTV.
2. Features
 HDMI 1.3, HDCP1.1 and DVI1.0 compliant.
 Supports 30/36 bit color depth display.
 Supports High Definition audio-Dolby Digital TrureHD and DTS-HD.
 Auto Signal Enhancement feature can improve signal quality after long
distance transmission.
 Signal Enhancement feature allows you to improve signal quality after long
distance transmission.
 Supports high resolution input:
PC: VGA, SVGA, XGA, SXGA, UXGA and 1920 x 1200.
HDTV: 480i, 480p, 576i, 576p, 720p, 1080i and 1080p.
 Remote control.
 Ideal for home theater integration.
 Easy to install and simple to operate.
1 2
3. Operation Controls and Functions
3.1 Front Panel
1 Remote control sensor.
2 Input select/Indicators: Press the “INPUT” button repeatedly to switch to
your desired input source and the LED will illuminate to indicate which
input source is selected.
3 Signal Enhancement/Indicator: Press the “Signal Enhance” button to turn
on this feature to improve signal quality after long distance transmission.
Press again to turn off. The LED will illuminate when the signal is enhanced.
4 POWER Switch/Indicator: When the power supply connected to the
system, the system will automatically to turn on and the power LED will
illuminate. Press the "POWER" button to turn on/off the system.
1 2 3 4
1 2 3 4 INPUT ENHANCE POWER
CLUX-41AP
3
3.2 Rear Panel
1 HDMI output: Connect the HDMI out of the unit to the HDMI input of your
display using HDMI cable.
2 HDMI Inputs: Connect each of the input ports to the HDMI or DVI output
of your source equipment such as DVD player or set-top-box.
3 Power: Plug the 5V DC power supply into this unit and connect the
adaptor to AC wall outlet.
1 2 3
IN 1IN 2IN 3IN 4OUTPUT
DC 5V

1. Introduction................................................................................
2. Features......................................................................................
3. Operation Controls and Functions..........................................
3.1 Front Panel...........................................................................
3.2 Rear Panel............................................................................
4. Connection and Installation.....................................................
5. Specifications............................................................................
6. Cypress HDMI v1.3 Series........................................................
TABLE OF CONTENTS
1
1
2
2
2
3
3
6
2
3. Operation Controls and Functions
3.1 Front Panel
1 Remote control sensor.
2 Input select/Indicators: Press the “INPUT” button repeatedly to switch to
your desired input source and the LED will illuminate to indicate which
input source is selected.
3 Signal Enhancement/Indicator: Press the “Signal Enhance” button to turn
on this feature to improve signal quality after long distance transmission.
Press again to turn off. The LED will illuminate when the signal is enhanced.
4 POWER Switch/Indicator: When the power supply connected to the
system, the system will automatically to turn on and the power LED will
illuminate. Press the "POWER" button to turn on/off the system.
1 2 3 4
1 2 3 4 INPUT ENHANCE POWER
CLUX-41AP

1. Introduction................................................................................
2. Features......................................................................................
3. Operation Controls and Functions..........................................
3.1 Front Panel...........................................................................
3.2 Rear Panel............................................................................
4. Connection and Installation.....................................................
5. Specifications............................................................................
6. Cypress HDMI v1.3 Series........................................................
TABLE OF CONTENTS
1
1
2
2
2
3
3
6
3
3.2 Rear Panel
1 HDMI output: Connect the HDMI out of the unit to the HDMI input of your
display using HDMI cable.
2 HDMI Inputs: Connect each of the input ports to the HDMI or DVI output
of your source equipment such as DVD player or set-top-box.
3 Power: Plug the 5V DC power supply into this unit and connect the
adaptor to AC wall outlet.
1 2 3
IN 1IN 2IN 3IN 4OUTPUT
DC 5V

1. Introduction................................................................................
2. Features......................................................................................
3. Operation Controls and Functions..........................................
3.1 Front Panel...........................................................................
3.2 Rear Panel............................................................................
4. Connection and Installation.....................................................
5. Specifications............................................................................
6. Cypress HDMI v1.3 Series........................................................
TABLE OF CONTENTS
1
1
2
2
2
3
3
6
4
Frequency bandwidth
Input ports
Output port
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silk Skin Color
Operating Temperature
2.25Gbps (single link)
4 x HDMI female ports (Type A connector)
1 x HDMI female port
5VDC/1A (US/EU standards, CE/FCC/UL certified)
206(W) x 111(D) x 32(H)
250
Plastic
Black
Operating from 0°C ~ 48°C
5. Specifications
4. Remote Control
5. Connection and Installation
LCD TV
DVD 3 STBDVD 2DVD 1
1. Power: Press the button to turn on/off the unit.
2. Direct input selector: Press 1, 2, 3 or 4 to select the
desired input source.
1
2

