CYP PU-8H8HBT User manual

PU-8H8HBT
8 x 8 HDMI HDBaseT™ Matrix (inc. PoE)
OPERATIONS MANUAL

DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2011 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sucient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
RDV1 21/05/2012 Preliminary Release

CONTENTS
1. Introduction ...........................................6
2. Applications ...........................................6
3. Package Contents ..................................6
4. System Requirements ...........................6
5. Features ..................................................7
6. Operation Controls and Functions .......8
6.1 Front Panels ................................................. 8
6.2 Rear Panels ................................................... 9
6.3 Side Panel ...................................................10
6.4 Remote Control ........................................10
6.5 IR Pin Assignment ....................................11
6.6 RS-232 Protocols ......................................12
6.7 RS-232 Commands ..................................13
7. Connection Diagram .......................... 14
8. Specications ...................................... 16
9. Acronyms ............................................. 17

6
1. INTRODUCTION
As the Flagship 8x8 HDBaseT™ Matrix, the PU-8H8HBT solution oers
complete HDBaseT™ convergence. Installers can switch and distribute up
to 8 HDMI sources, RS-232, 2-Way IR, and PoE to lengths of up to 100m
using CAT5e/6 cable infrastructure. This single box solution will enable an
installer to condently integrate an eight zone multi-room AV system. The
PU-8H8HBT is designed to be used with the PU-507-RX Receiver which
can utilise the Power over Ethernet (PoE) capabilities of the matrix.
2. APPLICATIONS
HDMI System controls
Video/TV wall display and control
Security surveillance and control
Commercial advertising, displaying and control
Lecture room display and control
Hyper market demonstration and control
3. PACKAGE CONTENTS
8×8 HDMI Matrix Switcher over CAT5e/6/7
HDMI over CAT5e/6/7 Receiver (Optional)
2×IR Extender
2×IR Blaster
2×24 V/6.25 A DC Power Adaptor (1 for PoE)
1×IR Remote control
Operation manual
4. SYSTEM REQUIREMENTS
Input source equipment with HDMI connection cables, industry
standard CAT5e/6/7 cables
Output display or audio receiver equipments with HDMI connection
cables
HDMI over CAT5e/6/7 Receiver(s)

7
5. FEATURES
Supports all v1.3 HDMI resolutions
Supports uncompressed video/audio up to 10.2Gbps
Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i,
1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.
HDMI, HDCP and DVI complaint
High Denition Audio supported: Dolby TrueHD, Dolby Digital Plus
and DTS-HD Master Audio plus LPCM (up to 192kHz)
Uncompressed data transfer over single CAT cable (100m - CAT6; 80m -
CAT5e)
Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit.
Supports RS-232, 2-Way IR, Manual Selection Buttons, and HDMI CEC
control pass through
Selectable EDID settings - TV (downstream) and STD (xed).
Compact 2U Rack mount design
Supports 3D signals
Supports additional IR Control via a master (ALL) Input/Output.
Note: The PoE function is designed for powering compatible receiver units
only—non-PoE receivers will need their own power supply.Receivers of
another brand may not be compatible.

8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panels
POWER LOCK
MENU OUTA 1B2C3D4
IN
E5F6G7H8
2 3 4 5 61
1
LCD Display: Displays the setting information of each input and
output selection.
2
Power button LED: Press this button to power the device on/o.
The LED will illuminate green when the power is on, red when it is in
'Standby' mode.
3
LOCK: Press this button to lock all the buttons on the panel, press
again to unlock. The LED will illuminate green when locked.
4
IR: IR Receiver window (accepts the remote control signal of this
device only).
5
MENU: Press this button to change the EDID setting from STD (internal)
1 to TV (external) 2 , press it again to conrm the selection.
6
1~8/A~H and Out/In button: Press the Out or In button to select the
output or input mode then press the required number button to make
the selection accordingly.
For example, if outputs A~D need to be set to input 1 and outputs
E~H need to be set to input 2 then the following sequence of button
presses need to be performed
Press: Out ABCDIn1Menu,
and then press: OutEFGHIn2Menu.
Note: If the menu button is not pressed the selection will not be changed.

