Dacor DTG30M954F User manual

User Manual
Contemporary Gas Cooktop
DTG30M954F*/DTG36M955F*

English2
WARNING
Never Operate the Top Surface Cooking Section of this Appliance
Unattended.
• Failure to follow this warning statement could result in re,
explosion, or burn hazard that could cause property damage,
personal injury, or death.
• If a re should occur, keep away from the appliance and
immediately call your re department.
DO NOT ATTEMPT TO EXTINGUISH AN OIL/GREASE FIRE WITH
WATER.
WARNING: Failure to follow the instructions in this manual exactly
may cause a re or explosion, and, consequently, property
damage, personal injury, or death.
• DO NOT keep or use gasoline or other ammable products near
this appliance.
• IF YOU SMELL GAS:
- DO NOT light any appliances.
- DO NOT touch any electrical switches.
- DO NOT use any phone in your building.
- Immediately call your gas supplier from a neighbor’s phone,
and follow the supplier’s instructions. (If you cannot reach
your gas supplier, call the re department.)
• Installation and service must be performed by a qualied
installer, service agency, or the gas supplier.

English 3
To Our Valued Customer:
Congratulations on your purchase of the very latest in Dacor products! Our unique
combination of features, style and performance make us a great addition to your home.
In order to familiarize yourself with the controls, functions and full potential of your new
Dacor Appliance, read this use and care manual thoroughly, beginning with the Before you
begin section.
All Dacor appliances are designed and manufactured with quality and pride, while working
within the framework of our company value. Should you ever experience a problem with
your product, please first check the Troubleshooting section of this manual for guidance. It
provides useful suggestions and remedies prior to calling for service.
Valuable customer input helps us to continuously improve our products and services, so
please feel free to contact our Customer Service Team for assistance with any of your
product support needs.
Dacor Customer Assurance
• USA
Samsung Electronics America, Inc.
85 Challenger Road
Ridgefield Park, NJ 07660
• Canada
Samsung Electronics Canada Inc.
2050 Derry Road West, Mississauga,
Ontario L5N 0B9 Canada
Telephone: [phone](USA), 844-509-4659(Canada)
Hours of Operation: Mon – Fri, 8:00 a.m. to 8:00 p.m. Pacific Time
Website: www.dacor.com
Thank you for choosing Dacor for your home. We are a company built by families for
families, and we are dedicated to serving yours. We are confident that your new Dacor
product will deliver a high level of performance and enjoyment for many years to come.
Sincerely,

English4
Contents
Contents
Before you begin 6
About this manual 6
Important note to the installer 6
Important note to the consumer 6
Important note to the servicer 6
Regulatory Notice 7
Important safety instructions 10
Read all instructions before using this appliance 10
Symbols used in this manual 10
Commonwealth of Massachusetts 11
General safety 11
Fire safety 12
Gas safety 13
Electrical and grounding safety 14
Installation safety 15
Location safety 16
Cooktop safety 17
Usage in high altitude area 18
Overview 19
Layout 19
What’s included 21
Using the cooktop burners 22
Ignition 22
Cookware 24
Installing the grates 26
Using the iQ Connect feature 27
Using the hood control feature 30

English 5
Contents
Care and maintenance 32
Cleaning the cooktop surface 32
Stainless steel surfaces 33
Control knobs 34
Burner grates and components 35
Burner caps and heads 36
Burner bases 37
Electrodes 38
Grates 39
Burner head and cap replacement 39
Troubleshooting 42
Checkpoints 42
Warranty and Service 44
Getting Help 44
Warranty 44
Appendix 47
Model name & serial number 47
Open Source Announcement 48

English6
Before you begin
Before you begin
About this manual
READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY.
Important note to the installer
• Read all instructions contained in these installation instructions before installing the
cooktop.
• Remove all packing materials from the cooktop compartments before connecting the
electric and gas supply to the cooktop.
• Observe all governing codes and ordinances.
• Be sure to leave these instructions with the consumer.
• Installation of this appliance requires basic mechanical skills.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under the Warranty.
Important note to the consumer
Keep these instructions with your user manual for future reference.
• As when using any appliance generating heat, there are certain safety precautions you
should follow.
• Be sure your cooktop is installed and grounded properly by a qualified installer or
service technician.
• Make sure the wall coverings around the cooktop can withstand the heat generated by
the cooktop.
• Cabinet storage space above the cooktop burners should be a minimum of 30 in
(76.2 cm).
Important note to the servicer
The electrical diagram is attached inside the burner box.

