D-Link ShareCenter Quattro DNS-345 User manual

DNS-345
B.Y.O.D.
YOU CAN ADD UP TO
4 SATA DISK DRIVES
BRING YOUR OWN DRIVE
ShareCenter®4-Bay Cloud Storage 4000
Share les over your network
and also with guest users
Stream media to your PCs,
TVs and mobile devices
Protect and backup your
important les
Manage your data with mydlink
and remotely access Cloud
• Four3.5”SATAHardDriveBays1
• mydlinkCloudSupport-PersonalCloudStorage
• MobileAppsupportforvirtuallyallsmartphones
includingiOS,Android,BlackberryandWindows
Mobiledevices
• CPUSpeed:1.6GHz
• Tool-lessHardDriveInstallation
• MultipleHardDriveCongurations:RAID0,1,5,5+
 hotspare,10,StandardandJBODmode
• DualGigabitEthernetPortsforHighSpeedData
 TransferandFailoverServer
• USBPortSupportsPrintServing,UPSMonitoring
 andOneTouchBackup
Product Highlights Complete Storage Solution
D-Link’sShareCenter4-BayCloudStorage4000(DNS-345)istheperfectwaytostore,safeguard,
shareandremotelyaccessorstreamyourdigitaldocuments,music,videos,andphotosfrom
anywhereintheworld.Theelegant,user-friendlydesignallowsforeasyinsertionofupto4SATA
drives,withouttheneedfortoolsorcomplicatedassembly.Plus,the4-BayCloudStorage4000
scaleswithyourstoragerequirements,allowingyoutostartowithoneSATAharddiskdrive
(HDD)andaddadditionaldrivesasyourstorageneedsgrow.
Remotely Access, Stream and Sync your Digital Files via
mydlink Cloud
WiththemydlinkCloudShareCenterappandmobileappsavailableforfreeoniTunes,GooglePlay,
theAmazonAppStore,WindowsPhoneMarketPlaceandBlackberryAppWorld,conguringyour
ShareCenterforremoteaccesshasneverbeeneasier.Streamordownloadyourdigitalcontentto
yourcomputers,smartphonesortabletswithout theneedforanyspecialnetworkconguration.
ThemydlinkCloudServicealsosupports2-waysyncingsoyou’llalwayshavethelatestdataonthe
ShareCenter and your computers.You can even set up guest user accounts and experience the
convenienceofsharinglesfromyourShareCenterviaaweblink.Enjoythepowerandconvenience
ofyourownpersonalcloudstorageservcewiththeShareCenter4-BayCloudStorage4000!

DNS-345 ShareCenter 4-Bay Cloud Storage 4000
Share
• Storedigitaldocuments,music,photosandvideosinacentrallocationfortheentirefamily
• Shareyourleswithfriendsandguestuserswithasimpleweblink
• CreateandsharephotoalbumswiththeMyPhotosApp
• ShareasingleUSBprinterwitheverycomputerinyournetwork
  Stream
• StreamdigitalmediafromyourShareCentertoyourcomputers,tablets,andsmartphones
• StreammoviesfromyourShareCentertoyourTVusingacompatiblemediaplayer
• StreamaudiousingtheShareCenteraudioadd-onapplications
• iTunesServer4supportallowsyoutoshareandstreammusicandvideoswithinyournetwork
Protect
• RAIDtechnologyprotectsyourdataintheeventofaharddrivefailure
• MonitoryourhomeorocewiththeuseofD-LinkCloudcamerasinSurveillanceCenterApp
• ScheduleroutinePCbackupsusingtheShareCenterSyncPCbackuputility
• ProtectyourdatawithCloudbackupsupportintheeventofacatastrophe
Manage
• Manageandorganizeyourleswithanintuitiveweb-basedinterface
• SyncdatabetweenyourShareCenterandcomputerswithmydlinkCloudSync
• ManageyourdatafromanywhereusingthemydlinkCloudMobileApp
• Setle/folderpermissionsandstoragequotasforspecicusersandgroups
Package Contents
• ShareCenter®4-BayCloudStorage4000(DNS-345)
• EthernetCable
• PowerAdapter
• QuickInstallGuide
• CD-ROM8
Minimum System Requirements
Computer with:
• 1GHzProcessor
• 512MBRAM
• 200MBHardDiskSpace
• Windows®75,WindowsVista®5,orWindows®XPSP25
• CD-ROMDrivetoViewProductDocumentation
For Storage:
• Internal3.5”SATAHardDrive(s)1
• RAID0/1requiresaminimumoftwoSATADrives
• RAID5requiresaminimumofthreeSATADrives
•RAID5+HotSpareandRaid10requirefourSATADrives

