Service Manual
Digital Satellite Receiver
MODEL : DSD-9420
March. 2006
S/M No : DSD9420001

PRODUCT SPECIFICATION ...............................................................................................2
BOM LIST.............................................................................................................................3
SC EMATIC DIAGRAM ......................................................................................................7
EXPLODED VIEW................................................................................................................14
1
CONTENTS

2
Product Specification
Tuner & Service Decoder
MPEG Transport Stream A/V Decoding
Main System
A/V In/Out
Power Supply
Physical Specification
Antenna 75 ohms(UHF)
Channel Coverage UHF : Ch21 - Ch69
RF Frequency Range 474 - 858 MHz
Channel Bandwidth 8MHz
RF Input/Output Connector IEC connector 169-2(female),diameter 9.5mm
Modulator COFDM
Transport stream MPEG2 compatible
Profile level MPEG-2 MP@ML
Input rate 68Mbits/s Max
Aspect ratio 4:3,16:9
Video resolution 720 X 576
Audio format MPEG2 -Musicam(layer 1 &2)
Audio sampling 32,44.1,48kHz
Main Processor STi5518
Flash Memory 2MByte
Sync DRAM 8MByte
Antenna Jack Type
- Antenna Jack Layout In : Up , Out : Down
Scart Jack
- TV Composite/RGB/S-video +audio(stereo)
- VCR/DVD RGB,SVHS,CVBS Input
Input Voltage 240V, 50/60Hz
Type ADAPTOR(5V,1.2A)
Power consumption
- Maximum 11W
- Operate 11W
- Stand-by 10W
Dimensions(W x H x D) 230 X 36 X 180mm
Storage temp -5°C~40°C
Storage humidity 5% to 90%

