AC2000 Wi-Fi Range Extender
Quick Install Guide
DAP-1820

2DAP-1820 Install Guide
Package Contents
DAP-1820 AC2000 Wi-Fi Range Extender
Quick Install Card
Quick Install Guide
If any of the above items are missing, please contact your reseller.
• Make sure the area that you want to plug the extender into has a
strong connection to your router. Use a wireless laptop, tablet, or
mobile phone in that area to test the connection to verify.
• If your wireless router or access point does not support WPS, follow
the steps under Congure the DAP-1820 Using D-Link Wi-Fi Setup to
connect to the DAP-1820 and run the Setup Wizard. If you are not
sure how to enable WPS on your wireless router, please refer to your
router’s user manual.
Before You Begin

DAP-1820 Install Guide 3
Product Overview
LED Color Status Description
Status LED
Red Solid The device is powering on.
Amber Blinking The device is ready but not connected to a router.
Green
Solid Indicates that the DAP-1820 is securely connected
to your wireless router or access point.
Blinking The WPS button has been pushed and the device is
processing a connection.
Signal Strength Indicators
Very Weak (Amber)
Weak (1 x Green)
Good (2 x Green)
Strong (3 x Green)
Signal
Strength
Indicators
Status
LED
WPS
Button
Ethernet
Port
Reset
Button

4DAP-1820 Install Guide
Method One: Connect to Your
Router Using WPS
1Find an available outlet near your wireless router.
Plug in the DAP-1820 and wait until the Status
LED is blinking amber.
2Press the WPS (Wi-Fi Protected Setup) button
on your wireless router.
Within one minute, press the WPS button on
the DAP-1820. The Status LED will start to blink.
3
WPS
DAP-1320
There are two easy ways to set up your DAP-1820.
It is recommened that you use Method One if your router has a WPS
button. If your router does not support WPS or you are not sure, see
Method Two, Congure the DAP-1820 Using D-Link Wi-Fi Setup, on page 6.

DAP-1820 Install Guide 5
4When the Status LED turns solid green, this indicates that the DAP-1820 is
securely connected to your wireless router or access point. You can now unplug
and move the DAP-1820 to a location between your wireless router and the
area that you need wireless coverage.
If after moving your DAP-1820, the signal strength
indicators are showing one single amber bar or if the
DAP-1820 is not connecting (Status LED is no longer
green), move the DAP-1820 to a wall outlet closer to
your wireless router or access point.
Note: WPS may not be enabled on all Routers or Modems. If
the Status LED on your Range Extender does not turn solid
green after running WPS setup, try again. If it still does not
turn solid green, see Congure the DAP-1820 Using D-Link
Wi-Fi Setup, on page 6.
Your setup is complete!

6DAP-1820 Install Guide
Method Two: Congure the
DAP-1820 Using D-Link Wi-Fi Setup
1Scan the code below or search “D-Link Wi-Fi” (App Store or Google Play) to
download the D-Link Wi-Fi App to your iPhone, iPad, or Android device.
Once your app is installed, tap on the D-Link Wi-Fi icon from your mobile
device. Please follow the on-screen instructions to complete the setup.
When asked to scan the setup QR Code, scan the QR Code located on
the Quick Install Card.
2
SmartConnect: By default, SmartConnect is enabled on this Range Extender.
SmartConnect will automatically steer your device to the optimal wireless
band according to current network trac. When enabled, you will only see
one wireless network from your Range Extender.
iOS Android D-Link Wi-Fi App
Your setup is complete!
Quick Install Card

DAP-1820 Install Guide 7
Troubleshooting
Why is my DAP-1820 not connecting or dropping signal from my router?
1. Verify that the DAP-1820 is within range of your wireless router. Try plugging it into
a location closer to the router and verify the Status LED is solid green.
Note: When repeating a wireless signal from a router or access point, devices
connected to the repeater will not get the same speed/throughput as when
connected directly to the router.
How do I change the wireless settings on the DAP-1820?
1. Open a web browser (e.g., Internet Explorer, Firefox, Chrome, or Safari) and go to
http://dlinkap.local./
2. At the login screen, enter your password and click Log in.
3. Go to Settings > Extender.
4. Enter a new Wi-Fi Network Name (SSID) and modify the security (Wi-Fi password)
settings as needed.
5. Click Save.
Note: If you have changed the Wi-Fi Network name, the device you are currently using to connect to the
DAP-1820 will drop. You will need to open your wireless utility and connect to the DAP-1820 using the
new network name and password.

8DAP-1820 Install Guide
Where should I place my DAP-1820 when using it as a range extender?
A Range Extender only works as well as the signal it is extending.
Therefore, proper placement of your DAP-1820 is important in
achieving desired results.
For best performance, place your DAP-1820 in between your
router and your dead zone, making sure it is placed in a location
where theWi-Fi signal is still strong. Use the Smart Signal Indicator
to help nd a location with a strong signal. The more bars lit on
the signal indicator, the stronger the Wi-Fi signal is.
Poor
location
Ideal
location
!
!!
Poor
location
Ideal
location
!
!!

DAP-1820 Install Guide 9
What if I forgot my DAP-1820 password?
1. If you forgot your password or want to reset the DAP-1820
back to the factory default settings, press and hold the
reset button on the bottom of the extender using a paper
clip and release after a minimum of 10 seconds. The Status
light will turn red.
Note: This process will erase all your settings.
2. You may repeat the WPS process on page 4. Follow the
steps under Connect to Your Router Using WPS.
Reset
Button
What if WPS setup is not working?
WPS may not be enabled on all Routers or Modems. If the
Status LED on your Range Extender does not turn solid
green after running WPS setup, try again. If it still does not
turn solid green, see Congure the DAP-1820 Using D-Link
Wi-Fi Setup, on page 6.

10 DAP-1820 Install Guide
GPL Code Statement
This D-Link product includes software code developed by third parties, including
software code subject to the GNU General Public License (“GPL”) or GNU Lesser
General Public License (“LGPL”). As applicable, the terms of the GPL and LGPL,
and information on obtaining access to the GPL code and LGPL code used in this
product, are available to you at:
http://tsd.dlink.com.tw/GPL
The GPL code and LGPL code used in this product is distributed WITHOUT ANY
WARRANTY and is subject to the copyrights of one or more authors. For details,
see the GPL code and the LGPL code for this product and the terms of the GPL and
LGPL.
Written Oer for GPL and LGPL Source Code
Where such specic license terms entitle you to the source code of such software,
D-Link will provide upon written request via email and/or traditional paper mail the
applicable GPL and LGPLsource code les via CD-ROM for a nominal cost to cover
shipping and media charges as allowed under the GPL and LGPL.
Please direct all inquiries to:
Email:
GPLC[email protected]
Snail Mail:
Attn: GPLSOURCE REQUEST
D-Link Systems, Inc.
17595 Mt. Herrmann Street
Fountain Valley, CA 92708
GNU GENERAL PUBLIC LICENSE
Version 3, 29 June 2007
Copyright (C) 2007 Free Software Foundation, Inc. <http://fsf.org/>
View the full GPL Code Statement at http://www.gnu.org/licenses/gpl.html

DAP-1820 Install Guide 11
Technical Support
This guide is for rst time conguration. Please refer to the user manual to learn more.