1. Introduction................................................................................
2. Features......................................................................................
3. Operation Controls and Functions..........................................
3.1 Front Panel...........................................................................
3.2 Rear Panel............................................................................
4. Connection and Installation.....................................................
5. Specifications............................................................................
6. Cypress HDMI v1.3 Series........................................................
TABLE OF CONTENTS
1
1
2
2
2
3
3
6
2
3. Operation Controls and Functions
3.1 Front Panel
1 Remote control sensor.
2 Input select/Indicators: Press the “INPUT” button repeatedly to switch to
your desired input source and the LED will illuminate to indicate which
input source is selected.
3 Signal Enhancement/Indicator: Press the “Signal Enhance” button to turn
on this feature to improve signal quality after long distance transmission.
Press again to turn off. The LED will illuminate when the signal is enhanced.
4 POWER Switch/Indicator: When the power supply connected to the
system, the system will automatically to turn on and the power LED will
illuminate. Press the "POWER" button to turn on/off the system.
1 2 3 4
1 2 3 4 INPUT ENHANCE POWER
CLUX-41AP
3
3.2 Rear Panel
1 HDMI output: Connect the HDMI out of the unit to the HDMI input of your
display using HDMI cable.
2 HDMI Inputs: Connect each of the input ports to the HDMI or DVI output
of your source equipment such as DVD player or set-top-box.
3 Power: Plug the 5V DC power supply into this unit and connect the
adaptor to AC wall outlet.
1 2 3
IN 1IN 2IN 3IN 4OUTPUT
DC 5V

20071015 MPM-CLUX41AP
Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
6. Cypress HDMI v1.3 Series:
Product Description
CLUX-11S 1x1 HDMI V1.3 Repeater
CLUX-12S 1x2 HDMI V1.3 Splitter
CLUX-14S 1x4 HDMI V1.3 Splitter
CLUX-18S 1x8 HDMI V1.3 Splitter
CLUX-21SY 2x1 HDMI V1.3 Switcher
CLUX-31S 3x1 HDMI V1.3 Switcher
CLUX-31SY 3x1 HDMI V1.3 Switcher
CLUX-41SY 4x1 HDMI V1.3 Switcher
CLUX-41AT 4x1 HDMI V1.3 Switcher with Digital Audio
CLUX-42S 4x2 HDMI V1.3 Switcher
CLUX-110S 1x10 HDMI V1.3 Splitter
CLUX-210S 2x10 HDMI V1.3 Splitter
CLUX-210T 2x10 HDMI V1.3 Splitter with Digital Audio
1. Introduction................................................................................
2. Features......................................................................................
3. Operation Controls and Functions..........................................
3.1 Front Panel...........................................................................
3.2 Rear Panel............................................................................
4. Connection and Installation.....................................................
5. Specifications............................................................................
6. Cypress HDMI v1.3 Series........................................................
TABLE OF CONTENTS
1
1
2
2
2
3
3
6
2
3. Operation Controls and Functions
3.1 Front Panel
1 Remote control sensor.
2 Input select/Indicators: Press the “INPUT” button repeatedly to switch to
your desired input source and the LED will illuminate to indicate which
input source is selected.
3 Signal Enhancement/Indicator: Press the “Signal Enhance” button to turn
on this feature to improve signal quality after long distance transmission.
Press again to turn off. The LED will illuminate when the signal is enhanced.
4 POWER Switch/Indicator: When the power supply connected to the
system, the system will automatically to turn on and the power LED will
illuminate. Press the "POWER" button to turn on/off the system.
1 2 3 4
1 2 3 4 INPUT ENHANCE POWER
CLUX-41AP
3
3.2 Rear Panel
1 HDMI output: Connect the HDMI out of the unit to the HDMI input of your
display using HDMI cable.
2 HDMI Inputs: Connect each of the input ports to the HDMI or DVI output
of your source equipment such as DVD player or set-top-box.
3 Power: Plug the 5V DC power supply into this unit and connect the
adaptor to AC wall outlet.
1 2 3
IN 1IN 2IN 3IN 4OUTPUT
DC 5V
