CYP EL-5600 User manual

EL-5600
Multi Format Presentation Switch (including SDI)
OPERATION MANUAL


3
DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2011 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

4
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sucient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
v1.00 29/07/2013 First release
v1.01 06/07/2013 Corrections

5
CONTENTS
1. Introduction...........................................6
2. Applications ...........................................6
3. Package Contents ..................................6
4. System Requirements ...........................6
5. Features..................................................7
6. Operation Controls and Functions .......8
6.1 Front Panel................................................... 8
6.2 Rear Panel..................................................... 9
6.3 Remote Control........................................10
6.4 RS-232 Protocols......................................11
6.5 RS-232 Commands..................................12
6.6 OSD MENU .................................................14
7. Connection and Installation .............. 16
8. Specications...................................... 17
8.1 Technical Specications ........................17
8.2 Supported Input/Output Resolution .......18
9. Acronyms............................................. 20

6
1. INTRODUCTION
The EL-5600 presentation switch is an advanced HDMI, PC, SDI,
Composite, S-Video and Component switcher/scaler. This device can
scale and switch input sources and display them via the HDMI and VGA/
HD outputs simultaneously with their associated audio signals at a wide
range of output resolutions (up to 1080p or WUXGA reduced blanking).
Audio can be de-embedded from HDMI and SDI input sources using the
built-in Digital to Analogue audio converter (DAC), whilst analogue audio
can also be converted to digital for ultimate exibility in audio signal
management. In addition, there is an SDI Loop Out for monitoring or
extending the SDI input signal. Control is via the IR remote, RS-232, or via
front panel buttons and includes an on-screen menu providing settings
and system information.
2. APPLICATIONS
Digital and analogue signal convergence
Convert analogue video/audio signals for use with digital displays
Integrate multiple sources and signal types to a single display in a
Meeting room or Conference hall environment
3. PACKAGE CONTENTS
EL-5600 Multi format switch
Remote Control (CR-117)
15-pin D-Sub to 3 RCA adaptor cable
Power Adaptor
Operation Manual
4. SYSTEM REQUIREMENTS
Source equipment such as Blu-ray players or SDI camera, VGA or HDMI
display and amplier/active speakers with connection cables.

7
5. FEATURES
Supports HDMI, Composite Video, S-Video, PC (VGA)/HD (Component)
and SDI inputs
Supports HDMI and VGA/Component (with adaptor) outputs
Supports SDI loop-through output
Supports analogue stereo, optical and coaxial digital inputs and
optical digital output, analogue stereo output or embedding to HDMI
output
Supports conversion of multiple video formats and audio input to
HDMI or PC/HD and analogue stereo outputs
Supports EDID and HDCP
Supports 3D de-interlacing, noise reduction and 3D comb lter
Supports frame rate conversion
Supports RS-232, IR remote control, and front panel control
Supports SDI Standards of SMPTE 425M (Level A and Level B), SMPTE
424M, SMPTE 292M, SMPTE 259M-C
Supports SDI bit rates at 2.970 Gb/s, 2.970/1.001 Gb/s, 1.485 Gb/s,
1.485/1.001 Gb/s and 270 Mb/s
Supports SDI signal input and output distances of up to 300m for SD
signals, 200m for HD signals and 100m for 3G signals
Supports SDI Auto video mode detection (3G/SD/HD)
Video functions: Aspect Ratio Adjustment / Video Noise Reduction /
Underscan & Overscan Selection / De-Interlacing
Note: SDI cable operating distance tested with belden 1694A cable. Operating
distances may vary for cables of dierent specications.

8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
TUPNIREWOP PMOCVSVCRI RETNEUNEMIDS2IMDH1IMDHCP
-
+
CSLUX-300I DIGITAL VIDEO SCALER
XGA
720P
1 2 4 63 5
1POWER & POWER LED: Press this button to switch the device on or
to set it to standby mode. Once the device is connected to an active
power supply the LED will illuminate and the device will switch on
automatically.
2IR Receiver window: Receives only the IR signal from the remote
control included in the package.
3INPUT button and LEDs: Press this button repeatedly to cycle
through the input sources sequentially. An LED on the front panel will
illuminate to indicate the selected input source.
4MENU: Press this button to enter the OSD menu.
5−/+: Press these buttons to navigate up and down in the OSD menu.
6ENTER: Press this button to conrm the selection in the OSD menu.
Press this button simultaneously with the '+' (plus) button to instantly
switch the output to XGA resolution or with the '−' (minus) button to
instantly switch the output to 720p resolution.

