D-Link DCH-M225 User manual

MUSIC EVERYWHERE
DCH-M225
QUICK
INSTALLATION
GUIDE
INSTALLATIONS-ANLEITUNG
GUIDE D’INSTALLATION
GUÍA DE INSTALACIÓN
GUIDA DI INSTALLAZIONE
INSTALLATIEHANDLEIDING
INSTRUKCJA INSTALACJI
INSTALAČNÍ PŘÍRUČKA
TELEPÍTÉSI SEGÉDLET
INSTALLASJONSVEILEDNING
INSTALLATIONSVEJLEDNING
ASENNUSOPAS
INSTALLATIONSGUIDE
GUIA DE INSTALAÇÃO
ΟΔΗΓΟΣ ΓΡΗΓΟΡΗΣ ΕΓΚΑΤΑ
VODIČ ZA BRZU INSTALACIJU
KRATKA NAVODILA ZA UPORABO
GHID DE INSTALARE RAPIDĂ

DCH-M225 3
ENGLISH
CONTENTS OF
PACKAGING
MUSIC EVERYWHERE
DCH-M225
WI-FI CONFIGURATION CARD
If any of these items are missing from your packaging,
contact your reseller.
For the full product manual, please go to
http://www.dlink.com

DCH-M225
4
ENGLISH
INTRODUCTION
Music Everywhere (DCH-M225) allows you to play music from your smartphone,
tablet or computer wirelessly to your speakers. Simply plug in your speaker jack into
Music Everywhere (DCH-M225) and connect it to your Wi-Fi network. It also has a Wi-
Fi extender built-in to help you eliminate any Wi-Fi black spots in your home. If you
do not have access to a Wi-Fi network, you can also use the direct connect mode to
play music wirelessly, which connects your smart phone, tablet or computer directly to
Music Everywhere.
Play your music from your smartphone, tablet or computer wirelessly to your speakers as
well as extend your Wi-Fi coverage.
Smartphone
Internet Modem
Computer
Router
DCH-M225
Tablet
Speaker
Smartphone
Computer
DCH-M225
Tablet
Speaker
Or play music wirelessly directly from your smartphone, tablet or computer to Music
Everywhere without a Wi-Fi network.
CONNECT TO YOUR WI-FI NETWORK
CONNECT DIRECTLY TO MUSIC EVERYWHERE

DCH-M225 5
ENGLISH
PRODUCT SETUP
SETUP
SELECT YOUR METHOD
There are 3 easy ways to set up Music Everywhere.
1. Download the QRS Mobile app and follow the step by step instructions
2. One button secure connection using Wi-Fi Protected Setup (WPS)
3. Or you can log into Music Everywhere's web conguration using an Internet
browser
1. SET UP MUSIC EVERYWHERE WITH QRS MOBILE APP
First, download and install the QRS Mobile app.
This is available from the Apple App Store or
Google Play. Simply scan the corresponding QR
code below.
Before launching the QRS Mobile app, you must rst connect your smartphone or
tablet wirelessly to Music Everywhere. Music Everywhere's Wi-Fi network name
(SSID) and Wi-Fi password can be found on the Wi-Fi Conguration Card provided
and also on the device label.
Make sure the Wi-Fi functionality on your smartphone or tablet is ON. From your
device's wireless connection settings, search for and select Music Everywhere's Wi-
Fi network name (SSID). Enter the Wi-Fi password to connect to Music Everywhere.
If you are unsure how to do this, please refer to your smartphone or tablet manual for
more information.
QRS
If you are planning to use Music Everywhere without a Wi-Fi network, after you
have connected your smartphone, tablet or computer to Music Everywhere's
Wi-Fi, please go directly to the "PLAYING YOUR MUSIC WIRELESSLY TO
YOUR SPEAKERS" section of this quick installation guide to continue set up.
DIRECT CONNECT MODE

DCH-M225
6
ENGLISH
PRODUCT SETUP
SETUP
Once your smartphone or tablet is connected to
Music Everywhere, launch the QRS Mobile app.
The Setup Wizard will rst search and list all the
Wi-Fi networks available. Select your home Wi-Fi
network and enter your W-Fi network password.
Music Everywhere is now connected to your home
Wi-Fi network.
For the Wi-Fi extender function, you now have the
option to either keep the existing Wi-Fi network
name (SSID) and password for the extended Wi-
Fi network, or enter a new Wi-Fi network name
(SSID) and password. You can also choose
to create an administrator password to secure
access to Music Everywhere's web-based
configuration. Note: If you choose to change
the SSID and password, it is recommended that
you make a record of this information for future
reference.
A summary of the network settings will then be
displayed. Once you are satised, click Save, and
the setup wizard will reboot Music Everywhere for
the new settings to take effect. Music Everywhere
is now ready for you to wirelessly stream music
to your speakers as well as extending your
existing Wi-Fi network.