3
BOM LIST
✐ CAUTION :In this Service Manual, some parts can be changed for improving their
performance without notice in the parts list. So, if you need the latest parts
information, please refer to PPL(Parts Price List)in Service information
Center
LOC PART CODE PART NAME PART DESC REMARK
01 - PSACPSP571 ACCESSROYAS DSD-9420EU
DP03 97NP509500 DVB-TSTBBAG LDPE260X355+40
M1001 97P770D522 PSUADAPTER *CE*FRIWOSW.MODE2PIN
M1002 97P880R310 CABLERF PALDS1.0M(PLUGSHIELD)
M2002 97P7701000 CABLECANALPLUS PERI-PERI1200M/M9PIN
M2003 97P1R9CAA0 REMOCON NBUSTBREMOTE
M3010 486A716202 BATTERY AAA1.5V(SUPERGARD)
M3011 B2MNDAE009L0 MANUAL OWNERS DSD-9420MANUAL
02 - PSPKCPP571 PACKINGAS DSD-9420EU
CP02 NULL-ITEM- PHANTOMITEM DONOTFIT
M101 SWN1F05615 FLASHPGM EB01.1.3.1EUUSEYELLOWLABEL
M3013 97P9320114 RATINGLABEL BLANKPESILVER56X35
03 - PSMCASP571 CHASSISMAINAS DSD-9420EU
A040 97P0488500 COVERTOP SECCT0.5PCM
A041 7173300852 SCREWTAPPTITE TT2BIN3X8BK 3CR
A060 97P0488600 COVERBOTTOM SECCT0.8
A061 7173300851 SCREWTAPPTITE TT2BIN3X8MFZN 3CR
M01 97PP349500D02 FRONT PANEL DSD-9420DAEWOO NO SLOT
M2001 97FUS7090D09 BOXCARTON DSD-9420BOX
M2008 97FUSINSD02 BOXINSERT CARDBOARDTRAYFORDSD-9420
M3012 97P9320101 DOUBLEOUTPUT LABEL 67X27 / 67X 11
Z001 PSMPMSP571 PCB MAINMANUALAS DSD-9420EU
AM01 2193010300 SOLDERWIRE SN63% PB37%DIA.3.00MM
C821 CEXF1A332E CELECTRO 10VRM 3300MF (13X20)
IR902 1TSOP1136- IRRECEIVER TSOP11365V 36KHZ 3PIN
JK101 97P6318640 JACKSCART SINGLESCART CLIP
JK102 97P6318640 JACKSCART SINGLESCART CLIP
JK104 97P63DC001 SOCKETDC IN WS-DC001BSNT1
RF01 97P761344Y TUNER2 IN 1 TD1344L/IHP-2DTT TUNER NO MOD
Z0011 PSMPJ2P571 MAINCHIP TOP AS DSD-9420EU
AMB1 2193011650 SOLDERPASTE SMQ92JTYPE 3 (INDIUM)
C102 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C103 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C104 HCFF105ZBA CCHIP CERA Y5V16V 1000NF+80~-20%1608
C106 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C107 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C108 HCFF105ZBA CCHIP CERA Y5V16V 1000NF+80~-20%1608
C109 HCFF105ZBA CCHIP CERA Y5V16V 1000NF+80~-20%1608
C110 HCBK471KBA CCHIP CERA X7R50V 470PF10%1608
C111 HCBK471KBA CCHIP CERA X7R50V 470PF10%1608
C114 HCQK430JBA CCHIP CERA COG50V43PF5%1608
C115 HCQK430JBA CCHIP CERA COG50V43PF5%1608
C116 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C119 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C120 HCQK101JBA CCHIP CERA COG50V100PF5%1608
C121 HCQK101JBA CCHIP CERA COG50V100PF5%1608
C122 HCFK154ZCA CCHIPCERA 50VY5V 0.15MFZ
LOC PART CODE PART NAME PART DESC REMARK
C123 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C124 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C125 HCQK220JBA CCHIP CERA COG50V22PF5%1608
C126 HCQK220JBA CCHIP CERA COG50V22PF5%1608
C127 HCQK430JBA CCHIP CERA COG50V43PF5%1608
C128 HCQK430JBA CCHIP CERA COG50V43PF5%1608
C129 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C130 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C131 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C132 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C133 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C134 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C135 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C136 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C137 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C138 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C139 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C140 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C141 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C142 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C143 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C144 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C145 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C146 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C147 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C148 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C149 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C150 HCQK470JBA CCHIP CERA COG50V47PF5%1608
C151 HCQK101JBA CCHIP CERA COG50V100PF5%1608
C152 HCQK101JBA CCHIP CERA COG50V100PF5%1608
C153 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C154 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C155 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C156 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C157 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C158 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C159 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C160 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C161 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C162 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C163 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C164 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C165 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C166 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C167 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C168 HCBK103KBA CCHIP CERA X7R50V 10NF10%1608
C169 HCQK101JBA CCHIP CERA COG50V100PF5%1608