9
6.2 Rear Panel
DC 5V
2ECIVRES1ECIVRES
OPTICAL OPTICAL
RS232
L/R L/R
Cr/Pr Cb/Pb Y SV
R L
R L
R LCV
HDMI HDMI 1 HDMI 2
PC/HD PC
SDI
LOOP OUTPUT SDI
OUTPUT INPUT
1 63
2 4 5 7
1OUTPUT:
L/R: Connect to an amplier or active speakers for audio output in
stereo format.
HDMI: Connect to an HDMI display or amplier for video and/or audio
output.
OPTICAL: Connect to an amplier or active speakers for audio output
in digital format.
PC/HD: Connect to a monitor/display for video output. For HD
(Component) output,use the supplied D-Sub 9pin to 3 RCA adaptor
cable for HD resolutions from 480p~1080p.
2SERVICE 1: Reserved for manufacturer use only.
3SDI LOOP OUTPUT: Connect to an SDI display for monitoring of the
SDI input signal or an SDI extender for extending the SDI signal to
further areas.
4RS-232: Connect to a PC/Laptop to use RS-232 commands to control
the device (See Section 6.5 for details on RS-232 commands).
5SERVICE 2: Reserved for manufacturer use only.
6INPUT:
SDI: Connect to an SDI camera or other SDI source for both video and
audio signal conversion.
HDMI 1: Connect to an HDMI source such as Blu-ray/DVD player for
both video and audio signal conversion.
HDMI 2: Connect to an HDMI source such as Blu-ray/DVD player for
both video and audio signal conversion.

10
L/R: Connect to source's L/R output with 3.5mm mini-jack for audio
signal conversion.
PC/HD: Connect to a PC/Laptop source for video signal input with a
D-Sub 15pin cable.
OPTICAL: Connect to a source's optical output for audio signal
conversion.
YCbCr/HDPbPr + L/R: Connect to source equipment such as a DVD
player for both video and audio signal conversion.
CV + L/R: Connect to a composite video source such as video/DVD
player for both video and audio signal conversion.
SV + L/R: Connect to an S-Video source such as a video/DVD player for
both video and audio signal conversion.
7DC 5V: Plug the 5V DC power supply into the unit and connect the
adaptor to an AC outlet.
6.3 Remote Control
1INPUT: Press this button repeatedly
to cycle through the input sources
sequentially. An LED on the front panel
will illuminate to indicate the selected
input source.
2POWER: Press this button to switch the
device on or to set it to standby mode.
3CV/SV/COMP/PC/HDMI1/HDMI2/SDI:
Direct source selection keys. Press one
of these keys to switch to the selected
source.
4EXIT: Press this button to exit the menu or
the current selection in the OSD menu.
5MENU: Press this button to enter the OSD
menu.
6RESET: Press this button to reset the
device back into the default settings.
CR-117
POWERINPUT
PC HDMI 1 HDMI 2
SDI
EXIT MENU
OK
RESET AUTO
ADJUST
1
4
6
2
5
7
8
3
SVCV COMP

11
7AUTO ADJUST: Press this button when the image being output does
not correctly t the display's screen. The device will auto adjust the
image to ll the screen.
8OK & ʆʈʉʇ: Press OK to conrm the selection or press the arrow
buttons to navigate the OSD menu.
6.4 RS-232 Protocols
EL-5600 ʇ
ʉRemote Control
PIN Assignment PIN Assignment
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 9600bps
Data bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1

