1. INTRODUCTION
As the Flagship 8x8 HDBaseT™ Matrix, the PU-8H8HBT solution oers
complete HDBaseT™ convergence. Installers can switch and distribute
up to 8 HDMI sources, 2-Way IR, and PoE to lengths of up to 100m using
CAT5e/6 cable infrastructure. Control of the matrix is via IP, RS-232, IR
remote, or manual selection buttons.
This single box solution will enable an installer to condently integrate an
eight zone multi-room AV system. The PU-8H8HBT is designed to be used
with the PU-507-RX Receiver which can utilise the Power over Ethernet
(PoE) capabilities of the matrix.
2. APPLICATIONS
• Domestic HDMI Matrix System
• Video/TV wall display and control
• Security surveillance and control
• Commercial advertising, display and control
• University lecture hall, display and control
• Retail sales and demonstration
3. PACKAGE CONTENTS
• HDBaseT™ 8×8 HDMI Matrix over CAT5e/6/7
• 9×IR Extender
• 9×IR Blaster
• 2×24 V/6.25 A DC Power Adaptor (1 for PoE)
• 1×IR Remote Control
• Operation Manual

2
4. SYSTEM REQUIREMENTS
• HDMI equipped source devices, connect with HDMI cables or DVI
equipped source, connect with DVI to HDMI cables
• HDMI equipped displays (TVs or monitors) or HDMI equipped AV
receivers, connect with HDMI cables
• Industry standard CAT5e/6/7 cables
• HDBaseT™ Receivers (i.e. PU-506RX, PU-507RX or PU-1109RX)
5. FEATURES
• Supports all v1.3 HDMI resolutions
• Supports uncompressed video/audio up to 10.2Gbps
• Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i,
1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.
• HDMI, HDCP and DVI complaint
• High Denition Audio supported: Dolby TrueHD, Dolby Digital Plus
and DTS-HD Master Audio plus LPCM (up to 192kHz)
• Uncompressed data transfer over single CAT cable (100m - CAT6; 80m -
CAT5e)
• Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit.
• Supports RS-232, 2-Way IR, Manual Selection Buttons, and HDMI CEC
control pass through
• Selectable EDID settings - TV (downstream) and STD (xed).
• Compact 2U Rack mount design
• Supports IP control
• Supports 3D signals
• Supports additional IR Control via a master (ALL) Input/Output..
Note:
1. The PoE function is designed for powering compatible receiver units
only—non-PoE receivers will need their own power supply. Receivers of
another brand may not be compatible.
2. Do not connect the LAN/CONTROL port to CAT outputs of this device.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER LOCK
MENU OUTA 1B2C3D4
IN
E5F6G7H8
2 3 4 5 61
1 LCM : Displays the setting information of each input and output
setting.
2 POWER: Press this button to power the device on/o. The LED will
illuminate green when the power is on, red when it is in 'Standby'
mode.
3 LOCK: Press this button to lock all the buttons on the panel; press
again to unlock. The LED will illuminate green when locked.
4 IR: IR Receiver window (accepts the remote control signal of this
device only).
5 MENU: Press this button to access the LCM menu system, from here
EDID settings can be managed and IP system settings are displayed.
6 1~8/A~H and OUT/IN: Press the OUT or IN button to select the
output or input mode and then press the required number button to
make the selection accordingly.
For example, if outputs A~D need to be set to input 1 and outputs
E~H need to be set to input 2, then the following sequence of button
presses need to be performed:
Press: OUTABCDIN1MENU,
and then press: OUTEFGHIN2MENU.
Note: If the MENU button is not pressed the selection will not be changed.

4
6.2 Rear Panel
LAN
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E F G H
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUTCAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
12
34
V+
GND
GND
GND
V+
24
3
5 10 111 7
96
8
1
LAN: This port is the link for Telnet and Web GUI controls, connect to an
active Ethernet link with an RJ45 terminated cable (for further details,
please refer to sections 6.8 and 6.9).
Warning: Please do not connect this port directly to the PC/Laptop
as the Telnet function will not work.
2
RS-232: Connect to a PC or control system with D-Sub 9-pin cable for
the transmission of RS-232 commands.
3 ALL IR OUT: Connect to the IR blaster for IR signal transmission of the
source or display equipment. Place the IR blaster in direct line-of-sight
of the equipment to be controlled.
4
ALL IR IN: Connect to the IR extender for IR signal reception of the remote
control of this device or the source and display equipment. Ensure that
remote being used is within the direct line-of-sight of the IR extender.
5 SERVICE: Manufacturer use only.
6
IR OUT A~H: Connect to the IR blasters for IR signal transmission. Place
the IR blaster in direct line-of-sight of the equipment to be controlled.
7 CAT5e/6/7 OUT A~H: Connect from these CAT outputs to the CAT input
port of the receiver units with a single CAT5e/6/7 cable for HDMI Audio/
Video and IR control signal transmission.
8
HDMI IN 1~8: Connect to the HDMI input source devices such as a DVD
player or a Set-top Box with HDMI cable or DVI to HDMI cable.
9
IR IN 1~8: Connect to the IR extenders for IR signal reception. Ensure
that the remote being used is within the direct line-of-sight of the IR
extender.
10
DC 24V MAIN POWER: Plug the 24 V DC power supply into the unit and
connect the adaptor to an AC outlet.
11
PoE 24V: Plug the 24 V PoE power supply into the unit and connect the
adaptor to an AC outlet. This unit will mainly power PoE (Power over
Ethernet) capaable receiver units.
Warning: Please do not connect the CAT5e/6/7 cable into the
receiver's LAN port.