BOM LIST
4
LOC PART CODE PART NAME PART DESC REMARK
C171 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C172 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C173 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C174 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C175 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C176 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C177 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C185 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C188 HCBK392KBA CCHIPCERA X7R50V 3900PF10%1608
C189 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C190 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C191 HCBK103KBA CCHIPCERA X7R50V 10NF10%1608
C192 HCBK392KBA CCHIPCERA X7R50V 3900PF10%1608
C193 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C194 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C195 HCBK103KBA CCHIPCERA X7R50V 10NF10%1608
C196 HCBK392KBA CCHIPCERA X7R50V 3900PF10%1608
C197 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C198 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C199 HCBK103KBA CCHIPCERA X7R50V 10NF10%1608
C200 HCBK392KBA CCHIPCERA X7R50V 3900PF10%1608
C201 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C202 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C203 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C204 HCBK392KBA CCHIPCERA X7R50V 3900PF10%1608
C205 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C206 HCQK391JBA CCHIPCERA COG50V 390PF5%1608
C207 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C215 HCQK181JBA CCHIPCERA COG50V 180PF5%1608
C216 HCQK181JBA CCHIPCERA COG50V 180PF5%1608
C217 HCQK181JBA CCHIPCERA COG50V 180PF5%1608
C218 HCQK181JBA CCHIPCERA COG50V 180PF5%1608
C219 HCQK181JBA CCHIPCERA COG50V 180PF5%1608
C220 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C221 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C222 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C223 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C224 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C225 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C226 HCBK102KBA CCHIPCERA X7R50V 1NF10%1608
C227 HCBK102KBA CCHIPCERA X7R50V 1NF10%1608
C228 HCBK102KBA CCHIPCERA X7R50V 1NF10%1608
C229 HCBK102KBA CCHIPCERA X7R50V 1NF10%1608
C230 HCBK102KBA CCHIPCERA X7R50V 1NF10%1608
C231 HCBK102KBA CCHIPCERA X7R50V 1NF10%1608
C234 HCQK181JBA CCHIPCERA COG50V 180PF5%1608
C235 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C245 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C247 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C261 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C311 HCBK103KBA CCHIPCERA X7R50V 10NF10%1608
C312 HCQK471JBA CCHIPCERA COG50V 470PF5%1608
C341 HCFF105ZBA CCHIPCERA Y5V16V 1000NF+80~-20%1608
C804 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
C902 HCFH104ZBA CCHIPCERA Y5V25V 100NF(-20%+80%)1608
LOC PART CODE PART NAME PART DESC REMARK
D125 DBAV99 -B DIODE CHIP BAV 99 /S0T23
D802 DBAT54 DIODESCHOTTKY BAT54 SOT23
F802 5PZJYS51R5 FILTEREMI ZJYS51R5-2PTSMD
IC01 1ST5518BVC ICCPU/MPEG2 ST5518-CVERSION
IC02 1EDS6416AH ICSDRAM EDS6416AHTA-75-E64MTSOP
IC04 1S29AL016M ICFLASH S29AL016M90TAI01016MB TSOP48
IC05 1ZL10353 ICCOFDM DEMODULATOR ZL10353 LQFP64
IC07 1A1117E18D ICREGULATOR AP1117E18A1.8V 2% SOT-223
IC08 1AMD809SAR ICRESET ADM809SART2.93V SMD S0T23
IC09 1CS4334KS- ICAUDIODAC CS4334KS24 BIT SOIC8
IC12 1K1A358F-C ICCHIPOP AMP KIA358FDUAL OP AMP FLP-8
IC13 1SN74HCU0D ICHEXINVERTER 2BCONFIRMED
IC14 1SP6650 - ICSWITCH CONTROLLER SP6650 SO10
IC21 1ML0308 - ICDCDCCONVERTER ML0308
IC22 1A1117E33D ICREGULATOR AP1117E33D3.3V 2% SOT-223
L101 HRFS000-BA RCHIP 1/160 OHM 1608
L102 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L103 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L104 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L106 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L107 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L108 HRFS000-BA RCHIP 1/160 OHM 1608
L111 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L112 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L113 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L114 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L115 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L120 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L121 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L122 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L123 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L124 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L125 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L127 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L128 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L129 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L130 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L131 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L132 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L133 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L134 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L135 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L140 HRFS000-BA RCHIP 1/160 OHM 1608
L141 HRFS000-BA RCHIP 1/160 OHM 1608
L142 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L143 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L144 HRFS000-BA RCHIP 1/160 OHM 1608
L145 HRFS000-BA RCHIP 1/160 OHM 1608
L146 HRFS000-BA RCHIP 1/160 OHM 1608
L151 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
L152 HLX601-01B LCHIP BEAD BLM18AG601SN1 200MA 600OHM
Q103 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q104 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q105 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q106 TBC857 TRCHIP BC857 LOWNOISETRPNP