12
6.5 RS-232 Commands
Command Description Contents
S SOURCE 0~6 Select input source SDI(0) / HDMI1(1) / HDMI2(2)
/ YPBPR(3) / VIDEO(4) /
SVIDEO(5)/ PC(6)
R SOURCE Inquire input source
S OUTPUT 1~25 Select output timing 640*480(1)/800*600(2)/
1024*768(3)/1280*768(4)/
1360*768(5)/1280*720(6)/
1280*800(7)/1280*1024(8)/
1440*900(9)/1400*1050(10)/1
680*1050(11)/
1600*1200(12)1920*1080(13)/1
920*1200(16)/
480p(17)/720p 60(18)/ 1080p
60(19)/ 1080i 60(20)/
576p(22)/720p 50(23)/ 1080p
50(24)/ 1080i 50(25)
R OUTPUT Inquire output timing
S SIZE 0~6 Select output size OVERSCAN(0) / FULL(1) /BEST
FIT(2) / PAN SCAN(3)/LETTER
BOX(4) /UNDER 2(5) / UNDER
1(6)
R SIZE Inquire output size
S CONTRAST 0~60 Contrast Setting
R CONTRAST Inquire contrast setting
S BRIGHTNESS 0~60 Brightness setting
R BRIGHTNESS Inquire brightness setting
S HUE 0~60 Hue setting
R HUE Inquire hue setting
S SATURATION 0~60 Saturation setting
R SATURATION Inquire saturation setting
S SHARPNESS 0~30 Sharpness setting
R SHARPNESS Inquire sharpness setting
S NR 0~3 Noise reduction setting OFF(0) / LOW (1) / MIDDLE(2)
/ HIGH(3)
R NR Inquire noise reduction
setting

13
Command Description Contents
S AUDIODELAY 0~3 Audio delay setting OFF(0) / 40ms (1) / 110ms(2)
/ 150ms(3)
R AUDIODELAY Inquire audio delay setting
S AUDIOMUTE 0/1 Audio mute setting ON(0) / MUTE(1)
R AUDIOMUTE Inquire audio mute setting
S SDIAUDIO 0~3 SDI Audio channel setting CH1CH2(0), CH3CH4(1)
CH5CH6(2), CH7CH8(3)
R SDIAUDIO Inquire SDI Audio channel
setting
S AUDIOSELECT 0/1 Audio Input setting ANALOG(0) / SPDIF(1)
R AUDIOSELECT Inquire audio Input setting
S KEY LOCK 0/1 Key lock setting ENABLE(0) / DISABLE(1)
R KEY LOCK Inquire key lock setting
FW Firmware checking
S RESET 1 Pre-reset
S POWER 0/1 Power Setting OFF (0) / ON (1)
R POWER Inquire Power Setting
EXIT Exit
Note:
1.Audio delay is only supported on analogue L/R output.
2.When the HDMI input is encoded with HDCP, no image will be output from
the PC/HD output.
3.Only LPCM 2 channel digital audio is supported, please ensure that the
source audio is set to LPCM 2 channel audio in order to avoid unneccessary
audio noise.

6.6 OSD MENU
1st Layer 2nd Layer 3rd Layer 4th Layer
DISPLAY
OUTPUT
640×480 60
800×600 60
1024×768 60
1280×768 60
1360×768 60
1280×720 60
1280×800 60
1280×1024 60
1440×900 60
1400×1050 60
1680×1050 60
1600×1200 60
1920×1080 60
1920×1200 60
720×480P 60
1280×720P 60
1920×1080i 60
1920×1080p 60
720×576p 50
1280×720p 50
1920×1080i 50
1920×1080p 50
SIZE (VIDEO mode only)
OVER SCAN
FULL
BEST FIT
PAN SCAN
LETTER BOX
UNDER 2
UNDER 1
MODE INFO
OFF
INFO
ON
PC (PC mode only)
AUTO SETUP
H_POSITION
V_POSITION
PHASE
CLOCK
WXGA/XGA XGA
WXGA
RESET

1st Layer 2nd Layer 3rd Layer 4th Layer
COLOUR
COLOUR
R
G
B
R OFFSET
G OFFSET
B OFFSET
CONTRAST 0~60
BRIGHTNESS 0~60
HUE 0~60
SATURATION 0~60
SHARPNESS 0~30
NR.
OFF
LOW
MIDDLE
HIGH
AUDIO
VOLUME 0~100
DELAY
OFF
40ms
110ms
150ms
SOUND ON
MUTE
SDI AUDIO
CH1 – CH2
CH3 – CH4
CH5 – CH6
CH7 – CH8
AUDIO SELECT
(AV/SV/YPbPr/VGA
only)
ANALOG
SPDIF
SETUP
FACTORY RESET
KEY LOCK OFF
ON
POWER SAVE OFF
ON
INFORMATION INPUT
OUTPUT
REVISION
Items in Bold are the default settings.