DNS-345 ShareCenter 4-Bay Cloud Storage 4000
Features
• Built-inWeb File Server and Secure FTP Server for
 FileAccessOvertheInternet2
• DLNA™CertiedMediaServertoStreamMusic, 
 Photos,andVideotoCompatibleMediaPlayers3 
 IncludingtheBoxeeBoxbyD-Link,PlayStation®3, 
 andXbox®360
• iTunesServer4
• AppleTimeMachineSupport
• Peer-to-Peer(P2P)DownloadEngine
• Users and Groups can be Assigned to Folders with
 ReadorRead/WriteAccess
• EstablishStorageQuotasforUsersandGroups
• SupportsLocalBackup,AppleTimeMachine 
 Backup,andCloudBackup(viaAmazonS3)
• AutoPowerRecoversandPower-oScheduling
• AutomaticE-mailNoticationofDeviceStatus
• CIFS/SMB,NFSandAFPSupport
• SupportsAdd-onApplications:
 • SurveillanceCenter,LogitechSqueezeCenter,
  AudioStreamer,BlogApp,PhotoCenter,Aja 
  Xplorer,aMule.
• 24/7BasicInstallationSupport6
• 3-YearLimitedWarranty7
Remote Cloud Access
Modem
Internet
Router
Smartphones
D-Link Cloud Cameras
ShareCenter 4 -Bay
Cloud Storage 4000
DNS-345
Tablets
Computer
• Easy-to-useandsecurewebportalforremoteaccess
• Nospecialnetworkcongurationrequired
• Remotelystreamphotos,musicandmoviestoPCsand
 smartphones
• mydlinkCloudmobileappavailableforiPhone/iPad,Android, 
 BlackBerryandWindows7mobiledevices
• Sharecontentwithguestusersviaweblink
• 2-waydatasyncbetweenmultiplecomputersandShareCenter
mydlink Cloud
Surveillance Center
• EmbeddedNVR(networkvideorecoder)supportsreal-timemonitoring,recordingand
 playbackofsurveillancevideousingmydlink-enabledNetworkCameras
• Supportsupto4D-LinknetworkCloudcameras
• Supportsrecordingmodesincludingcontinuous,motion-detection,andscheduled
 recording
• Supportssnapshotcaptureandzoomin/outfromlivevideo
• Supportedcameramodels:DCS-930L,DCS-932L,DCS-1100L,DCS-1130L,DCS-5230L,
 DCS-942L,DCS-2132L,DCS-5222L.(Expectingmoremodelssupportinthefuture)

Building Networks for People
©2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, mydlink, ShareCenter, the D-Link RoHS logo and trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or
other countries. Other trademarks or registered trademarks are the property of their respective owners.Visit www.dlink.com for more details.
Updated 02/02/12
For more information
U.S.A. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | dlink.com Canada | 2525 Meadowvale Blvd | Mississauga, ON L5N 5S2 | 800.361.5265 | dlink.ca
DNS-345 ShareCenter 4-Bay Cloud Storage 4000
Technical Specications
Standards
• IEEE802.3
• IEEE802.3ab
• IEEE802.3u
• IEEE802.3ad
• TCP/IP
• CIFS/SMB
• AFP
• NFS
• UPnPAV
• Bonjour
• DDNS
• NTP
• FTPoverSSL/TLS,FXP
• HTTP/HTTPS
• WebDAV
• USB2.0
• DHCPClient
• PnP-X
• LLTD
Supported Hard Drive Type
• 3.5”InternalSATA,SATAIIandSATAIIIdrives
Ports
• 4SATAI/II/III3.5-inchharddrivebays,
 supportsharddrivecapacitiesupto4TB
• 210/100/1000GigabitEthernetPorts
• 1USB2.0Port
Clients Supported
• Windows
• OSX(Mac)
• Linux
Backup Management
• ScheduleBackupfromPCtoNAS
• ScheduleLocalBackups
• ScheduleRemoteBackups
 (Rsync,RemoteSnapshot)
• AppleTimeMachinesupport
• USBBackups
• CloudStorageBackup(AmazonS3)
Device Management
• WebinterfacewithsupportforInternet
 Explorer7,Firefox3,Safari4,Chrome3,
 andOpera10orabove
• EasySearchUtility
• E-MailNotications
• SMSNotications
• System/FTPlog
• Yahoo!Widget
• SNMPv2
• ResourceMonitor
• Add-onsPackages
Power Management
• PowerSavingmode
• AutoPowerRecovery
• SchedulePoweron/o
• SmartFancontrol
• D-LinkGreenEthernet
• Auto-ooadsystemwhen
 UPSislowonbattery
• NetworkUPS
Remote File Sharing
• WebFileServer
• FTPServer
• WebDAV
• AjaXplorer
Mobile Apps Support
• iOS(iPhone/iPad)
• Android
• Blackberry
• MicrosoftMobileOS
LEDs
• LAN(onLANports)
• Ethernet(onEthernetports)
OLED Display Screen
• 128x32OLEDDisplayScreen
Drive Management
• MultipleHardDriveCongurations:
 RAID0/1/5/5+HotSpare/10/JBOD/Standard
• RAIDmigrationfromNon-RAIDtoRAID1/5,
 RAID1toRAID5
• HardDriveFormats
  - Internal:EXT4
  - External:FAT16/32,NTFS
• Scandisk
• S.M.A.R.T.
• AESbasedvolumeencryption
• DiskRoaming
• RAIDRoaming
Account Management
• WindowsActiveDirectoryServicesupport
 forWindowsServer2003/2008
• Useraccountmanagement
• Groupaccountmanagement
• User/GroupQuotamanagement
• NetworkSharemanagement
• ISOMountmanagement
• BatchUserCreation
Download Management
• HTTP/FTPscheduledownload
• PeertoPeer(P2P),aMule
File Sharing
• Max.UserAccounts:
 512(nonADS)/800(ADS)
• Max.Groups:64(non-ADS)/200(ADS)
• Max.SharedFolders:128(withoutP2P)
• Max.ConcurrentConnections:
 64(Samba)/10(FTP)
Power Supply
• ExternalPowerSupply:
 DC19V/4.74ASwitching
Power Consumption
• Normalmode:53W
• Sleepmode:13.5W
Operating Temperature
• 0to40˚C(32to104˚F)
Storage Temperature
• -20to70˚C(-4to158˚F)
Operating Humidity
• 5%to90%(Non-condensing)
Dimensions (W x D x H)
• Device:5”x7.9”x7”(128x200x178mm)
• Packaging:9.52”x10.94”x10.04”
 (242x278x255mm)
Weight
• Device:5.95lbs(2.7kg)
• Packaging:8.86lbs(4.02kg)
Certications
• CE
• FCC
• IC
• C-Tick
• DLNA