English 7
Regulatory Notice
Regulatory Notice
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment. This device complies with Part
15 of FCC Rules. Operation is Subject to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products sold in the US and Canadian markets, only channels
1–11 are available. You cannot select any other channels.
FCC STATEMENT:
This equipment has been tested and found to comply within the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver

English8
Regulatory Notice
Regulatory Notice
• Connecting the equipment to an outlet that is on a different circuit
than the radio or TV
• Consulting the dealer or an experienced radio/TV technician for
help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
2. IC Notice
The term IC before the radio certification number only signifies
that Industry Canada technical specifications were met. Operation
is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only channels
1–11 are available. You cannot select any other channels.

English 9
Regulatory Notice
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits
set forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
General safety instructions
This unit has been tested and found to comply with the limits for
a class B digital device, pursuant to Part 18 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This unit generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this unit does cause harmful interference to
radio or television reception, which can be determined by turning
the unit off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorienting or relocating the receiving antennae.
• Increasing the distance between the unit and receiver.
• Connecting the equipment to an outlet that is on a different circuit
than the radio or TV.

English10
Important safety instructions
Important safety instructions
Read all instructions before using this appliance
• All electrical and gas equipment with moving parts can be dangerous. Be sure to read
the Important Safety Information in this manual. The instructions must be followed to
minimize the risk of property damage, injury, or death.
• Keep this manual in a handy place so you can refer to it as needed.
Symbols used in this manual
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in electric shock, personal injury, or property
damage.
NOTE
Useful tips and instructions
These warning icons and symbols are intended to prevent property damage and personal
injury. Follow them explicitly.

English 11
Important safety instructions
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Commonwealth of Massachusetts
This product must be installed by a licensed plumber or gas fitter qualified or licensed by
the State of Massachusetts. When using ball-type gas shut-off valves, you must use the
T-handle type. Multiple flexible gas lines must not be connected in series.
General safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• Do not touch any surface, component,
or mechanism of the cooktop during or
immediately after cooking.
• Learn where and how to shut off the
valve that feeds gas to the cooktop.
• Make sure the cooktop’s hold-down brackets are properly installed. (See the Installation
Instructions for details.)
• Do not let children sit/stand on the cooktop or play with any of its parts. Do not leave
children unattended in the kitchen when the cooktop is in use.
• Remove all packaging before operating the cooktop to keep this material from catching
fire. Keep all packaging away from children. Properly dispose of packaging as soon as
the cooktop is unpacked.
• Do not keep objects of interest to children on or around the cooktop.
• Do not operate the cooktop if it is damaged in any way, if it malfunctions, or is missing
parts.
• Do not use the cooktop as a space heater. Use the cooktop for cooking only.
• Use only dry pot holders.
• Do not use the cooktop to heat sealed food containers. Do not use the cooktop to heat
sealed food containers.
• Unplug the cooktop before service/maintenance.

Important safety instructions
English12
Important safety instructions
• To avoid fires/explosions if storing combustibles (e.g., dishtowels, paper, cleaning
supplies) or packaged/canned food under the cooktop, be sure these items do not
contact the bottom of the cooktop.
• To prevent gas leaks or inefficient function, make sure the gas line is not compressed
or kinked.
• An air curtain or other overhead range hood, which operates by blowing a downward
airflow onto a range, shall not be used in conjunction with a gas range unless the
hood and range have been designed and tested in accordance with the Standard
for Domestic Gas Ranges, ANSI Z21.1 • CSA1.1, and listed by an independent testing
laboratory for combination use.
WARNING
NEVER use this appliance as a space heater to heat or warm the room. Doing so may
result in carbon monoxide poisoning and overheating of the oven.
Fire safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• Do not store/place/use combustible materials (e.g., paper, plastic, pot holders, linens,
gasoline, alcohol) near the cooktop.
• Do not wear loose fitting or hanging garments while using the cooktop.
• To avoid grease buildup, regularly clean the vents.
• Do not let pot holders or other flammable material touch a heating element. Do not use
a towel or other bulky cloth item as a pot holder.
• Do not douse a grease fire with water. Instead, turn off the heat source, and smother
the fire with a tight-fitting lid, or use a multi-purpose, dry-chemical or foam
extinguisher.
• Do not heat unopened food containers. The buildup of pressure may cause the
container to burst and result in injury.
• Always check if the burners are combusting normally. Overheating may cause a fire,
and incomplete combustion may cause carbon-monoxide poisoning.

English 13
Important safety instructions
Gas safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
Checking for gas leaks
Leak-testing the appliance must be done according to the manufacturer’s instructions. Do
not use a flame to check for gas leaks. Use a brush to spread a soap-and-water solution
around the area you are checking. If there is a gas leak, small bubbles will appear in the
solution.
If you smell gas:
• Close the valve and do not use the cooktop.
• Do not light a match, candle, or cigarette.
• Do not turn on any gas or electric appliances.
• Do not touch an electrical switch or plug in a power cord.
• Do not use any phone in your building.
• Evacuate everyone from the building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the fire department.