9
6.2 Rear Panels
LAN
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E F G H
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUTCAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
12
34
V+
GND
GND
GND
V+
2 4
3
5 10 111 7
96
8
1
LAN: Reserved.
2
RS-232: Connect to a PC or laptop with D-Sub 9-pin female cable for
the transmission of RS-232 commands.
3 MATRIX IR OUT: Connect to the IR blaster (included in the package) for
transmitting IR signals to the source or display equipment. Place the IR
blaster in direct line-of-sight of the equipment to be controlled
4
MATRIX IR IN: Connect to the IR extender (included in the package) for
the reception of IR signals from the remote control of this device or the
source and display equipment. Ensure that remote being used is within
the direct line-of-sight of the IR extender.
5
SERVICE: This slot is to connect with mini USB-B type cable for rmware
update only.
6
IR IN 1~8: Connect the supplied IR extenders (included in the package)
for IR signal reception. Ensure that remote being used is within the
direct line-of-sight of the IR extender
7
IR OUT 1~8: Connect the supplied IR blasters (included in the package)
for IR signal transmission. Place the IR blaster in direct line-of-sight of
the equipment to be controlled.
8
CAT5e/6/7 OUT 1~8: Connect to the Receiver units with a single
CAT5e/6/7 cable from the Receiver for HDMI Audio/Video and IR/RS232
control.
9
HDMI IN 1~8: Connect to the HDMI input source devices such as a DVD
player or a Set-top Box with HDMI cable or DVI to HDMI converter cable.
10
PoE 24V: This slot is to plug the power cord with adaptor included in the
package and then connect them with AC wall outlet for power supply, for
powering receivers with Power-over-Ethernet capability.
11
DC 24V MAIN POWER: This slot is where user connect the 24V DC power
adaptor included in the package and plug the adaptor to an AC wall
outlet for power supply, for powering the main unit.

10
6.3 Side Panel
1
1
Fan Ventilator: These are air ventilation areas, DO NOT block these
areas or cover it with any object. Please allow adequate space around
the unit for air circulation
6.4 Remote Control
1
Power: Press this button to switch
on the device or set it to standby
mode.
2
IN: Input ports selection 1~8.
3
OUT: Output ports selection A~H.
1
23

11
6.5 IR Pin Assignment
3
1
3
2
2
1Power 5 V
IR Blaster Signal
NC
IR Signal
Power 5 V
Grounding
IR Receiver
IR Blaster

12
6.6 RS-232 Protocols
Pin Assignment
CMSI-8H8CV Remote Control Console
PIN Assignment PIN Assignment
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200bps
Data bit: 8 bits
Parity: None
Stop Bit: 1
Flow Control: None

13
6.7 RS-232 Commands
Command (Case
Sensitive)
Description
A1~A8 Switch output A to 1~8
B1~B8 Switch output B to 1~8
C1~C8 Switch output C to 1~8
D1~D8 Switch output D to 1~8
E1~E8 Switch output E to 1~8
F1~F8 Switch output F to 1~8
G1~G8 Switch output G to 1~8
H1~H8 Switch output H to 1~8
ABCD...1~ABCD...8 Switch output ABCD... to 1~8 at the same time
P0 POWER OFF
P1 POWER ON
I1~I8 Switch all the output to 1~8
ST Display the current matrix status and F/W version
RS System Reset to A1, B2, C3, D4, E5, F6, G7, H8
?Display all available commands

7. CONNECTION DIAGRAM
ZONE A
LAN
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E
F G H
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
12
34
V+
GND
GND
GND
V+
1 2 3 4
5 6 87
RX
ZONE
B
Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE C
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE
D
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE EZONE FZONE GZONE H
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
RS232 Equipped
PC or Notebook
IR Out (All)
IR In (ALL)

ZONE A
LAN
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E
F G H
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
CAT5e/6 OUT
IR OUT
IR IN
CAT5e/6 OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
12
34
V+
GND
GND
GND
V+
1 2 3 4 5 6
87
RX
ZONE B
Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE C
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE D
RX
Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
ZONE
EZONE
FZONE GZONE
H
RX Power
Extender Blaster
IR 2
IR 1
RS232 Out CAT5e/6 In
Link
IR BLASTER
1.5m
60°
IR RECEIVER
7m
3m 3m
60°
m
Main Power Supply
Power Supply for
Power-over-Ethernet
Receiver Units
Single
CAT 5e/6 Cable
HDMI Inputs
IR Out/In
HDMI Outputs
IR Out/In
Source
Equipment
Displays

8. SPECIFICATIONS
Max. TMDS Bandwidth 6.75 Gbps
Input Ports 8×HDMI, 9×IR Extender, 1×RS-232,
1×Mini USB-B type(for rmware update
only)
Output Ports 8×CAT5e/6/7, 9×IR Blaster
ESD Protection Human body model:
± 8kV (Air-gap discharge)
± 4kV (Contact discharge)
Power Supply 24 V/6.25 A DC (US/EU standards, CE/
FCC/UL certied)
Dimensions 438 mm(W)×255 mm(D)×93 mm(H)
Weight 4458 g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0 ºC~40 ºC/32 ºF~104 ºF
Storage Temperature −20 ºC~60 ºC/−4 ºF~140 ºF
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 64 W Tx(Main), 56 W Rx(PoE)

9. ACRONYMS
ACRONYM COMPLETE TERM
DTS Digital Theater System
DVI Digital Visual Interface
EDID Extended Display Identification Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television
LCM Liquid Crystal Monitor
USB Universal Serial Bus
UXGA Ultra Extended Graphics Array
VGA Video Graphics Array

CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue,
Shepperton, Middlesex, TW17 8BA
Tel: [phone] | Fax: [phone]
Email: [email protected]
www.cypeurope.com
