CZone Switch Control Interface Installation guide

Product description:
The Switch Control Interface (SCI) is a module which converts signals from traditional mechanical switches and converts them into a CAN
signal to control loads via channels on output interface modules
• 8 switch channels per module (sixteen switch points)
• Single switch position can control multiple OI channels
• Multiple SCI switches can control single OI channel
• Output for backlighting of switch labels (dimmable)
• Outputs systems on and function/fault codes to systems
on LED of switches (dimmable)
• Programmable switch types
Normally open
Normally closed
Momentary open or closed
Dimmer
Timer
Interlocking
Dimensions:
H 100mm (3”29/32) x W156mm (6”3/32) x D 42mm (1”5/8)
• IPX5 water ingress rated
Weight: 281g
SCI features:
Switch Control Interface (SCI)
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
EMC ratings:
• IEC EN 60945
• IEC EN 61000
• FCC Class B
• ISO 7637 - 1 (12V Passenger cars and light commercial vehicles
with nominal 12V supply voltage - Electrical transient conduction
along supply lines only)
• ISO 7637 - 2 (24V Commercial vehicles with nominal 24 V supply
voltage - Electrical transient conduction along supply lines only)
• IEC Standards for indirect lighting strikes

For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
LED Flash Codes
Network Status indicator
Network Status Indicator
• Extinguished = Network power disconnected
• Green = Network power connected
• Red = Network traffic
Channel Status Indicators
In the Case of the SCI module the LED channel status indicator flashes are displayed on the Carling switches that are connected to the
SCI (Systems in operation window)



For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
Connections
SCI – 8 Way connector housing
Front View
Plugs into
carling Switch
Plugs to SCI 8
Way connector



For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
Connections
Internal SCI Conductor connections
RJ45 Conductor Colour Carling terminal Housing Conductor Designation
(in relation to SCI)
1 Green/White 8 Backlighting + 2V
2 NC
3 NC
4 Brown/White 3 Switch O/P Position 1
5 Green 1 Switch O/P Position 2
6 Blue 7 NEG
7 Orange Systems on + 2V
8 Brown 2 Switch I/P centre position
Internal SCI Conductor connections
SCI Cable Connections



For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
Labelling
Connections/LED flash code label
This label is located on the inside of the front lid of the unit, it shows the LED codes and electrical connections to the unit
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com


For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
Pictorial Overview
NMEA 2000
connector
Carling
8 way RJ45
connector bank
Proprietary
cable assembly
Waterproof
Cable grommet

For more information contact BEP | ph: [phone] | email: [email protected] | www.bepmarine.com
Dimensions