5
BOM LIST
LOC PART CODE PART NAME PART DESC REMARK
Q107 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q109 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q113 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q114 HRFS000-CA RCHIP 1/160OHM2012
Q115 HRFS000-CA RCHIP 1/160OHM2012
Q116 HRFS000-CA RCHIP 1/160OHM2012
Q117 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q118 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q119 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q120 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q121 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q122 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q123 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q124 TKSR1104-B TRCHIP KSR1104
Q125 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q126 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q128 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q129 TKSR1104-B TRCHIP KSR1104
Q130 TKSR1104-B TRCHIP KSR1104
Q131 TPMBT2222A TRCHIP PMBT2222ATR NPN SOT23
Q132 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q142 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q143 TBC857 TRCHIP BC857 LOWNOISETRPNP
Q145 TBC857 TRCHIP BC857 LOWNOISETRPNP
R108 HRFS330JBA RCHIP 1/16 33OHM5%1608
R111 HRFS000-BA RCHIP 1/160 OHM 1608
R119 HRFS101JBA RCHIP 1/16100ROHM5% 1608
R120 HRFS330JBA RCHIP 1/16 33OHM5%1608
R121 HRFS330JBA RCHIP 1/16 33OHM5%1608
R122 HRFS330JBA RCHIP 1/16 33OHM5%1608
R123 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R124 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R127 HRFS223JBA RCHIP 1/1622KOHM5% 1608
R128 HRFS223JBA RCHIP 1/1622KOHM5% 1608
R133 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R134 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R135 HRFS750JBA RCHIP 1/16 75OHM5%1608
R137 HRFS105JBA RCHIP 1/161MOHM5% 1608
R138 HRFS101JBA RCHIP 1/16100ROHM5% 1608
R139 HRFS101JBA RCHIP 1/16100ROHM5% 1608
R141 HRFS102JBA RCHIP 1/161KOHM5% 1608
R142 HRFS102JBA RCHIP 1/161KOHM5% 1608
R143 HRFS101JBA RCHIP 1/16100ROHM5% 1608
R144 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R145 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R146 HRFS470JBA RCHIP 1/1647ROHM5% 1608
R147 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R148 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R149 HRFS101JBA RCHIP 1/16100ROHM5% 1608
R150 HRFS101JBA RCHIP 1/16100ROHM5% 1608
R151 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R152 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R154 HRFS000-BA RCHIP 1/160 OHM 1608
R155 HRFS000-BA RCHIP 1/160 OHM 1608
R156 HRFS101JBA RCHIP 1/16100ROHM5% 1608
LOC PART CODE PART NAME PART DESC REMARK
R157 HRFS101JBA RCHIP 1/16100ROHM5% 1608
R158 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R165 HRFS203JBA RCHIP 1/1620KOHM5% 1608
R166 HRFS203JBA RCHIP 1/1620KOHM5% 1608
R167 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R168 HRFS680JBA RCHIP 1/1668ROHM5% 1608
R169 HRFS680JBA RCHIP 1/1668ROHM5% 1608
R170 HRFS680JBA RCHIP 1/1668ROHM5% 1608
R171 HRFS680JBA RCHIP 1/1668ROHM5% 1608
R172 HRFS680JBA RCHIP 1/1668ROHM5% 1608
R173 HRFS680JBA RCHIP 1/1668ROHM5% 1608
R174 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R175 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R176 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R177 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R178 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R179 HRFS330JBA RCHIP 1/16 33OHM5%1608
R180 HRFS470JBA RCHIP 1/1647ROHM5% 1608
R181 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R182 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R183 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R184 HRFS560JBA RCHIP 1/1656ROHM5% 1608
R185 HRFS330JBA RCHIP 1/16 33OHM5%1608
R186 HRFS330JBA RCHIP 1/16 33OHM5%1608
R187 HRFS330JBA RCHIP 1/16 33OHM5%1608
R188 HRFS330JBA RCHIP 1/16 33OHM5%1608
R189 HRFS330JBA RCHIP 1/16 33OHM5%1608
R190 HRFS330JBA RCHIP 1/16 33OHM5%1608
R191 HRFS330JBA RCHIP 1/16 33OHM5%1608
R192 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R193 HRFS560JBA RCHIP 1/1656ROHM5% 1608
R194 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R198 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R199 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R200 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R201 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R205 HRFS821JBA RCHIP 1/16820ROHM5% 1608
R206 HRFS221JBA RCHIP 1/16220R OHM5%1608
R207 HRFS222JBA RCHIP 1/162.2KOHM5% 1608
R208 HRFS120JBA RCHIP 1/1612OHM5% 1608
R209 HRFS759JBA RCHIP 1/167.5OHMJ 1608
R210 HRFS750JBA RCHIP 1/16 75OHM5%1608
R211 HRFS821JBA RCHIP 1/16820ROHM5% 1608
R212 HRFS221JBA RCHIP 1/16220R OHM5%1608
R213 HRFS222JBA RCHIP 1/162.2KOHM5% 1608
R214 HRFS120JBA RCHIP 1/1612OHM5% 1608
R215 HRFS759JBA RCHIP 1/167.5OHMJ 1608
R216 HRFS750JBA RCHIP 1/16 75OHM5%1608
R217 HRFS821JBA RCHIP 1/16820ROHM5% 1608
R218 HRFS221JBA RCHIP 1/16220R OHM5%1608
R219 HRFS222JBA RCHIP 1/162.2KOHM5% 1608
R220 HRFS120JBA RCHIP 1/1612OHM5% 1608
R221 HRFS759JBA RCHIP 1/167.5OHMJ 1608
R222 HRFS750JBA RCHIP 1/16 75OHM5%1608
R223 HRFS821JBA RCHIP 1/16820ROHM5% 1608