DCH-M225 7
ENGLISH
2. SET UP MUSIC EVERYWHERE USING Wi-Fi PROTECTED SETUP (WPS)
NOTE: In order to use the one touch WPS secure wireless connection, please make
sure that your home Wi-Fi router supports WPS and has the corresponding WPS
button.
PRODUCT SETUP
SETUP
Plug Music Everywhere into a wall outlet and wait until
the power LED is blinking amber. Push the WPS button
on your home Wi-Fi router (please refer to your home
Wi-Fi router's manual if necessary) and then push the
WPS button on Music Everywhere within 120 seconds.
The LED will start to ash green.
Music Everywhere is now ready for you to wirelessly
stream music to your speakers as well as extending
your existing Wi-Fi network. If you are connecting to the
extended wireless network that was set up using WPS,
the extended SSID will have the extension “-EXT” added
to the original SSID and the password will be same as
your existing wireless password.
Please allow up to two minutes for the process to nish.
The LED will turn solid green when Music Everywhere
has connected successfully to your home Wi-Fi network.
3. SET UP MUSIC EVERYWHERE USING WEB CONFIGURATION
Music Everywhere can also be congured using the web conguration. After you have
plugged Music Everywhere into a wall outlet and the power LED is blinking amber,
go to wireless utility on your computer, select and connect to Music Everywhere's Wi-
Fi network and enter the Wi-Fi password (both can be found on the included Wi-Fi
Conguration Card and also on the device label). Then open a web browser and type
http://dlinkap.local. By default, the username is Admin, and the password field
should be left blank. Please refer to the product manual, which can be found on the
enclosed CD, for further information on conguring Music Everywhere using the web
GUI.

DCH-M225
8
ENGLISH
PLAYING YOUR MUSIC WITH APPLE IOS DEVICES
NOTE: The below guide is for iOS 7. For more information on how to enable AirPlay
on devices using iOS versions earlier than iOS 7, please refer to Apple's support
page.
PRODUCT SETUP
PLAYING YOUR MUSIC WIRELESSLY TO YOUR SPEAKERS
1. Make sure Wi-Fi is turned on for your iOS device and that
your iOS device is connected to the same network as
Music Everywhere.
2. Swipe up from the bottom of your screen to access the
‘Control Center’ function of your device.
3. Tap "AirPlay"
4. Choose Music Everywhere (DCH-M225) from the list of
devices.
5. To choose a song to play, press the home button to
navigate and now navigate to the music App (or another
Airplay enabled music App).
PLAYING YOUR MUSIC WITH ANDROID DEVICES
1. In order to stream music from an Android smartphone or tablet to Music
Everywhere, you will need to download and install an AirPlay or DLNA
streaming capable music app, such as BubbleUPnP or iMediaShare.
2. Make sure Wi-Fi is turned on for your Android device and that your Android
device is connected to the same network as Music Everywhere.
3. For instruction on how to stream music from your Android device to Music
Everywhere, please refer to the app's user's guide.
NOTE: D-Link cannot be held responsible or liable for any direct or consequential
damages resulting from the use of third party applications. For more information
relating to any third party applications, please refer to the app information on Apple
App Store or Google Play, or contact the application developer.
NOTE: Music Everywhere plays music from only one device at a time. To switch
devices, stop the current device before playing music on another device.

DCH-M225 9
ENGLISH
PLAYING YOUR MUSIC WITH WINDOWS MEDIA PLAYER
NOTE: The below guide is for Windows Media Player version 12. For more
information on how to enable the "Play To" function in versions earlier than 12,
please refer to Microsoft's support page.
PRODUCT SETUP
PLAYING YOUR MUSIC WIRELESSLY TO YOUR SPEAKERS
1. Make sure your desktop or laptop computer is connected to the same network
as Music Everywhere.
2. Launch Windows Media Player and make sure it's showing the "Play" tab on
the right hand side
3. Select music you want to play if you haven't done so already.
4. Click the "Play To" button at the top of the "Play" tab and select
"DCH-M225".
5. In the "Play To" dialog box, use the playback controls to play, pause, or stop
the media stream, and to change to the next or previous item in the list.

DCH-M225
10
ENGLISH
PLAYING YOUR MUSIC WITH ITUNES
NOTE: The below guide is for iTunes version 11. For more information on how to
enable the "AirPlay" function in versions earlier than 11, please refer to Apple's
support page.
PRODUCT SETUP
PLAYING YOUR MUSIC WIRELESSLY TO YOUR SPEAKERS
1. Make sure your desktop or laptop computer is connected to the same network
as Music Everywhere.
2. Launch iTunes and select the music you want to play if you haven't done so
already.
3. Click the "AirPlay" icon and select "DCH-M225".
