CYP CMSI-8D8DSA User manual

CMSI-8D8DSA
8 x 8 DVI Matrix with Audio
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.0 September 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 05/03/12 Preliminary Release

CONTENTS
1. Introduction............................................1
2. Applications...........................................1
3. Package Contents ................................1
4. System Requirements............................1
5. Features..................................................1
6. Operation Controls and Functions.......2
6.1 Front Panel........................................2
6.2 Rear Panel.........................................3
6.3 Side Panel.........................................4
6.4 Remote Control................................4
6.5 RS-232 Protocols ...............................5
6.6 RS-232 Commands...........................5
7. Specications ........................................6
8. Connection and Installation.................7
9. Acronyms...............................................8

1
1. INTRODUCTION
The 8 x 8 DVI Matrix with Audio allows DVI-D signal from any of it eight
cources to be routed to and displayed on any of its eight connected
DVI monitors or HDTV simultaneously. Each DVI input or output port
has an associated phone jack connector, for the audio signal to be
processed with video synchronously. The matrix supports full range of
PC and HDTV timings up to WUXGA and 1080p, 2.25Gbps bandwidth,
12-bit Deep Color, and 3D. The management of source/sink scenarios
can be handled easily through on-panel buttons, IR remote control,
or RS-232 protocol.
2. APPLICATIONS
• Video/TV wall display
• Commercial advertising and displaying
• Lecture room display and control
• Hyper market demonstration and control
3. PACKAGE CONTENTS
• 8 x8 DVI Matrix with Audio
• 24V/6.25A DC adaptor x 1
• Remote control x 1
• IR receiver cable x 1
• Operation manual
4. SYSTEM REQUIREMENTS
• Input source equipments with DVI connection cables and 3.5mm
phone jack cable or other audio equipment.
• Output DVI display with DVI connection cables.
5. FEATURES
• HDMI, HDCP1.1 and DVI compliant
• Supports HDMI 3D feature (with HDMI to DVI adaptor cable)
• Supports resolutions to VGA ~ WUXGA and 480i~1080p follow by
output display’s EDID
• Supports 3D signal display follow by display TV’s EDID

2
• Supports IR extension
• Supports RS-232, remote control and on panel control
• 2U size design

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
1 62 3 4 5
POWER LOCK
MENU OUTA 1B2C3D4
IN
E5F6G7H8
8X8 DVI MATRIX CMSI-8D8DSA
1LCM
This monitor displays your setting information with each input and
output selection.
2POWER button & LED
Press this button to turn on the device and the green LED will
illuminate when the power is on. When the LED illuminate in red it is
in standby mode
3LOCK button & LED
Press this button to lock all the buttons on the panel. To unlock, just
press it again.
4IR
This IR window accepts the remote control signal of this device
only.
5MENU
Press this button once to select EDID setting from STD (internal) 1 or
TV (external) 2 then press it again to conrm the selection. Press
this button every to conrm the selection.
EDID TV: The device will read the EDID of HDMI output A and
record it.
EDID STD: The device's built-in EDID is 1080p@60/12bits for video
and LPCM 2CH for Audio.
61 ~8 /A ~ H & Out/In button
Press Out/In button rst to select the output/input then press the

4
number button to make the selection accordingly. For example,
output A ~ D wish to select input 1 and E ~ H wish to select input
2. Press Out→A→B→C→D→In→1→Menu, and then press Out
→E→F→G→H→In→2→Menu. If the menu button is not press the
selection will not be changed.
6.2 Rear Panel
1
23
4
V+
GND
GND GND
V+
LAN IR IN
RS232 SERVICE
ABCDEFFG
DVI IN
DVI OUT
12345678
DVI OUT
AUDIO OUT
AUDIO IN
AB
12
CDEFGH
345678
12 3 4 765
1
LAN
Reserved.
2
RS-232
This slot is to connect with D-Sub 9pin cable from the PC/NB device
for RS-232 control.
3
IR-IN
This slot is to connect with the IR extender included in the package
for IR signal receiving from the remote control of this device.
4
SERVICE
This slot is to connect with USB cable for manufacturers’ rmware
update only.
5
DVI OUT A~H with Audio
These slots are to connect with display or monitor with DVI cables
and active speakers with 3.5mm phone jack for output image
display and audio simultaneously.
6
DVI IN 1~8 with Audio
These slots are to connect with input source equipment such as
PC/NB or Graphic card with DVI cable or HDMI to DVI converter

