D-Link AirSpot DSA-3200 User manual

This product can be set up using
any current Web browser, i.e.,
Internet Explorer 6 or Netscape
Navigator 7 or above.
Wireless G Public
/Private Gateway
5VDC 3APowerAdapter
Before You Begin
Check Your Package Contents
DSA-3200 Airspot™Wireless G Public/Private
Gateway
CD-ROM (containing Manual and Warranty)
1x Ethernet (CAT5 UTP/Crossover) Cable
Using a power supply
with a different voltage
rating will damage this product
and void its warranty.
If any of the above items are missing, please contact your reseller.
DSA-3200
©2004D-LinkSystems,Inc.Allrightsreserved.Trademarksorregisteredtrademarksarethepropertyoftheirrespectiveholders.Softwareand
specificationssubjecttochangewithoutnotice.DSA-3200.12202004
Console Cable (RS-232)
These are the items included with your DSA-3200 purchase:
2x Ethernet (CAT5 UTP/Straight-Through) Cable
You will need the following:
• ComputerwithanEthernetadapterandaWindows,Mac,orUnixbasedoperatingsystem.
• InternetExplorer6orNetscapeNavigator,version7.0orabove,withJavaScriptenabled.

2
STATUS LED: A solid LED indicates
theDSA-3200isworkingproperly.The
LEDwillflashduringreboot.
Connecting The DSA-3200 To Your Network
WAN Port: Connects to your
highspeedInternetconnection.
Private LAN Ports:
Connect to your private
network.
CONSOLE: Connects to your
computer’sCOMportusingthe
providedConsoleCable.
(Port also connects to optional
DSA-3100PTicketPrinter)
COM Settings: 9600, 8, n, l, n.
POWER LED: A solid light
indicatesaproperconnection
to the power supply.
NETWORK LEDs:Asolidlightonthe
portindicatesa good connection. The
LEDs blink during data transmission.
Power Receptor:
Connection for the
PowerAdapter.
Public LAN Ports: Connect
to your public network .
Reset Button: PushOnce
to restart. Push and hold
for 15 seconds to reset.
Public WLAN LED: This
LED will flash to indicate
properRFoperation and
blink with activity.

3
A. Poweron the DSA-3200.
B. Connectan Ethernet cablefroma Public LAN portto a switchorwireless access
point on your public network. The Public LAN LED will illuminate to indicate a
proper connection. If the Public LAN LED doesn’t light up, please check the
connections.
C. Connect an Ethernet cable from a Private LAN port to an Ethernet port on your
privatenetwork’sswitch.Ifproperlyconnected,thePrivateLANLEDwillilluminate.
(Note: For configuration purposes a computer can be connected directly to this
port using a standard Ethernet cable)
D. Attach an Ethernet cable to the WAN port on the back panel of the DSA-3200.
Connect the other end to a router or directly to a broadband modem. The WAN
LED light will illuminate to indicate proper connection.
Connecting The DSA-3200 To Your Network
(continued)
When you have completed the steps in this Quick Installation Guide, your connected
network should look similar to this:

4
Using The Setup Wizard
Open your Web browser andtype
https://192.168.0.40 into the URL
address box. Then press the Enter
or Return key.
Type admin for both the
usernameandpassword.
Click Enter
The DSA-3200 provides Web based configuration.You can configure your DSA-3200
using a Web browser such as Internet Explorer or Netscape Navigator in Windows,
Macintosh,or UNIX OS.
(TheIPAddress shownin theexample aboveis thedefault setting.If you’vechanged the
IPAddress of the DSA-3200 to conform to anetworktheninputthatIPAddress instead
of the default IPAddress.)
Toobtain a new IP address from the DSA-3200 you may need to restartyour computer
or release and renew your IP address. Make sure that the network adapter in your
computerisconfiguredproperly.Instructionsforconfiguringthenetworkadaptertoobtain
an IP address automatically from the DSA-3200 can be found in theAppendix.
Connect the computer you will be using for configuration to the Private Network
or directly to a Private LAN Port.
Be sure to use https instead of http when typing in the URL address. This ensures
that a secure connection is made between your system and the DSA-3200.