Important safety instructions
English14
Important safety instructions
Electrical and grounding safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• Plug the power cord into a grounded 3-prong outlet.
• Do not remove the grounding prong.
• Do not use an adapter or an extension cord.
• Do not use a damaged power plug, power cord, or loose power outlet.
• Do not modify the power plug, cord, or outlet.
• Do not put a fuse in a neutral or ground circuit.
• Use a dedicated 120-volt, 60-Hz, 15-amp, AC, fused electrical circuit for this cooktop.
A time-delay fuse or circuit breaker is recommended. Do not plug more than one
appliance into this circuit.
• Do not connect the ground wire to plastic plumbing lines, gas lines, or hot water pipes.
• This cooktop must be grounded. If the cooktop malfunctions or breaks down, grounding
reduces the risk of electric shock by providing a safe path for the current. This
cooktop’s power cord has a grounding plug, which must be firmly plugged into an
outlet that is properly installed and grounded according to local regulations. If you
are not sure your electrical outlet is properly grounded, have it checked by a licensed
electrician.
• If codes allow for a separate ground wire, you should have a qualified electrician
determine this wire’s proper path.
• Electrical service to the cooktop must conform to local codes, or in the absence of local
codes, to the National Electrical code/NFPA No. 70 – Latest Revision (for the U.S.) or the
Canadian Electrical Code CSA C22.1 or Latest Revisions.
• The cooktop owner shall ensure that the proper electrical service is provided for the
cooktop.

English 15
Important safety instructions
Installation safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• The cooktop should be installed and properly grounded by a qualified installer, as
specified in the Installation Instructions. Adjustments and service should be performed
only by qualified gas cooktop installer or service technician.
• Do not try to service/modify/replace the cooktop or any part of it unless specifically
recommended in this manual. All other service should be performed by a qualified
technician.
• Use only new, flexible connectors when installing the cooktop.
• Make sure the cooktop’s hold-down brackets are properly installed. (See the Installation
Instructions for details.)
• Remove all tape and packaging materials.
• After unpacking the cooktop, remove all accessories from inside and around it.
(Cautiously handle the heavy grates and griddles.)
• Make sure no parts came loose during shipping.
• Make sure the cooktop is correctly installed/adjusted by a qualified service technician
or installer for the type of gas (natural or LP) you will use. For the cooktop to use LP
gas, the installer must replace the 5 surface burner orifices with the provided LP orifice
set, and reverse the GPR adapter. These adjustments must be made by a qualified
technician according to manufacturer instructions and local regulations. The qualified
agency performing this work shall be responsible for the gas conversion.
• Installation of this cooktop must conform with local codes or, in the absence of local
codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA.54, latest edition. In Canada,
installation must conform with the current Natural Gas and Propane Installation Code,
CAN/CGA-B149.1, or the current Propane Installation Code, CAN/CGA-B149.2, and with
local codes where applicable. This cooktop has been design-certified by ETL according
to ANSI Z21.1, latest edition, and Canadian Gas Association according to CAN/CGA-1.1,
latest edition.
• Make sure the middle valve has adequate capacity and is not clogged.

Important safety instructions
English16
Important safety instructions
Location safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• This cooktop is for indoor household use only. Do not install the cooktop outdoors or
anywhere that it will be exposed to weather/water or wind/strong drafts.
• The cooktop must be installed within easy reach of a grounded, 3-prong outlet.
• Do not hang paper blinds on a window near the cooktop; do not hand long curtains that
could be blown over/onto the cooktop.
• For proper ventilation, the cooktop needs sufficient space below and all around the
chassis. Vents in the chassis exhaust heat and fumes so the cooktop can operate
properly.
• Make sure the wall coverings around the cooktop can withstand heat up to 194 °F (90 °C).
• Do not store items above the cooktop. If cabinet storage above the cooktop is
necessary, allow a minimum clearance of 30 in. (76.2 cm) between the cooking surface
and the bottom of the cabinets.

