D-Link DFM 562I User manual

If you purchased this Modem to make your Internet connection with PC, you must
have an established Internet account from an Internet Service Provider (ISP).
Check Your Package Contents
These are the items included with your D-Link 562I purchase:
If any of the above items are missing, please contact your reseller.
©2003 D-Link Corporation, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice. D-Link DFM-562I Controllerless Modem Card
• D-Link DFM-562I
Controllerless Modem Card
• CD-ROM (containing Manual and Q.I.G.)
• Phone Cable
• D-Link DFM-562I User’s Guide
Using a powe
r
supply with a
different voltage rating
will damage and void
the warranty for this
product.
D-Link DFM-562I
Controllerless
Modem Card
Before Your Begin

Hardware Installation
Please unplug the telephone Line and plug the telephone line into the socket on the
back of the modem marked LINE.
COMPUTER PHONE
WALL SOCKET
Telephone
PHONE LINE
LINE
SP
K
MIC

Install Drivers
2.1 Windows 98
Click
Install Drivers
Click OK
When the system was
complete, windows will
detect the modem
automatic, please click
Cancel. Then insert the
driver CD supplied.

Please click OK
to end the window
Click OK
Click OK

2.1 Windows 98 (continue)
Please select Start /
Settings / Control Panel
and double-click on the
Modems icon.
Click Modems
Check Modem Model For
D-Link DFM-562I
Controllerless Modem Card.
If correct the installation is
complete then click OK to exit.
Click OK

2.2 Windows ME
Click OK
Click
Install Drivers
When the system was
complete, windows will
detect the modem
automatic, please click
Cancel. Then insert the
driver CD supplied.

Click OK
Please click OK to
end the window
Click OK

2.2 Windows ME (continue)
Please select Start /
Settings/Control Panel
and double-click
on the Modems icon.
Check Modem Model For
D-Link DFM-562I
Controllerless Modem Card
If correct the installation is
complete then click OK to exit.
Click OK
Click Modems

2.3 Windows NT4
Click
Install Drivers
Click Yes
Insert the driver CD
supplied.

Click Change
Click OK

Click Next
Click OK

2.3 Windows NT4(continue)
Click Close
Please select Start /
Settings/Control Panel
and double-click on the
Modems icon.
Click Modems
Check Modem Model For
D-Link DFM-562I
Controllerless Modem Card
If installation is complete
then click Close to exit.

2.4 Windows 2K
Click
Install Drivers
Click OK
When the system was
complete, windows will
detect the modem
automatic, please click
Cancel. Then insert the
driver CD supplied.

Click OK
Click Yes ignore the
message.
Click Yes
Click Yes ignore the
message.
Click Yes
Please click OK
to end the window

2.4 Windo2K(continue)
Please select Start /
Settings/Control Panel
and double-click on the
Phone and Modem
Options icon.
Click Phone and
Modem Options
Check Modem Model For
D-Link DFM-562I
Controllerless Modem Card
If installation is complete
then click OK to exit.
Click OK

2.5 Windows XP
Click Install Drivers
Click OK
When the system was
complete, windows will
detect the modem
automatic, please click
Cancel. Then insert the
driver CD supplied.

Click Continue
Anyway
Select the Install from
a list or specific location
{Advanced} then click
Next to search for
the driver.
Click Next

Select the Include this
location in the search:
G：\Driver\WinXP
（G is the letter of CD-ROM）
C
li
c
kN
e
x
t
Click
Continue
Anyway

Please click Finish
to end the window
Click Finish
Click OK
Please click OK
to end the window

2.4 Windows XP(continue)
Please select Start /
Settings/Control Panel
and double-click on the
Phone and Modem
Options icon.
Click Phone and
Modem Options
Click OK
Check Modem Model For
D-Link DFM-562I
Controllerless Modem Card
If installation is complete
then click OK to exit.
