D-Link DCS-2310L User manual

DCS-2310L
Cloud Camera 2300
720P
Outdoor HD Network Camera
Product Highlights Outdoor HD Network Camera
The D-Link® Cloud Camera 2300 (DCS-2310L) is an Outdoor HD Network Camera. With
an outdoor-ready design, HD 720p surveillance recording, and Cloud Services-enabled
remote management, the Cloud Camera 2300 provides a perimeter of protection so you
can keep an eye on what matters most.
Outdoor-Ready Coverage
D-Link’s Cloud Camera 2300 is outdoor-ready with a IP65 resistant casing equipped to
handle dust and low-pressure water contact. It also features a versatile -13°F to 122°F
operating temperature range so you can keep an eye on the bigger picture–whatever the
weather, whatever the season.
720p HD for Superior Image Quality
The Cloud Camera 2300 delivers the condence of 720p HD video clarity, ensuring rich
detail and crisp image quality for your surveillance recording. And with integrated night-
vision and PIR motion-sensing technology, the Cloud Camera 2300 remains vigilant 24
hours a day, whether you’re there or not.
Day/Night : See up to
15-feet in the dark
Outdoor-Ready:
Weatherproof casing
Remote Viewing: View on iPhone®,
iPad® or Android® with mydlink™ app
Record Video:
microSD/SDHC card slot
Motion Detection: Trigger
recording and send email alerts
HD Image Quality and Detail
A high-resolution megapixel sensor provides 720p
HD resolution images and video to ensure that you
capture the details you need
All-Day Outdoor Surveillance
A built-in ICR lter and IR illuminator let you
monitor an area 24 hours a day, and the IP65
weatherproof housing protects the camera from
the elements
mydlink-enabled Cloud Access
Easy remote viewing and management of your
camera on your mobile device or through the
mydlink website

DCS-2310L Cloud Camera 2300
Package Contents
• CloudCamera2300(DCS-2310L)
• EthernetCable
• PowerAdapter
• QuickInstallGuide
Minimum System Requirements
Computer with:
• 1.3GHzProcessor
• 128MBMemory
• Windows®75, Windows Vista®5and Windows® XP
SP3®5,orMacOSX(10.5andabove,IntelProcessor)
• InternetExplorer®7,Mozilla®Firefox®v3.5,
 Google®Chrome8.0,orSafari®v4
For Internet Access:
• CableorDSLModem
• SubscriptionwithanInternetServiceProvider(ISP)
Features
• RemotelyMonitorYourHomeorOceover
the Internet
• 802.3afPoEPoweroverEthernet
• HDresolution1280x720(Max.1280x800)
• 2-WayAudio(Bulit-inMicandSpeaker)
• SupportsH.264/MJPEG/MPEG-4VideoCodec
• Built-In5MIRLEDforViewingDarkEnvironments
• Built-InPIRSensorforEnhancedMotionDetection
• microSD/SDHCCardSlotforLocalRecording1
• MotionDetectiontoTriggerRecordingandSend
E-mail Alerts
• PrivacyMaskSupport
• DigitalPan/Tilt/Zoom
• SupportforiPhone®,iPad®&Android®Apps2
• mydlink.comPortalforEasyViewingandManagement
• Administrator/UserPasswordProtection
• UPnP®SupportforNetworkSetup&Conguration
• IP65Weatherproof
• OperatingTemperature:-13°F-122°F(-25°C-50°C)
• 24/7BasicInstallationSupport3
• 1-YearLimitedWarranty4
Industry-Leading Remote Viewing with mydlink
With the free mydlink camera portal app, you can monitor your home or business on
your iPhone, iPad or Android device and experience the peace of mind that comes from
having round-the-clock surveillance at your ngertips. Check in on your home while
you’reatwork,ormonitoronyourbusinesswhenyou’reoutoftheoce–withmydlink,
you can keep an eye on what matters, whenever and wherever you want.
Make Easy Setup Even Easier – With Zero Conguration6
Connecting your D-Link camera with any router is easy – make it even easier with your
D-LinkCloudRouter.ZeroCongurationautomaticallyconguresandintelligentlysyncs
your D-Link camera to your mydlink account – it’s as easy as connect and view!
Versatile operating temperature range. Dust, water and heat-
resistant. Reliable coverage for any time, any season.