English 17
Important safety instructions
Cooktop safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• Select cookware that is designed for cooktops and that is large enough to cover the
grates. Burner flames should not extend beyond the bottom of the cookware.
• Make sure all burners are off when not in use.
• Do not use aluminium foil to line the grates or any part of the cooktop.
• Do not leave burners unattended on medium or high heat settings.
• Before igniting, make sure all burner caps are properly in place and all burners are
level.
• Always use the LITE position to ignite a burner, then make sure the burner has ignited.
If ignition fails, turn the knob to OFF, and wait a few minutes for the gas to dissipate.
• When you set a burner to simmer, do not turn the knob quickly. Make sure the flame
stays on.
• Do not place any objects other than cookware on the cooktop.
• Foods should only be flamed under an active ventilation hood.
• Before removing or changing cookware, turn off the burners.
• Remove food and cookware immediately after cooking.
• Make sure all cooktop burners are off and all surfaces have completely cooled before
removing the grates and disassembling the burners.
• After cleaning the burner spreader, make sure it is completely dry before reassembling
it.
• To avoid carbon monoxide poisoning, do not pour water or other liquids into the
cooktop during cleaning.
• To avoid cookware discoloration, deformity, and/or carbon monoxide poisoning, do not
use cookware that is substantially larger than the grate.
• Turn cookware handles to the side or rear of the cooktop and not over active burners
or the front edge of the cooktop.
• Stand at a safe distance while frying to avoid hot spatter.
• When frying, always heat the oil slowly, and monitor the oil as it heats. When frying
foods at high heat, monitor the oil throughout the cooking process. If combining fats or
oils for frying, mix them together before heating.
• Use a deep-fry thermometer when possible to avoid heating the oil beyond its smoke
point. (Know the smoke point of the oil you are using.)
• Always use a minimum amount of oil for any type of frying. Always thaw food before
frying, and do not frying food that is overly cold or that has clumps of ice attached to
it.

Important safety instructions
English18
Important safety instructions
• Always let the oil/fat in the cookware to cool to room temperature before moving the
cookware.
• To avoid delayed-eruptive boiling, let hot oil/fat stand at least 20 seconds after turning
off the burner so the temperature can stabilize. In the event of scalding, follow these
first-aid instructions:
1. Immerse the scalded area in cool or lukewarm water for at least 10 minutes.
2. Do not apply any creams, oils, or lotions.
3. Cover the scalded area with a clean, dry cloth.
• During a power failure or if the ignition system malfunctions, do not use matches/
lighters to ignite the burners.
• Do not place/use appliances such as IH rice cookers or desktop hot plates on the
cooktop. Electromagnetic forces from these appliances may cause the cooktop to
malfunction.
CAUTION
If the cooktop is installed above an oven, do not use the cooktop while the oven’s self-
cleaning function is on.
Pots must be put within the grate
CAUTION
Make sure you put cookware on the grate
so that the overall cookware size does not
exceed the grate.
Usage in high altitude area
• This appliance has been tested for operation up to an altitude of 7,800 ft elevation
above sea level.
• If desired, for altitudes above 2,000 ft elevation above sea level, adjustments can
be made to the cooktop burners for low flame settings. If flame performance is
satisfactory, adjustment will not be required.
• See the LP conversion instruction for information about adjustment for low flame
settings.
* However, 36” Models (Rangetop and Pro-Range) should not be used in high altitude
environments.

English 19
Overview
Overview
Layout
30” Model: DTG30M954F*
03
04
06
07
01
02
08
05
LRLR RRRR
LFLF RFRF
36” Model: DTG36M955F*
03
04
06
07
01
08
05
02
LRLR RRRR
LFLF RFRF
CenterCenter

English20
Overview
Overview
30” Model: DTG30M954F*
01 Left Rear
Rapid burner 13000 BTU
02 Left Front
Dual burner 18500 BTU
03 Right Front / Rear
Semi rapid burner 9500 BTU
04 iQ Connect module
05 Grate (2 pcs) 06 Surface burner knobs (4 pcs)
07 iQ Connect button (below knob) 08 Bluetooth button (below knob)
36” Model: DTG36M955F*
01 Left Front / Rear
Rapid burner 13000 BTU
02 Center
Dual burner 18500 BTU
03 Right Front / Rear
Semi rapid burner 9500 BTU
04 iQ Connect module
05 Grate (3 pcs) 06 Surface burner knobs (5 pcs)
07 iQ Connect button (below knob) 08 Bluetooth button (below knob)
Each burner has a corresponding knob by which you can set the flame level from LO to
HI as well as LITE (which setting ignites the corresponding burner.) The burner indicators
are above each knob and show which burner the knob controls. See the table for each
burner’s specific cooking purpose.
Burner Purpose Food type Characteristics
Power 30” LF General heating/
Low simmering
Boiling food,
tomato sauce Maximum output
36” Center
Rapid 30” LR Quick heating General General-purpose
cooking
36” LF, LR
Semi rapid 30” RF, RR General heating/
Low simmering
General food,
casseroles
General-purpose
cooking
36”
Simmer 30” / 36” Low simmering Chocolate,
casseroles, sauces
Delicate food
that requires
low heat for
extended cook
times