5
Using The Setup Wizard (continued)
Once you have logged in, the home
screenwill appear.
Youhavetheoptiontoestablishanew
passwordfortheadminaccount.
Click Run Wizard
Select the appropriate time zone for
yourlocation.
Click Next
Enteranewadminpassword
andretypeit for verification
Click Next

6
Using The Setup Wizard (continued)
Click Next
Enter the system information:
•Succeed Page: The URL users are
directed to when successfully
authenticated.
•Time Server: Specify an external
timeserver fortimesynchronization.
•DNS Server IP: IP address of the
DomainNameServer.
Click Next
TheDSA-3200 will attempt todetermine
your WAN connection type. If dynamic
IP is detected, no configuration is
necessary. IfPPPoEisdetected,youwill
be promted to enter your account user
name and password. Should the
DSA-3200 fail to detect either dynamic
or PPPoE, you will see this screen.
SelectthetypeofInternetconnectionthat
youhave.
Select an Option
Click Next
ConfigurethePublicLANPort:
•IPAddress: TheIPaddressusedfor
the DSA-3200 on the Public LAN.
•Subnet Mask: The Subnet Mask of
the DSA-3200 on the Public LAN.
•DHCP Server Enabled/Disabled:
With DHCP Server enabled, IP
addressesareprovidedautomatically
to clients on the Public LAN.

7
Enter the desired Wireless Network
SSID, select RF Channel (auto or
manual), and Wireless Transmission
Mode. The Sync to Ticket option will
automaticallyaddtheSSIDoftheInternal
APtothe On-Demand User Receipt.
Using The Setup Wizard (continued)
Click Next
SpecifytheDHCPServerSettings.
Click Next
Configurethe Public WLAN Port:
•IP Address: The IP address used for
the DSA-3200 on the Public WLAN.
•SubnetMask: TheSubnetMaskofthe
DSA-3200 on the Public WLAN.
•DHCP Server Enabled/Disabled:
With DHCP Server enabled, IP
addresses are provided automatically
to clients on the Public WLAN.
Click Next
Specify arangeof IPaddressesto assign
the DHCP clients. The range is entered
in the format “Start IP – End IP” i.e.
192.168.1.101–192.168.1.200.Enterthe
Domain Name and Primary DNS Server
settings for the clients. Entering a
SecondaryDNSServer is optional.

8
Click Next
SpecifytheDHCPServerSettings.
Specify a range of IP addresses to assign
the DHCP clients. The range is entered in
the format “Start IP – End IP” i.e.
192.168.2.101–192.168.2.200. Enter the
Domain Name and Primary DNS Server
settings for the clients. Entering a
SecondaryDNSServer is optional.
Using The Setup Wizard (continued)
Click Restart
Setup Wizard is Now Complete
Click the Restart Link to complete the
configurationWizard and apply settings.
TheDSA-3200 will Restartafterclicking
the restart link. Reboot time will take
approx. 1.5 ~ 2 Minutes.
Note: If you are unable to browse the Internet after setting up your DSA-3200, release
andrenew yourDynamicIP andverifythat youreceivea validDNSserver address.

9
Toconnectto thenetwork,makesurethenetworkadapter inyourcomputerisconfigured
properly.Here’showtoconfigurethenetworkadaptertoobtainanIPaddressautomatically
from the DSA-3200 Airspot™Wireless G Public/Private Gateway.
Microsoft Windows XP:
Go to Start > right click on
My Network Places > select Properties >
Right-clickontheNetwork Connection of the
Ethernet adapter connecting to the DSA-3200
andselectProperties.
Appendix - IP Configuration
ClickOK
Click Internet Protocol (TCP/IP)
ClickProperties
Select Obtain an IP address
automatically

10
Apple Mac OS X:
Go to the Apple Menu and Select System
Preferences.
TheIP addressinformation, theSubnet
Mask, the DSA-3200 IP address and
the Ethernet adapter address will
appear.
Click on Network
Click on Apply Now
Select Using DHCP in the
Configure pull down menu
Select Built-in Ethernet in
the show pull down menu
Appendix - IP Configuration (continued)

11