5
6.3 Side Panel
1
1
Fan Ventilator: These are air ventilation areas, DO NOT block these
areas or cover it with any object. Please allow adequate space around
the unit for air circulation.
6.4 Remote Control
1
POWER: Press this button to
switch on the device or set it to
standby mode.
2
IN: Input ports selection 1~8.
3
OUT: Output ports selection A~H.
1
23

6
6.5 IR Cable Pin Assignment
3
1
3
2
2
1Power 5 V
IR Blaster Signal
NC
IR Signal
Power 5 V
Grounding
IR Receiver
IR Blaster

7
6.6 RS-232 Pin Assignment
PU-8H8HBT Remote Control Console
PIN Assignment PIN Assignment
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200 bps
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None

8
6.7 RS-232 and Telnet Commands
Command Description
A1~A8 Switch Output A to 1~8
B1~B8 Switch Output B to 1~8
C1~C8 Switch Output C to 1~8
D1~D8 Switch Output D to 1~8
E1~E8 Switch Output E to 1~8
F1~F8 Switch Output F to 1~8
G1~G8 Switch Output G to 1~8
H1~H8 Switch Output H to 1~8
ABCE…1~ABCD…8 Switch Output ABCD… to 1~8 at the
same time
SETIP <IP><SubNet><GW> Setting IP. SubNet.GateWay<Static IP>
RSTIP IP conguration was reset to factory
defaults<DHCP>
IPCONFIG Display the current IP cong
P0 Power Off
P1 Power On
I1~I8 Switch all the output to 1~8
ST Display the current matrix state and
rmware version
RS System Reset to H8
EM Setting EDID MODE. 1-STD 2-TV.
?Display all available commands
QUIT Exit (Telnet only)
Note: Any commands will not be executed unless followed by a carriage
return. Commands are not case-sensitive.

9
6.8 Telnet Control
Before attempting to use the telnet control, please ensure that both the
Matrix (via the 'LAN /CONTROL' port) and the PC/Laptop are connected to
active networks.
Note: Please do not connect both the Matrix and the PC/Laptop with a single
CAT5e/6 cable as it will not access the telnet function.
To access the telnet control in Windows 7, click on the 'Start' menu and
type "cmd" in the Search eld then press enter.
Under Windows XP go to the 'Start' menu and click on "Run", type "cmd"
with then press enter.
Under Mac OS X, go to GoApplicationsUtilitiesTerminal
See below for reference.

10
Once in the command line interface (CLI) type "telnet", a space, then the
IP address of the unit you wish to control, a space and "23", then hit enter.
Note: The IP address of the Matrix can be displayed on the device's LCM
monitor by pressing the Menu button twice.
This will bring us into the device which we wish to control. Type "HELP" to
list the available commands.
Type “IPCONFIG” To show all IP congurations. To reset the IP, type “RSTIP”
and to use a set static IP, type ”SETIP” (For a full list of commands, see
Section 6.7).
Note: Any commands will not be executed unless followed by a carriage
return. Commands are not case-sensitive. If the IP is changed then the IP
Address required for Telnet access will also change accordingly.

11
6.9 Web GUI Control
On a PC/Laptop that is connected to an active network, open a web
browser and type the Matrix's IP address on the web address entry bar.
The browser will display the device's status, control and User setting
pages.
Click on the 'Control' tab to control power, input/output ports, EDID and
reset mode.

12
Click on the 'User Setting' tab allows you to reset the IP conguration. The
system will ask for a reboot of the device every time any of the settings
are changed. The IP address needed to access the Web GUI control will
also need to be changed accordingly on the web address entry bar.

13
7. CONNECTION DIAGRAM
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
ZONE A
CONTROL
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E F
G H
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CA
T5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
12
34
V+
GND
GND
GND
V+
1 2 3 4 5 6
87
RX
ZONE B
Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE C
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE D
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE EZONE FZONE GZONE H
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
IR Out (All)
IR In (ALL)
RS-232 Equipped
PC or Notebook
Smartphone
or Tablet
Wireless
Router

14
Main Power Supply
Power Supply for
Power-over-Ethernet
Receiver Units
Single
CAT 5e/6 Cable
HDMI Inputs
IR Out/In
Model Shown:
HDBaseT 8×8 HDMI Matrix over CAT5e/6/7
HDMI Outputs
IR Out/In
Source
Equipment
Displays
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
ZONE A
CONTROL
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E F
G H
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OU
T
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
12
34
V+
GND
GND
GND
V+
1 2 3 4 5 6
87
RX
ZONE B
Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE C
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE D
RX Power
Extender
Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE
EZONE FZONE GZONE H
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link

15
8. SPECIFICATIONS
Video Bandwidth 255 MHz/6.75 Gbps
Input Ports 8×HDMI , 9×IR Extender, 1×RS-232,
1×LAN, 1×Mini USB-B type(for rmware
update only)
Output Ports 8×CAT5e/6/7, 9×IR Blaster
ESD Protection Human-body Model:
± 8kV (Air-gap discharge)
± 4kV (Contact discharge)
Power Supply 24 V/6.25 A DC (US/EU standards, CE/
FCC/UL certied)
Dimensions 438 mm (W)×255 mm (D)×93 mm (H)
Weight 4238g (4H4CV), 4458g (8H8CV)
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0 ºC~40 ºC/32 ºF~104 ºF
Storage Temperature −20 ºC~60 ºC/−4 ºF~140 ºF
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 64 W Tx (Main), 56 W Rx (PoE)