5
cable for input signal sending along with 3.5mm phone jack cable
for audio signal input.
7
DC24V
This slot is to plug the power cord with adaptor included in the
package and then connect them with AC wall outlet for power
supply.
6.3 Side Panel
1
1
VENTILATOR
These are fan ventilator area, DO NOT block these area or cover it
with any object.
6.4 Remote Control
1
Power
Press this button to switch on the device or
set it to standby mode.
2
IN
Input ports selection 1~8.
3
OUT
Output ports selection A~H.
H
8
1A
B
2
3
4D
5E
6F
7G
CR-110
IN OUT
1
2 3
C

6
6.5 RS-232 Protocols
CMSI-8D8DSA
►
◄
Remote Control Console
PIN Assignment PIN Assignment
1 NC 1 NC
2 Tx2 Rx
3 Rx3 Tx
4 NC 4 NC
5GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200bps
Data bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1
6.6 RS-232 Commands
Command Description
A1~A8 Switch output A to 1~8
B1~B8 Switch output B to 1~8
C1~C8 Switch output C to 1~8
D1~D8 Switch output D to 1~8
E1~E8 Switch output E to 1~8
F1~F8 Switch output F to 1~8
G1~G8 Switch output G to 1~8

7
H1~H8 Switch output H to 1~8
ABCD...1~ABCD...8 Switch output ABCD... to 1~8 at the same time
P0 POWER OFF
P1 POWER ON
I1~I8 Switch all the output to 1~8
ST Display the current matrix status and F/W ver-
sion
RS System Reset to A1, B2, C3, D4, E5, F6, G7, H8
?Display all available commands
7. SPECIFICATIONS
Video Bandwidth 225MHz/6.75 Gbps
Input Ports 8 x DVI, 8 x 3.5mm Phone Jack
1 x IR,
1 x RS-232,
1 x mini USB B type
(for rmware update only),
1 x RJ-45 (LAN)
Output Ports 8 x DVI , 8 x 3.5mm Phone Jack
ESD Protection Human body model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Power Supply 24V/6.25A DC (US/EU standards, CE/
FCC/UL certied)
Dimensions 438mm(W) x 255mm(D) x 93mm(H)
Weight 4554g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0˚C ~ 40˚C / 32 ˚F ~ 104 ˚F
Storage Temperature -20˚C ~ 60˚C / -4 ˚F ~ 140 ˚F

8
Relative Humidity 20 ~ 90% RH (non-condensing)
Power Consumption 48W
8. CONNECTION AND INSTALLATION
LAN IR IN
RS232 SERVICE
ABCDEFFG
DVI IN
DVI OUT
12345678
DC 24V
12
34
V+
GND
GND
GND
V+
AUDIO OUT
AUDIO IN
AB
12
CDEFGH
345678
Monitor
Monitor Monitor
Amplier Amplier Amplier Amplier
Active
Speakers Active Speakers Active Speakers Active Speakers
Monitor
PCNB
NB
NB
NB
PC
Monitor
PC PC
Monitor Monitor Monitor
Audio Cable DVI Cable
Audio Equipment

9. ACRONYMS
ACRONYM COMPLETE TERM
DTS Digital Theater System
DVI Digital Visual Interface
EDID Extended Display Identication Data
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDTV High-Denition Television
LCM Liquid Crystal Monitor
USB Universal Serial Bus
VGA Video Graphics Array
WUXGA Wide Ultra Extended Graphics Array