16
7. CONNECTION AND INSTALLATION
DC 5V
2ECIVRES1ECIVRES
OPTICAL OPTICAL
RS232
L/R L/R
Cr/Pr Cb/Pb Y SV
R L
R L
R LCV
HDMI 1 HDMI 2
PC/HD PC
SDI
LOOP OUTPUT SDI
OUTPUT INPUT
HDMI
OR
HD Satelite Receiver
SDI Camera
SDI
Input
Set-top Box
PC
PC or RS-232
Control System Blu-ray/DVD Player
VGA and Analogue Audio Inputs
HDMI, Optical Digital
and Analogue Audio
Inputs
HDMI, Composite Video &
Analogue Audio Inputs
SDI
Loopthrough
Output
HDMI
Output
Analogue
Audio
Output
Coaxial
Digital
Output
VGA
Output
Component
Output
SDI MonitorTV or Monitor with
3.5mm audio input
TV or MonitorAV Receiver
RS-232

17
8. SPECIFICATIONS
8.1 Technical Specications
Input Ports 1×Composite,1×S-Video,
1×Component, 1×PC/HD, 2×HDMI,
1×SDI, 1×Optical, 4×Analogue Stereo
(L/R), 1×USB (service only), 1xMini-jack
(service only), 1xRS-232 (Control Only)
Output Ports 1×HDMI, 1×PC/HD, 1× SDI (Loop out),
1×Optical, 1×Analogue Stereo (L/R)
Supports Input Resolutions Up to UXGA & 1080p
Supports Output Resolutions Up to WUXGA & 1080p
Power Supply 5 V/3 A DC (US/EU standards, CE/FCC/
8/FHUWLÀHGDimensions 320mm(W) × 182mm(D) × 44mm(H)
Weight 1600g
Chassis Material Metal
Silkscreen Colour Black
Operating Temperature Ý&aÝ&Ý)aÝ)Storage Temperature ïÝ&aÝ&ïÝ)aÝ)Relative Humidity a5+QRQFRQGHQVLQJPower Consumption 10.5 W

18
8.2 Supported Input/Output Resolutions
Input
Resolution CV/SV Component PC HDMI
NTSC/PAL 9
480i/576i 99
480p/576p 99
720p@50/60Hz 99
1080i@50/60Hz 99
1080p@50/60Hz 99
VGA@60/72/75Hz 99
SVGA@56/60/72/75Hz 99
XGA@60/70/75Hz 99
SXGA@60/75Hz 99
UXGA@60Hz 99
1280x800@60Hz 99
1680x1050RB@60Hz 99
1920x1080@60Hz 99

19
Output
Resolution PC/HD HDMI
480p/576p 9(HD) 9
720p@50/60Hz 9(HD) 9
1080i@50/60Hz 9(HD) 9
1080p@50/60Hz 9(HD) 9
VGA@60Hz 99
SVGA@60Hz 99
XGA@60Hz 99
SXGA@60Hz 99
UXGA@60Hz 99
1280x768@60Hz 99
1280x800@60Hz 99
1360x768@60Hz 99
1400x1050@60Hz 99
1440x900@60Hz 99
1680x1050@60Hz 99
1920x1200@60Hz 99

20
9. ACRONYMS
ACRONYM COMPLETE TERM
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protectionl
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television
OSD On-screen Display (Menu)
SDI Serial digital interface
USB Universal Serial Bus
VGA Video Graphics Array
WUXGA Wide Ultra Extended Graphics Array
Table of contents
Other CYP Switch manuals