DCS-2310L Cloud Camera 2300
Technical Specications
Camera
Hardware Profile •1/4”MegapixelprogressiveCMOSsensor
•5meterIRilluminationdistance
•Minimumillumination:0luxwithIRLEDon
•Built-inInfrared-CutRemovable(ICR)Filtermodule
•Built-inPIRsensor(5meter)
•Built-inmicrophoneandspeaker
•10xdigitalzoom
•Focallength:3.45mm
•Aperture:F2.0
Field of View •(H)57.8°,(V)37.8°,(D)66°
Camera Housing •IP65compliantweatherproofhousing
Image Features •Configurableimagesize,quality,framerate,andbitrate
•Timestampandtextoverlays
•Configurablemotiondetectionwindows
•Configurableprivacymaskzones
•Configurableshutterspeed,brightness,saturation,
contrast, and sharpness
Video Compression •H.264/MPEG-4/MJPEGsimultaneous
format compression
•JPEGforstillimages
Video Resolution •16:9-1280x800,1280x720,800x450,640x360,
 480x270,320x176,176x144upto30fpsrecording1
•4:3-1024x768,800x600,640x480,480x360,
320 x 240, 176 x 144 up to 30 fps recording1
Audio Support •G.726 •G.711
External Device Interface •10/100BASE-TXFastEthernetport
•Supports802.3afPoE
•microSD/SDHCcardslot
Network
Network Protocols •IPv6
•IPv4
•TCP/IP
•UDP
•ICMP
•DHCPclient
•NTPclient(D-Link)
•DNSclient
•DDNSclient(D-Link)
•SMTPclient
•FTPclient
•HTTP/HTTPS
•Sambaclient
•PPPoE
•UPnPportforwarding
•RTP/RTSP/RTCP
•IPfiltering
•QoS
•CoS
•IGMP
•ONVIFcompliant
Security •Administratorandusergroupprotection
•Passwordauthentication
•HTTPandRTSPdigestencryption
SystemManagement
System Requirements for Web Interface •Browser:InternetExplorer,MozillaFirefox,orGoogleChrome
EventManagement •Motiondetection
•Eventnotificationanduploadsnapshots/videoclips
via email or FTP
•SupportsmultipleSMTPandFTPservers
•Multipleeventnotification
•Multiplerecordingmethodsforeasybackup
RemoteManagement •Configurationaccessibleviawebbrowser
•Takesnapshots/videoclipsandsavetolocalharddriveorNASviawebbrowser
MobileSupport •Windows7®/Vista®/XP®system,PocketPC,ormobilephone
•mydlink™mobileappforiOSandAndroidmobiledevices
D-ViewCam™SystemRequirements •OperatingSystem:MicrosoftWindows7/Vista/XP5
•WebBrowser:InternetExplorer7orhigher
•Protocol:StandardTCP/IP
D-ViewCam™SoftwareFunctions •Remotemanagement/controlofupto32cameras
•Viewingofupto32camerasononescreen
• Supportsallmanagementfunctionsinwebinterface
• Scheduledmotiontriggeredormanualrecordingoptions

Building Networks for People
DCS-2310L Cloud Camera 2300
©2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, mydlink, and the D-Link RoHS logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or other
countries. Other trademarks or registered trademarks are the property of their respective owners. iPhone and iPad are registered trademarks of Apple Inc. Android is a trademark of Google Inc.
Updated 8/28/12
U.S.A. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | dlink.com Canada | 2525 Meadowvale Blvd | Mississauga, ON L5N 5S2 | 800.361.5265 | dlink.ca
For more information
1Useofaudioorvideoequipmentforrecordingtheimageofapersonwithouttheirknowledgeandconsentisprohibitedincertainstatesorjurisdictions.Theend-userassumesallliabilityforcompliancewithapplicablestate,localandfederal
laws. 2The inclusion of a specic product or manufacturer does not imply its endorsement of D-Link or the D-Link product. 324/7BasicInstallationSupportisavailableonlyintheUSAfortherst30daysfromdateoforiginalpurchase.4 1-Year
LimitedWarrantyavailableonlyintheUSAandCanada.5 ComputermustadheretoMicrosoft’srecommendedSystemRequirements.6ZeroCongurationrequiresmydlink-enabledCloudRouter.7Frame rates when streaming video may vary
depending on network conditions and method used
Allreferencestospeedandrange,includingtheperformancechart,areforcomparisonpurposesonly.Productspecications,size,andshapearesubjecttochangewithoutnotice,andactualproductappearancemaydierfromthatdepicted
on the package. See inside package for warranty details.
GeneralSpecications
Power •5VDC,1.2AthroughexternalpoweradapterorPoEconnection
•ExternalPowerAdapterInput:100to240VAC,50/60Hz
Max.PowerConsumption •5.3watts
Operating Temperature •-13°to122°F(-25°to50°C)
Storage Temperature •-4°to158°F(-20°to70°C)
Operating Humidity •20%to80%non-condensing
Storage Humidity •5%to95%non-condensing
Certifications •CE
•CELVD
•FCC
•C-Tick
Dimensions •2.6”x5.47”x3.66”(66mmx138.9mmx93mm)
Weight •8.32oz(235grams)
Warranty
Warranty •1-YearLimited4
Order Information
Part Number Description
DCS-2310L Cloud Camera 2300