6
BOM LIST
LOC PART CODE PART NAME PART DESC REMARK
R224 HRFS221JBA RCHIP 1/16220R OHM5%1608
R225 HRFS222JBA RCHIP 1/162.2KOHM5% 1608
R226 HRFS120JBA RCHIP 1/1612OHM5% 1608
R227 HRFS759JBA RCHIP 1/167.5OHMJ 1608
R228 HRFS750JBA RCHIP 1/16 75OHM5%1608
R229 HRFS120JBA RCHIP 1/1612OHM5% 1608
R230 HRFS759JBA RCHIP 1/167.5OHMJ 1608
R231 HRFS750JBA RCHIP 1/16 75OHM5%1608
R235 HRFS222JBA RCHIP 1/162.2KOHM5% 1608
R239 HRFS102JBA RCHIP 1/161KOHM5% 1608
R243 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R244 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R245 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R246 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R247 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R248 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R249 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R250 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R251 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R252 HRFS102JBA RCHIP 1/161KOHM5% 1608
R253 HRFS102JBA RCHIP 1/161KOHM5% 1608
R254 HRFS102JBA RCHIP 1/161KOHM5% 1608
R255 HRFS102JBA RCHIP 1/161KOHM5% 1608
R256 HRFS102JBA RCHIP 1/161KOHM5% 1608
R257 HRFS102JBA RCHIP 1/161KOHM5% 1608
R258 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R260 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R261 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R262 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R263 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R264 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R265 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R266 HRFS222JBA RCHIP 1/162.2KOHM5% 1608
R267 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R268 HRFS472JBA RCHIP 1/164.7KOHM5% 1608
R271 HRFT102JCA RCHIP 1/101KOHM5%2012
R272 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R273 HRFS822JBA RCHIP 1/168.2KOHM5% 1608
R274 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R275 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R276 HRFS330JBA RCHIP 1/16 33OHM5%1608
R277 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R278 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R279 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R291 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R292 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R293 HRFS222JBA RCHIP 1/162.2KOHM5% 1608
LOC PART CODE PART NAME PART DESC REMARK
R294 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R296 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R333 HRFS103JBA RCHIP 1/1610KOHM5% 1608
R410 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R412 HRFS100JBA RCHIP 1/1610ROHM5% 1608
R413 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R416 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R417 HRFS104JBA RCHIP 1/16100KOHM5% 1608
R805 HRFS563JBA RCHIP 1/1656KOHM5% 1608
R806 HRFS102JBA RCHIP 1/161KOHM5% 1608
R906 HRFS331JBA RCHIP 1/16 330ROHM5%1608
R907 HRFS331JBA RCHIP 1/16 330ROHM5%1608
R908 HRFS123JBA RCHIP 1/1612KOHM5% 1608
R909 HRFS331JBA RCHIP 1/16 330ROHM5%1608
RA05 HRTS8E470J RCHIP ARRAY 1/16 8P47OHM5%3216
RA06 HRTS8E470J RCHIP ARRAY 1/16 8P47OHM5%3216
U100 97P65500MA PCBMAIN 219X164G2V
X001 HXJ27R000F SMDXTALQUARTZ 27MHZ30PPM HC49/4H SMX 30PF
X002 HXJ20R480C SMDXTAL QUARTZ 20M4820PPM HC49/4H SMX 30PF
Z0013 PSMPJRP571 PCBMAINRADIAL AS DSD-9420EU
C313 CEXF1C101V CELECTRO 16VRSS 100MF (6.3X11) TP
C314 CEXF1C471V CELECTRO RSS16V 470MF 10X12.5
C315 CEXF1H100V CELECTRO 50VRSS 10MF (5X11) TP
C318 CEXF1H100V CELECTRO 50VRSS 10MF (5X11) TP
C319 CEXF1H100V CELECTRO 50VRSS 10MF (5X11) TP
C321 CEXF1H100V CELECTRO 50VRSS 10MF (5X11) TP
C344 CEXF1H100V CELECTRO 50VRSS 10MF (5X11) TP
C345 CEXF1H100V CELECTRO 50VRSS 10MF (5X11) TP
C406 CEXF1C101V CELECTRO 16VRSS 100MF (6.3X11) TP
C409 CEXF1H100V CELECTRO 50VRSS 10MF (5X11) TP
C416 CEXF1C471V CELECTRO RSS16V 470MF 10X12.5
C423 CEXF1C471V CELECTRO RSS16V 470MF 10X12.5
C424 CEXF1C101V CELECTRO 16VRSS 100MF (6.3X11) TP
C425 CEXF1C101V CELECTRO 16VRSS 100MF (6.3X11) TP
C426 CEXF1C101V CELECTRO 16VRSS 100MF (6.3X11) TP
C427 CEXF1C471V CELECTRO RSS16V 470MF 10X12.5
C428 CEXF1C101V CELECTRO 16VRSS 100MF (6.3X11) TP
C435 CEXF1C471V CELECTRO RSS16V 470MF 10X12.5
C454 CEXF1C471V CELECTRO RSS16V 470MF 10X12.5
C455 CEXF1C471V CELECTRO RSS16V 470MF 10X12.5
C809 CEXF1C471V CELECTRO RSS16V 470MF 10X12.5
C811 CEXF1H470V CELECTRO 50VRSS 47MF (6.3X11) TP
L126 5CPX220J2T COILPEAKING EL0305RA22UH J RADIAL
L410 5CPX220J2T COILPEAKING EL0305RA22UH J RADIAL
L803 5CPX220J2T COILPEAKING EL0305RA22UH J RADIAL
LD905 DBL-B2141- LED BL-B2141GREEN 5MM RADIAL

7
SCHEMATIC DIAGRAM

8
SC EMATIC DIAGRAM

9
SC EMATIC DIAGRAM

10
SC EMATIC DIAGRAM

11
SC EMATIC DIAGRAM

12
SC EMATIC DIAGRAM

13
SC EMATIC DIAGRAM

14
EXPLODED VIEW
2
1
3
4
5
6
7
7
COVER BOTTOM
197P0488600 1 SECC T=0.8
2
PCB MAIN MANUAL AS -1-
3
4
5
6
7
PANEL FRONT AS 97PP349500 DSD-94301
COVER TOP 97P0488500 1 SECC T0.5 PCM
CUSHION LEG 97P4220000 4 EVA T4.0
SCREW TAPPTITE 7174300811 1 TT2 RND 3X8 MFZN PCB MAIN FIX
TT2 RND 3X8 MFZN BKSCREW TAPPTITE 7273300812 3 T/COVER FIX
PART NAMENO. MATERIALQ'TYPART NO. REMARK

DAEWOO ELECTRONICS CORP.
686, AHYEON-DONG, MAPO-GU,
SEOUL, KOREA.
C.P.O. BOX 8003 SEOUL KOREA
PRINTED DATE: March. 2006
